Fig. 2 - ReServ1WPV
unswitched
220VAC
60Hz, 2 amp
power mains
(non power-limited)
power-
limited
Green
Lead
12VDC Rechargeable Battery
ReServWPV
Non-power limited
CAUTION: Risk of explosion if battery is replaced by an
incorrect type. Dispose of used batteires according to the instructions.
(order separately)
Note: Two (2) 12VDC rechargeable batteries
connected in series required.
--- 24VDC +
LOW BATTERY
SHUTDOWN
P
N
1
2
3
4
5
6
7
8
12VDC
Power-
Power-Limited Outputs
Limited
Outputs
Supervised - Non power-limited
12VDC Rechargeable Battery
(order separately)
Input
9
10 11 12 13 14 15 16
24VAC
- 5 -
