Introduction
1.2

GENERAL TECHNICAL SPECIFICATIONS

Camera Type Medium Format Digital SLR camera with Auto-focus, Auto-exposure, interchangeable Viewfinders and Lenses.
One piece stainless steel shell. Die-cast aluminium internal structure. Tripod sockets (1/4 and 3/8") and quick coupling tripod plate
Construction
for rapid mounting.
Display 3 inch TFT type, 24 bit colour, 920K pixels; Touch functionality: Yes, full support
Live View On camera, host and iOS device with high frame rate
Wi-Fi 802.11 a, ac, b, g, n (a and ac are depending on region).
Hasselblad HC/HCD lenses with built-in electronically controlled shutter and aperture. Automatic or manual
Lenses focusing with instant manual focus override. All HC/HCD lenses meet the exacting requirements of digital photography. Lens shades
can be mounted in reverse for transport.
A 90° reflex viewfinder, providing 100% field of view even when wearing eyeglasses, and built-in multi-mode light
metering system. Image magnification 3.1x for H6D-50c and 2.7x for H6D-100c. Integrated fill-in flash with guide number 12.
Viewfinder
Hot-shoe for automatic flash (Metz SCA3002 system / adapter SCA3902). Dot matrix display with presentation of all relevant
information. Built in dioptre adjustment from -5 to + 3.5D. Interchangeable.
Automatic and manual focusing with electronic focus aid in manual mode. Instant manual focus override. Automatic focusing using
Focusing
passive central cross type phase detection sensor. AF metering range EV 1 to 19 (ISO 100).
Electronically controlled lens shutter with speeds up to 1/2000 (H6D only. 1/1000 with other H System Cameras). Flash sync at all
Shutter
speeds.
TTL centre-weighted system. Can be used with the built-in flash or a wide variety of flashes compatible with the
Flash Control SCA3002 (Metz) system using adapter SCA3902. ISO range 16 to 6400. Flash output can be adjusted (-3 to +3EV) for fill-in
purposes independent of ambient light. Synch at all shutter speeds.
Multi-mode exposure metering using 90° reflex viewfinder. Metering options are: Spot (diameter 7.5 mm),
Exposure Metering Centre Weighted, and Centre Spot. Metering range at f/2.8 and ISO100: Spot: EV2 to 21, Centre-weighted: EV1 to 21, Centre Spot:
EV1 to 21.
Auto Bracketing Bracketing using predetermined number of captures (2, 3, 5, 7 or 9) in 1/3, 1/2, or 1 EV step difference intervals.
Interval Timer Number of captures from 2 to No Limit and interval from 1 second to 1 hour.
The camera features two dot-matrix displays that provide clear and easy-to-understand information to the user. One is located on the
Displays
grip and the other in the 90° viewfinder. The sensor unit has a high resolution full touch 3 inch TFT display.
Focusing Screen Bright Spherical Acute-Matte type D with sensor format markings. Grid marked type also available as option.
A large number of the H6D's functions can be customized by the user to suit specific styles or situations through the built-in menu
Customization
system.
Full touch user interface, including swipe, scroll and pinch/spread to zoom. Camera grip with buttons and control wheels. Many
User Interface
camera functions and settings can be controlled from a tethered computer or iPhone/iPad over Wi-Fi.
Power supply Rechargeable Li-ion battery (7.2 VDC/3200 mAh); Socket for external power
