| Chapter 2: Installation
Refer to
•
shipping bracket and screws from the back of the reader.
Pull down the door to the carrier compartment.
•
Install the carrier shipping bracket to the front of the carrier and mounting
•
block.
Refer to
Figure 4
Place two foam caps into the bottom of the shipping container.
1.
Slide the accessories box into the shipping container.
2.
Place the reader inside its plastic bag and carefully lower it into the two
3.
foam caps in the bottom of the box. Note the orientation of the reader in the
box.
Place two foam caps over the reader.
4.
Place the power supply, cord, and communication cables into the
5.
accessories box.
Close the top of the box and secure it with shipping tape. When finished,
6.
write the RMA number on the outside of the box and ship the box to
BioTek.
on page 27. Using a screwdriver, remove the carrier
Figure 1
on page 33 when performing these steps:
