Feiyu Electronics Company
FY31AP Flight Modes (SW 1)
a) The FY31AP has three flight modes controlled by SW-1.
b) You can activate any of the flight modes via a free Receiver channel and a 3-position
switch on your computer radio connected to the SW 1 interface on the FY31AP.
c) Mode 1: Deactivated Mode. In this mode, all control of the aircraft is by the pilot. The
FY31AP does not participate in flight control.
d) Mode 2: Stabilized mode
the FY31AP will continuously send out controlling signal (aileron, elevator, rudder) to
ensure the aircraft maintains a stabilized, horizontal flight and constant flight direction.
In this mode FY31AP will not allow acrobatic flights.
e) Model 3: Airline flight mode, in this mode, the waypoint will be set according to the
flight path to automatic flight.
FY31AP Autonomous Flight Modes (SW 2)
a) Three autopilot modes are incorporated into the FY31AP controlled by SW 2.
b) You may set the modes via a free receiver channel and a 3-position switch.
c) Autopilot mode 1: Deactivated. The autopilot function is not activated.
d) Autopilot mode 2: Auto Return To Launch
FY31AP will automatically fly the plane back to the take-off point, while maintaining
altitude. Upon reaching the launch area, the unit will automatically fly the plane in a circle
at a default circling radius of 120 meters.
e) Autopilot mode 3: Auto Circling Mode (ACM). When activated in this mode, the
plane will immediately fly in a circle.
default circle radius is 120 meters. The aircraft altitude will be automatically maintained
throughout the ACM.
8 |
P a g e
.
In this mode and your transmitter control sticks at center,
RCL
¡
The centre of the circle is the point of activation.
. When activated in this mode, the
¢
The
