Summary of Contents for Inter-m PMU-240NA
- Page 1 (Webpage Setting) Operation anual Mixing mplifier PMU-240N /600N...
-
Page 2: Table Of Contents
MIXINg AMPLIfIER Contents Contents Webpage Setting ..........................1 Ⅰ. Device network initial setup information ..................1 Ⅰ. 1 What you need before network connection..................1 Ⅰ. 2 Connecting device and configuration ..................1 Webpage operation manual ......................3 Ⅱ. Common Page ...........................3 Ⅱ. 1 Operation Mode Setup ......................4 Ⅱ. -
Page 3: Webpage Setting
IP address information (IP, Subnet Mask, and DNS, etc) through the STATUS page. - DHCP ENABLE: If there is ‘NO’ on the screen, find the same IP CLASS in the network. And, set the IP information within the same network. PMU-240NA/600NA... - Page 4 ※ If there is no webpage on users PC. Turn off the wireless network and try again. ※ Please download the latest version of the manual on the website(www.inter-m.net). The description on the manual may change depending on the firmware version.
-
Page 5: Webpage Operation Manual
④ This window shows related helpful tips. ※ Check PMU-NA’s manual to find the detailed descriptions of each function, ※ If the webpage is not operated or the user doesn’t use the webpage for more than 5 minutes, “refresh” the webpage. PMU-240NA/600NA... -
Page 6: Ⅱ.1 Operation Mode Setup
③ When user select [Apply] button, user’s play mode will apply to the device. ※ If there is no audio input for more than 15 minutes, the device will go back to standby mode. ④ In [Operation Mode Setup], the window will show helpful tips. PMU-240NA/600NA... -
Page 7: Ⅱ.1.1 Operation Mode Setup - Usb
[ ▶ ] button: Play the selected song [ || ] button: Pause the current song [ ■ ] button: Stop current song [ ▶▶| ] button: Play next song ④ It shows current commend, It will shows the current file’s status. (Play, Stop, or Pause) PMU-240NA/600NA... -
Page 8: Ⅱ.1.2 Operation Mode Setup - I-Radio
MIXINg AMPLIfIER Ⅱ.1.2 Operation Mode Setup – I-RADIO PMU-240NA/600NA... - Page 9 ⑤ Radio channel list: This is the setup window for internet radio address. Title: Type the radio title URL: Type the Dario server’s address Change: Click the button for update the radio information. Change All: Click the button to update all radio channels’ information. (20 radio channel list, Title and address) PMU-240NA/600NA...
-
Page 10: Ⅱ.1.3 Operation Mode Setup - Aoe Stream
- Main address and port: type the AOE device’s IP address and port number. - Dual address and port: type AOE dual device’s IP address and prot number. [Save]: Click the button to store server channel list in AOE connection setup information. PMU-240NA/600NA... - Page 11 MIXINg AMPLIfIER [Connect]: Click the button to connect current server to access its setup information. [Disconnect]: Disconnect the current radio channel PMU-240NA/600NA...
-
Page 12: Ⅱ.2 Input Volume 1 Setup
When clicking the mute button, sound source shuts off. Drag the mouse slide bar to the aimed volume to set it up. (Volume Value) ② Setup the volume about INPUT1~INPUT6. ③ [Input Volume 1 Setup] page will show the help page. PMU-240NA/600NA... -
Page 13: Ⅱ.3 Input Volume 2 Setup
AUX: Setup the volume of AUX input at the front side of the device. PC AUDIO: Setup the volume of PC AUDIO input at the back side of the device. NETWORK: Setup the volume of AOE Stream and I-RADIO of the device. ③ [Input Volume2 Setup] page will show the help page. PMU-240NA/600NA... -
Page 14: Ⅱ.4 Tel/Ext In Setup
① Setup the TEL IN volume. Select among 100%, 75%, 50%, 25% and click [Apply] button so it applies to the device. ② Setup the EXT IN volume. Select among 100%, 75%, 50%, 25% and click [Apply] button so it applies to the device. ③ [TEL/EXT IN Setup] page will show the help page. PMU-240NA/600NA... -
Page 15: Ⅱ.5 Eq Setup
The 6-BAND EQ value that was setup by the user, will be stored in [USER1], [USER2], [USER3]. ⑥ (Among the PRESET list, when clicking [USER1], [USER2], [USER3], you can check the stored value.) ⑦ [EQ setup] page will show the help page. PMU-240NA/600NA... -
Page 16: Ⅱ.6 Speaker Setup
- SPEAKER2 is in Off condition, but when clicking [Off] button again, it turns to On condition. ② ALL(On/Off): You can control every speaker(SPEAKER1~5). - On: Every speaker (SPEAKER1~5) turns to On condition. - Off: Every speaker(SPEAKER1~5) turns to Off condition. ③ [Speaker Setup] page will show the help page. PMU-240NA/600NA... -
Page 17: Ⅱ.7 Dsp1 Setup
- LPf Enable: Setup whether to use Low Pass filter or not. (LPf: LOW PASS fILER) - frequency: Setup frequency value. (20Hz ~ 400Hz) - Volume: Setup MIX-OUT’s volume. (0~100) ⑦ [DSP1 Setup] page will show the help page. PMU-240NA/600NA... -
Page 18: Ⅱ.8 Dsp2 Setup
- Set up Signal Detection value according to different types of input. (CH1~CH6,TEL IN, EXT IN, USB, CHIME, AUX, PC AUDIO, AOE, I-RADIO, ) - Setup to the wanted value, then click [Apply] button and it will apply to the device. ② [DSP2 Setup] page will show the help page. PMU-240NA/600NA... -
Page 19: Ⅱ.9 Priority Setup
When clicking [Initialize] button, priorities reset. ■ priority reset value. 1ST PRIORITY: TEL IN 2ND PRIORITY: CH1, CH2, CHIME, EXT IN NO PRIORITY: CH3, CH4, CH5, CH6, AOE, AUX, PC AUDIO, USB MEMORY, I-RADIO ⑤ [Priority Setup] page will show the help page. PMU-240NA/600NA... -
Page 20: Ⅱ.10 Network Setup
- Manual Setting: input the IP address, subnet mask, gateway, DNS1, DNS2 setup value. ④ When clicking [Apply] button, present setup value will apply to the device. When clicking [Initialize] button, network setup will reset. ⑤ [Network Setup] page will show the help page. PMU-240NA/600NA... -
Page 21: Ⅱ.11 Device Setup
TONE, after starting chime bell is done, front side’s CHIME LED will blink. Then, press CHIME button once more and ending chime bell will broadcast. If you have set up the ending chime bell to NON, only starting chime bell will broadcast. ③ You can decrease number 5 speaker to fixed ratio (100%, 50%, 25%). PMU-240NA/600NA... - Page 22 ⑥ [Device Setup] page will show the help page. ※ When the contact closer is at input condition, it is unable to setup the operation of contact closer 1-4, so be cautious when using. PMU-240NA/600NA...
-
Page 23: Ⅱ.12 Time Setup
[Automatic Time Synchronization]: Reset time of the server and it will setup the device’s time. ③ When clicking [Apply] button, the time that was setup will apply to the device. ④ [Time Setup] page will show the help page. PMU-240NA/600NA... -
Page 24: Ⅱ.13 View Log
① Logs that occurs while device operates, will show at the relevant domain. - When clicking [Refresh] button, log rereads. - When clicking [Clear Log] button, log information becomes deleted. ② [View Log] page will show the help page. PMU-240NA/600NA... -
Page 25: Ⅱ.14 System Management
“firmware has been successfully uploaded. Proceed with upgrade” will appear. Then click [Confirm] button and it will say, “System will be restarted. Please re-connect after a fewminutes” When finally clicking [Confirm] button once again, upgrade will be finished. - When pressing [Initialize] button, the selected file becomes reset. PMU-240NA/600NA... - Page 26 ③ gUI that appears at the front side LCD, its password can reset. - When clicking [Apply] button, password of the front side LCD’s gUI resets. ④ You can restart main programs of the device. - When clicking [Apply] button, main program of the device will reset. PMU-240NA/600NA...
- Page 27 Inter-M, Ltd. (Korea) began operations in 1983. Since then, Inter-M has grown to become one of the largest manufacturers of professional audio and commercial sound electronics equipment in the world. Inter-M has gained worldwide recognition for its own branded products, as well as private label manufacturing of electronics sold under other names (OEM).
