HIS -UM19.5-***A User Manual

19.5" universal mount industrial monitor

Advertisement

Quick Links

19.5" UNIVERSAL MOUNT INDUSTRIAL MONITOR
REVISION A
USER MANUAL
Model No. HIS-UM19.5- _ _ _ A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HIS-UM19.5-***A and is the answer not in the manual?

Questions and answers

Summary of Contents for HIS HIS-UM19.5-***A

  • Page 1 19.5" UNIVERSAL MOUNT INDUSTRIAL MONITOR REVISION A USER MANUAL Model No. HIS-UM19.5- _ _ _ A...
  • Page 2: Table Of Contents

    Table of Contents Safety and Regulatory Information ���������������������������������������������������������������������������������������������� 3 FCC Notice ������������������������������������������������������������������������������������������������������������������������������������� 3 Hazardous Locations ���������������������������������������������������������������������������������������������������������������������� 4 Waste Electrical and Electronic Equipment Directive (WEEE) ������������������������������������������������������� 4 Mechanical Drawings �������������������������������������������������������������������������������������������������������������������� 5 Front View �������������������������������������������������������������������������������������������������������������������������������������� 5 Rear View ��������������������������������������������������������������������������������������������������������������������������������������� 5 Side View���������������������������������������������������������������������������������������������������������������������������������������� 6 Installation Instructions ����������������������������������������������������������������������������������������������������������������...
  • Page 3: Safety And Regulatory Information

    Any changes or modifications not expressly approved by the grantee of this device could void the user’s authority to operate the device�...
  • Page 4: Hazardous Locations

    The following applies only to monitors rated for hazardous locations (model numbers HIS-UM19.5- _ _ HA and HIS-UM19.5- _ _ UA): This equipment is suitable for use in Class I, Division 2, Groups A, B, C, and D; Class II, Division 2, Groups F and G;...
  • Page 5: Mechanical Drawings

    Mechanical Drawings Mechanical Drawings Front View 514.4 mm (20.25") 437.4 mm (17.22") 317.5 mm (12.50") 241.3 mm (9.50") Rear View 514.4 mm (20.25") 317.5 mm (12.50") 98.8 mm (3.89") 241.3 mm (9.50") CABLE ENTRY UM19.5A User Manual, 99159, March 2017...
  • Page 6: Side View

    Mechanical Drawings Side View 71.2 mm (2.80") 34.3 mm (1.35") 158.8 mm (6.25") KVM EXTENDER Side Mounting Holes (optional) 1/4"-20 Internal Thread x 0.625" Deep 123.7 mm (4.87") 174.0 mm (6.85") KEYBOARD (optional) UM19.5A User Manual, 99159, March 2017...
  • Page 7: Installation Instructions

    3� Ensure that the air temperature around the unit (top and bottom) will not exceed the rated specifications of the unit. f The maximum rated temperature for the HIS-UM19.5 is 50°C (122°F). f Remember that even though this product is designed to operate at 50°C, the life span of any electronic device is shortened when it is...
  • Page 8: Step 2: Bench-Test Configuration

    (if applicable) to your monitor� Video Connection The HIS-UM19.5 supports digital video through its DVI port, and analog video through its VGA port� After selecting the appropriate interface, connect one end of your video cable to the input port on the rear of the monitor and the other end to the appropriate port on your host computer or other video source�...
  • Page 9: Power Connection

    Installation Instructions Power Connection The HIS-UM19.5 is available with either AC or DC power input. AC power input models are powered by 100 to 240 VAC, 0�8/0�4 A, 60/50 Hz� Connect the AC power cable to the power input port on the rear of the monitor� Connect the other end into a nearby outlet�...
  • Page 10 Installation Instructions 3� A cable retention bracket comes installed on the USB port on the rear of the monitor and will help to secure the cable and ensure adequate strain relief. Without removing the bracket, route one end of the USB cable through the retention bracket and connect it to the USB input port on the monitor.
  • Page 11: Step 3: Install The Monitor

    Installation Instructions Step 3: Install the Monitor Once you have completed the full bench-test configuration and confirmed that all components are working properly, you are ready for final installation and mounting of the monitor. WARNING! Hope Industrial will not assume liability for damage to internal electronics due to improper installation�...
  • Page 12: Mount The Monitor

    Installation Instructions Mount the Monitor Hope Industrial Systems offers a variety of mounting options for your Universal Mount Monitor. Individual installation instructions are shipped with the following products and may also be found on our website at the addresses listed below� Heavy Industrial Yoke Mounts The standard yoke may be used alone, with our benchtop mounting kit for through-surface cable routing, or with our Pedestal Mount for free-standing...
  • Page 13 Installation Instructions Heavy Industrial Arm Mounts Our wall arm mounting options range from solid wall yoke to fully articulating arms. Complete installation instructions are shipped with the following products and may also be found on our website at the following addresses: Wall Mount Arms (for YA _ _ -15 and YA _ _ -24 Series): http://www�HopeIndustrial�com/Installations/99090�pdf Wall Yoke (for YW _ _ -07 Series):...
  • Page 14 Installation Instructions All Hope Industrial Universal Mount Monitors come standard with a 100 mm square VESA mounting pattern with M4 threads. Below is the VESA mounting diagram for Hope Industrial Universal Mount Monitors. Detailed installation instructions for specific VESA mounting options are shipped with the product and may also be found on our website at the following address: http://www�HopeIndustrial�com/Installations/99034�pdf IMPORTANT!
  • Page 15: Video Settings

    Video Settings Video Settings Setting the Timing Mode Setting the timing mode of your computer graphics adapter (or other video source) is important for maximizing the quality of the screen image and for minimizing eye strain. The timing mode consists of the resolution (e.g. 1920 x 1080) and refresh rate (or vertical frequency; e.g. 60 Hz). After setting the timing mode, use the On-Screen Display (OSD) controls to adjust the screen image.
  • Page 16: Control Panel Buttons

    Video Settings Control Panel Buttons Use the control panel buttons located on the back of the monitor to display and adjust various settings on the On-Screen Display (OSD) menu. CONTROL PANEL BUTTONS 1� To display the Main Menu, press button [1]� NOTE: All OSD menus and adjustment screens disappear automatically after 15 seconds.
  • Page 17: Osd And Power Lock Settings

    Video Settings Button Control Functions Power • Turns the monitor on and off� • The Power Indicator light glows blue during normal operation and orange when the monitor is in Power Saving mode. Menu • Opens the OSD menu� • Exits the OSD menu and saves adjustments.
  • Page 18: On-Screen Display (Osd) Menus

    Includes the Contrast and Brightness functions. Input Select Allows the user to toggle between inputs. Audio Adjust HIS-UM19.5 monitors do not include audio capabilities; these functions are inoperative for Hope Industrial monitors� Color Adjust Provides several color adjustment modes. Information Displays the timing mode (video signal input).
  • Page 19: Auto Image Adjust Menu

    Use D-Sub for analog VGA signals and DVI for digital signals. Audio Adjust Menu HIS-UM19.5 monitors do not include audio capabilities; these menu functions are inoperative for Hope Industrial monitors� UM19.5A User Manual, 99159, March 2017...
  • Page 20: Color Adjust Menu

    Video Settings Color Adjust Menu The Color Adjust menu provides several color adjustment modes, including preset color temperatures and a User Color mode which allows independent adjustment of red (R), green (G), and blue (B). The factory setting for this product is Native. Color Adjust Menu Description sRGB...
  • Page 21: Information Menu

    Video Settings Information Menu The Information menu displays the timing mode (video signal input) coming from the graphics card in the computer. See your graphics card's user guide for instructions on changing the resolution and refresh rate (vertical frequency)� NOTE: VESA 1920 x 1080 @ 60 Hz (recommended) means that the resolution is 1920 x 1080 and the refresh rate is 60 Hz�...
  • Page 22: Setup Menu

    Video Settings Manual Image Adjust Description ECO Mode Provides lower power consumption by reducing the brightness. • Standard is the default brightness setting. • Optimize reduces brightness by 25%. • Conserve reduces brightness by 50%. View Mode Allows the user to select from five image modes to find the optimal screen setting for different applications, as well as the default "Standard"...
  • Page 23: Memory Recall Menu

    Video Settings Setup Menu Description Language Select Allows the user to choose the language used in the menus and control screens� Resolution Notice Advises the optimal resolution to use� OSD Position Allows the user to move the OSD menus and control screens� OSD Time Out Sets the length of time the OSD screen is displayed.
  • Page 24: Cleaning Instructions

    Cleaning Instructions Cleaning Instructions CAUTION! DO NOT USE ABRASIVE MATERIALS, SUCH AS PAPER TOWELS OR DIRTY SHOP RAGS, ON THE DISPLAY AS IT WILL SCRATCH THE PROTECTIVE COATING. ALWAYS USE A SOFT CLOTH, PREFERABLY MADE OF COTTON. All displays may be cleaned using any standard glass cleaner as long as there is no abrasive or oily content.
  • Page 25: Troubleshooting

    Troubleshooting Troubleshooting Video Troubleshooting IMPORTANT! If using a KVM extender, first try to resolve any problems using the solutions listed below. If the problem still exists, try bypassing the KVM extender. If this fixes the problem and allows the monitor to work properly, then the KVM extender is the source of the problem�...
  • Page 26 Troubleshooting Symptom Causes Solutions "Out of Range" The source signal exceeds Adjust the computer settings to the message box the maximum resolution monitor's native resolution: and no image on and/or refresh rate that the 1920 x 1080 @ 60 Hz the screen monitor can handle ( >...
  • Page 27: Touch Screen Troubleshooting

    Troubleshooting Touch Screen Troubleshooting Applies to touch screen monitors only� To be sure that you have the most current driver, please check the following Internet address: http://www�HopeIndustrial�com/Touchscreen_Drivers�htm Symptom Causes Solutions No response Touch screen driver has not Download and install the latest driver from when touching been installed�...
  • Page 28: Specifications

    Specifications Specifications Display Type Thin-film transistor (TFT) Active Matrix Liquid Crystal Size 19.5" diagonal Image Size (W x H) 434�88 mm x 238�68 mm (17�1" x 9�4") Native Resolution Full HD 1080p (1920 x 1080, 16:9 aspect ratio) Minimum Resolution VGA (640 x 480) Pixel Pitch 0�2265 mm x 0�221 mm...
  • Page 29: Video

    Specifications Video Input Connectors • HD-15, DVI-D • Compatible inputs using optional adapter (call for details): • HDMI (via HDMI to DVI adapter) • DisplayPort (via DisplayPort to DVI adapter) • BNC (via HD-15 to 5-wire BNC adapter) Input Signal Formats •...
  • Page 30: Physical

    WEEE (Registration No. WEE/DJ1859ZX for UK only) Enclosure UL 50E (File No. E212889) For monitors with model numbers HIS-UM19.5- _ _ HA and Hazardous Location HIS-UM19.5- _ _ UA only: UL Rated for Hazardous Locations: I.T.E. Listed for Class I, Division 2 for Groups A, B, C, and D;...
  • Page 31: Warranty Statement

    Warranty Statement Warranty Statement Who is Covered? This warranty covers the purchaser of this product only and is not transferable without our written consent� What Does This Warranty Cover and What is the Period of Coverage? We warrant this product to be free from defects in material and workmanship, subject to the conditions set forth below�...
  • Page 32: Um19.5A User Manual, 99159, March

    Hope Industrial Systems, Inc. US / International 1325 Northmeadow Parkway Suite 100 Roswell, GA 30076 United States Toll Free: (877) 762-9790 International: +1 (678) 762-9790 Fax: +1 (678) 762-9789 Sales and Customer Service: sales@HopeIndustrial.com Support and Returns: support@HopeIndustrial.com Accounting Department: accounting@HopeIndustrial.com www.HopeIndustrial.com Harling Road...

This manual is also suitable for:

His-um22-***b
