Summary of Contents for Lang DI-60
- Page 1 Installation, Operation, Maintenance, & Troubleshooting Model: DI-60, Drop-In Griddle Lang Manufacturing Company 6500 Merrill Creek Parkway Everett, WA 98203 Rev. # A Phone: 425-349-2400 Fax: 425-349-2733 WWW.LANGWORLD.COM © Copyright 2000...
- Page 2 THIS MANUAL MUST BE RETAINED FOR FUTURE REFERENCE. READ, UNDERSTAND AND FOLLOW THE INSTRUCTIONS AND WARNINGS CONTAINED IN THIS MANUAL. FOR YOUR SAFETY DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE VAPORS AND LIQUIDS IN THE VICINITY OF THIS OR ANY OTHER APPLIANCE.
-
Page 3: Table Of Contents
TABLE OF CONTENTS CHAPTER PAGE TABLE OF CONTENTS................3 READ FIRST....................4 EQUIPMENT DESCRIPTION...............6 UNPACKING ....................7 INSTALLATION....................8 INITIAL START-UP ..................10 OPERATION ....................11 CLEANING & MAINTENANCE PROCEDURES ........12 TROUBLESHOOTING..................13 10. PARTS LISTS....................14 11. WIRING DIAGRAMS..................15 12. WARRANTY....................17... -
Page 4: Read First
IMPORTANT READ FIRST IMPORTANT CAUTION: THE GRIDDLE IS EXTREMELY HEAVY. FOR SAFE HANDLING, INSTALLER SHOULD OBTAIN HELP AS NEEDED, OR EMPLOY APPROPRIATE MATERIALS HANDLING EQUIPMENT (SUCH AS A FORKLIFT, DOLLY, OR PALLET JACK) TO REMOVE THE UNIT FROM THE SKID AND MOVE IT TO THE PLACE OF INSTALLATION. - Page 5 WARNING AND FOLLOW THE DIRECTIONS ON THE LABEL OF THE CLEANER TO BE USED. NOTICE: Service on this, or any other, LANG appliance must be performed by qualified personnel only. Consult your authorized service station directory or call the factory at 1-800-224-LANG (5264), or WWW.LANGWORLD.COM...
-
Page 6: Equipment Description
Control Box ! The Control box dimensions are 26” (66cm) Wide, 4” (10cm) Deep, and 7 1/8 (18cm) High. ! The Sides, Bottom, and Rear walls are constructed of stainless steel. Controls The DI-60 Griddle comes standard with three 550° thermostats. -
Page 7: Unpacking
15 days of delivery. All packing material should be kept for inspection. Do not return damaged merchandise to Lang Manufacturing Company. File your claim with the carrier. -
Page 8: Installation
INSTALLATION DANGER: THIS APPLIANCE MUST BE GROUNDED AT THE TERMINAL PROVIDED. FAILURE TO GROUND THE APPLIANCE COULD RESULT IN ELECTROCUTION AND DEATH. WARNING: INSTALLATION OF THE UNIT MUST BE DONE BY PERSONNEL QUALIFIED TO WORK WITH ELECTRICITY. IMPROPER INSTALLATION CAN CAUSE INJURY TO PERSONNEL AND/OR DAMAGE TO EQUIPMENT. - Page 9 INSTALLATION CONT’D Total Three Phase Single Phase K.W. 208 Volt 240 Volt 480 Volt 208 V 240 V Conn 18.0 50.0 50.0 50.0 43.3 43.3 43.3 21.7 21.7 21.7 80.5 75.0 Phasing Three Phase Single Phase...
-
Page 10: Initial Start-Up
INITIAL START UP Prior to putting any griddle into full time operation at normal cooking temperatures, it must be thoroughly "seasoned" or dried out. Moisture absorption in the closed spaces, in the insulation and even inside the heating elements can cause future trouble if not properly treated. -
Page 11: Operation
OPERATION CAUTION: ALWAYS KEEP THE AREA NEAR THE APPLIANCE FREE FROM COMBUSTIBLE MATERIALS. CAUTION: KEEP FLOOR IN FRONT OF EQUIPMENT CLEAN AND DRY. IF SPILLS OCCUR, CLEAN IMMEDIATELY, TO AVOID THE DANGER OF SLIPS OR FALLS. The griddle is provided with two thermostats for controlling the middle two feet of the griddle surface. -
Page 12: Cleaning & Maintenance Procedures
MAINTENANCE & CLEANING Cleaning WARNING: KEEP WATER AND SOLUTIONS OUT OF CONTROLS. NEVER SPRAY OR HOSE CONTROL CONSOLE, ELECTRICAL CONNECTIONS, ETC. CAUTION: MOST CLEANERS ARE HARMFUL TO THE SKIN, EYES, MUCOUS MEMBRANES AND CLOTHING. PRECAUTIONS SHOULD BE TAKEN TO WEAR RUBBER GLOVES, GOGGLES OR FACE SHIELD AND PROTECTIVE CLOTHING. -
Page 13: Troubleshooting
Product is burning Thermostat out of calibration TESTS NOTICE: Service on this, or any other, LANG appliance must be performed by qualified personnel only. Consult your authorized service station directory or call the factory at 1- 800-224-LANG (5264), or WWW.LANGWORLD.COM For the service station nearest you. -
Page 14: Parts Lists
PARTS LIST DESCRIPTION PART NO. Griddle Element 208 / 240Volt O/S 4500 Watts / 6000 Watts 11030-29 Griddle Element 208 Volt I/S 1491 Watts 11030-30 Griddle Element 480 Volt 5991 Watts 11030-31 30402-07 Thermostat 550° F 48” Capillary Tube 70701-15 Knob Thermostat 550°... -
Page 15: Wiring Diagrams
WIRING DIAGRAM 208 VOLT... - Page 16 WIRING DIAGRAM 240 / 480 VOLT...
-
Page 17: Warranty
I. This parts and labor warranty is limited to Lang V. THIS WARRANTY IS EXCLUSIVE AND IS IN Equipment sold to the original commercial LIEU OF ALL OTHER WARRANTIES, EXPRESSED...
