  • Page 1 601HW User Guide...

  • Page 3: Table Of Contents

    Getting Started Parts & Functions.............. 6 Home Screen................ 6 Notification for Setting Maximum Traffic....10 USIM Card................10 Inserting/Removing Battery..........13 601HW User Guide Contents Charging Battery.............. 14 Power On/Off..............16 Connecting with WLAN WLAN (Wi-Fi)..............20 Activating WLAN (Wi-Fi) Function........21 Connecting Windows PC........... 21 Connecting Mac..............25...

  • Page 4: Safety Precautions

    System................151 Showing/Setting Data Usage.........159 Confirming Information..........166 Setting Software Update..........171 Setting from Mobile Device...........173 Setting LAN Wi-Fi (on Mobile)........178 Setting Mobile Network (on Mobile)......188 Showing/Setting Data Usage (on Mobile)..... 190 Confirming Information (on Mobile)......200 Checking Wi-Fi Router Information (on Mobile)..205 Appendix Troubleshooting..............

  • Page 5: Introduction

    Introduction Introduction Operating Environment (Compatible OSs) Before You Begin Use Wi-Fi router in any of these operating environments. Use outside these environments may affect performance. Operating environment (hardware, connected peripherals, Read "クイックスタート(Quick Start)" (Japanese), "お願いとご注 installed applications, etc.) may also affect performance. 意(Safety Precautions)"...

  • Page 6: Package Contents

    SoftBank Group Corp. in Japan and other countries. Wi-Fi Name and Password (Security Key) ・Pocket WiFi is a registered trademark of SoftBank Corp. ・HUAWEI is a trademark or registered trademark of HUAWEI When connecting to a Wi-Fi device, Wi-Fi name (Network TECHNOLOGIES CO., LTD.

  • Page 7: Getting Started

    Getting Started Parts & Functions.............. 6 Home Screen................ 6 Notification for Setting Maximum Traffic....10 USIM Card................10 Inserting/Removing Battery..........13 Charging Battery.............. 14 Power On/Off..............16...

  • Page 8: Parts & Functions

    Parts & Functions Home Screen Front/Top/Bottom Layout Part Description Home First page of Home Screen Screen (First Page) Home Second page of Home Screen; Flick left/ Screen Part Description right to change page (Second Page) Wi-Fi router status appears; Display is Display Status Indicators for communication Touchscreen;...

  • Page 9: Status Indicators

    Set a WPS connection Notifications for Maximum Traffic." Show Wi-Fi router’s phone number, Device Info software version, etc. Connect to household/company WLAN Wi-Fi Spot routers and SoftBank Wi-Fi spots and make the settings Help Show Help for Icons on Display...
  • Page 10 Using Touchscreen Appears when data traffic approaches the value at which communication speed reduction starts, or once a communication Wi-Fi router uses a touchscreen-type Display. Operate with Data Usage speed reduction has started. You can your fingers on Display. apply to return to normal speed, apply ahead to keep normal speed or cancel ・Tap application...
  • Page 11 Text Entry Window Text Entry Use onscreen keyboards for text entry. Multiple letters ("ABC," "DEF") are assigned to each key. Tapping key toggles characters. ・ Example: For "b," Tap twice. ・ Example: For "c," Tap three times. To go back to the previous character assigned to the same key, Tap ・...

  • Page 12: Notification For Setting Maximum Traffic

    ・Specifications and capabilities are subject to change speed reduction has started without notice. ・Keep a copy of information saved to USIM Card. SoftBank Release Notification is sent and is shown Corp. is not responsible for damages due to loss of saved...
  • Page 13 Installing USIM Card Close USIM Card Stopper Be sure to power off to perform the following steps. Remove Battery Cover ・ Lower USIM Card Stopper to , then slide it to ・Make sure USIM Card is inserted completely. Insert Battery ・Use notch ( ○...
  • Page 14 Removing USIM Card Close USIM Card Stopper Power off Wi-Fi router in advance. Remove Battery Cover ・ Lower USIM Card Stopper in direction , then slide it in direction ・Use notch ( ○ ) to lift Battery Cover then remove it. Insert Battery ・Be careful not to hurt your fingernail etc.

  • Page 15: Inserting/Removing Battery

    Inserting/Removing Battery Removing Battery Power off Wi-Fi router in advance. Inserting Battery Remove Battery Cover Remove Battery Cover ・Use notch ( ○ ) to lift Battery Cover then remove it. ・Be careful not to hurt your fingernail etc. ・Use notch ( ○ ) to lift Battery Cover then remove it. ・Be careful not to hurt your fingernail etc.

  • Page 16: Charging Battery

    Charging Battery Wi-Fi Name and Password (Security Key) Wi-Fi router is not fully charged by default. Charge Wi-Fi Remove Battery and check Wi-Fi name (Network Name) and router before use. password (Security Key: WPA Key or WEP Key). Wi-Fi router discharges even when not in use. Charge Wi-Fi Be sure to power off to perform the following steps.
  • Page 17 Insert USB Cable (Type-C plug) into External Device Port and AC Charger is sold separately. USB Cable (USB plug) to a computer Use products specified by SoftBank such as follows. Product name: AC Charger (with USB Type-C Quick Charge 3.0 capability) [ZSCAZX]...

  • Page 18: Power On/Off

    Power On/Off Flick Display up/down Power On (Press & Hold) Lock Screen appears when powered on and WLAN function is enabled. Wi-Fi router automatically connects to the Home Screen appears. Internet. ・Clock is shown on Lock Screen. ・ When WLAN is enabled, (Wi-Fi connection standard Shown date and time are obtained from connected network.
  • Page 19 Power Off (Press & Hold) Power off Power is off.
  • Page 21 Connecting with WLAN WLAN (Wi-Fi)..............20 Activating WLAN (Wi-Fi) Function........21 Connecting Windows PC........... 21 Connecting Mac..............25 Connecting Android™ Device........... 26 Connecting iPhone/iPod touch/iPad........27 Connecting Nintendo 3DS LL/3DS........30 Connecting Wii U/Wii............32 Connecting PlayStation Vita........... 34 ® Connecting PlayStation 4..........35 ® Connecting PlayStation 3..........

  • Page 22: Connecting With Wlan

    WLAN (Wi-Fi) Overview Wi-Fi router supports IEEE 802.11 a/b/g/n/ac standards. WLAN (Wi-Fi) Connect WLAN devices (computer, game console, etc.) via WLAN for wireless data transfers. Advanced Settings Wi-Fi router supports Wi-Fi Protected Setup (WPS), which allows WLAN connection settings to be easily configured on Change WLAN settings as required.

  • Page 23: Activating Wlan (Wi-Fi) Function

    Activating WLAN (Wi-Fi) Function Connecting Windows PC Power on to connect to the Internet automatically. Connect a Windows PC to connect to the Internet. Wi-Fi Name (Network Name) and Connecting to 4G/LTE/3G Password (Security Key: WPA Key or WEP Key) (Press &...
  • Page 24 Windows 8.1 Select Wi-Fi router's Wi-Fi name Connect This section describes setup operations with screenshots and steps for Wi-Fi (SSID A) at WPA security setting on Windows 8.1. (Press & Hold) ・ When Wi-Fi name is not shown, press to exit Sleep mode.
  • Page 25 Windows 7 Enter password (Security Key) Next This section describes setup operations with screenshots and steps for Wi-Fi (SSID A) at WPA security setting on Windows (Press & Hold) Lock Screen appears when powered on and WLAN function WLAN connection counter number on Display increases by is enabled.

  • Page 26: Windows Vista

    Windows Vista Select Wi-Fi router's Wi-Fi name Connect This section describes setup operations with screenshots and steps for Wi-Fi (SSID A) at WPA security setting on Windows Vista. (Press & Hold) Lock Screen appears when powered on and WLAN function is enabled.

  • Page 27: Connecting Mac

    Connecting Mac Connect to a network Connect a Mac to connect to the Internet. Wi-Fi Name (Network Name) and Password (Security Key: WPA Key or WEP Key) For Wi-Fi Name and password (Security Key), see "Wi-Fi Name and Password (Security Key)."...

  • Page 28: Connecting Android™ Device

    Connecting Android™ Device Wi-Fi Turn Wi-Fi On Connect an Android™ device to connect to the Internet. Wi-Fi Name (Network Name) and Password (Security Key: WPA Key or WEP Key) For Wi-Fi Name and password (Security Key), see "Wi-Fi Name and Password (Security Key)."...

  • Page 29: Connecting Iphone/Ipod Touch/Ipad

    Connecting iPhone/iPod touch/iPad Enter password (Security Key) in "Password" Connect Connect an iPhone/iPod touch/iPad to connect to the Internet. WLAN connection counter number on Display increases by Wi-Fi Name (Network Name) and one (e.g. Password (Security Key: WPA Key or WEP Key) For Wi-Fi Name and password (Security Key), see "Wi-Fi...
  • Page 30 Enable Wi-Fi Enter password (Security Key) in "Password" Join WLAN function on iPhone/iPod touch is enabled. In "CHOOSE A NETWORK..." list, Tap Wi-Fi router's Wi-Fi name WLAN connection counter number on Display increases by one (e.g. ・ When Wi-Fi name is not shown, press to exit Sleep mode.
  • Page 31 iPad In "CHOOSE A NETWORK..." list, Tap Wi-Fi router's Wi-Fi name This section describes setup operations with screenshots and steps for "Wi-Fi (SSID A)" under "WPA" security setting on iPad with iOS 10. (Press & Hold) Lock Screen appears when powered on and WLAN function ・...

  • Page 32: Connecting Nintendo 3Ds Ll/3Ds

    Connecting Nintendo 3DS LL/3DS インターネット接続設定 Connect Nintendo 3DS LL/3DS to Wi-Fi router to connect to Internet. Method of connection in this guide is confirmed and described by HUAWEI TECHNOLOGIES CO., LTD. Please refrain from contacting Nintendo Co., Ltd. regarding these descriptions. Wi-Fi name (Network Name) and Password (Security Key: WPA Key or WEP Key)
  • Page 33 アクセスポイントを検索 In list, touch Wi-Fi router's Wi-Fi name ・ When Wi-Fi name is not shown, press to exit Sleep Connection test starts. When "接続テストに成功しまし mode. た！" appears, touch "OK" to complete. WLAN connection count number on Display increases by one (e.g. Enter password (Security Key) 決定...

  • Page 34: Connecting Wii U/Wii

    Connecting Wii U/Wii In list, select Wi-Fi router's Wi-Fi name Connect Wii U/Wii to connect to Internet. ・ When Wi-Fi name is not shown, press to exit Sleep Method of connection in this guide is confirmed and described mode. by HUAWEI TECHNOLOGIES CO., LTD. Please refrain from contacting Nintendo Co., Ltd.
  • Page 35 This section describes setup operations with screenshots and steps for "Wi-Fi (SSID A)" at "WPA" security setting. Some Saving of settings starts. operations and screenshots vary by security method. For details, refer to Wii user guide. (Press & Hold) Connection test starts. When "接続テストに成功しました。 "...

  • Page 36: Connecting Playstation ® Vita

    Connecting PlayStation Vita ® Network Connect PS Vita to connect to the Internet. Method of connection for PlayStation Vita in this guide is ® confirmed and described by HUAWEI TECHNOLOGIES CO., LTD. Please refrain from contacting Sony Interactive Entertainment Inc. regarding these descriptions. Wi-Fi name (Network Name) and Password (Security Key: WPA Key or WEP Key)

  • Page 37: Connecting Playstation ® 4

    Connecting PlayStation ® Connect PS4 to connect to the Internet. ® Method of connection for PlayStation 4 in this guide is ® confirmed and described by HUAWEI TECHNOLOGIES CO., LTD. Please refrain from contacting Sony Interactive Entertainment Inc. regarding these descriptions. Wi-Fi name (Network Name) and Password (Security Key: WPA Key or WEP Key)
  • Page 38 In PS4 Home menu, Settings Network Set Up In list, select Wi-Fi router's Wi-Fi name Press ® button Internet Connection Press button ・ When Wi-Fi name is not shown, press to exit Sleep mode. Use Wi-Fi Press button Enter password (Security Key) Done Press button...

  • Page 39: Connecting Playstation ® 3

    Connecting PlayStation ® In PS3 Home menu, Settings Network Settings ® Connect PS3 to connect to the Internet. ® Internet Connection Settings Method of connection for PlayStation 3 in this guide is ® confirmed and described by HUAWEI TECHNOLOGIES CO., LTD. Please refrain from contacting Sony Interactive Entertainment Inc.
  • Page 40 Wireless Press direction key " " Confirm SSID Press direction key " " WPA-PSK / WPA2-PSK Press direction key " " Scan Press direction key " " In list, select Wi-Fi router's Wi-Fi name Press Press button Enter password (Security Key) button Press direction key "...

  • Page 41: Connecting Wps Supported Wlan Devices

    Connecting WPS Supported WLAN Devices Confirm the setting list Press button Precautions for Using WPS Function SSID Stealth While Wi-Fi router's stealth is enabled, WPS function is not available. For SSID stealth function, see "Quick Setup," "Setting LAN Wi-Fi." Encryption When encryption is set to WEP, WPS function is not available.
  • Page 42 ・ When "WPS connection failed." appears, Tap , then retry. LAN Wi-Fi To make other settings on WLAN device, follow the onscreen instructions WLAN connection count number on Display increases by one (e.g. Wi-Fi-router is on standby to accept WLAN device connection.

  • Page 43: Connecting With Usb Cable (Windows)

    Connecting with USB Cable (Windows) Device Recognition/Removal on Windows PC....42 Installing/Uninstalling Driver (Windows PC)....43...

  • Page 44: Device Recognition/Removal On Windows Pc

    Device Recognition/Removal on Device Removal (Windows) Windows PC ・When using a PC, check that data uploading/downloading is completed before removing Wi-Fi router. Wi-Fi router automatically connects to the Internet when powered on. Connect with PC via USB Cable to allow data communication.

  • Page 45: Installing/Uninstalling Driver (Windows Pc)

    Installing/Uninstalling Driver Uninstalling Driver (Windows PC) Screenshots/operations are based on Windows 10. Notes on Installation/Uninstallation Start menu Activate File Explorer Removing Do not remove Wi-Fi router during installation/ uninstallation. May cause failure of installation/ This PC Uninstall or change a program uninstallation, system shutdown or other abnormality.
  • Page 46 Windows 7 Operate as follows. Start menu Control Panel Programs Programs and Features Pocket WiFi setting tool Uninstall/Change In "User Account Control," Uninstall Uninstallation starts.

  • Page 47: Connecting With Usb Cable (Mac)

    Connecting with USB Cable (Mac) Device Recognition/Removal on Mac....... 46 Installing/Uninstalling Driver (Mac)........46...

  • Page 48: Device Recognition/Removal On Mac

    Device Recognition/Removal on Installing/Uninstalling Driver (Mac) Wi-Fi router automatically connects to the Internet when Driver Installation (Mac) powered on. Connect with Mac via USB Cable to allow data communication. Screenshots and steps described here are for Mac OS X 10.12. Removal Cautions Before Entering Sleep Mode Connect Wi-Fi router to Mac...
  • Page 49 Uninstalling Driver (Mac) In Macintosh HD, Library StartupItems MobileBrServ Double-click Uninstall Enter user name and password Uninstallation is complete.

  • Page 51: Settings (Using Router Touch Menu)

    Settings (Using Router Touch Menu) Touch Menu............... 50 Quick Setup...............50 Showing/Setting Data Usage........... 52 Setting Wi-Fi Spot............56 Confirming Notifications..........58 Checking WLAN Connected Device Information....61 Setting Wi-Fi Name or Authorization Method....61 Using WPS................. 65 Using Power Save Setting..........67 Other Settings..............

  • Page 52: Touch Menu

    Touch Menu Quick Setup Wi-Fi router Display is a touchscreen. Tap Touch Menu Icons Use Simple setting to show Wi-Fi name and password (Security to check function settings or product information. Key), and set Pass Code for unlocking Screen Lock. Touch Menu Quick Setup Touch Menu Icons are as follows.
  • Page 53 Next Enter four-digit Pass Code ・Enter Wi-Fi name and password (Security Key) shown on the ・When Pass Code is set, Pass Code entry screen appears when screen to connect WLAN devices. unlocking screen. For unlocking screen by entering Pass ・For connection to WLAN devices, see "Connecting Windows Code, see "Entering Pass Code to Unlock...

  • Page 54: Showing/Setting Data Usage

    Showing/Setting Data Usage Showing Data Traffic on Home Screen and Lock Screen Set to show/hide data traffic volume for mobile network. Also, set a maximum on data traffic or the reset date for Set to show data traffic volume on "Data traffic" icon on data traffic.
  • Page 55 Setting Maximum Traffic Check maximum traffic setting next Set monthly data traffic volume. When data traffic volume exceeds the set volume, notification icon etc. appears. ・When "Monthly" is selected to show data traffic volume on Home Screen, (bar icon) is shown on Home screen. When data traffic volume exceeds the maximum volume set in Maximum traffic (step ), bar icon of data traffic...
  • Page 56 Setting Auto Reset Date Tap number in "Maximum traffic" Set date of month for automatically resetting accumulated data traffic. It is reset at the timing which changes on the next day from set date. Data traffic ・ Tap (GB) to change unit for maximum traffic to (MB).
  • Page 57 Resetting Data Traffic Tap number in "Auto reset date" Reset all data traffic volumes for "Month," "Today," "Yesterday," "Two days ago," and "Three days ago." Data traffic Enter day for auto reset date ・If confirmation for showing data traffic volume on Home screen and Lock screen appears, tap Cancel Data traffic settings...

  • Page 58: Setting Wi-Fi Spot

    Setting Wi-Fi Spot Wi-Fi router connects to the Internet via a household or office WLAN router, SoftBank Wi-Fi spot, etc. This internet connection is called Wi-Fi spot. Setting Wi-Fi Spot Connect to the Internet via Wi-Fi. ・Simultaneous use of Wi-Fi spot and Multi-SSID (SSID B) is not available.
  • Page 59 Setting Up SoftBank Wi-Fi Spot Tap network to connect Use a SoftBank Wi-Fi Spot to connect to the Internet. ・SoftBank Wi-Fi Spot password is a four-digit security code set at subscription. Wi-Fi Spot Enter password (Security Key) In "Softbank Wi-Fi Spot,"...

  • Page 60: Confirming Notifications

    Confirming Notifications Login password Wi-Fi router receives available notifications. Confirming Notifications Information Tap Number Keys to enter four-digit login password Tap notification to confirm Wi-Fi router connects to SoftBank Wi-Fi Spot. Internet connection is available. Confirm notification.
  • Page 61 Deleting Confirmed Notifications Information Tap notification to delete Notification is deleted. Delete...
  • Page 62 Selecting and Deleting Notifications Information Checkmark notifications to delete Selected notifications are deleted. ・Checkmark Checkbox on the top of screen to select all.

  • Page 63: Checking Wlan Connected Device Information

    Checking WLAN Connected Device Setting Wi-Fi Name or Information Authorization Method Check WLAN device information such as computers, Set Wi-Fi name (Network Name) of Wi-Fi router, password smartphones, and game consoles connected to Wi-Fi router. (Security Key: WPA Key or WEP Key), authorization or encryption.
  • Page 64 Authorization Method and Encryption Method Enter Wi-Fi name Select authorization and encryption used for WLAN connection. Select authorization method and encryption method from the following. ・Authorization method Item Description "Open" or "Shared key" is selected automatically according to the connecting Auto device authorization method;...
  • Page 65 Tap authentication method Tap encryption method Tap authorization method Tap encryption method Authorization method is modified. Selected authorization and encryption are set. ・Notification appears for some authorization methods requiring that password (Security Key) be changed. In that case, tap and enter password (Security Key) on Entry screen.
  • Page 66 Enabling Multi-SSID Turn on Multi-SSID (SSID B) to set basic WLAN for Wi-Fi name (SSID B). ・To use Wi-Fi name (SSID B), turn off Wi-Fi spot function. Connect to the Internet via mobile network. ・Wi-Fi name (SSID B) does not support WPA/WPA2. ・When Multi-SSID is enabled, connect to Wi-Fi name (SSID A) up to 7 devices, and Wi-Fi name (SSID B) up to 6 devices.

  • Page 67: Using Wps

    Using WPS Set Wi-Fi name and password (Security Key), authorization and Wi-Fi router supports WPS. Use WPS to connect WPS encryption the same as Wi-Fi name (SSID A) supported game console or wireless LAN router easily. Connecting WLAN Devices Connect WPS supported WLAN devices. Enable WLAN function on WLAN device, and make any required WPS settings ・Method of setting WPS function varies by device.
  • Page 68 Connecting to the Access Point While window below appears (within 120 seconds), set up WPS Connect WPS supported access point. connection on WLAN device ・Enable Wi-Fi spot in advance. Enable WLAN function on access point device, and make any required WPS settings ・Method of setting WPS function varies by device.

  • Page 69: Using Power Save Setting

    Using Power Save Setting While window below appears (within 120 seconds), make WPS Set Power save setting to ON to save power consumption connection settings on access point device during use for longer usage time. The maximum communication speed of mobile network and WLAN is reduced to save power consumption.

  • Page 70: Other Settings

    Other Settings Tap Icon to switch Make settings including rearranging Touch Menu Icons in Home Screen, roaming, Pass Code for unlocking Screen Lock, brightness, Sleep, Wi-Fi communication standard, USB tethering, language/time, software update, clearing notification icons, checking URL for WEB UI, etc. Home Screen Rearrange Touch Menu Icons on Home Screen.
  • Page 71 International Roaming Screen Lock Enable auto-International roaming connection. Set Pass Code entry for canceling Screen Lock. Settings Settings International Roaming Screen Lock In "International Roaming," In "Passcode Lock," "International Roaming" is turned to . International "Passcode Lock" is turned to roaming is available.
  • Page 72 Entering Pass Code to Unlock Screen Enter four-digit Pass Code Flick Display up or down to unlock Re-enter four-digit Pass Code Enter four-digit Pass Code Unlocking Pass Code is set. ・If re-entered Pass Code is different from the first one Screen is unlocked.
  • Page 73 Changing Screen Brightness Changing Backlight Time Set screen brightness. Set backlight timeout when there is no operation of Wi-Fi router. Settings Settings Display Display Drag bar to adjust brightness Tap sleep time Screen backlight is changed to the set brightness.
  • Page 74 Setting Sleep Mode Tap desired seconds When operation is not performed for a certain period of time or when charging Battery without connection to any WLAN device, Wi-Fi router goes into Sleep mode for energy-saving. Set time period for Sleep mode. Five minutes are set by default.
  • Page 75 Wi-Fi Communication Standard Setting Tap auto turn off time If you are unable to connect with WLAN at the time of purchase, you may be able to do so by changing Wi-Fi communication standard setting. Settings ・ When not using Sleep mode, tap to turn to Tap desired minutes Wi-Fi Communication...
  • Page 76 Setting USB Tethering Tap communication standard Change USB standard to use Wi-Fi router by USB connection. ・When USB3.0 is set for data communication, signal reception may be affected. In this case, use in a place where signal is strong. Settings Wi-Fi communication standard is set.
  • Page 77 Setting Language Tap desired USB communication standard Select Japanese or English for language shown on Display. Settings USB communication standard is set. 言語設定 Tap desired language Language is set.
  • Page 78 Setting Time In "24-hour time," Change time (24-hour time/12-hour time) and time zone shown on Lock Screen. Settings Time switches between 24-hour time/12-hour time. ・ To change the time zone, tap Auto in "Time zone" to select the desired time zone. Time...
  • Page 79 Updating Software Confirm message Update software. Settings Checks for the latest software. If software update is found, update software. ・When software in use is the latest, "The latest version." appears. Software Update Software Update Packet communication charges are not applied for Software update.
  • Page 80 Clearing Notifications for Maximum Traffic Clear present notification icons for data traffic. Settings Clear Notification Icon Shown notification icons are cleared. ・This step clears only notification icons shown on Status Bar. "Data Usage" Icon on Touch Menu is not cleared. Data usage...

  • Page 81: Checking Wi-Fi Router Information

    Phone number Phone number saved to USIM Card IMEI Serial number Software Software version version Device name Product name (601HW) Authentication Various standards by which Wi-Fi router information is authenticated Device Info Advanced Settings Information is shown. URL and QR code for WEB UI and Login password are shown.

  • Page 82: Checking Help

    Checking Help Viewing Description for Touch Menu Icons Check description for Status Indicators or Touch Menu Icons appearing in the top of Display. Help Viewing Description for Status Indicators Help Menu icon Status icon Description for Touch Menu Icons appears. Description for Status Indicators appears.

  • Page 83: Operation For Setting Maximum Traffic

    Operation for Setting Maximum Traffic Data usage Clearing Notification Icons Clear present notification icons for data traffic. Settings Clear Notification Icon Shown notification icons are cleared. ・This step clears only notification icons shown on Status Bar. "Data Usage" Icon on Touch Menu is not cleared.
  • Page 84 If application ahead is set but not used within the billing month, application ahead is canceled. ・Closing dates vary depending on customers. Check on My SoftBank or the copy of the contract.
  • Page 85 If application ahead is set but not used within the billing month, application ahead is canceled. ・Closing dates vary depending on customers. Check on My SoftBank or the copy of the contract.
  • Page 86 Canceling Application for Release from Speed Reduction If release from speed reduction is applied for ahead, you can cancel your application. ・Operation screen may look different from the actual screens. Data Usage ・When error message is shown, retry. Cancel reservation Application ahead is canceled.
  • Page 87 Releasing Speed Reduction (on Pop-up Screen) When a pop-up notice appears for the start of communication speed reduction, you can apply to have the speed reduction released and return to normal speed. ・Operation screen may look different from the actual screens.
  • Page 88 Releasing Speed Reduction (on Touch Menu) You can apply to have data traffic released from speed reduction on Touch Menu. ・Operation screen may look different from the actual screens. Data Usage ・When error message is shown, retry. Tap data traffic to release Application is complete.

  • Page 89: Settings (Using Web Ui)

    Settings (Using WEB UI) Overview of WEB UI............88 WEB UI Window on PC............. 91 Setting LAN Wi-Fi............93 Setting Mobile Network..........106 Setting Wi-Fi Spot............120 Router Setting..............127 System................151 Showing/Setting Data Usage.........159 Confirming Information..........166 Setting Software Update..........171 Setting from Mobile Device...........173 Setting LAN Wi-Fi (on Mobile)........

  • Page 90: Overview Of Web Ui

    Overview of WEB UI Connect Wi-Fi router to a computer or mobile device via USB Cable or WLAN. Use web browser to check Wi-Fi router information or make settings. For web browser support, see "Operating Environment (Compatible OSs)." Activating WEB UI on Computer Screenshots and steps described here are for PC (Windows 10) compatible with WEB UI.
  • Page 91 Logging In to WEB UI from Computer In WEB UI Home Page, Log In Login window opens. Enter Login password Log In Log Out appears at top right, and login is complete. ・Password is "admin" by default. Default Login Password For enhancing security, it is recommended to change default Login password.
  • Page 92 Cautions for Operating WEB UI Logging In to WEB UI Please note the following for WEB UI login. ・While operating Wi-Fi router, Login to WEB UI is not available. Return to Lock Screen on Wi-Fi router before logging in to WEB UI. ・Login to WEB UI from two or more devices simultaneously is not available.

  • Page 93: Web Ui Window On Pc

    Toggle setting menu Connected network Connected network details and signal level SupportSite Connect SoftBank website and open Support Site of 601HW User Manual Connect SoftBank website and open User Guide of 601HW Received data volume: ・ Show accumulated received data traffic at the moment from start of connection Transmitted data volume: ・...
  • Page 94 : SoftBank LTE connected Network Type : SoftBank 3G connected Wi-Fi Spot :Wi-Fi Spot connected (Including SoftBank Wi-Fi spot) : Connected to Internet Internet Connection Status : Not connected to Internet : WLAN is ON, operating at 2.4 GHz (Wi-Fi)

  • Page 95: Setting Lan Wi-Fi

    Setting LAN Wi-Fi Connect to computers, smartphones, game consoles, etc. via WLAN. This WLAN connection is described as "LAN Wi-Fi." WLAN devices connected to Wi-Fi router via LAN Wi-Fi access the Internet using Wi-Fi spot function of Wi-Fi router. Note on Changing LAN Wi-Fi Settings Changing LAN Wi-Fi setting on WEB UI from device connected via WLAN may disconnect WLAN connection.
  • Page 96 Set each item Apply LAN Wi-Fi basic settings for Wi-Fi name (SSID A) are made.
  • Page 97 Enabling Multi-SSID Function (SSID B) Make basic WLAN settings for Wi-Fi name (SSID B). ・To use Wi-Fi name (SSID B), turn off Wi-Fi spot function. Connect to the Internet via mobile network. ・Wi-Fi name (SSID B) does not support WPA/WPA2. ・When Multi-SSID is enabled, connect to Wi-Fi name (SSID A) up to 7 devices, and Wi-Fi name (SSID B) up to 6 devices.
  • Page 98 Turn "SSID B" to ・ Information screen appears when clicking of "SSID B" with Wi-Fi spot enabled. Click to disable Wi-Fi spot function automatically.
  • Page 99 Set each item Apply LAN Wi-Fi basic settings for Wi-Fi name (SSID B) are made.
  • Page 100 LAN Wi-Fi Advanced Settings Setting items are as follows: Item Description Country Set country where you use WLAN Communication standard Set WLAN communication standard Channel Set WLAN channel; only Auto is selected when Wi-Fi spot is enabled Set whether to permit interactive communication between devices connected SSID A and SSID Multi-SSID AP isolation B;...
  • Page 101 Set each item Apply LAN Wi-Fi advanced settings are made.

  • Page 102: Mac Address Filtering

    MAC Address Filtering Save MAC addresses of WLAN devices and set WLAN connection permission to enhance security. ・When Multi-SSID (SSID B) is enabled, MAC Address Filtering is set in Wi-Fi name (SSID B). In Menu List, LAN Wi-Fi MAC Address Filtering In "MAC Address Filtering,"...
  • Page 103 MAC Address Filtering is set.
  • Page 104 Canceling MAC Address Filtering Set MAC addresses are deleted and MAC Address Filtering is canceled. In Menu List, LAN Wi-Fi MAC Address Filtering In "MAC Address Filtering," Disable Apply...
  • Page 105 MAC Address Filtering is canceled.
  • Page 106 DHCP Assign IP addresses to devices inside LAN. Setting items are as follows: Item Description IP address Set Wi-Fi router private address Subnet mask Set subnet mask DHCP server Set whether to use DHCP function Start IP address Set lowest IP address to be assigned to WLAN devices End IP address Set highest IP address to be assigned to WLAN devices DHCP lease time (s)
  • Page 107 Set each item Apply DHCP is set.

  • Page 108: Setting Mobile Network

    Setting Mobile Network Make advanced settings when using 4G/LTE/3G network. Setting Network Search Search for and set mobile network during international roaming. In Japan, always use auto-mode. Settings are not changed. In Menu List, Mobile Network Setting Mobile Network In network search mode, Manual Apply...
  • Page 109 Select the network Network search is set.
  • Page 110 International Roaming In Menu List, Mobile Network Setting Mobile Network Change International roaming Apply International roaming setting is changed. ・ When turning Disable Enable , information screen appears. Click to change international roaming setting.
  • Page 111 Creating Profile Set the following items and create profile. Item Description Profile name Enter profile name Enter APN User name Enter username Password Enter password Authorization method Select authorization method In Menu List, Mobile Network Setting Profile Management New profile...
  • Page 112 Set each item Apply Created profile appears for profile name.
  • Page 113 Editing Profile Edit already saved profile. Initial profile set by default and currently used profile cannot be edited. In Menu List, Mobile Network Setting Profile Management Select profile name Edit...
  • Page 114 Enter each item Apply Edited information appears.
  • Page 115 Deleting Profile Delete created profiles. Preset profiles are not deleted. In Menu List, Mobile Network Setting Profile Management Select profile name Delete...
  • Page 116 Profile is deleted. USIM PIN PIN (Personal Identification Number) is a code to prevent unauthorized use. ・ Set PIN verification to Enable to use Wi-Fi router by PIN entry on Wi-Fi router or WEB UI when Wi-Fi router is powered on. ・Incorrectly entering PIN code three consecutive times activates PIN Lock.

  • Page 117: Pin Verification

    PIN Verification Set PIN Verification. USIM PIN is "9999" by default. In Menu List, Mobile Network Setting PIN Management Set "PIN verification" to Enable Enter PIN code Apply PIN code entry from Wi-Fi router or WEB UI is required when Wi-Fi router is powered on.
  • Page 118 PIN Verification (WEB UI) Activate web browser and enter "http://web.setting" in address bar Enter four- to eight-digit PIN code Apply When correct PIN is entered, Home Page appears.
  • Page 119 PIN Verification (Wi-Fi Router) Slide Display up or down to unlock Enter four- to eight-digit PIN When correct PIN is entered, Home Screen appears.
  • Page 120 Changing PIN Change the PIN to any four- to eight-digit number if required. In Menu List, Mobile Network Setting PIN Management Set "PIN verification" to Modify Set required items Apply PIN is modified.
  • Page 121 Canceling PIN Verification Disable PIN verification. In Menu List, Mobile Network Setting PIN Management Set "PIN verification" to Disable Enter PIN code Apply PIN verification is canceled.

  • Page 122: Setting Wi-Fi Spot

    Setting Wi-Fi Spot Wi-Fi router connects to the Internet via a household or office WLAN router, SoftBank Wi-Fi spot, etc. This internet connection is called "Wi-Fi Spot." Simultaneous use of Wi-Fi spot and Multi-SSID (SSID B) is not available. Connecting to a New Network via Wi-Fi Spot...
  • Page 123 Turn "Wi-Fi Spot" to In access point to connect, Connect ・ Click Scan to re-scan surrounding Wi-Fi spot access points. ・ When of "Wi-Fi Spot" is clicked with Multi-SSID (SSID B) enabled, information screen appears. Click to disable Multi-SSID automatically. Enter password (Security Key) Connect Connection is established and "Connected"...
  • Page 124 Setting Up SoftBank Wi-Fi Spot Turning on SoftBank Wi-Fi Spot automatically connects when entering a SoftBank Wi-Fi Spot service area. ・SoftBank Wi-Fi Spot password is a four-digit security code set at subscription. In Menu List, Wi-Fi Spot Wi-Fi Spot Confirm that "Wi-Fi Spot" is set to Turn "SoftBank Wi-Fi spot"...
  • Page 125 Enter SoftBank Wi-Fi spot password Apply SoftBank Wi-Fi Spot setup is complete.
  • Page 126 ・ To edit access point, Edit set content Click Apply ・ To delete access point, Click Pre-set Access Points Four SoftBank Wi-Fi Spot access points are pre-set. Priority of those four access points cannot be changed or deleted.
  • Page 127 Setting IP Address Set the following items and set IP address. Item Description IP address Enter IP address Subnet mask Enter subnet mask Default gateway Enter default gateway Primary DNS server Enter primary DNS server Secondary DNS server Enter secondary DNS server In Menu List, Wi-Fi Spot IP Address Settings...
  • Page 128 Set each item Apply IP address settings are made.

  • Page 129: Router Setting

    Router Setting Set router function such as Firewall and IP address filter. Firewall Switch Set Firewall function. Setting items are as follows: Item Description Firewall Set whether to use Firewall function IP address filtering Set whether to use IP Address Filter function WAN port ping reply Set whether to enable WAN ping to respond In Menu List,...
  • Page 130 Set each item Apply Firewall is set.
  • Page 131 Setting IP Address and Port Filtering Set whether to apply rules and allow transmissions from Internet through Firewall, based on sender/receiver addresses. Setting items are as follows: Item Description LAN IP Address Set source IP address to apply rules; specify IP address from IP addresses used on LAN LAN Port Set source port number to apply rules WAN IP Address...
  • Page 132 In "Filter mode," Blacklist Whitelist...
  • Page 133 Enter each item ・To set IPv6 addresses, enter a prefix at the end of the IP address. ・ Turn Status to to filter set IP addresses and reject connection. ・ Turn Status to not to filter set IP addresses and permit connection. Use for temporarily deactivating filtering. Filtering is not canceled.
  • Page 134 Canceling IP Address and Port Filtering In Menu List, Router Setting IP Address Filtering In "Filter mode," Blacklist Whitelist...
  • Page 135 Delete Apply IP address filtering settings are canceled.
  • Page 136 Setting Portmapping Set a virtual server for accessing a specified device inside LAN via the Internet. Setting items are as follows: Item Description Name Name of virtual server WAN Port Set source port number Set IP address for device inside LAN to make available as a server; specify IP address from IP LAN IP Address addresses used on LAN Set destination port number for device inside LAN to make available as a server when...
  • Page 137 Enter each item ・ Turn Status to to activate portmapping. ・ Turn Status to to deactivate portmapping. Use for temporarily deactivating mapping. Mapping is not canceled.
  • Page 138 Apply Portmapping is set.
  • Page 139 Canceling Portmapping In Menu List, Router Setting Portmapping Delete...
  • Page 140 Apply Portmapping settings are canceled.
  • Page 141 Setting Special Applications Enable to use special applications such as online games and video phone system. Setting items are as follows: Item Description Name Name applications Status Set whether to apply rules Trigger Port Set port number for data control Trigger Protocol Select protocol for data control Open protocol...
  • Page 142 Enter each item...
  • Page 143 Apply Special application settings are added.
  • Page 144 Canceling Special Applications In Menu List, Router Setting Special Applications Delete...
  • Page 145 Apply Special application settings are canceled.
  • Page 146 Set specified device inside LAN as DMZ host isolated from other devices. Setting items are as follows: Item Description Select whether to set DMZ host DMZ IP address Set IP address for DMZ host In Menu List, Router Setting Set each item Apply DMZ host settings are applied.
  • Page 147 SIP ALG Set when using an SIP application to use Internet telephone, etc. Setting items are as follows: Item Description SIP ALG Select whether to enable SIP ALG function SIP port Enter port number provided by SIP service provider 1　SIP ALG is to be enabled when using SIP applications (e.g. X-Lite, Yate, Sipdroid, etc.) on a WLAN device connected to Wi-Fi router. If normal calling is not available with the SIP application, uncheck "SIP ALG"...
  • Page 148 Set each item Apply SIP ALG settings are applied.
  • Page 149 UPnP Set UPnP for using UPnP-compatible peripheral devices, audio visual devices, appliances and UPnP-compatible applications such as messenger software. Setting items are as follows: Item Description UPnP Set whether to use UPnP In Menu List, Router Setting UPnP Enable Disable Apply UPnP settings are applied.
  • Page 150 Convert private IP address used inside LAN to global IP address for connecting to the Internet. Setting items are as follows: Item Description Low security but normal operation of application; high compatibility with applications, Cone gaming device etc. Symmetric Used for higher security gateway Set how long to maintain a session when there is no transmission after a TCP session is Tcp Nat Time(s) established;...
  • Page 151 Cone Symmetric Enter each item Apply NAT settings are applied.
  • Page 152 Out of Service Notification Set whether to show notification when Wi-Fi router is out of network service area on the browser of a terminal accessing the Internet via Wi-Fi router. In Menu List, Router Setting Out Of Service Notification Turn On Turn Off Apply Out of service notification setting is applied.

  • Page 153: System

    Check Wi-Fi router device information and change login password for WEB UI. Also reset and reboot Wi-Fi router. Checking Wi-Fi Router Information Check device information such as software version. Item Description Device name Product name (601HW) IMEI Serial number Number Phone number saved to USIM Card Hardware version Hardware version...
  • Page 154 Changing Login Password for WEB UI Change Login password. ・For enhancing security, it is recommended to change Login password regularly. ・Set safer Login password when setting a new one. In Menu List, System Change Login Password Enter current password Enter a new password Re-enter the new password Apply New password is set and WEB UI Home Page appears.
  • Page 155 Setting Power Save Set Power Save Setting to ON to save power consumption during use for longer usage time. The maximum communication speed of mobile network and WLAN is reduced to save power consumption. In Menu List, System Power Save Setting Apply Power save setting is made.
  • Page 156 Setting USB Tethering Set USB standard. In Menu List, System USB Tethering USB2.0 USB3.0 Apply USB communication standard is set.
  • Page 157 Resetting Wi-Fi Router Restore Wi-Fi router settings to their factory defaults. ・All settings are restored except contents in USIM Card. ・Alternatively, use Reset Button of Wi-Fi router. See description of Reset Button in "Front/Top/Bottom." In Menu List, System Factory Data Reset Reset...
  • Page 158 Wi-Fi router reboots to its default settings.
  • Page 159 Rebooting Wi-Fi Router In Menu List, System Reboot Reboot...
  • Page 160 Wi-Fi router is rebooted.

  • Page 161: Showing/Setting Data Usage

    Check data traffic volume. Also, set maximum traffic or reset date for data traffic. Data traffic is an estimation. May differ from actual traffic volume. For actual traffic volume, contact SoftBank Customer Support. Data traffic does not include Wi-Fi spot communication.
  • Page 162 Setting Auto Reset Date Set date of month for automatically resetting accumulated data traffic. In Main Menu, Data Traffic Setting...
  • Page 163 Select date for resetting Apply Auto reset date is set. ・Value number is selected between 1 and 31. ・If 31 is set, data traffic is reset at the end of the month. "Reset" and "Auto Reset" The reset items differ in "Reset" and "Auto Reset." With "Reset,"...
  • Page 164 Setting Maximum Traffic Set monthly data traffic volume. When data traffic volume exceeds the set volume, notification icon etc. appears in Home Screen of Wi-Fi router. ・ When " Monthly" is selected to show data traffic volume on Home Screen of Wi-Fi router, (bar icon) is shown on Home Screen.
  • Page 165 Enter number for data traffic Select units Apply Maximum traffic is set. ・Enter value between 1 and 999. ・Set data volume in GB/MB.
  • Page 166 Resetting Data Traffic In Main Menu, Data Traffic Reset...
  • Page 167 Data traffic volume is reset.

  • Page 168: Confirming Information

    Confirming Information Information is received by Wi-Fi router. Confirming Information In Main Menu, Information Select information to confirm Information is shown.
  • Page 169 Deleting Viewed Information In Main Menu, Information Select information...
  • Page 170 Delete Information is deleted after pop-up screen is shown.
  • Page 171 Selecting and Deleting Information In Main Menu, Information Checkmark information to delete ・Checkmark "Select All" to select all.
  • Page 172 Delete Information is deleted after pop-up screen is shown.

  • Page 173: Setting Software Update

    Setting Software Update Make settings for software updates. Turn auto-software update to Enable to automatically update. If it is Disable , Wi-Fi router checks updates but does not update automatically. Setting Auto-Software Update In Main Menu, Software Update Enable Disable Auto-software update downloading turns Enable Disable...
  • Page 174 Updating Software In Main Menu, Software Update Update Wi-Fi router checks the latest software. ・When software is the latest, "The latest version" appears. If not the latest, software is updated. Software Update Packet communication charges are not applied for software update. While software is updated, other functions are disabled.

  • Page 175: Setting From Mobile Device

    Access WEB UI from a smartphone etc. to show WEB UI page for mobile devices. Activating WEB UI from Mobile Device ・SoftBank Corp. does not guarantee compatibility with all mobile devices. ・Available functions differ in WEB UI for mobile devices and WEB UI for computers.
  • Page 176 Logging In to WEB UI from Mobile Device In WEB UI Home Page, Settings Login window opens. Enter Login password Login Settings open. ・"admin" is set for Login password by default. For Login password, see "Changing Login Password for WEB UI."...
  • Page 177 Show accumulated data traffic at the moment from start of connection Settings Show settings for all functions Customer Support Connect SoftBank website and open Support Site of 601HW User Manual Connect SoftBank website and open User Manual of 601HW PC View...
  • Page 178 : 4G connected : LTE connected : 3G connected ・Wi-Fi spot Icons :Wi-Fi spot connected (including SoftBank Wi-Fi Spot) ・Internet connection status : Appears when Internet connected : Appears when Internet not connected ・WLAN status : Appears when WLAN is ON, operating at 2.4 GHz (Wi-Fi) : Appears when WLAN is ON, operating at 5 GHz (Wi-Fi) Number below Wi-Fi communication standard (2.4G/5G) is current number of connected WLAN...
  • Page 179 Layout Other than Home Page Item Description Log Out Log out from WEB UI Home Return to Home Page Menu Show settings for all functions...

  • Page 180: Setting Lan Wi-Fi (On Mobile)

    Setting LAN Wi-Fi (on Mobile) LAN Wi-Fi Sleep Settings Setting items are as follows: Item Description Set whether to disable WLAN function automatically when Wi-Fi router does not connect to Sleep Mode Settings WLAN devices; WLAN function is not turned off while charging even if Sleep Mode Settings is In WEB UI menu, Settings Login window opens.
  • Page 181 Enter Login password Login Settings open. LAN Wi-Fi...
  • Page 182 Set time until entering Sleep mode Apply ・ Select to disable Sleep setting. Sleep mode setting is complete.
  • Page 183 LAN Wi-Fi Basic Settings (SSID A) Make basic WLAN settings for Wi-Fi name (SSID A). ・Setting items are as follows: Item Description SSID Set Wi-Fi name (Network Name) Authorization method Set authorization method Encryption method Set encryption method Appears when "WPA2-PSK" or "WPA/WPA2-PSK" is selected in "Authorization method;" enter WPA security key password (Security Key) Appears when "Auto,"...
  • Page 184 Enter Login password Login Settings open. LAN Wi-Fi...
  • Page 185 Set each item Apply LAN Wi-Fi basic settings for Wi-Fi name (SSID A) are made.
  • Page 186 Enabling Multi-SSID Function (SSID B) Make basic WLAN settings for Wi-Fi name (SSID B). ・To use Wi-Fi name (SSID B), turn off Wi-Fi spot function. Connect to the Internet via mobile network. ・Wi-Fi name (SSID B) does not support WPA/WPA2. ・When Multi-SSID is enabled, connect to Wi-Fi name (SSID A) up to 7 devices, and Wi-Fi name (SSID B) up to 6 devices.
  • Page 187 Enter Login password Login Settings open. LAN Wi-Fi...
  • Page 188 Turn "SSID B" to ・ Information screen appears when Tapping of "SSID B" with Wi-Fi spot enabled. Tap to disable Wi-Fi spot function automatically. Set each item Apply...
  • Page 189 LAN Wi-Fi basic settings for Wi-Fi- name (SSID B) are made.

  • Page 190: Setting Mobile Network (On Mobile)

    Setting Mobile Network (on Mobile) Connect to a 4G/LTE/3G network with Wi-Fi router and make detailed settings. International Roaming In WEB UI menu, Settings Login window opens. ・ When already logged in, go to step Enter Login password Login Settings open.
  • Page 191 Mobile Network Change International roaming Apply International roaming setting is changed. ・ When turning Disable Enable , information screen appears. Click to change international roaming setting. ・The mobile network can be set manually during International roaming. For details, see "Setting Mobile Network."...

  • Page 192: Showing/Setting Data Usage (On Mobile)

    Showing/Setting Data Usage (on Mobile) Check data traffic volume. Also, set maximum traffic or reset date for data traffic. Data traffic is an estimation. May differ from actual traffic volume. For actual traffic volume, contact SoftBank Customer Support. Checking Data Traffic Volume Accumulated data traffic volume at the moment from start of use or reset is shown.
  • Page 193 Data Usage Data traffic volume is shown. ・ Data traffic volume to present for Maximum Traffic set in Data Usage is shown. For setting maximum traffic, see "Setting Maximum Traffic."...
  • Page 194 Setting Auto Reset Date Set date of month for automatically resetting accumulated data traffic. In WEB UI menu, Settings Login window opens. ・ When already logged in, go to step Enter Login password Login Settings open.
  • Page 195 Data Usage Select date for resetting Apply Auto reset date is set. ・Value number is selected between 1 and 31. ・If 31 is set, data traffic is reset at the end of the month.
  • Page 196 "Reset" and "Auto Reset" The reset items differ in "Reset" and "Auto Reset." With "Reset," reset this month, current day, a day ago, two days ago, three days ago immediately. With "Auto Reset," data traffic for this month resets as the date changes to the day after the auto reset date. Data traffic after the reset date continues to accumulate.
  • Page 197 Setting Maximum Traffic Set monthly data traffic volume. ・Maximum traffic does not mean a limit on data communication. Use this volume as measure of usage. In WEB UI menu, Settings Login window opens. ・ When already logged in, go to step Enter Login password Login Settings open.
  • Page 198 Data Usage Enter number for data traffic Select units Apply Maximum traffic is set. ・Enter value number between 1 and 999. ・Set data volume in GB/MB.
  • Page 199 Resetting Data Traffic In WEB UI menu, Settings Login window opens. ・ When already logged in, go to step Enter Login password Login Settings open.
  • Page 200 Data Usage Reset...
  • Page 201 Data volume is reset.

  • Page 202: Confirming Information (On Mobile)

    Confirming Information (on Mobile) Information is received by Wi-Fi router. Confirming Information In WEB UI menu, Settings Login window opens. ・ When already logged in, go to step Enter Login password Login Settings open.
  • Page 203 Information Information is shown. Select information to confirm Information is shown.
  • Page 204 Selecting and Deleting Information In WEB UI menu, Settings Login window opens. ・ When already logged in, go to step Enter Login password Login Settings open.
  • Page 205 Information Checkmark information to delete ・Checkmark "Select All" to select all.
  • Page 206 Delete Information is deleted after pop-up screen is shown.

  • Page 207: Checking Wi-Fi Router Information (On Mobile)

    Checking Wi-Fi Router Information (on Mobile) Checking Wi-Fi Router Information Check device information such as software version. Item Description Device name Product name (601HW) IMEI Serial number Number Phone number saved to USIM Card Hardware version Current hardware version Software version...
  • Page 208 Enter Login password Login Settings open. Device Information Information is shown.

  • Page 209: Appendix

    Appendix Troubleshooting.............. 208 Specifications..............211 Warranty & Service............213 Customer Service............214...

  • Page 210: Troubleshooting

    Confirm that Wi-Fi router is properly connected to PC. Remove Wi-Fi router from PC, restart PC, then If symptoms continue even after checking, contact a nearby reconnect Wi-Fi router. SoftBank Shop or Customer Service. Follow these steps to confirm proper Wi-Fi router installation.
  • Page 211 PC does not recognize Wi-Fi router by USB connection Transmission fails (Windows Vista) Signal may be weak. Move to where signal is stronger. Confirm that Wi-Fi router is properly connected to PC. Check Battery of Wi-Fi router. If Battery is low, Remove Wi-Fi router from PC, restart PC, then charge Battery with PC using USB Cable or AC Charger reconnect Wi-Fi router.
  • Page 212 When Power save setting is ON, the maximum communication speed is reduced to save power Resetting factory defaults (Reset) consumption. Turn Power save setting to OFF. For Use Reset Button or WEB UI to reset. For details, see details, see "Using Power Save Setting"...

  • Page 213: Specifications

    Description the Internet through the access point of the public Product Name 601HW WLAN service, duplicating the IP address of the LAN Wi-Fi and Wi-Fi spot may occur and Internet connection Approx. 65.1 mm (H) × 109.9 mm (W) ×...
  • Page 214 Battery Upstream: 2496 MHz to 2690 MHz, 3480 Mhz to 3600MHz Item Description Downstream: 2496 MHz to 2690 MHz, 3480 Mhz to 3600MHz Product Name Battery (HWBCK1) FDD-LTE: Voltage 3.8 V Upstream: B1 (1920 MHz to 1980 MHz), Type Lithium-ion polymer battery B2 (1850 MHz to 1910 MHz), B3 (1710 Capacity 2400 mAh...

  • Page 215: Warranty & Service

    Precautions This product contains free software complying with GNU Damages General Public License (Version 2). For details, refer to the SoftBank Corp. is not liable for any damages resulting from following web page use of Wi-Fi router. http://consumer.huawei.com/minisite/copyright_notice/ or contact mobile@huawei.com.

  • Page 216: Customer Service

    Information. For repairs, call Customer Assistance. SoftBank Customer Support General Information From a SoftBank handset, dial toll free at 157 From a landline/IP phone, dial toll free at 0800-919-0157 For Customer Assistance From a SoftBank handset, dial toll free at 113...

  • Page 217: Safety Precautions

    Safety Precautions Safety Precautions............216 General Notes..............223 Specific Absorption Rate (SAR) Information for this Product................225...

  • Page 218: Safety Precautions

    Safety Precautions Wi-Fi Router, USIM Card, Battery, USB Cable Charger Read safety precautions before using Wi-Fi router. Observe precautions to avoid injury to self or others, or damage to property. Labels & Symbols Do not use, store, or leave Wi-Fi router/ These labels indicate the degree of risk from improper use.
  • Page 219 Do not charge Wi-Fi router/related hardware while wet with liquids such as water (beverage, Do not drop, step on, throw or otherwise sweat, sea water, pet urine, etc.). subject to strong force, impact or vibration. May cause fire, burns, injury, electric shock, etc. May cause fire, burns, injury, electric shock, etc.
  • Page 220 Wi-Fi Router Do not use Wi-Fi router/related hardware when damaged. May cause fire, burns, injury, etc. Do not heat or dispose of Wi-Fi router in fire. Battery may ignite, burst, overheat, or leak, and may result in fire, burns, injury, etc. Do not place Wi-Fi router/related hardware on unstable/uneven surfaces.
  • Page 221 Do not put liquid such as water (beverage, If you damage Display and the internal matter sweat, sea water, pet urine, etc.) or foreign leaks, do not let it get on face or hands, on objects such as anything metal or flammable clothes, etc.
  • Page 222 May cause ignition, resulting in fire, burns, injury, etc. May cause environmental destruction. Tape terminals to insulate them, and bring it to a nearby SoftBank Shop or follow municipality regulations. Do not heat or dispose of Battery in fire.
  • Page 223 AC Charger & USB Cable Do not apply excessive force where Wi-Fi router is connected to USB Cable. May cause fire, burns, injury, electric shock, etc. Do not use AC Charger (sold separately)/USB Cable if these cords are damaged. May cause fire, burns, electric shock, etc. Do not touch AC Charger (sold separately) cord/USB Cable, terminals, or power plug with wet hands.
  • Page 224 Wi-Fi Router Use & Electronic Medical Equipment If charging terminal is bent or otherwise deformed, stop using Wi-Fi router immediately. Do not fix the deformed shape to use it. May cause short circuit, resulting in fire, burns, injury, electric shock, etc. Persons with an electric medical device such as an implanted pacemaker or implanted cardioverter defibrillator should keep Wi-Fi...

  • Page 225: General Notes

    ・Files may be lost or damaged in the following situations. malfunction. Wi-Fi router or related hardware may become SoftBank Corp. is not liable for damages incurred due to too hot to touch, leading to burn injuries, etc. lost or altered information. To minimize damages, back up ・Wi-Fi router may become hot while in use or while charging...
  • Page 226 Touchscreen Wi-Fi (Wireless LAN) ・Do not press Display surface with nails, sharp or hard Wi-Fi router uses 2.4 GHz frequency band WLAN between object, etc. forcibly. May cause scratch or damage. Touch 2400 MHz and 2483.5 MHz. lightly with your fingers. Do not push Display with your Wireless Frequencies &...

  • Page 227: Specific Absorption Rate (Sar) Information For This Product

    - Inquire with Customer Service to consult if you are unable Specific Absorption Rate (SAR) to configure the security settings. Information for this Product (for - SoftBank Corp. cannot be held liable for WLAN security Japan) issues. This product [601HW] meets Japanese technical regulations* and international guidelines for exposure to radio waves.
  • Page 228 -World Health Organization http://www.who.int/emf -List of Specific Absorption Rates (SAR) for radio waves by smartphone/3G model http://www.softbank.jp/mobile/support/sar/ (Japanese)
  • Page 229 Activating WLAN (Wi-Fi) Function........21 Ｃ Charging Battery.............. 14 Checking Help..............80 Checking Wi-Fi Router Information........ 79 601HW User Guide Index Checking Wi-Fi Router Information (on Mobile)..205 Checking WLAN Connected Device Information....61 Confirming Information..........166 Confirming Information (on Mobile)......200 Confirming Notifications..........58 Connecting Android™...
  • Page 230 Ｏ Ｗ on Mobile.................178 Warranty & Service............213 on Mobile.................188 WEB UI Window on PC............. 91 on Mobile.................190 Wi-Fi...................20 on Mobile.................200 Wi-Fi...................21 on Mobile.................205 Windows PC...............43 Operation for Setting Maximum Traffic......81 WLAN (Wi-Fi)..............20 Other Settings..............68 Overview of WEB UI............88 Ｐ...
  • Page 232 601HW User Guide March 2017, First Edition SoftBank Corp. Visit SoftBank Shop for assistance Model : 601HW Manufacturer : HUAWEI TECHNOLOGIES CO., LTD.

Table of Contents
