Summary of Contents for HIS HIS-ML15
- Page 1 Hope Industrial Systems, Inc. User Manual 15” Industrial LCD Monitor Model No. HIS-ML15...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety and Regulation Information ......3 Factory Preset Timing ..........4 Panel Controls and OSD Functions ......5 Brightness/Contrast Controls ........6 OSD main menu ............7 Phase and Pitch Adjustments ........8 Horizontal and Vertical Centering ......9 Color and Language Functions ....... -
Page 3: Safety And Regulation Information
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Any changes or modifica- tions not expressly approved by the grantee of this device could void the user’s authority to operate... -
Page 4: Factory Preset Timing
Factory Preset Timing Horizontal Vertical Scan Freq. (KHz) Freq. (Hz) Type Resolution Pixel Frequency 640 x 350 31.469 ** N.I. 25.175 720 x 400 31.469 N.I. 28.322 640 x 400 24.83 N.I. 21.053 640 x 480 31.469 N.I. 25.175 640 x 480 35.000 66.67 N.I. -
Page 5: Panel Controls And Osd Functions
Panel Controls and OSD Functions Controls Description Power On/Off switch* Soft power on/off button. Adjacent LED is lit when on. OSD button Press to access On-Screen-Display Main Menu and save the setting (if any). Contrast/Adjust button To increase or decrease the panel back light lumin- ance. -
Page 6: Brightness/Contrast Controls
Brightness and Contrast Controls Instant Brightness Control • Press the “up” or “down” button to display the “ Brightness” icon. • Press the “up” or “down” button again to increase or decrease the video raster luminance. Instant Contrast Control • Press the “+ ” or “- ” button to display the “ Contrast” icon. •... -
Page 7: Osd Main Menu
OSD menu, select “Exit” from the menu, and then press the OSD button again, or press the OSD button twice while in any sub menu. • The OSD main menu includes the following functions: Exit, Phase, Pitch, H-Center, V-Center, Zoom, Color, Language, and Option. (The Zoom function is not available on the HIS ML-15.) -
Page 8: Phase And Pitch Adjustments
Phase and Pitch Adjustments Phase Adjustment • Note: Adjust the “Pitch” function first before adjusting the “Phase” function! • Select the “Phase” function from the OSD main menu. • Press the “+” and “-“ buttons to eliminate noise and jitter from the display. Pitch Adjustment •... -
Page 9: Horizontal And Vertical Centering
Horizontal and Vertical Centering H-Center Adjustment • Select the “H-Center” function from the OSD main menu. • Press the “+” or “-” buttons to move the display left or right. V-Center Adjustment • Select the “V-Center” function from the OSD main menu. •... -
Page 10: Color And Language Functions
Color and Language Functions Color Function • Select the “Color” function from the OSD main menu. • Press the “up” and “down“ buttons to select a desired color temperature for the display. • Selecting “User Mode” from the color menu will allow individual colors (R, G, B) to be set to create a desire color coordinate. -
Page 11: Option Function
Option Function Select the “Option” function from the OSD main menu. Press the “up” or “down“ buttons to select the desired function from the option menu, then press the OSD button again to activate the selected function. To manually close the option menu, select “Exit” from the menu, and then press the OSD button again. - Page 12 While the “Backlight” menu item is selected press the OSD button again to control the back light level of the LCD module. While the “Factory Preset” menu item is selected press the OSD button to recall factory de- fault parameters. After several seconds all user settings will be replaced by factory default values.
-
Page 13: Osd Information
OSD Information Auto Adjusting Press the “Auto” button to automatically adjust the monitor settings to accommodate the current video signal. The “Auto Adjusting” message will appear on the screen during the adjustment process. No Signal The “No Signal” message appears when the computer stops sending a video signal. -
Page 14: Installation Instructions
° ° The maximum rated temperature of the HIS-ML15 is 50 C (132 Remember that heat rises – the temperature at the top of the cabi- net will be much hotter than at the bottom when the air is not cir- culating. - Page 15 Tighten all 12 nuts to a torque of 24 inch-pounds to assure a water-tight seal between the poron bezel gasket on the monitor and equipment panel. HIS will not assume liability for damage to internal electronics due to improper installation.
-
Page 16: Cleaning
Cleaning Resistive Touchscreen model Any standard glass cleaner can be used to clean the touchscreen. Always spray the glass cleaner on the cloth or towel and then clean the touchscreen. Glass cleaner sprayed directly on the monitor could possibly leak inside a non-sealed unit and cause damage. Vinegar or ammonia will not hurt the touchscreen. -
Page 17: Troubleshooting
Troubleshooting Blank Screen After installing the power adapter and connecting I/O cable to a PC, the monitor displays a blank screen. • Press the power button and check to see if the power LED is lit. • If the LED turns green, make sure the PC is powered on. Make sure all cables are connected. -
Page 18: Drawings
Drawings Front and Side Views Rear View (showing Cutout Dimensions) - Page 19 Bottom View Rear View...
-
Page 20: Specifications
Specifications Display Type Thin-film transistor (TFT) Active Matrix Liquid Crystal Size 15.1” diagonal Image size 12.0” (304mm) x 9.0” (228mm) Native resolution XGA (1024 x 768) Plug and Play DDC1/2B compatible` Minimum resolution VGA (640 x 480) Pixel pitch 0.297mm x 0.297mm Number of colors 262,144 (18 bit) Viewing Angle (Hori/Vert) - Page 21 Electrical Power Adapter Input 88VAC – 264VAC, 50-60 Hz Power adapter output 12VDC @ 3 amps Monitor input 12VDC Power consumption Approximately 30 watts Power management DPMS/energy star, < 3W Compliance UL 1950, cUL 959; FCC Class A Environmental Temperature 0-50°C (consult factory for installation instructions when con- tinuous 24/7 operation exceeds 40°C) Humidity...
- Page 22 Enclosure Type Panel mount; rear collar compresses gasket against panel, held by 12 10-32 studs Panel rating NEMA 12/4/4X (with proper installation) – built to IP65 stan- dards Physical Depth 2.5” (64mm) behind panel maximum Bezel Acrylic – matte finish, black; or Stainless Steel Front bezel outside di- 17.2”...
-
Page 23: Warranty Statement
HIS or a service agency authorized by HIS to perform such repairs; fire, flood, “acts of God”, or other contingencies beyond the control of HIS. - Page 24 2001 Hope Industrial Systems, Inc. Publication UM-ML15-1.2 Nov 2001...
