Display Description
22
VFC
21
20
19
18
17
1.
Relative mode
2.
See units prefix list below
3.
Ohms (Resistance)
4.
Hertz (Frequency)
5.
See units prefix list below
6.
Voltage
7.
See units prefix list below
8.
Amperes (Amps) Current
9.
Farads (Capacitance)
10.
Percent (%) duty cycle (for AC only)
11.
Battery status icon
12.
APO (Auto Power OFF) active
13.
Measurement reading digits
14.
Non‐contact voltage detector (displays EF in reading area)
15.
Auto Range is shown in Auto Range mode
16.
MAX‐MIN memory active
17.
Data Hold active
18.
Continuity test (Resistance)
19.
Diode test
20.
Minus (negative) sign
21.
AC (alternating current) or DC (direct current) mode
22.
VFC (low pass filter) Variable Frequency Control
Measurement unit prefixes
‐9
n
nano (10
) (capacitance)
‐6
µ
micro (10
‐3
m
milli (10
) (volts, amps)
3
k
kilo (10
) (ohms)
6
M
mega (10
) (ohms)
3
5
1
2
4
15
16
) (amps, cap)
7
8 9 10 11
6
14
6
12
13
MN62‐en‐GB_V1.1 12/15
