Summary of Contents for HIS HIS-RL15-***H
- Page 1 15" RACK MOUNT INDUSTRIAL MONITOR REVISION H USER MANUAL Model No. HIS-RL15- _ _ _ H...
-
Page 2: Table Of Contents
Table of Contents Safety and Regulatory Information ��������������������������������������������������������������������������������3 FCC Notice ����������������������������������������������������������������������������������������������������������������������������� 3 Hazardous Locations �������������������������������������������������������������������������������������������������������������� 4 Waste Electrical and Electronic Equipment Directive (WEEE) ����������������������������������������������� 4 Mechanical Drawings ������������������������������������������������������������������������������������������������������5 Front View ������������������������������������������������������������������������������������������������������������������������������� 5 Bottom View ���������������������������������������������������������������������������������������������������������������������������� 5 Rear View ������������������������������������������������������������������������������������������������������������������������������� 6 Side View ��������������������������������������������������������������������������������������������������������������������������������... -
Page 3: Safety And Regulatory Information
Any changes or modifications not expressly approved by the grantee of this device could void the user’s authority to operate the device�... -
Page 4: Hazardous Locations
The following applies only to monitors rated for hazardous locations (model numbers HIS-RL15- _ _ HH and HIS-RL15- _ _ UH): This equipment is suitable for use in Class I, Division 2, Groups A, B, C, and D; Class II, Division 2, Groups F, G;... -
Page 5: Mechanical Drawings
Mechanical Drawings Mechanical Drawings Front View 482.6 mm (19.00") 37.5 mm (1.48") 6.4 mm (0.25") 231.6 mm (9.12") 265.4 mm (10.45") 228.0 mm (8.98") 307.6 mm (12.11") 458.8 mm (18.06") Bottom View 377.8 mm (14.87") 54.2 mm (2.14") 3.2 mm (0.125") RL15H User Manual, 99144, March 2017... -
Page 6: Rear View
Mechanical Drawings Rear View 377.8 mm (14.87") 265.4 mm (10.45") Side View 54.2 mm (2.14") 265.4 mm (10.45") RL15H User Manual, 99144, March 2017... -
Page 7: Installation Instructions
3� Ensure that the air temperature around the unit (top and bottom) will not exceed the rated specifications of the unit. f The maximum rated temperature for the HIS-RL15 is 60°C (140°F). f Remember that heat rises – the temperature at the top of the cabinet will be much hotter than at the bottom if air inside the enclosure is not actively circulating. -
Page 8: Step 2: Bench-Test Configuration
Installation Instructions Step 2: Bench-test Configuration Make sure everything works before installing into the production environment. TIP! If using a KVM extender, please refer to the installation instructions included with the KVM extender module. It is particularly important to bench-test the full configuration prior to final installation. -
Page 9: Video Connection
Installation Instructions Video Connection The HIS-RL15 supports digital video through its DVI port, and analog video through its VGA port. After selecting the appropriate interface, connect one end of your video cable to the input port on the rear of the monitor and the other end to the appropriate port on your host computer or other video source�... -
Page 10: Usb Connection
Installation Instructions IMPORTANT! If you will be using a USB connection, install the touch screen driver first, and then connect the USB cable. If you will be using a Serial connection, connect the Serial cable first, and then install the touch screen driver� USB Connection 1�... - Page 11 Installation Instructions 3� Click to "Run" the software when prompted� Follow on-screen instructions to download and execute the touch screen driver installation� Calibrate the Touch Screen Once the driver has finished installing, you are ready to calibrate the touch screen. Open the touch screen's Control Panel by clicking on the "Elo Touchscreen"...
-
Page 12: Step 3: Install Into Rack
WARNING! Hope Industrial Systems will not assume liability for damage to internal electronics due to improper installation� Contact Hope Industrial Systems if you need additional assistance� The HIS-RL15 has a panel height of 6U (shown below). 0" 37.5 mm (1.48") (10.45") -
Page 13: Video Settings
Video Settings Video Settings Setting the Timing Mode Setting the timing mode of your computer graphics adapter (or other video source) is important for maximizing the quality of the screen image and for minimizing eye strain. The timing mode consists of the resolution (e.g. 1024 x 768) and refresh rate (or vertical frequency; e.g. 60 Hz). After setting the timing mode, use the On-Screen Display (OSD) controls to adjust the screen image. -
Page 14: Control Panel Buttons
Video Settings Control Panel Buttons Use the control panel buttons located on the back of the monitor to display and adjust various settings on the On-Screen Display (OSD) menu. CONTROL PANEL BUTTONS 1� To open the OSD menu, press the Menu button. NOTE: All OSD menus and adjustments screens disappear automatically after 60 seconds. - Page 15 Video Settings Button Control Functions Menu • Opens the OSD menu� • Exits the submenu� • Exits the OSD menu� Select / When the OSD menu IS NOT displayed: Navigate Down • Shortcut to Auto setup function� When the OSD menu IS displayed: •...
-
Page 16: On-Screen Display (Osd) Menus
Video Settings On-Screen Display (OSD) Menus To open the OSD menu, press the Menu button once. Main Menu Description Picture Includes the Contrast, Brightness, Sharpness, and Color functions� VGA Settings Includes the Timing, Auto setup, H total, V position, H position, and Phase functions�... -
Page 17: Color Menu
Video Settings Picture Menu Description Brightness • Adjusts the background black level of the screen image. • This feature may also be accessed by pressing the minus [ – ] button outside of the OSD menu. Sharpness Adjusts the clarity of the screen to make the image sharper or softer�... - Page 18 Video Settings Color Menu Description Theme mode Allows the user to select from three image modes for different usage, as well as the default "Off" setting: • Multimedia optimizes the screen for multimedia applications, such as video playback� • Desktop optimizes the screen for desktop applications� •...
-
Page 19: Vga Settings Menu
Video Settings VGA Settings Menu The VGA Settings menu includes the Timing, Auto setup, H total, V position, H position, and Phase functions� VGA Settings Menu Description Timing Displays the timing mode (video signal input) coming from the graphics card in the computer. Auto setup •... -
Page 20: Setup Menu
Video Settings VGA Settings Menu Description Phase Adjusts the focus of the screen image. Allows the user to remove any horizontal noise and sharpen the image of characters� Setup Menu The Setup menu includes the Inputs, OSD, Info, Reset to factory defaults, Source scan, and Advanced Setup functions�... - Page 21 Video Settings Setup Menu Description The OSD submenu provides several adjustments for the OSD menu settings. • Time out sets the length of time (in seconds) the OSD screen is displayed. For example, with a "60" setting, if a control is not pushed within 60 seconds, the display screen disappears�...
- Page 22 Video Settings Setup Menu Description Source scan Allows the user to turn source scan "On" or "Off�" When Source scan is enabled and there is no active video signal present, the display will cycle through video connections until a video source is detected�...
-
Page 23: Cleaning Instructions
Cleaning Instructions Cleaning Instructions CAUTION! DO NOT USE ABRASIVE MATERIALS, SUCH AS PAPER TOWELS OR DIRTY SHOP RAGS, ON THE DISPLAY AS IT WILL SCRATCH THE PROTECTIVE COATING. ALWAYS USE A SOFT CLOTH, PREFERABLY MADE OF COTTON. IMPORTANT! Always spray the cleaner on the cloth or towel first and then clean the monitor screen. -
Page 24: Troubleshooting
Troubleshooting Troubleshooting Video Troubleshooting IMPORTANT! If using a KVM extender, first try to resolve any problems using the solutions listed below. If the problem still exists, try bypassing the KVM extender. If this fixes the problem and allows the monitor to work properly, then the KVM extender is the source of the problem�... - Page 25 Troubleshooting Symptom Causes Solutions "Scanning Ports / No Video cable is not plugged Check the video cable connection at Signal" message box in correctly� the monitor, PC, and/or KVM extender. and no image on the PC is not powered on� Ensure PC is powered on�...
-
Page 26: Touch Screen Troubleshooting
Troubleshooting Touch Screen Troubleshooting Applies to touch screen monitors only� To be sure that you have the most current driver, please check the following Internet address: http://www�HopeIndustrial�com/Touchscreen_Drivers�htm Symptom Causes Solutions No response when Touch screen driver has Download and install the latest driver touching the touch not been installed�... -
Page 27: Specifications
Specifications Specifications Display Type Thin-film transistor (TFT) Active Matrix Liquid Crystal Size 15" diagonal Image Size (W x H) 304 mm x 228 mm (12�0" x 9�0") Native Resolution XGA (1024 x 768, 4:3 aspect ratio) Minimum Resolution VGA (640 x 400) Pixel Pitch 0�297 mm x 0�297 mm Number of Colors... -
Page 28: Video
Specifications Video Input Connectors • HD-15, DVI-D • Compatible inputs using optional adapter (contact Hope Industrial Systems for details): • HDMI (via HDMI to DVI adapter) • DisplayPort (via DisplayPort to DVI adapter) • BNC (via HD-15 to 5-wire BNC adapter) Input Signal Formats •... -
Page 29: Rack Compatibility
• WEEE (Registration No. WEE/DJ1859ZX for UK only) Enclosure UL 50E (File No. E318630) For monitors with model numbers HIS-RL15- _ _ HH and Hazardous Location HIS-RL15- _ _ UH only: UL Rated for Hazardous Locations: Industrial Control Equipment for Hazardous Location: Listed for Class I, Division 2 for Groups A, B, C, and D;... -
Page 30: Warranty Statement
Warranty Statement Warranty Statement Who is Covered? This warranty covers the purchaser of this product only and is not transferable without our written consent� What Does This Warranty Cover and What is the Period of Coverage? We warrant this product to be free from defects in material and workmanship, subject to the conditions set forth below. - Page 31 (This page intentionally left blank.) RL15H User Manual, 99144, March 2017...
- Page 32 Hope Industrial Systems, Inc. US / International 1325 Northmeadow Parkway Suite 100 Roswell, GA 30076 United States Toll Free: (877) 762-9790 International: +1 (678) 762-9790 Fax: +1 (678) 762-9789 Sales and Customer Service: sales@HopeIndustrial.com Support and Returns: support@HopeIndustrial.com Accounting Department: accounting@HopeIndustrial.com www.HopeIndustrial.com United Kingdom...
