Advantech PCM-9365 Startup Manual

PCM-9365
Intel Celeron
®
2GB/4GB On-board Memory, VGA, 48-bit LVDS, 2GbE,
Mini PCIe, PCI-104, SUSI 4
Startup Manual
Packing List
Before you begin installing your card, please make sure that
the following items have been shipped:
1. 1 PCM-9365 SBC
2. 1 Startup Manual
3. 1 RS-232 COM3/4 cable
4. 1 SATA power cable
5. 1 RS-232 COM2 cable
6. 2 USB Cable
7. 1 SATA Cable
8. 1 Audio cable
9. 1 Heatsink
10. mini jumper pack
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note 1:
For detailed contents of PCM-9365, please refer
to Advantech website for detailed information.
Note 2: Acrobat Reader is required to view any PDF
file. Acrobat Reader can be downloaded at:
http://get.adobe.com/reader/ (Acrobat is a trade-
mark of Adobe)
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
For technical support and service, please visit our
support website at:
http://support.advantech.com
This manual is for the PCM-9365 Series Rev. A1
Part No. 2006936500
Printed in China
N2930 & Atom™ E3825, 3.5" SBC,
®
p/n: 1701200220
p/n: 1700018785
p/n: 1700019414
p/n: 1700018730
p/n: 1700008941
p/n: 1700019584
p/n: 1960067897T001
p/n: 9689000002
1st Edition
June 2015
Specifications
General
• CPU: Intel
Celeron N2930 Quad Core 1.83 GHz, burst
® ®
frequency 2.16GHz/ Atom™ E3825 Dual Core 1.33 GHz
• System Memory: 2GB/4GB DDR3L on-board memory,
N2930 with 1333MHz, E3825 with 1066MHz
• L2 Cache: 2 MB (N2930) / 1 MB (E3825)
• BIOS: AMI uEFI 64 Mbit
• Watchdog Timer: 255 levels timer interval, programmable
by software. Multi-level WDT (set by SUSI 4)
• Battery: Lithium 3 V/210 mAH
• Audio: High definition audio (HD), line-in, line-out, Mic-in

Expansion Interface

• 1 x Full-size Mini PCIe
• 1 x Full-size mSATA
• 1 x PCI-104
Display
• Controller: Intel
Gen 7 graphics and media encode/
®
decode engine
• Maximum Resolution:
- VGA: 2560 x 1600 @ 60 Hz
- HDMI (support by request):
* HDMI 1.4a with audio, 1920x1080
- LVDS/eDP:
* 48-bit LVDS up to WUXGA 1920 x 1200 at
60Hz, the 2nd LVDS is supported by request
- Dual Display: VGA + LVDS, HDMI+ LVDS, LVDS + LVDS
(HDMI and the 2nd LVDS are supported by request)

Ethernet Interface

• Speed: 10/100/1000 BASE-T
• Controller: Realtek RTL8111E-VL-CG

Mechanical and Environmental

• Dimensions: 146 x 102 mm (5.7" x 4")
• Power Supply Type: ACPI support
• Power Requirement: +12 V ± 10%
• Power Consumption:
- Typical in Window 8:
PCM-9365E-2GS3A1E :0.39A @ 12V (4.68W)
PCM-9365EV-4GS3A1E : 0.44A @ 12V (5.28W)
PCM-9365N-4GS8A1E: 0.509A @ 12V (6.108W)
- Max in HCT:
PCM-9365E-2GS3A1E :0.49A @ 12V (5.88W)
PCM-9365EV-4GS3A1E : 0.554A @ 12V (6.648W)
PCM-9365N-4GS8A1E: 0.745A @ 12V (8.94W)
• Operating Temperature: 0 ~ 60 °C (32 ~ 140 °F)
• Weight: 0.54 kg (1.19 lb) (reference total weight)
PCM-9365 Startup Manual 1
