  • Page 1: User Manual

    TECHLOGIN (For Technicians Only) Wireless FTTH Gateway Model #: V1000H User Manual Ver 1.0 Solutions for the Digital Life ™...

  • Page 2: Table Of Contents

    Table of Contents 1 Introduction Features Getting to Know the Gateway 2 Using the Home Screen Accessing the Home Screen Icon Bar General Information 3 Configuring Wireless Settings Accessing Wireless Settings Basic Settings Advanced Settings Wireless MAC Authentication 4 Configuring Firewall Settings Accessing Firewall Settings Firewall Port Forwarding...
  • Page 3 Table of Contents Admin Password Port Bridging Traffic Mirroring Configuring Download and Upload HPNA Diagnostics Rebooting the Gateway Restoring Factory Default Settings Upgrade Firmware Time Zone IGMP Setting IGMP Proxy Upgrade Log System Log Ping Test Traceroute 6 Viewing the Gateway’s Status Accessing Status Tables Connection Status WAN DSL Status...

  • Page 4: Introduction

    Introduction Thank you for choosing the Actiontec V1000H Gateway. With its powerful wire- less N radio, gigabit Ethernet switch, and WAN port, as well as its dual-core processor and support for HPNA, the Gateway will propel you to new speeds as you traverse the Internet.
  • Page 5 Actiontec V1000H Gateway • QoS support, including diffserv and random early detection • PPPoE support • External Radius support • Web-based configuration support • FTP firmware upgradeable • Web download support • 802.11b/g/n support • WPS support • Advanced firewall • ALG...

  • Page 6: Getting To Know The Gateway

    Chapter 1 Introduction Getting to Know the Gateway This section contains a quick description of the Gateway’s lights, ports, etc. The Gateway has several indicator lights ( s) and a button on its front panel, and a series of ports and switches on its rear panel. Front Panel The front panel of the Gateway features 11 LEDs: Power, DSL, WAN Ethernet, Internet, Ethernet (4), HPNA, USB, Wireless, and WPS Push Button.
  • Page 7 Actiontec V1000H Gateway Power The Power LED displays the Gateway’s current status. If the Power LED glows steadily green, the Gateway is receiving power and fully operational. When the Power LED is rapidly flashing, the Gateway is initializing. If the Power LED is glows red when the Power cord is plugged in, the Gateway has suffered a critical error and technical support should be contacted.
  • Page 8 Chapter 1 Introduction The USB LED illuminates when a USB device is connected via the Gateway’s USB port. This port is not currently operational, but may be enabled in a future firmware update. Wireless The Wireless LED illuminates when the Gateway is connected wirelessly, assum- ing the Gateway’s Wireless feature is turned on.

  • Page 9: Rear Panel

    Actiontec V1000H Gateway Rear Panel The rear panel of the Gateway features 9 ports (Line, HPNA, LAN Ethernet (4), WAN Ethernet, USB, and Power), as well as a Reset button. Line Port Coaxial Cable Ethernet Cable Ethernet Cable USB Cable Power Adapter The Line Port is used to connect the Gateway to a DSL line connection.
  • Page 10 Chapter 1 Introduction USB Port The USB 1 port is used to connect the Gateway to a USB device. This port is not currently operational, but may be enabled in a future firmware update. Reset Button Depressing the Reset button for 2 seconds will restore the Gateway’s factory default settings.

  • Page 11: Using The Home Screen

    Using the Home Screen This chapter gives a short overview of the Home screen of the Gateway’s firmware, including explanations of the Home screen’s sections and links. Accessing the Home Screen To access the Home screen: Open a Web browser. In the “Address” text box, type: http://172.16.1.254/TECHLOGIN then press Enter on the keyboard.

  • Page 12: Icon Bar

    Chapter 2 Home Screen 3. The Gateway’s Home screen appears. You can now access all of the Home screen’s options Icon Bar At the top of the Home screen is the Icon Bar. Here, you can quickly access the other four main sections of the Gateway’s firmware by clicking on the appropriate icon: Status (see chapter 6 for more details);...

  • Page 13: General Information

    Actiontec V1000H Gateway General Information The next section of the Home screen is the General Information section. This section is divided into three subsections: Summary, Home Network, and Tools. Summary The Summary subsection contains four status lines. Broadband displays the status of the Gateway’s broadband connection (connected or disconnected).

  • Page 14: Configuring Wireless Settings

    Configuring Wireless Settings This chapter explains the options provided in the Wireless section of the Gateway’s firmware, including setting up wireless security and WPS. Accessing Wireless Settings To access the Wireless screens: Open a Web browser. In the “Address” text box, type: http://172.16.1.254/TECHLOGIN then press Enter on the keyboard.
  • Page 15 Actiontec V1000H Gateway The Gateway’s Home screen appears. Enter your password, then click the Wireless Setup icon from the row of icons at the top of the screen. The Wireless Settings screen appears, with various options listed in the menu...

  • Page 16: Basic Settings

    Chapter 3 Wireless Settings Basic Settings Click Basic Settings from any Wireless screen to generate the Basic Settings screen. If the wireless radio of the Gateway has not been enabled, the following screen appears. Click in the radio button next to Enable to turn on the Gateway’s wireless radio. The full Basic Settings screen appears, displaying a series of settings relating to the core functionality of the Gateway’s wireless capabilities.
  • Page 17 Actiontec V1000H Gateway Select SSID Select an ISP-configured SSID (wireless network name) from the drop-down list. SSID State Enable or disable this option, which activates the Gateway’s ability to use multiple SSIDs, by clicking in the appropriate radio button. SSID Broadcast...
  • Page 18 Chapter 3 Wireless Settings Security There are four choices available in this drop-down list: WPA/WPA2 This form of wireless security is the default setting on the Gateway. When select- ed, you can select the WPA Type (WPA or WPA2-Personal, WPA Personal, or WPA2-Personal), Encryption Type (AES, TKP, or Both), and whether to use the Gateway’s automatically generated default key/passphrase, or create one of your own. Click Apply to save your changes.

  • Page 19: Advanced Settings

    Actiontec V1000H Gateway Selecting Off from the Security drop-down list leaves the Gateway’s wireless net- work completely open, allowing anyone to join the network. Advanced Settings Click Advanced Settings from any Wireless screen to generate the Advanced Settings screen. These settings should only be adjusted by experienced technical users who are extremely familiar with wireless networking concepts.
  • Page 20 Chapter 3 Wireless Settings Maximum Spatial Streams Spatial streams boost the efficiency of the wireless network, resulting in higher speeds across the network. However, the more spatial streams you use, the less stable the wireless network connections. This option can only be set to Auto. Channel Width Choices include 20 MHz and 40 MHz.

  • Page 21: Wps

    Actiontec V1000H Gateway Click WPS in any Wireless screen to generate the WPS (Wi-Fi Protected Setup) screen. WPS provides a simple method of setting up a wireless network by auto- matically sharing the network key between the Gateway and other wireless devices. To set up WPS: Enable WPS by clicking in the Enable radio button.

  • Page 22: Wireless Mac Authentication

    Chapter 3 Wireless Settings If connecting a device to the wireless network with PBC (Push Button Configuration), click Connect, then press the PBC-compatible button on the device within two minutes. If the connecting device uses the End Device PIN method, enter the PIN in the appropriate text box, then enter in the device’s End Device PIN configuration. Wireless MAC Authentication Click MAC address control in any Wireless screen to generate the Wireless MAC Authentication screen. MAC addresses are alphanumeric designations provided to every networkable device that act as unique identifiers. Using MAC addresses, you...
  • Page 23 Actiontec V1000H Gateway To set up wireless MAC authentication: Select the SSID from the SSID drop-down menu. Turn on the MAC authentication by clicking in the Enable radio button next to MAC Authentication. To allow or delete certain devices from the Gateway’s wireless network, click in the appropriate radio button (Allow device list or Deny device list). Once you choose Allow/Deny, the state of the device list is frozen;...

  • Page 24: Configuring Firewall Settings

    Configuring Firewall Settings This chapter will explain the options provided in the Firewall section of the Gateway’s firmware, including various firewall options, port forwarding, and DMZ hosting. Accessing Firewall Settings To access the Firewall screens: Open a Web browser. In the Address text box, type: http://172.16.1.254/TECHLOGIN then press Enter on the keyboard. A Login screen appears. Enter your password in the Password text box, then click Apply.
  • Page 25 Actiontec V1000H Gateway Firewall The Gateway’s Home screen appears. Enter your password, then click from the row of icons at the top of the screen. The Firewall screen appears, with various firewall options listed in the menu on the left side of the screen.

  • Page 26: Firewall

    Chapter 4 Firewall Firewall Click Firewall from any Firewall screen to generate the Firewall screen. This screen allows you to configure the firewall settings of the Gateway. If you make changes in this screen, click Apply at the bottom of the screen to save them. WAN Ping Block Mode Click in the Enable radio button next to WAN PING block mode to activate the WAN Ping Block Mode. This will block all pings originating from the WAN (i.e., the Internet) side of the network. Clicking Disable turns off the block mode.

  • Page 27: Port Forwarding

    Actiontec V1000H Gateway Firewall Security Level Select the level of firewall security level here, by clicking in the appropriate radio but- ton. NAT Only provides no firewall security, while Low, Medium, and High provide different levels of security, as displayed in the Firewall table in the lower part of the screen. Additionally, after choosing a level of firewall security, you can manually allow (by clicking in a check box to generate a check mark) or deny (by clicking in a check box to delete a check mark) selected Internet services listed in the Firewall table.

  • Page 28: Applications

    Chapter 4 Firewall To set up port forwarding: Select the device from the Select Device drop-down list, or enter the device’s IP address in the text box next to Enter IP address. Enter the LAN starting port in the Starting Port text box. Enter the LAN ending port in the Ending Port text box.
  • Page 29 Actiontec V1000H Gateway To set up a forwarded application: Select a networked device by selecting it from Select Device drop-down list, or enter its IP address in the Enter IP Address text box. Select the application’s category from the Application Category drop- down list, or select All to see all the applications provided.

  • Page 30: Dmz Hosting

    Chapter 4 Firewall DMZ Hosting Click DMZ Hosting from any Firewall screen to generate the DMZ Hosting screen. The DMZ (De-Militarized Zone) host feature allows one device on the network to operate outside the firewall to use an Internet service that otherwise would be blocked, or to expose a networked device to all services without restriction or security. Caution! A DMZ host is not protected by the firewall and may be vulnerable to attack.

  • Page 31: Upnp

    Actiontec V1000H Gateway UPnP Click UPnP from any Firewall screen to generate the UPnP screen. UPnP (Universal Plug and Play) allows all supported devices on the Gateway’s network to discover and interface with each other without additional configuration. To enable UPnP on the Gateway’s network, click in the Enable radio button, then click Apply.

  • Page 32: Sip Alg

    Chapter 4 Firewall SIP ALG Click SIP ALG from any Firewall screen to generate the SIP ALG screen. To activate SIP ALG on the Gateway, click in the Enable radio, then click Apply.

  • Page 33: Using Advanced Configuration

    Using Advanced Configuration This chapter will explain the options provided in the Advanced Configuration sec- tion of the Gateway’s firmware, including services blocking, restoring the Gateway to factory default settings, and performing a ping test. Accessing Advanced Configuration To access the Advanced Configuration screens: Open a Web browser. In the Address text box, type: http://172.16.1.254/TECHLOGIN then press Enter on the keyboard. A Login screen appears.
  • Page 34 Chapter 5 Advanced Configuration The Gateway’s Home screen appears. Enter your password, then click Advanced Configuration from the row of icons at the top of the screen. An Advanced Configuration screen appears, with various options listed in the menu on the left side of the screen.

  • Page 35: Services Blocking

    Actiontec V1000H Gateway Services Blocking Services Blocking is used to prevent a device on the Gateway’s network from access- ing particular services available on the Internet, such as receiving e-mail or down- loading files from FTP sites. To set up services blocking on a networked device: Services Blocking from the menu on the left side of any Advanced Click Configuration screen. The Services Blocking screen appears.

  • Page 36: Website Blocking

    Chapter 5 Advanced Configuration Website Blocking Web site blocking is used to prevent all devices on the Gateway’s network from accessing particular web sites on the Internet. To set up web site blocking on the Gateway’s network: Website Blocking from the menu on the left side of any Advanced Click Configuration screen. The Website Blocking screen appears.

  • Page 37: Scheduling Access

    Actiontec V1000H Gateway Scheduling Access Scheduling access is used to allow a device on the Gateway’s network to access the Internet at certain times of the day, or certain days of the week, only. During times not configured in the Scheduling Access screen, the device will not be able to access the Internet.

  • Page 38: Broadband Settings

    Chapter 5 Advanced Configuration Add to create a schedule access. Click Repeat steps 1-5 to create multiple access schedules for other devices on the Gateway’s network. The devices that are configured with an access schedule are listed at the bottom of the screen.

  • Page 39: Wan Ip Addressing

    Actiontec V1000H Gateway WAN IP Addressing The WAN IP Address screen allows you to manually set up the WAN IP address of the Gateway. To do this: Click WAN IP Address from the menu on the left side of any Advanced Configuration screen. The WAN IP Address screen appears.
  • Page 40 Chapter 5 Advanced Configuration Select the IP type. If Single Static IP Address was selected, enter the IP address in the “Single Static IP” text box. If “Block of Static IP Addresses (Unnumbered Mode)” was selected, enter the designated gateway IP address and subnet mask address in the “Modem Address”...

  • Page 41: Lan Ip And Dhcp Settings

    Actiontec V1000H Gateway LAN IP and DHCP Settings The LAN IP and DHCP Settings screen allows you to change the Gateway’s default LAN IP address, and adjust the DHCP settings. To change the LAN IP: Click LAN IP Settings from the menu on the left side of any Advanced Configuration screen. The LAN IP and DHCP Settings screen appears. Enter the new modem IP address and modem subnet mask in the appropriate text boxes.

  • Page 42: Dhcp Reservation

    Chapter 5 Advanced Configuration Enter the DHCP server’s lease time period by entering the days, hours, and minutes in the appropriate text boxes. Set the DNS values by selecting Dynamic or Static (clicking in the appropriate radio button), then, if needed enter the IP addresses for DNS server 1 and 2. Apply to save your changes. Click DHCP Reservation DHCP reservation allows devices on the Gateway’s network to be permanently...

  • Page 43: Dynamic Dns

    Actiontec V1000H Gateway Apply to save your changes. Click Repeat steps 1-4 to reserve IP addresses for other devices on the Gateway’s network. The devices with DHCP reserved IP addresses are listed at the bottom of the screen. To remove a schedule, click the Remove button next to the device in the DHCP Reservation List at the bottom of the screen.
  • Page 44 Chapter 5 Advanced Configuration To configure Dynamic DNS: Dynamic DNS from the menu on the left side of any Advanced Click Configuration screen. The Dynamic DNS screen appears. Select the Gateway’s Dynamic DNS account provider from the drop-down list. Enter the Dynamic DNS username and password in the appropriate text boxes. 4.

  • Page 45: Hpna Settings

    Actiontec V1000H Gateway HPNA Settings Click HPNA Settings from any Advanced Configuration screen to generate the HPNA Settings screen. This screen allows you to enable HPNA. Click in the Enable radio button to activate. Remote GUI The Remote GUI screen allows you to setup the Gateway so that it can be accessed from a remote location. To use: Click Remote GUI from the menu on the left side of any Advanced...
  • Page 46 Chapter 5 Advanced Configuration Click in the Enable radio button next to Remote GUI to activate. Enter a user name and password in the appropriate text boxes beneath step 2. Set the remote management port. It is set to port 443 by default. If the remote management port number has been changed, you will need to use the URL “https://”...

  • Page 47: Static Routing

    Actiontec V1000H Gateway Static Routing The Static Routing screen allows you to set up static routes on the Gateway. To use: Static Routing from the menu on the left side of any Advanced Click Configuration screen. The Static Routing screen appears. Enter the destination IP address of the static route in the Destination IP text box.

  • Page 48: Dns Host Mapping

    Chapter 5 Advanced Configuration DNS Host Mapping The DNS Host Mapping screen allows you create static host names for specified IP addresses on the Gateway. To use: Click DNS Host Mapping from the menu on the left side of any Advanced Configuration screen. The DNS Host Mapping screen appears.

  • Page 49: Admin Password

    Actiontec V1000H Gateway Admin Password To change the password that allow access to the Gateway’s firmware screens: Admin Password from the menu on the left side of any Advanced Click Configuration screen. The Admin Password screen appears. ter a new password in the Admin Password text box.

  • Page 50: Port Bridging

    Chapter 5 Advanced Configuration Port Bridging The Port Bridging screen allows you to set up the Gateway’s Ethernet port 1 as a bridge. This will only work for customers who have subscribed to Static IP, with the static IP assigned to a host on Ethernet Port 1. Apply port bridging only when specifically instructed to do so by SaskTel.

  • Page 51: Traffic Mirroring

    Actiontec V1000H Gateway Traffic Mirroring The Traffic Mirroring (Tool Box) screen allows you to mirror select types of traffic to certain ports on the Gateway. This is used for packet capturing purposes. Do not enable traffic mirroring unless you are an experienced network technician. To use:...

  • Page 52: Configuring Download And Upload

    Chapter 5 Advanced Configuration Configuring Download and Upload Selecting Config Download/Upload from any Advanced Configuration screen generates the Configuration Download and Upload screen. Here, you can save the Gateway’s current firmware configuration for archiving or later use. To do this, click Download, then select a location to save the file. To upload and install a previously saved configuration, enter its location in the text box at the bottom of the screen, or click Browse to locate it.

  • Page 53: Hpna Diagnostics

    Actiontec V1000H Gateway HPNA Diagnostics Selecting HPNA Diagnostics from any Advanced Configuration screen generates the HPNA Diagnostics screen, which is used to check the HPNA connection of the Gateway. Click the appropriate Test button to perform a test.

  • Page 54: Rebooting The Gateway

    Chapter 5 Advanced Configuration Rebooting the Gateway To reboot the Gateway: Reboot from the menu on the left side of any Advanced Configuration Click screen. The Reboot Modem screen appears. Reboot to reboot the Gateway. This may take up to one minute. Click To reenter the Gateway’s firmware after restarting the Gateway, click the web browser’s Refresh button.

  • Page 55: Restoring Factory Default Settings

    Actiontec V1000H Gateway Restoring Factory Default Settings If the Gateway’s factory default settings need to be restored (to build a new net- work from the beginning, for example), use the following procedure: Click Restore Defaults in any Advanced Configuration screen. The Restore Defaults screen appears. Restore If you want to restore only the Gateway’s default wireless settings, click across from Restore Default Wireless Settings.

  • Page 56: Upgrade Firmware

    Upgrade Firmware Selecting Upgrade Firmware from any Advanced Configuration screen generates the Upgrade Firmware screen, which is used to upgrade the Gateway’s firmware. Actiontec periodically updates the Gateways’s firmware to enhance performance, add new capabilities, and eradicated software bugs. To upgrade the Gateway’s firmware: Go to the SaskTel support web site and go to the firmware upgrade section.

  • Page 57: Time Zone

    Actiontec V1000H Gateway Time Zone To set the correct time zone on the Gateway: Time Zone from the left side of any Advanced Configuration screen. Click The Time Zone screen appears. Click in the appropriate radio button for your time zone. If da ylight saving is currently in effect, click in the Day Light Saving check box to activate Apply to save your settings.

  • Page 58: Igmp Setting

    Chapter 5 Advanced Configuration IGMP Setting The IGMP (Internet Group Management Protocol) Settings allows you to con- figure various IGMP settings to establish multicast group memberships on IP networks. Only experienced network technicians should change IGMP settings. Also, note that changing any of the IGMP settings could cause the performance of SaskTel MAX to degrade.

  • Page 59: Igmp Proxy

    Actiontec V1000H Gateway The Query Response Interval is the maximum amount of time the Gateway waits to receive a response to a general query message. The entered time period (in seconds) must be greater than or equal to 1. Enter the last member query interval in the appropriate text box. Enter the robustness value in the appropriate text box.

  • Page 60: Upgrade Log

    Chapter 5 Advanced Configuration Upgrade Log Selecting Upgrade Log from any Advanced Configuration screen generates the Upgrade Log screen, which lists the complete history of firmware upgrades per- formed on this device. System Log Click System Log in the Advanced Configuration screen to generate the System Log screen. The System Log displays a list of the most recent activities of the Gateway.

  • Page 61: Ping Test

    Actiontec V1000H Gateway Ping Test Selecting Ping Test from any Advanced Configuration screen generates the Ping Test screen, which is used to check whether the Gateway is properly connected to the Internet. Follow the on-screen instructions to perform the test. The results will be displayed at the bottom of the screen.

  • Page 62: Traceroute

    Chapter 5 Advanced Configuration Traceroute Selecting Traceroute from any Advanced Configuration screen generates the Traceroute screen, which is used to determine the route taken by packets across a network. Follow the on-screen instructions to perform the test. The results will be displayed at the bottom of the screen.

  • Page 63: Viewing The Gateway's Status

    Viewing the Gateway’s Status This chapter gives an overview of the various Status tables provided by the Gateway, which allow you check on various parameters, including xDSL connec- tions, WAN Ethernet connection, and wireless status. Accessing Status Tables To access the Status screens: Open a web browser.
  • Page 64 Chapter 6 Status Status The Gateway’s Home screen appears. Enter your password, then click from the row of icons at the top of the screen. The Status screen appears, with various options for checking the Gateway’s status listed in the menu on the left side of the screen.

  • Page 65: Connection Status

    Actiontec V1000H Gateway Connection Status Click Connection Status from any Status screen to generate the Connection Status screen. This table displays various parameters regarding the Internet con- nection of the Gateway, including broadband and ISP connection status, upstream rate, lease time remaining, and DNS addresses. The only user-configurable option in this screen is the Release/Renew button, which, when clicked, releases and renews the Gateway’s IP address.

  • Page 66: Wan Dsl Status

    Chapter 6 Status WAN DSL Status Click WAN DSL Status from any Status screen to generate the WAN DSL Status screen. This screen displays various parameters relating to the DSL connection of the Gateway, including VPI, downstream speed, and attenuation. There are no user-configurable options in this screen, but there is a Clear button at the bottom of the screen (not shown) that resets all statistics back to zero, at which time the WAN DSL statistics will begin accumulating again.

  • Page 67: Wan Ethernet Status

    Actiontec V1000H Gateway WAN Ethernet Status Click WAN Ethernet Status from any Status screen to generate the WAN Ethernet Status screen. This table displays various parameters relating to the WAN Ethernet connection of the Gateway, including subnet mask, default gateway, and sent pack- ets.

  • Page 68: Firewall Status

    Chapter 6 Status Firewall Status Click Firewall Status from any Status screen to generate the Firewall Status screen. This table displays the status of the Gateway’s firewall. There are no user-configu- rable options in this screen. For more details, see chapter 4, Configuring Firewall Settings. NAT Table Click NAT Table from any Status screen to generate the NAT Table screen. This screen displays the Gateway’s NAT table. There are no user-configurable options in this screen.

  • Page 69: Wireless Status

    Actiontec V1000H Gateway Wireless Status Click Wireless Status from any Status screen to generate the Wireless Status screen. This table displays the Gateway’s wireless network statistics, including wireless secu- rity type, wireless mode, and packets received. If the Gateway is set to use multiple SSIDs, select the SSID from the drop-down list at the top of the screen.

  • Page 70: Modem Utilization

    Chapter 6 Status Modem Utilization Click Modem Utilizations from any Status screen to generate the Modem Utilization screen. This table displays the Gateway’s modem statistics, including wireless memory used, LAN TCP settings, and, at the bottom of the screen, a LAN device session log. There are no user-configurable options in this screen.

  • Page 71: Lan Status

    Actiontec V1000H Gateway LAN Status Click LAN Status from any Status screen to generate the LAN Status screen. This table displays the Gateway’s LAN (local network) statistics, including Ethernet con- nections, HPNA link status, and various networked device details. There are no user-...

  • Page 72: A Specifications

    Specifications General Model Number V1000H (Actiontec Wireless VDSL Gateway) Standards IEEE 802.3 (10BaseT) IEEE 802.3u (100BaseTX) IEEE 802.3ab (1000BaseTX) IEEE 802.11 b, g, n (Wireless) G.dmt, G.lite t1.413 RFC 1483, 2364, 2516 Protocol LAN - CSMA WAN - , Static DHCP VDSL2 interface...

  • Page 73: Wireless Operating Range

    Appendix A Specifications Wireless Operating Range Indoors Up to 91M (300 ft.) @ 300 Mbps Outdoors Up to 457M (1500 ft.) @ 300 Mbps Topology Star (Ethernet) LED Indicators Power, DSL (2), Internet, WAN Ethernet, Internet, Ethernet (4), Wireless, HPNA, USB (2), and WPS Push Button Environmental Power...

  • Page 74: Notices

    Reorient or relocate the receiving antenna; Increase the separation between the equipment and receiver; Connect the equipment to an outlet on a circuit different from that to which the receiver is connected; Consult the dealer or an experienced radio or television technician for help. Modifications The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by Actiontec Electronics, Inc., may void the user’s authority to operate the equipment.

  • Page 75: Gpl (General Public License)

    20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. For questions regarding your product or the FCC declaration, contact: Actiontec Electronics, Inc. 760 North Mary Ave. Sunnyvale, CA 94086 United States Tel: (408) 752-7700...

  • Page 76: Limited Warranty

    Software: Actiontec Electronics warrants to Customer that each software pro- gram licensed from it will perform in substantial conformance to its program spec- ifications, for a period of ninety (90) days from the date of purchase from Actiontec Electronics or its authorized reseller. Actiontec Electronics warrants the media con- taining software against failure during the warranty period.
  • Page 77 Actiontec V1000H Gateway the non-compatibility is caused by a “bug” or defect in the third party’s product or from use of the software product not in accordance with Actiontec Electronics published specifications or user guide. THIS ACTIONTEC ELECTRONICS PRODUCT MAY INCLUDE OR BE BUNDLED WITH THIRD-PARTY SOFTWARE, THE USE OF WHICH IS GOVERNED BY A SEPARATE END-USER LICENSE AGREEMENT. THIS ACTIONTEC ELECTRONICS WARRANTY DOES NOT APPLY TO SUCH THIRD-PARTY SOFTWARE. FOR THE APPLICABLE WARRANTY, PLEASE REFER...
  • Page 78 Limited Warranty Actiontec Electronics shall not be responsible for any software, firmware, informa- tion, memory data, or Customer data contained in, stored on, or integrated with any products returned to Actiontec Electronics for repair, whether under warranty or not. WARRANTIES EXCLUSIVE: IF AN ACTIONTEC ELECTRONICS’ PRODUCT DOES NOT OPERATE AS WARRANTED ABOVE, CUSTOMER’S SOLE REMEDY FOR BREACH OF THAT WARRANTY SHALL BE REPAIR, REPLACEMENT, OR REFUND OF THE PURCHASE PRICE PAID, AT ACTIONTEC ELECTRONICS’ OPTION. TO THE FULL EXTENT ALLOWED BY LAW, THE FOREGOING WARRANTIES AND REMEDIES ARE EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES, TERMS OR CONDITIONS, EXPRESS OR IMPLIED, EITHER IN FACT OR BY OPERATION OF LAW, STATUTORY OR OTHERWISE, INCLUDING WARRANTIES, TERMS OR CONDITIONS OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, SATISFACTORY QUALITY, CORRESPONDENCE WITH DESCRIPTION, AND NON- INFRINGEMENT, ALL OF WHICH ARE EXPRESSLY DISCLAIMED. ACTIONTEC ELECTRONICS NEITHER ASSUMES NOR AUTHORIZES ANY OTHER PERSON TO ASSUME FOR IT ANY OTHER LIABILITY IN CONNECTION WITH THE SALE, INSTALLATION, MAINTENANCE OR USE OF ITS PRODUCTS.
  • Page 79 Actiontec V1000H Gateway LIABILITY TO REPAIR, REPLACEMENT,OR REFUND OF THE PURCHASE PRICE PAID, AT ACTIONTEC ELECTRONICS’ OPTION. THIS DISCLAIMER OF LIABILITY FOR DAMAGES WILL NOT BE AFFECTED IF ANY REMEDY PROVIDED HEREIN SHALL FAIL OF ITS ESSENTIAL PURPOSE. Disclaimer: Some countries, states or provinces do not allow the exclusion or limitation of implied warranties or the limitation of incidental or consequential damages for certain products supplied to consumers, or the limitation of liability for personal injury, so the above limitations and exclusions may be limited in their application to you.
