Procom PCK110VT Owner's Manual page 22

1
16
KEY
NO. PART NO.
1 160001-01
2 160023-01
3 160003-01
4 160006-01
5 160088-01
6 160007-01
7 160009-01
8 160008-01
9 160010-01
10 160057-01
11 160106-01
12 160024-01
13 160090-01
14 160089-01
15 160029-01
16 160004-01
KEY
NO. PART NO.
1 160041-03
2 160092-02
3 160016-01
22
MOTOR AND PUMP ASSEMBLY
3
2
15
DESCRIPTION
Motor
Rotor Insert
Pump Rotor
Pump Body
Screw, 10-32 x .62
Pump Cover
Lint Filter
Output Filter Assembly
Intake Filter
Filter End Cover
Adjusting Screw
Pipe Plug
Screw, 10-32 x 1.0
Screw, 10-32 x 1.12
90° Nylon Elbow
Pump Blade
PHOTOCELL ASSEMBLY
1
DESCRIPTION
Photocell Bracket
Screw, 6-32 x .38
Photocell Assembly
www.usaprocom.com
PARTS
4
5
6
14
2
8
7
9
13
QTY QTY QTY
110 160 175
1 1
1 1
1 1
1 1
2 2
1 1
1 1
1 1
1 1
1 1
1 1
1 1
3 3
6 6
1 1
4 4
3
QTY QTY QTY
110 160 175
1 1
2 2
1 1
10
11
12
QTY
220
1 1
1 1
1 1
1 1
2 2
1 1
1 1
1 1
1 1
1 1
1 1
1 1
3 3
6 6
1 1
4 4
QTY
220
1 1
2 2
1 1
160108-01
