JKL-T JKL-T10W For household use JKL-T15W Clay Ceramic IH Microcomputer controlled Rice Cooker/Warmer USER MANUAL Before using the Rice Cooker, read all these instructions through to the end. After reading these instructions, keep them in a handy location for future reference.
IMPORTANT SAFEGUARDS When using electrical appliances, basic safety precautions should always be followed including the following: 1. Read all instructions. 2. Do not touch hot surfaces. Use handles or knobs. 3. To protect against electrical shock, do not immerse cord or plugs in water or other liquid. 4.
English Contents Inner Pan (Clay Ceramic) …………………………………………… 5 Easy Cooking Guide - All you need to know to start cooking - …… 5 Tips for cooking delicious rice ……………………………………… 6 1 Safety Instructions ………………………………………………… 7 2 Names and Functions of Component Parts …………………… 11 3 Using the Audio Guide / Adjusting the Volume / Switching Languages ………………………………………………...
Easy Cooking Guide Tips for cooking Inner Pan (Clay Ceramic) delicious rice - All you need to know to The Warmth of an start cooking - ● Carefully measure rice with the Clay Ceramic Pan supplied cup. →P.15 This Clay Ceramic pan is produced one Rinse the rice by one as Yokkaichi pottery to provide the Add the correct amount of...
Safety Instructions Read all warnings and instructions before using the rice cooker. * The precautions described below are intended to protect the user and other individuals from Warning physical harm and to safeguard against damage to property. Be sure to follow the instructions since they are important safeguards. * Do not remove the safety instructions seal attached to the unit.
Page 6
Safety Instructions This appliance is intended to be used in Do not wash the entire rice cooker. CAUTION household and similar applications such Do not wash the entire rice cooker or pour water into the cooker or its bottom. Doing so may result in short circuiting or electrical •...
Names and Functions of Component Parts Steam cap (See P.44) Inner lid release button < Operation Panel *Press buttons firmly. Sound signals are provided for each press. > Steam vent Display unit Steam vent lid sensor Cooking Menu Hour/Min When you insert the plug into the AC outlet, the liquid crystal display will turn on.
Using the Audio Guide / Adjusting the Volume/ Switching Languages The audio guide and screen display can be Press Press , and select Voice Press switched between Chinese and English. Audio Guide Recognition: Yes or No. The setting is completed, and the regular display returns.
Rinsing the Rice, Adding the Correct Amount of Water, and Placing the Inner Pan in the Main Unit Amounts of rice that can be cooked Guidelines for fine adjustment of water Measure rice and put it into the Rinsing the rice at one time inner pan.
Selecting a Menu and Cooking Rice Rinsing the Rice, Adding the Correct Amount of Water, and Placing the Inner Pan in the Main Unit About switching menus Wipe the water from the outside Attach the power plug to the rice Press , and select [White and edge of the inner pan...
Page 11
Selecting a Menu and Cooking Rice Approximate Cooking Times Press Press and select the heat Size level Menu [White Rice/Plain display] 1.0L (5.5-cup) Rice Cooker 1.44L (8-cup) Rice Cooker Plain 43 - 64 minutes 46 - 64 minutes (for White Rice/Plain, White Rice/Rinse-free, Other Grains/Mixed Rice, Other Grains/Bean Rice, and Long-grain 35 - 45 minutes...
When the Rice is Cooked / When Finished Using Selecting a Menu and Cooking Rice the Rice Cooker / Keeping the Rice Warm Menu option functions and their features ■When selecting Keep Warm Yes When the rice cooker enters the Heat Keep Steaming stage, the time before...
Page 13
When the Rice is Cooked / When Finished Using the Rice Cooker / Keeping the Rice Warm Rice Crust Stir and loosen the cooked rice. When warming is required after After Using Cooker/Warmer. When the rice is cooked, there will be a rice crust; cooking without the warming Mound the rice slightly inside the inner pan so that no when loosening the rice, the crust may be mixed in.
Enjoy Cooked Rice at Your Desired Time ( Timer Cooking ) ■When setting the timer for Other Grains ■When setting the timer for Oatmeal Check the current time. Cooking Menu Cooking Menu Press and select Other Grains. Press and select Multi-cook. Press the key to select Press...
Page 15
Cooking Rice After Soaking it in Water ( Soak Timer ) Enjoy Cooked Rice at Your Desired Time ( Timer Cooking ) When setting the soak timer for Other Grains If you set the timer to start cooking after a certain time Caution ■...
Cooking Rice After Soaking it in Water ( Soak Timer ) ■ When setting the soak timer for Oatmeal Press , and set the amount Press (Timer setting Press , and select Soak Cooking Menu Press and select Multi-cook. Press Menu and select Oatmeal of time to soak the rice in water.
Cooking Porridge ([Porridge] Menu) Caution About switching menus When the porridge is cooked, an Press , and select Porridge alarm will sound. Do not press Cancel if extended heating is required. Each time you press Each time you press the button, the menu item will Before extending heating time, stir the contents well.
Cooking Stewed Dishes (Soup, Stew Menu) Soup Menu Suggested ingredient amounts After being brought to a boil, the soup is simmered at When the soup or stew is cooked, Press and select Soup or about 98ºC. Place the ingredients in the inner pan up to the an alert will sound and warming will Stew.
Cooking Steamed Dishes (Steam Menu) Cooking Stewed Dishes (Soup, Stew Menu) For details on cooking soups and stews, see the Keep Warm for Soup and Stew After Using Cooker/Warmer. Attach the power plug to the rice separate COOK BOOK. cooker, and then plug the power When cooking is finished, the rice cooker Press the key.
Page 20
Cooking Steamed Dishes (Steam Menu) ■When extending the steaming time Caution While the Keep Warm lamp is lit up, press Hour and Press and set the steam- Press (Begin steaming) Min , set the extended time, and press Start . The steam basket will be very hot when you remove it, (You can extend the steaming period 3 times, for a ing time.
Cooking Oatmeal (Oatmeal Menu) Caution Set oatmeal and water into the When cooking is completed, an alert Press , and select Multi- inner pan and close the lid will sound and the Keep Warm lamp If the food is still not cooked, do not press the cook.
Setting the Display Clock Cleaning and Maintenance Time is displayed in 24-hour format. Any other servicing should be performed by an authorized service representative. * Time adjustments cannot be made while cooking ● Clean the rice cooker the same day it is used to maintain cleanliness. Thoroughly clean the rice cooker regularly. ☆...
Page 23
Cleaning and Maintenance Caution Parts to wash when dirty Detaching and installing the inner lid How to detach and attach the steam cap. Do not pull on the lid gasket or the inner lid gasket. Main unit Detach the inner lid Detach the inner lid If they come off, they cannot be put back on.
Page 24
Cleaning and Maintenance Installing the steam cap When cleaning is finished… If you are concerned about odors, clean Press Start . immediately after use. Attach the cap lid as shown in the illustration. Fill the inner pan with water up to the [8] Cap lid ①...
If Rice Is Not Cooked Properly If Food Is Not Cooked Properly If something seems to be wrong with cooked or warmed rice, check the following points. Check for the following if there is a problem with the cooked food. Check point Check point Symptom...
Troubleshooting Check the following before requesting repair service. If the problem persists, contact the store where the rice cooker was purchased. Check point Action Check point Action Symptom Symptom page page There's no Is the Keep Warm lamp on? Press Cancel to cancel Keep The cooking time...
Troubleshooting Check point Action Check point Action Symptom Symptom page page The Keep warm There is a noise When Keep Warm No and Oatmeal are selected, the Keep The fan makes a humming noise when it is operating; this 22・40 lamp blinks.
In case of power failure Purchasing consumables and optional accessories Consult the store where you purchased the rice cooker in the following situations. If there is a power failure in If power is supplied again this situation If there are cracks or fissures in any part of the inner pan, or when the heating element is damaged. During timer cooking (timer The timer will begin operating again automatically.
