Product Description
3.4 Display Description
1.
Automatic range.
2.
Data Hold.
3.
Measurement reading.
4.
Maximum and Minimum
readings.
5.
Relative (zero).
6.
Diode test.
7.
Continuity test.
8.
Low Pass Filter.
9.
Low impedance.
10. Unit of measure and range
prefixes.
11. Bar graph (arrow on the right
of the graph indicates over-
range condition).
12. Low battery.
13. Alternating Current.
14. Negative polarity (minus).
15. Direct Current.
16. Auto Power Off (APO)
enabled.
#NAS100179; r. AA/97576/97580; en-US
Figure 3.3 Display Description
8
