Proportional Valve Group PVG 32
PVM - Montering af håndtag

PVM - Installation of lever

PVM - Montage von Hebel
PVM - Montage de manipulateur
Håndtaget skal skrues helt i bund
Screw the lever completely home
Den Hebel völlig einschrauben
Visser le manipulateur entierement au fond
PVE - Montering

PVE - Installation

PVE - Montage
PVE - Installation de PVE
PVEO/M/A Series 7
5 [0.2]
8 ± 0.5 Nm
[70 ± 4.4 lbf in]
PVEH/S Series 7
5 [0.2]
8 ± 0.5 Nm
[70 ± 4.4 lbf in]
6
3 (1±0.15N•m)
PVEP Series 4
5 [0.2]
8 ± 0.5 Nm
[70 ± 4.4 lbf in]
PVED-CC Series 4
5 [0.2]
8 ± 0.5 Nm
[70 ± 4.4 lbf in]
AN00000350xx-04 • Rev 0102 • Mar 2017
8 ±1 N•m
P109143
PVED Series 5
5 [0.2]
8 ± 0.5 Nm
[70 ± 4.4 lbf in]
© Danfoss A/S, 2017-03
P109144
