Summary of Contents for Hasselblad H4D-60
- Page 1 User Manual H4D-60 H4D-50 MS H4D-50 H4D-40 H4D-31...
-
Page 2: Table Of Contents
The images in this manual were not taken with a Hasselblad H4D. They are used for illustrative purposes only and are not intended to represent the image quality produced by a Hasselblad H4D. Unless otherwise stated, all images: ©... - Page 3 SU – getting started Inter val Set tings Set tings check Custom Options White Balance / Grey balance Image Info Media Tex t set ting Date & Time Browsing images System status Drive Basic image browsing Flash /strobe Zooming in and out Zooming in for more detail Thumbnail views General...
-
Page 4: Introduction
Hasselblad cameras, famed for quality and reliability, were chosen to record the lunar missions – there could hardly be better praise than that. Hasselblad con tinues the tradition of building on well proven technologies, refining and im proving to raise standards, always to produce a better product. By using Hasselblad equipment you share the decision made by of some of the world’s... - Page 5 5 HC/HCD lenses ranging from 28mm to 100mm. The CF adapter (optional accessory) allows use of the classic CF-lenses from the Hasselblad V System, with full use of their central shutters, allowing flash to be employed at shutter speeds up to 1/500s. The central shutter also improves image quality by reducing camera vibration.
-
Page 6: Instant Approval Architecture
IAA is a Hasselblad trademark and Hasselblad has a patent pending on the invention. Extra large 3”... - Page 7 Results will be good from the word go, that’s guaranteed, but when you want to make improvements or work more efficiently perhaps, the H4D will take care of it. The supreme Hasselblad potential is there, it’s up to you to exploit it!
-
Page 8: System Requirements
Finally, please check occasionally on the Hasselblad website for any updates regarding user instructions, changes, news, or other information. If you have no Internet access, please contact your Hasselblad dealer or distributor for the latest information. -
Page 9: H4D Models
However, virtually all the information in this manual applies to all models. When differences do occur, they are marked as such. Photo: Dirk Rees / Hasselblad Masters... - Page 10 H-series, resulting in a reduced coverage for the larger sen- Please ensure you are using version 2.5.1, or later, as earlier sors used in the H4D-60. So, if you use HCD lenses, be aware of versions do not support the H4D-60.
- Page 11 The H4D-50 produces 65 MB raw files that meet most TECHNICAL SPECIFICATIONS demands to produce the tremendous quality that Sensor size 50 Mpixels (6132 x 8176 pixels) Hasselblad is world renowned for. Sensor dimensions 36.7 x 49.1 mm Pixel size 6.0 μm Image size RAW 3FR: 65 MB.
- Page 12 Shutter Speed 256 sec. - 1/800 Color depth 16 bit Color management Hasselblad Natural Color Solution CF storage capacity 4 GB CF card holds 75 images on average Capture rate 1.1 sec. per capture. 50 captures per min. Color display...
-
Page 13: General Overview - Controls And Displays
General overview – controls and displays This section provides an introduction to the control buttons' functions as well as the information provided on the display screens. Photo: Claudio Napolitan / Hasselblad Masters... -
Page 14: But Ton Func Tions
Button functions − overview Below is an overview of the primary functions of the control wheels and buttons. Some controls have dual or triple functions according to the state of the menu or setting. A full description can be found further on in this manual. Shutter release button MENU button Releases shutter. -
Page 15: Display Information
This overview illustrates the Display information VIEWFINDER INFORMATION functions and features most commonly needed when shoot − overview ing, and how they are distri Metering method buted on the three displays. Aperture setting Shutter speed For example, aperture and shut- Exposure method ter settings appear in both the Capture counter... -
Page 16: Grip Display
Grip display − overview Typical camera grip display. Flash condition indication Focus setting Drive condition (No exposure compensation, (Autofocus setting, (Single setting) normal flash synchronisation) single shot mode) Aperture setting Shutter speed setting (f/5.6) (1/400s) Exposure Value display ISO setting (EV 13.8) (100 ISO) Low battery symbol... -
Page 17: View F Inder Display
Viewfinder display − overview Typical viewfinder display. Note the LEDs will only be visible when activated (by the camera or a setting). Exposure method indication Aperture setting Exposure compensation Metering method setting setting reminder symbol (‘aperture priority’ mode) (f/5.6) (Centre weighted) Focus Assist LED True Focus (all models) Flash LED... -
Page 18: Sensor Unit Display
Sensor unit display overview When shooting, the sensor unit can display the information most often required for a quick settings check. The unit's buttons are used to navigate the main menu and change settings. ISO setting White Storage ISO setting, white balance etc information is balance medium retained when navigating the menu. -
Page 19: But Tons And Controls - Details
Buttons and controls − details Shutter release button This button has half-press and full-press positions. By pressing half-way (or softly) the camera, auto focus function and exposure meter can be activated. By pressing all the way down (or more firmly) the shutter will be released (or the chosen exposure proce- dure for example, the self timer is activated with this button). - Page 20 Can be reassigned in Custom Options to another function. Remote release cord port For attaching a remote release cord (electrical). The Hasselblad accessory jack plug socket is protected by a captive rubber plug. STOP DOWN button Press this button to make a visual check of the depth-of-field on the viewfinder screen at the chosen aperture.
-
Page 21: Audio Feedback
There are also two control buttons on the viewfinder, as well as the eyesight correction adjustment wheel: Eyesight correction adjustment wheel The personal eyesight adjustment facility has a diopter range of -5 to +3.5, to suit most users. EV correction adjustment button Press this button to access the EV compensation screen. - Page 22 Saving settings changes on the grip The basic principle behind making changes is that the appropriate button is first pressed to access the menu and then settings altered by way of the control wheels. The appropriate control wheel is designated by arrowheads alongside the setting description.
-
Page 23: Camera Body
The integral ergonomic grip houses the main control interface and also contains the battery holder. The camera body also contains the viewfinder screen, which can be easily removed Photo: Nina Berman / Hasselblad Masters or exchanged without the use of special tools or adjustment procedures. -
Page 24: Carrying Strap
Carrying strap 1, 2 The carrying strap is attached by firstly withdrawing the safety collar. The hook is then freed and attached to the strap lug (fig. 1). Slide back the safety collar (fig. 2) to ensure the hook remains in the locked position between the small protruding lugs. -
Page 25: Charging The Battery
Charging the battery With the battery removed from the camera, insert the jack plug from the battery charger into the socket on the battery grip. Insert the battery charger into a standard (100–240V~ /50–60 Hz) domestic socket. During the charging procedure, the lamp on the charger signifies the following: —... -
Page 26: Rechargeable Battery Grip - Precautions
The lithium-battery grip should be • Keep the protective cover in place when not in use. (Short-circuiting across keys in a pocket, for example, could seen as a reserve for emergency use cause a fire risk). only. • Do not use the battery grip for anything other than H1/H1D/H2/H2D/H3D/H4D cameras. • Do not immerse the battery grip in liquids. • Do not incinerate the battery grip. Please recycle or discard in an environmentally approved manner. • Do not use any other charger than the Hasselblad battery charger BC-H Li-ion 7.2 VDC (3053568). Battery charger BC-H Li-ion 7.2 VDC – precautions: • Read the instructions before using the charger. • Use indoors only (protect against moisture). • Do not use charger for anything else than charging of Battery grip rechargeable 7.2 V (3043348). • Do not short-circuit the jack plug. • Do not alter the charger in any way other than changing the plug attachment. Reserve lithium-battery grip... -
Page 27: Bat Ter Y Status
Battery status (rechargeable battery only) An immediate full-screen information and battery status check appears on the grip display by holding down the illumination/battery status button. This screen displays: • the firmware version • the number of captures taken since the last battery recharge / change. • a rechargeable-battery status icon that provides a quick visual check as well as a figure estimate in percent. The information regarding the number of captures taken is intended to help you make an estimate of the number of possible remaining captures according to your way of work- ing. -
Page 28: Viewfinder Screen
If the screen becomes damp, do not use hot air to dry it. Use a soft cloth on the upper surface only. Seek advice from an Authorized Hasselblad Service Center if the screen becomes particularly soiled. Remember that particles or greasy... -
Page 29: Viewfinder
This display also duplicates much Photo: Joao Carlos / Hasselblad Masters information visible on the grip display for immediate check- ing. In addition to the display, there are four LEDs providing general warnings, flash and focus information. -
Page 30: Par Ts & Components
User functions are the same for both wish to wear eyeglasses. models. The eye cups can be rapidly changed by a Hasselblad Authorized Service Center. Integral flash unit See section on Flash for full details... -
Page 31: Lenses
All HC lenses have been specially formulated for the H system to produce the extremely high performance expected from Hasselblad. In addition to exceptional sharpness, the design also incorporates a very pleasing boké. All lenses feature an electronically controlled central shutter designed to extreme- ly fine tolerances for supreme accuracy. -
Page 32: Par Ts & Components
Parts and components A. Lens shade index B. Manual focus ring C. Focusing distance scales D. Depth-of-field scales E. Lens index Attaching a lens 2, 3 Remove the front protective cover on the camera body by depressing the lens release button and keeping it depressed while turning the cover counter-clockwise. -
Page 33: Depth-Of-F Ield / Visual Preview
Lens focus setting too far For specialists, please contact your Hasselblad dealer for information about sensor units beyond the distance of the subject framed by the central adapted solely for infrared photography. -
Page 34: Manual Focus
T i p the newly automatically made focus setting (AF-T can also be To expand your range of lenses, consider using a CF adapter used). to allow you to use most of the lenses from the Hasselblad V- system. -
Page 35: Autofocus
Manual focus There is both a Manual focus mode setting and a Manual Override capability. Manual focus is a specific setting that you actively make, whereas Manual Override is always available as a temporary override of an autofocus setting. In Manual focus mode, focusing is carried out by rotating the focusing ring in the conventional manner. -
Page 36: Continuous
Note though that in this mode the lens will focus at a distance and will remain focused at that distance while pressure remains on the shutter release button. In this way, you can focus on a nearby object for example, temporarily positioned within the focusing zone on the viewing screen and then without releasing pressure on the shutter release button, recompose knowing that the focus remains on the object chosen even though it is now outside the focusing zone. - Page 37 True Focus can be used with longer lenses, smaller apertures etc but the further you come from situations similar to the 'ideal' as described above, the less the effect will be until it has no visible effect at all. Please remember that although True Focus can noticeably improve a demanding shoot it will only work effectively in the specific circumstances it was designed for.
- Page 38 True Focus and Absolute Position Lock The obvious situation that would most benefit from using True Focus would be a fashion shoot with a fairly wide angle lens at a large aperture setting and where the central area of the image is clothing while retaining focus on the model's face. Ideally, a fairly controlled and static flow should be planned on (this means a change of pose by the model should take place only after captures and the photographer must resist crouching down, or leaning forwards or backwards too much before capture).
- Page 39 True Focus True Focus can be used in combination with other autofocus settings to achieve various functions. Activated by shutter release button – True Focus retained In this mode the autofocus function is effectively converted into the True Focus func- tion. That is, focus is set by half-pressing the shutter release button. Remember, MENU though, that the True Focus function is retained until turned off in Custom Options.
-
Page 40: Light Metering & Exposure Control
A great deal of control is available ranging from 100% manual through to sophisticated fully automatic by way of the various exposure methods: Manual, Aperture priority, Shutter prior- Photo: Lyle Owerko / Hasselblad Masters ity, Program and Program variable. -
Page 41: Iso & White Balance Button
Light metering and exposure control Two primary factors have to be considered when making exposure control choice, namely, metering method and exposure method: ISO/WB Metering method determines in which manner the light measurement is made and how much of the image is taken into account (Centre Weighted, CentreSpot and Spot). Exposure method involves the parameters and deciding factors about how the light measurement is translated into aperture and shutter speeds. -
Page 42: Metering Method
Metering method There are three metering modes available. All three are reflective methods (measuring Centre Weighted (23 x 20 mm) ≈ 25% the light reflected off various selected parts of the subject according to method) and are through the lens (TTL). These have the following designations (with their respective display symbols): –... -
Page 43: Manual Exposure Mode
Manual Exposure – M Manual mode will provide total user control of the shutter and aperture settings. To set the Manual mode, proceed as follows with the camera in active mode: 1) Press the EXP button on the viewfinder. 2) Turn the front control wheel in either direction until you reach M (Manual). -
Page 44: Ae-L But Ton 4
Programmed variable: Pv - This mode is very similar to Pro- grammed, except with the additional parameters of lens focal length being automatically taken into account. For example, long shutter speeds will automatically be avoided with a long focal length lens. To set one of the modes, proceed as follows with the camera in active mode: 1) Press the EXP button on the viewfinder. - Page 45 b) The AE-L button also allows the spot metering function to make zone placements. When the AE-L button is pressed, the metered area is saved as a mid-grey (Zone 5). When the spot area is then placed over another part of the scene, the new area is then compared to the saved area and the difference can be read off New metered area is 1.8 EV lower than the area the scale seen in the viewfinder.
-
Page 46: Exposure Compensation/Quick Adjust
Exposure compensation/Quick Adjust The exposure compensation function, for both manual and Custom Options #3, #17 and automatic modes can be set from -5 to +5 EV, in 1/3, 1 or 1/2 EV #23 used to deactivate and increments (Custom Option #3) and is visible above the scale in alter the settings for the rear the viewfinder and as a ±... -
Page 47: Profiles
Profiles Profiles not only allow for rapid setup in changing working environments but also ensure an element of security. Photo: Mark Holthusen / Hasselblad Masters... -
Page 48: Making A Profile
Profiles The profiles feature allows rapid access to pre-determined combinations of settings that increase the speed and security of workflow. One example might be in a social situa- tion where there might be a need for formal outdoor portraiture followed by informal indoor handheld flash-assisted wide-angle shots, both situations requiring very different settings in a stressful environment. -
Page 49: Using Profiles
3) Use the scroll bar to go through the list of profiles. Choose a Spare profile or a named profile (except Default). You can either save the new profile under the original name or you can change it 4) Press Save (ISO/WB button). The Profile name screen is then displayed where you can rename the profile to what suits you (see section Image Info 4.2 for procedure details ON•OFF... -
Page 50: Su - Introduction
Sensor unit – introduction Photo: Dirk Rees / Hasselblad Masters... - Page 51 In keeping with Hasselblad’s modular design philosophy, the sensor unit is an independ- ent component of the H4D. In this way it can be used with view/large format cameras to...
-
Page 52: Par Ts And Components
M N O H4D-31 / 40 / 50 H4D-60 Parts, components & control panel buttons The buttons are used for browsing images and navigating the menu system to make settings. Two of the buttons, located at the bottom-right and -left of the screen, are given an on-screen label that changes according to the current context. For example, the Approval button sets the approval rating when browsing images, but becomes an OK button to confirm settings. - Page 53 Never attempt to remove the glass filter from the front of the CCD–you will probably ruin the CCD if you do so. If dust manages to get between the IR filter and CCD, it can only be removed at the Hasselblad factory. Contact your Hasselblad dealer for assistance.
-
Page 54: Over View Of Menu System And Navigation
Introductory overview of menu access, navigation and settings choice. The menu is structured in a manner similar to mobile/cell phones and similar small electronic devices. Various branches within the tree system are accessed by pressing the navigation button until you reach the point where a choice has to be made. The OK (Approve) button or SELECTION (ZOOM IN / ZOOM OUT) buttons are then used to confirm choice. -
Page 55: Over View Of Menu Struc Ture
Schematic view of sensor unit menu Here you can see where all the screens are situated with regard to each other. Navigating to them is just a matter of tracing along the paths using the Navigation button. You can revert by either pressing the Navigation button in the opposite direction or the Menu/Exit button. -
Page 56: Description Of Menu Items
By using the buttons on the control panel and the control wheels on the Simple description of grip you can navigate down through the various levels in the menu. menu items Below is an overview of the setting options available. MENU WHITE BALANCE Sets the light sensitivity of the sensor. Sets the color temperature of light used. BROWSE Sets the IAA approval status (rating) filter for easier and quicker image browsing.. STORAGE DELETE DELETE FORMAT For single or multiple dele- For single or multiple deletion of images. Used to format CF cards for optimum use. tion of images. DEFAULT APP LEVEL BATCH Used to create new storage folders (batches) Assigns a default IAA approval status (rating) to all new images. and name them. SETTINGS CAMERA ABOUT USER INTERFACE Sets menu language, power down, Sets options when sensor unit is Displays serial number and... -
Page 57: Su - Initial Settings
General sensor unit overview – initial settings This section deals with getting started as well as a general overview of tethered and untethered shooting and capture storage modes. Photo: Mark Zibert / Hasselblad Masters... -
Page 58: Setting The Menu Language
Getting started The initial general setting is language choice. This choice is retained but can be changed at any time. You can choose between: ENGLISH GERMAN FRENCH ITALIAN SPANISH JAPANESE CHINESE Before each shoot an ISO and a white balance setting should be made (white balance is for your convenience regarding the appearance of the image on the display though;... -
Page 59: Capture Storage
Hasselblad Phocus software and store captures on a computer hard-disk. • The main advantages with this mode are the almost limitless storage capacity, remote camera-control and being able to see the images (with Hasselblad Phocus) on a large screen. • The main disadvantage with this mode is the lack of mobility to any great extent. -
Page 60: Compac T Cards
Using compact flash memory cards When using a compact-flash card, the H4D is completely self- contained. No additional wires or connectors need to be attached. The H4D is shipped with a 4GB (or larger) compact-flash card, which is capable of holding approximately 50 − 100 captures (according to model). -
Page 61: Formatting
Formatting The camera is only able to read and write to storage media that have been formatted. New cards or disks sometimes have no for- matting, or you might want to convert media that are currently using a format that the camera cannot read. There are two ways to format cards. -
Page 62: Tethered To A Computer
16-bit 3F file in the currently selected folder on the computer hard disk. 3FR is a proprietary Hasselblad format for storing raw captures. It contains the complete raw image exactly as it was captured by the camera, plus technical details that enable Phocus to process and display the image correctly, amongst other things. -
Page 63: Su - Getting Started
Sensor unit – getting started This section covers basic initial settings: ISO, white balance and selection of media. Photo: Claudio Napolitan / Hasselblad Masters... -
Page 64: Settings Check
Settings check ISO, White Balance and Browse settings should be checked before each session. They are therefore placed at the top level of the ISO/WB menu for quick and easy access. They are also shown on-screen in most preview modes, so you can easily keep an eye on them as your work. - Page 65 To set the white balance on the grip The ISO/WB button provides immediate access to white balance settings. The rear control wheel is used to make the desired ISO/WB changes. The settings are automatically and simultaneously transferred from the camera to the sensor unit. Please note that the changes are only displayed on the sensor unit when the settings have been saved.
-
Page 66: Media
3b. Alternatively, you can position the central spot in the view- finder over an area that you consider should be rendered as neutral in color in the image (a ‘grey card’ or even a sheet of white paper is ideal) and make a test capture (ensure the exposure is approximately correct otherwise you will get a warning message). -
Page 67: Browsing Images
Browsing images This section is an overview of the various ways of browsing, zooming, sorting and viewing images. Photo: Mark Holthusen / Hasselblad Masters... -
Page 68: Basic Image Browsing
Basic image browsing The large, full-color display enables you to inspect your shots while you are still on-location. It offers full-screen previews, high- magnification zoom, two levels of thumbnails and analysis tools including a full histogram and camera settings. When you first turn on the camera, the display opens in standard browse mode, showing the last capture taken (if any) for the current batch. -
Page 69: Thumbnail Views
You work your way deeper into the menu branching off the selected item (framed in blue) each time you press the button – to view media, batch, thumbnail view etc. Conversely, you work your way back out of the menu each time you press the button. -
Page 70: Preview Modes
Preview Modes The preview can be set to various modes to show or hide technical information. It can be changed in seconds. Photo: Bang Peng / Hasselblad Masters... -
Page 71: Preview Modes
Preview Modes Standard preview mode You can cycle through all the available preview modes by pressing the View-Mode button. Histogram Full-screen mode preview mode Battery saver mode Histogram and full details mode Preview Modes Choosing the Preview mode Use the View Mode button to cycle through the available preview modes which are: • Standard preview: Shows a preview image surrounded by a display of a few important settings. -
Page 72: Histogram Mode
The Standard Preview display is the one shown Standard Preview ISO setting when you first turn on the camera and is probably the view you will use most often. White balance It shows a preview of your most recent capture Current storage medium and basic information about the settings. Furthermore, the display enables you to navigate the menu system and make camera settings;... -
Page 73: Full-Details Mode
Full Details Mode In full-details mode, you can read a complete list of camera settings, plus see the histogram and, in the background, a darkened preview of the image. The camera-setting details are stored with the image, so you can refer to them using Phocus even after you have loaded the image to your computer and stored it in your archive. -
Page 74: Ia A - Instant Approval
– Instant Approval Architecture IAA should be considered as a necessary part of your methods. It can help you browse efficiently and help in sorting before you download to a workstation. Photo: Nina Berman / Hasselblad Masters... -
Page 75: Using Iaa
Using Instant Approval Architecture The Instant Approval Architecture system helps you to evaluate your images as quickly as you take them. It works by supplying immediate audio feedback, which tells you instantly whether each new capture is exposed correctly or likely to be rated as over- or underexposed. - Page 76 3. If no problem is detected, then the image is saved with the chosen default approval status. N o t e 4. When you are browsing through your shots, keep an eye on the approval status of each and consider whether you should promote or demote each shot based on its When the current storage medium appearance on the preview screen.
-
Page 77: Default Approval Status
Default approval status By default, the system assigns an initial approval status for each new shot based on an analysis of the distribution of exposure levels. In the factory configuration, the status of each new shot is assigned as follows: • Green (approved): The new shot seems to have been exposed correctly. -
Page 78: Browsing By Approval Status
Browsing by approval status You can set the camera to browse by approval status, which Show all means, for example, that you will see only green-status images as (brackets on all) you browse a batch (or both green and yellow, or only red, etc.). The current filter setting is indicated on-screen, as illustrated. -
Page 79: Deleting By Approval Status
Deleting by approval status There are several ways to delete images, including approval status. You can choose to delete: • All red-status images from the selected batch or medium • All red- and yellow-status images from the selected batch or medium • All images from the selected batch or medium roceed as follows: 1. Starting at the single-image preview display, Select MAIN MENU > STORAGE > Delete. 2. -
Page 80: File Storage
File storage – working with batches This section covers navigation of the menu regarding storage media, the storage of captures in batches, viewing batches as well as rating and browsing captures of using the IAA system. Photo: Joao Carlos / Hasselblad Masters... - Page 81 Introductory overview Navigating to batches and media. – – – – – Zoomed Normal view 4-Thumbnail view 9-Thumbnail view Batch list Media Creating new batches The BATCH screen. Batch name Date the batch was created The blue frame around a folder tells you that it is the Current Batch.
-
Page 82: Organizing Work With Batches
Organizing work with batches Collections of captures are stored in named and dated folders called batches. They help you to organize your shots as you work and function exactly as folders on a computer. Batches have the following properties: • When you create a new batch, you assign a name to it. • When you copy images from a compact-flash card, each batch is saved as a sub-folder on the destination disk. -
Page 83: Navigating Batches
Navigating batches The camera always works with a current batch. This is the location at which the camera will save all new shots. To view batches using the browse controls: 1. Press the zoom-out ( ) button repeatedly until you are all the way at the top zoom level. -
Page 84: Deleting Images
Deleting images Photo: Stephan Zirwes / Hasselblad Masters... - Page 85 Menus for deleting single or several images from the current batch. Menus for deleting several images from a batch. Menus for deleting several images from all batches from a card.
-
Page 86: Delete
Delete The storage settings allow you to format media and create new batches. You can also set the initial approval status (green or yellow) assigned to new pictures. The first item on the storage list is file deletion. The great advantage of digital capture is of course the ability to judge images on the spot, delete them immediately if necessary and thereby make room for more valuable captures. -
Page 87: Deleting Several Images From A Batch
Deleting several images from a batch To delete several images from a selected batch: 1. Starting at the single-image preview display, Select MAIN MENU > STORAGE > Delete. 2. Use to enter the Delete submenu or use shortcut. – 3. -
Page 88: Transferring Images
3. Press to open the Delete Image dialog. 4. You must now select the approval status that you wish to delete. All images on the CF card that are also of the status that you select here will be deleted by the operation. Use ... -
Page 89: Settings
Settings This section covers various diverse settings such as sound, date & time, display brightness, etc. Photo: Bang Peng / Hasselblad Masters... -
Page 90: User Interface
Navigating the USER INTERFACE settings User Interface By altering the User Interface settings, you can control the way the sensor unit interacts to suit you and your preferred way of working. It also includes date and time settings. User interface menu items The user interface menu includes both items and sub-menus as follows: • ... - Page 91 • Sound: The H4D uses audio feedback to help let you know if each new image is exposed correctly. This is described in Standard Instant Approval Workflow. This menu item has Volume (choose between High, Low and Off), Key Click (choose between On and Off) and Exposure Warning (choose between On and Off).
-
Page 92: Camera
(which can be downloaded from the Hasselblad website). The serial number is also displayed in case Hasselblad Support need to know it for any eventual problem solving. The About box also shows the focus calibration ID (which must match the information on the grip display under 'System Status' to obtain the optimum performance). -
Page 93: Custom Options
Custom Options Selecting an option Proceed as follows: 1. Press MENU and navigate down to select SETTINGS. 2. Press the button and navigate down to Custom Options. 3. Press the button to select the option. Choices are selected –... -
Page 94: Su - View Cameras
Sensor unit – use with view cameras This section covers using the sensor unit when attached to a view or large format camera. Photo: Claudio Napolitan / Hasselblad Masters... - Page 95 View cameras – Flash sync shutters View cameras – Electronic shutters Flash sync input cable Any view camera with Hasselblad H adapter Rollei Lens- Control S Any view camera with Hasselblad H adapter Expose cable Flash sync input cable Schneider...
- Page 96 Setting CAMERA model and options These settings are only available when the sensor unit is not attached to an H4D body. Proceed as follows: 1. Press the menu (MENU) button to open the menu. 2. Use and to select the SETTINGS sub-menu. 3.
- Page 97 Setting EXPOSURE TIME and CAPTURE SEQUENCE Proceed as follows: 1. Press the menu (MENU) button to open the menu. 2. Use and to select the SETTINGS sub-menu. 3. Press to open the SETTINGS menu. 4. Use and to select CAMERA. 5.
- Page 98 – to make an INITIAL DELAY setting. 11. Press either the This setting controls the amount of time that elapses before the first capture in the sequence. 12. Press to select DELAY. – to make a DELAY setting. 13. Press either This setting controls the amount of time between each capture in the sequence.
-
Page 99: Custom Settings
Each one can be changed to suit your preferences so that the whole camera becomes a reflection of the way you like to work. Photo: Alexandfelix / Hasselblad Masters... -
Page 100: General Overview Of Camera Menu
General overview of camera menu MENU Text setting Self timer options Bracketing options Interval Settings options options Custom Options System status Drive... - Page 101 The H4D features the advantage of multiple customization Menu charts – general of settings. This means that your personal choice of settings, Throughout this manual you will find charts to explain the and thereby appearance of various combinations of symbols steps and procedures required to alter the various settings.
-
Page 102: Self Timer
There are a number of more advanced features that while not necessarily used every day still remain immediately accessible through the menu system. They provide the integral finesses that make the H4D a powerful and sophisticated tool to satisfy a variety of professional demands. - Page 103 Self timer setting The Self timer function is set in the following manner: MENU 1) Press the MENU button on the grip. 2) Turn the front control wheel until Self Timer appears. 3) Press ENTER (ISO/WB button) on the grip. 4) Turn the front control wheel to access the options, that are: Delay Mirror sequence...
-
Page 104: Bracketing
2 Bracketing 2 frames options available 3 frames 5 frames options available options available 1/3 EV 1/2 EV 1 EV 2 EV 3 EV 2 Bracketing T i p The bracketing function provides an automatic series of captures; one at the standard exposure setting (Manual or Auto) and the others with pre-determined deviations in EV A bracketing sequence can be from the standard exposure. -
Page 105: Bracketing Setting
Bracketing setting The Bracketing function is set in the following manner: 1) Press the MENU button. MENU 2) Turn the front control wheel until Bracketing appears 3) Press Enter (ISO/WB) button on the grip 4) Turn the front control wheel to access the options, that are: Number of Captures (the number of captures required in the sequence) Sequence (the sequential order of the over- or underexposures) ISO/WB... -
Page 106: 3 Interval
3 Interval options available 2 frames – 255 frames options available 1 second − 1 hour 3 Interval By using the interval setting, you can allow the camera to take a series of captures automatically over a set period. This is often MENU required for time and motion studies, security surveillance, nature study, etc. -
Page 107: 4 Settings
4 Settings / 4.1 Custom Options options available CUSTOM OPTIONS 4 Settings From the Settings screen you can access four main sub-settings: Custom options, Image info, Date & Time and System status MENU by turning the front control wheel. From each of these sub- settings you can access further items for setting changes. -
Page 108: 4.1 Custom Options
4.1 Custom options Stop down button function • Stop Down The following is a description of all 34 Custom Options. They are but can be reassigned to: accessed by Menu > Settings > Custom Options. The words and figures in red signify the default setting for that option. • B mode • T mode • Flash Measure •... - Page 109 Generates message on grip Zone makes the camera behave in the same display if attempted. fashion as the Hasselblad 205FCC. That is, the central spot is placed over a particular No allows the lens shutter and auxiliary shut-...
- Page 110 Rear wheel quick adjust Interval & Self Timer • Yes • No • Exit • Stay Allows rear control wheel to make a rapid Allows either the Interval or Self Timer EV adjustment (or EV compensation) in mode to remain active after a capture or auto-exposure mode. immediately return to standard setting.
- Page 111 Aperture control in Manual True Focus in AF-S • Front wheel • Rear wheel • Off • on Selects which control wheel changes the Re-assigns half press of shutter release aperture setting when in Manual expo- button to activate True Focus function in- sure mode. stead of standard automatic focus (single) Front wheel selects the front control wheel to change the aperture setting.
- Page 112 Customizable button function list The TRUE FOCUS, AE-L, STOP DOWN and M.UP buttons can all be reassigned to different functions. Default settings are as according to name. Flash Measure None Initiates flash measure function. The button has no function. Interval timer True Focus Initiates interval timer function.
-
Page 113: 4.2 Image Info
4.2 Image Info 4.2 Image Info In Image info you can compose your own combination of letters, words, symbols, etc to be included in the metadata. The same MENU procedure is also used to change a Profile name. Text setting 1) Press the MENU button on the grip. -
Page 114: 4.3 Date & Time
Changing text - an example Here is an example of how to change existing text (in this case the word ‘Text’ to a copyright symbol plus a photographer’s name -’Jens Karlsson’). See previous section ‘4.2 Image info' for proce- dure description. 1) Start by accessing the Image info screen. -
Page 115: 4.4 System Status
4.4 System status 4.4 System status Check component usage and general servicing information as follows: MENU 1) Press the MENU button on the grip. 2) Turn the front control wheel until Settings appears. 3) Press the Enter (ISO/WB button) on the grip. ISO/WB 4) Turn the front control wheel to access System Status. -
Page 116: Drive
5 Drive Drive There are two drive modes: Single and Continuous. MENU Single and Continuous In Single mode, a capture is made when the shutter release button is pressed and the camera is made ready for the next capture. To make the next capture however, you must first release the shutter release button and then press again. -
Page 117: Flash /Strobe
Metz and other top names in the field for powerful and reliable solutions When in the studio, the H system is capable of providing flash metering for maximum control and security. Photo: Mark Zibert / Hasselblad Masters... -
Page 118: General
Separate flash units can be used in dedicated mode when connected to the hot shoe if the unit is compatible with the SCA3002 (Metz) system using a Hasselblad SCA3902 adapter. This provides a cable free link up for information transfer. -
Page 119: Integral Flash
To access the controls: 1) Activate the camera and press the FLASH button once. FLASH 2) Turn the front control wheel to set the amount of compensa- tion required: • from +3EV through -3EV • press Clr (AF button) to clear the setting quickly if required. 3) Turn the rear control wheel to set: • normal sync (flash triggered just after the shutter opens) • rear sync (flash triggered just before the shutter closes) -
Page 120: Flash Measure
5) If the settings were incorrect to match the output of the flash unit, the viewfinder display shows a red triangle alongside a flashing green ‘flash’ symbol plus a warning message - ‘Low flash’. The grip display will also show a warning message - ‘Low flash’. -
Page 121: Multi Shot
Multi Shot This section provides an overview of the H4D- 50MS model. Photo: Lyle Owerko / Hasselblad Masters... - Page 122 Download the H4D MS datasheet from the Hasselblad website for a full description. This image was taken in both 1-shot and 4-shot mode to illustrate the increase in quality that the 4-shot mode produces.
-
Page 123: Optional Accessories
Camera strap H Focusing screens Release cord Lens accessories Optional accessories provide the opportunity to extend the capabilities of your system or just to add extra convenience to suit your way of working. Photo: Mark Holthusen / Hasselblad Masters... - Page 124 Proshade V/H 60 – 95 (3053393) (3040740) For connecting flashes compatible with An adjustable bellows lens shade that the SCA 3002 system to the Hasselblad provides highly efficient protection H4D. against stray light. Its compact, flat folding design saves space in the equip- ment case. With adapters fits all HC UV-sky filters lenses and virtually all V system lenses.
- Page 125 Hasselblad H system. The optical design consists of 6 elements in 4 groups. Check www.hasselblad.com for further details about lens shades, endcaps, lens pouches etc or news of new accessories.
- Page 126 HC lens range HCD 4/28 mm HC 3.5/35 mm HC 3.5/50II mm HC 2.8/80 mm HC 2.2/100 mm HC Macro 4/120II mm HC 3.2/150 mm HC 4/210 mm HC 4.5/300 mm HC 3.5–4.5/50–110 mm HC 4.0–5.6/35–90 mm V system C type lenses with optional CF lens adapter...
- Page 127 Sensor unit (included) Camera body View cameras – Flash sync shutters View cameras – Electronic shutters Flash sync input cable Any view camera with Hasselblad H adapter Rollei Lens- Control S Any view camera with Hasselblad H adapter Expose cable Flash sync...
-
Page 128: Appendix
Appendix P and Pv explanatory charts Technical specifications Problems, Equipment Care & Service This section provides an insight into the more technical aspects as well as some important reference information. Photo: Lyle Owerko / Hasselblad Masters... -
Page 129: True Exposure
At slow shutter speeds the effect is minimal but at faster speeds, e.g. 1/500s, the effect becomes clearly visible. As Hasselblad knows exactly how the shutters behave in HC lenses, automatic compensatory measures in speed setting adjustments are therefore employed. -
Page 130: P & P V Modes
Automatic exposure – P & Pv Mode P Mode Pv Mode 50-110 @ 50 50-110 @ 50 50-110 @ 110 50-110 @ 110 1000 1000 Shutter speed Shutter speed Shutterspeed Light metering method sensitivity distribution Centre Weighted (23 x 20 mm) ≈... -
Page 131: Technical Specifications
Technical specifications Camera Type Auto-focus, auto-exposure digital SLR camera with interchangeable viewfinders and lenses. Construction One piece stainless steel shell. Die-cast aluminium internal structure. Tripod sockets (1/4 and 3/8”) and quick coupling tripod plate for rapid mounting. Lenses Hasselblad HC/HCD lenses with built-in electronically controlled shutter and aperture. Automatic or manual focusing with instant manual focus override. All HC/HCD lenses meet the exacting requirements of digital photo- graphy. Lens shades can be mounted in reverse for transport. V- system lenses can be used with a CF adapter. Lens factor HC – 1.0 / HCD –1.0 (marginal crop). Viewfinder (HV 90x-II) A 90° reflex viewfinder, providing 100% field of view even when wearing eyeglasses, and built-in multi-mode light metering system. Image magnification 3.1x. Integrated fill-in flash with guide number 12. Hot-shoe for automatic flash (Metz SCA3002 system / adapter SCA3902). Dot matrix display with presentation of all relevant information. Built-in diopter adjustment from -5 to + 3.5D. Interchangeable. Focusing Automatic and manual focusing with electronic focus aid in manual mode. Instant manual focus override.Automatic focusing using passive central cross type phase detection sensor. AF metering range EV 1 to 19 (ISO 100). Shutter Electronically controlled lens shutter with speeds up to to 1/800. Flash sync at all speeds. Flash control TTL centre-weighted system. Can be used with the built-in flash or a wide variety of flashes compatible with the SCA3002 (Metz) system using adapter SCA3902. ISO range16 to 6400. Flash output can be adjusted (-3 to +3EV) for fill-in purposes independent of ambient light. Synch at all shutter speeds. Flash measurement The H4D has a built-in measurement system that measures flash light from non-TTL flashes, such as studio flashes. Exposure metering Multi-mode exposure metering using 90° reflex viewfinder. Metering options are: Spot (diameter 7.5 mm), Centre Weighted, and CentreSpot. Metering range at f/2.8 and ISO100: Spot: EV2 to 21, Centre-weighted: EV1 to 21, CentreSpot: EV1 to 21. -
Page 132: Sensor Unit
SENSOR UNIT H4D-60 H4D-50MS H4D-50 Sensor size 60.1 Mpixels: (6708 x 8956 pixels). 50 Mpixels: (6132 x 8176 pixels). 50 Mpixels: (6132 x 8176 pixels). Sensor dimensions 40.2 x 53.7 mm. 36.7 x 49.1 mm. 36.7 x 49.1 mm. Image size Raw 3FR capture. Raw 3FR capture. Raw 3FR capture. Compressed to 80 MB on average. Compressed to 65 MB on average. Compressed to 65 MB on average. 8 bit TIFF: 180MB. 8 bit TIFF: 150MB. 8 bit TIFF: 150MB. Capture rate 1.4 seconds per capture. 1.1 seconds per capture. 1.1 seconds per capture. 31 captures per minute. 33 captures per minute. 33 captures per minute. Storage capacity 8 GB CF card holds 100 images. 8 GB CF card holds 120 images. 8 GB CF card holds 120 images. ISO speed range ISO 50, 100, 200, 400 and 800. - Page 133 Storage capacity 4 GB CF card holds 75 images on average. 4 GB CF card holds 100 images on average. ISO speed range ISO 100, 200, 400, 800 and 1600. ISO 50, 100, 200, 400 and 800. Longest exposure time 256s Shooting mode Single shot. Color definition 16 bit. Color management Hasselblad Natural Color Solution. Image storage CF card type U-DMA (e.g. SanDisk extreme IV), or tethered to a Mac or PC Color display Yes – TFT 3 inch, 24 bit color, 230,400 pixels. Histogram /Acoustic feedback Yes. IR filter Mounted on CCD sensor. File format Lossless compressed Hasselblad 3FR/3F. Software Phocus (supplied) for Mac and PC.
-
Page 134: Default Set Tings
Default Settings ('Default' profile) Exp.mode A (Aperture priority) LM mode Centre weighted Exp. adjust Focus mode AF-S Drive mode Flash sync Normal (beginning of exp.) Flash adjust Self timer delay 10 sec Sequence Mirror up / Delay Mirror mode Mirror goes down Bracketing Frames Sequence... -
Page 135: Care, Sensor Unit
CCD – you will probably ruin the CCD if you do so. If dust manages to get between the IR filter and CCD, it can only be removed at the Hasselblad factory. Contact your Hasselblad dealer for assistance. - Page 136 Cleaning using the HAMA cleaning fluid and tissues Note! Hasselblad recommends HAMA Optic Cleaning Fluid 5902. 1. Carefully spray the fluid onto the IR filter at a distance of 10-15 cm (4-5 inches), so that the fluid is applied onto the filter as a thin, even haze. 1-2 sprays are enough. If you apply too little, the fluid will start to dry up before you start wiping the filter.
-
Page 137: Problems, Equipment Care And Ser Vice
Hasselblad Authorized Service Centers. They have the that the databus connections are not damaged or soiled in any way. Also... -
Page 138: Quick Index
Q U I C K I N D E X About Eyepiece adjustment Saving set tings Accessories Exposure compensation/Quick Adjust 46 Sensor unit (intro) Accessor y connec tion Exposure method Self timer AE-L but ton Set tings (Custom Options on grip) Appendix Shut ter and aper ture control Approval status... - Page 139 The images in this manual cannot be reprinted or reused without the express permission of the photographers who took them. All text in this manual : © Victor Hasselblad AB & Hasselblad A/S. All images in this manual not credited to the specific photogra- pher: ©...
- Page 140 Hasselblad A/S Hejrevej 30, DK - 2400 Copenhagen, Denmark Victor Hasselblad AB Box 220, SE - 401 23 Göteborg, Sweden 02.2011 - UK v8...
Need help?
Do you have a question about the H4D-60 and is the answer not in the manual?
Questions and answers
