D Rapid charging with the BC-214
The BC-214
multi charger
to 6 Li-ion battery packs.
The BC-214 is used with the BC-157S
the OPC-656
dc power cable
• Charging time of the BP-280
Approximately 3.5 hours
can simultaneously charge up
or
power adapter
(purchase separately).

BATTERY CHARGING

Transceiver
+ Battery pack
Battery
pack only
Turn OFF the power
Power adapter
(A different type is
supplied, depending on
the charger version.)
BC-214
DC power cable (OPC-656)
(Connect with a DC power supply,
13.8 V/at least 7 A)
CAUTION: DO NOT connect the OPC-
656 to a power source using reverse po-
olarity. This will ruin the battery charger.
Red line:
3
Black line :
10
