Page 1 Cat. No. Z147-E1-02 F160 Vision Sensor Manual 3: EXPERT MENU OPERATION MANUAL...
Page 2 F160 Vision Sensor Manual 3: Expert Menu Operation Manual Revised June 2002...
Page 4 OMRON Product References All OMRON products are capitalized in this manual. The word “Unit” is also capitalized when it refers to an OMRON product, regardless of whether or not it appears in the proper name of the product. Visual Aids The following headings appear in the left column of the manual to help you locate different types of information.
Page 6: Table Of Contents
Run Mode ........... . . 61 Saving Settings and Exiting the F160 ....... . 63 SECTION 3 Selecting and Setting Measurement Methods .
Page 7 TABLE OF CONTENTS Display Details..........225 Display Strings.
Page 8 TABLE OF CONTENTS Index..........329 Revision History .
Page 10: About This Manual
This manual describes setup procedures for the F160 Vision Sensor and it includes the sec- tions described below. This is one of four manuals used to operate the F160. Refer to the following table for the contents of each manual.
Page 12: Expert Menu Features
SECTION 1 Expert Menu Features This section explains the features of the Expert Menu mode and its compatibility with the Conversational Menu mode. Special Features of the Expert Menu....... . Types and Features of Measurement Methods .
Page 13: Special Features Of The Expert Menu
Section 1-1 Special Features of the Expert Menu Special Features of the Expert Menu Seventeen Measurement Methods for Various Detection Needs Select the measurement method according to application. Complicated detection is also possible, by combining multiple measurement methods and with detailed settings. •...
Page 14 Section 1-1 Special Features of the Expert Menu SeeAlso Refer to page 211. Up to 35 Screens of NG Measurement Object Images Past defects can be checked on screen. Saved images are cleared when the power is turned OFF. Images can be saved as bitmaps, which are useful when creating reports or operating procedures.
Page 15: Types And Features Of Measurement Methods
Section 1-2 Types and Features of Measurement Methods • The display method for the measurement results can also be changed as required. Fixed figures, such as lines, can always be displayed. (Useful as a guide to the position of the measurement object.) 0.LABEL OK 67ms Figures can be displayed at...
Page 16 Section 1-2 Types and Features of Measurement Methods Guide to Selecting Measurement Methods Measurement target Example Typical application measurement examples methods Size (area) Gravity and area Detect presence (expiration dates, parts, etc.) Area (var. box) Detect adhesive coatings. Detect caulking of metal parts. Position Center of gravity coor- Gravity and area...
Page 17: Features Of Measurement Methods
Right edge Left edge Lower edge With the edges detected, the F160 can determine where the measurement object is. Even if the size and position of the measurement object changes, the F160 can move the measurement region appropriately. Measurement region...
Page 18 Types and Features of Measurement Methods The image read by the Camera is a 256-gradation image. This is converted to a binary image made up of black and white pixels. The F160 focusses on the white areas only and performs measurement.
Page 19 OCR for 1 Character Use an OCR for 1 character measurement to recognize alphanumeric charac- ters and special symbols. The F160 provides a dictionary, so no models need to be registered. The F160 recognizes two candidates, 1st candidate and 2nd candidate, from the dictionary, that are most similar to the character image in the measurement region.
Page 20 Section 1-2 Types and Features of Measurement Methods The F160 outputs the number of the index for the model that most resembles the image. If there is no model that resembles the image, NG is output. Once that data has been received by the external device, the product can be classi- fied at the next processing stage.
Page 21 Section 1-2 Types and Features of Measurement Methods The difference in density is compared, so there will be little influence on the measurement if the overall image is dark due to deteriorated lighting. OK product NG product (no part) Part Background Average density: 30 Average density: 200...
Page 22 Section 1-2 Types and Features of Measurement Methods The edge is found by density changes within the measurement region. Set the search direction and color changes for each region. Meaurement region Want to find the X coordinate of this edge. Direction: →...
Page 23 Section 1-2 Types and Features of Measurement Methods The part of an input image that is most similar to the model is found, the degree of similarity is expressed with a correlation value, and the search coor- dinates (X, Y) are found. Correlation : 95 Search coordinates: (180, 291) Search...
Page 24 Section 1-2 Types and Features of Measurement Methods Images read by the Camera are converted to binary images and the white pix- els are extracted as labels. (Any value can be set to the judgement values to determine what area of white pixels becomes a label.) Measurement region Labels are extracted and the area and gravity coordinates found.
Page 25: Compatibility With Conversational Menu
Section 1-3 Compatibility with Conversational Menu the center position of the model becomes the search coordinates. (The search coordinates can be changed.) Model The angle of the measurement object is found in relation to the reference image (model) for the input image. Angle Compatibility with Conversational Menu Scene Data...
Page 26: Operational Flow
Operational Flow Turn ON the power. Preparations for Detection Starting the Expert Menus. Refer to page 22. See Starting the F160 and Dis- playing Images. SeeAlso Refer to page 35 for information on setting detection conditions. Refer to this section to learn about the basic operational flow from setting detection condi- tions to executing measurements.
Page 27: Menus
See Editing Measurement Regions and Position Compensation Regions. Saving Settings Save detection conditions. Refer to page 63. See Saving Settings and Ex- iting the F160. Back up image, system, and scene data. Refer to page 258 for information on how to back up settings.
Page 28 Section 1-5 Menus P.252 (0 to 31) P.37 Adjust Shutter Speed P.38 Light control P.41 Filtering order (Position) P.42 Filtering (Position) The structure of the P.44 BGS levels (Position) SET Menu will P.41 change when two Filtering order (Measurement) cameras are P.42 Filtering (Measurement) P.185...
Page 29 Section 1-5 Menus P.58 P.61 P.284 Camera settings Communications Serial Refer to Communications Normal Reference Host Link Manual . Parallel Output P.286 Output device P.287 Serial P.288 Memory card P.290 Display Display settings P.297 Monitor P.298 Designate colors P.299 Make colors Operation settings P.301 Set key operation...
Page 30: Menus For Two Cameras
Section 1-5 Menus 1-5-2 Menus for Two Cameras P.37 Adjust 0 Shutter Speed P.38 Light control P.41 Filtering order (Position) P.42 Filtering (Position) P.44 BGS levels (Position) P.41 Filtering order (Measurement) P.42 Filtering (Measurement) P.185 Sampling input P.44 BGS levels (Measurement) Specifying point P.190 P.000...
Page 31 Section 1-5 Menus Adjust 1 (Same as Adjust 0.) Camera 1 Same as 1st region. P.198 Position 1 3rd region (P4, P5) P.198 3rd direction P.198 4th region (P6, P7) P.198 4th direction (Same as Measurement 0.) Measurement 1 (16 to 31) P.211 Expression Variable...
Page 32: Basic Operations
Performing Measurement ....... . . Saving Settings and Exiting the F160 .......
Page 33: Starting The F160 And Displaying Images
Starting the F160 and Displaying Images Starting the F160 and Displaying Images This section describes how to start the F160 Expert Menus and how to display images on the monitor. Refer to the displayed image when adjusting the Cam- era position and focus.
Page 34: Displaying Images And Focussing
When the settings have been completed, it is useful to use Startup Mode when actually operating the F160. Startup Mode is used to set the startup conditions (display screen) when the F160 is next started. For example, set the F160 to start in Run Mode. This will allow measurements to be started immediately and will make day-to-day operations easier.
Page 35: Menu Operations
Setup Manual to focus the Camera. CHECK The light level for Intelligent Lighting can be adjusted from the F160. Refer to page 38. • When using a Camera Unit, turn the focus ring to focus the Camera.
Page 36: Screen Displays
Menu operations can be performed from a personal computer via a serial interface. Refer to the Communications Reference Manual. 2-2-2 Screen Displays The F160 is operated by selecting functions displayed on the screen. Familiar- ize yourself with each function before operating the F160. Scene Number Mode The current operating mode is displayed.
Page 37: Menu Tree
2-2-3 Menu Tree F160 menus are hierarchical. The cursor is moved to the required functions to set measurement conditions. Use the following procedure to move around the menu tree. Move the cursor to the desired function in Set Mode using the Up, Down, Left, and Right Keys.
Page 38 Menu Operations Move the cursor to the item to be set. In this example, a Camera alternative will be selected. Camera settings Camera F160-S1 Intelligent Lighting 0 Out of use Intelligent Lighting 1 Out of use Press the ENT Key.
Page 39: Drawing A Region
Section 2-2 Menu Operations 2-2-4 Drawing a Region Use the following method to draw model regions and measurement regions. Move the cursor with the Up, Down, Left and Right Keys. Use these keys together with the SHIFT Key to move the cursor quickly. Press the ENT Key at the desired positions and press the ESC Key to undo the setting.
Page 40: Inputting Values
Section 2-2 Menu Operations Measurement Measure- Drawing method item ment region selection Defect Line The whole The length The width changes. region moves. changes. The figure is set. The whole The end The mid-point The width region moves. point moves. moves.
Page 41 Section 2-2 Menu Operations Move the cursor to the item for which a value is to be changed. Judgement conditions Area : 2035.000 2000.000 : 247808.000] Gravity X : 180.000 [ 0.000 : 511.000] Gravity Y : 250.000 [ 0.000 : 483.000] Press the ENT Key.
Page 42: Inputting Characters
Section 2-2 Menu Operations 2-2-6 Inputting Characters This section explains how to input characters. The software keyboard shown below is displayed on the screen where characters are input. A B C D E F G H I J K These characters can be input. O P Q R S T U V W X Y Z Inserts a space.
Page 43: Two-Camera Unit
Section 2-3 Two-camera Unit Two-camera Unit Using the Two-camera Unit, two Cameras can be connected to the F160 to enable obtaining two images simultaneously. Synchronized Images from Different Directions Example: Checking Boxes from Both Ends Measurement can be performed for boxes from both ends simultaneously using two Cameras.
Page 44: Two-Camera Menus
Select the number of Cameras to be used for measurement and the type of image (Frame/Field). The default menu configuration for the F160 is for one-Camera operation. For two-Camera operation it is necessary to change the Camera mode. When entering Set Mode for a scene for which the inspection conditions have not been set, the screen for selecting the Camera mode will be displayed.
Page 45 Section 2-3 Two-camera Unit Item Selections Meaning Frame/Field Frame image Measures using frame images. (default) Field (high Measures images in fields. The processing time can be speed) reduced but the accuracy of the measurement will be reduced because the measurement is performed on an image with low resolution in the vertical direction.
Page 46: Setting Inspection Conditions
S+ENT:Camera mode CHECK Once the settings have been changed, save the settings to flash memory. Then restart the F160 and set the measurement conditions. Setting Inspection Conditions This section explains how to set inspection conditions using the Expert Menus and the basic steps before starting inspections. A gravity and area measure- ment will be used as an example.
Page 47 Section 2-4 Setting Inspection Conditions CHECK When Intelligent Lighting is connected, set the lighting format to be used before entering Set Mode. Refer to page 284. Display the Basic Screen, move the cursor to MON, and press the ENT Key. ---- ---ms 0.Scn 0 TOOL...
Page 48: Step 2: Adjusting Images
Adjust 0 is displayed for Camera 0 and Adjust 1 appears for Camera 1. 2-4-2-1 Shutter Speed Change the shutter speed when the object is moving quickly, causing the image to be blurred. For F150-S1A Cameras For F160-S1A Cameras Shutter speed Object movement Shutter speed Object movement Slow...
Page 49 The setting will be registered and the screen in (1.) will return. 2-4-2-2 Light Control When using Cameras with Intelligent Lighting, the light level can be adjusted from the F160. Before using Intelligent Lighting, be sure to change the settings in SYS/Camera settings. SeeAlso Refer to page 284.
Page 50 Refer to page 39. Adjustment Method 1: Sample Lighting Patterns There are 15 lighting patterns registered in the F160. The lighting can be set simply by going through the different patterns in order and selecting the one that gives the clearest image. Use the SHIFT+Left and Right Keys to switch between sample patterns.
Page 51 Section 2-4 Setting Inspection Conditions F150-LTC50, F160-LTC50 Pattern Light level Pattern Light level Pattern Light level Pattern Light level Pattern Light level 00004444 00700000 77777777 07070707 00000700 44440000 00007777 00000070 70000000 00070000 07000000 77770000 70707070 00007000 00000007 Adjustment Method 2: Adjusting Light Levels by Segment The light level for each segment can be set separately to a value between 0 and 7.
Page 52 Section 2-4 Setting Inspection Conditions The settings screen for light control will be displayed. Light control(LTC20) Lighting pattern 5: 27272 SFT+←→:Sample ←→:Segment ↑ ↓:Light volume Switch the sample pattern lighting level using the SHIFT+Left/Right Keys. A graphic showing the lighting level will be displayed. Light control(LTC20) Lighting pattern: 27272 SFT+←→:Sample...
Page 53 Section 2-4 Setting Inspection Conditions The settings screen for filtering order will be displayed. Filtering order(Measurement) Filtering →BGS levels BGS levels →Filtering Select the filtering order while monitoring the image. Press the ENT Key. The setting will be registered and the screen in (1.) will return. 2-4-2-4 Filtering The image read by the Camera can be manipulated to create an image that is...
Page 54 Section 2-4 Setting Inspection Conditions Filtering Target Function Example application Horizontal Measurement objects dif- Extracts the horizontal Defect inspec- edge extrac- ficult to extract due to bad edges (light and dark) of tion (using tion image contrast an image. binary pro- cessing) Edge extrac- Measurement objects dif-...
Page 55 Section 2-4 Setting Inspection Conditions 2-4-2-5 Background Suppression Background suppression (BGS) excludes the background of the measurement object from the measurement process for easier measurement. BGS can be set separately for position compensation and measurement. Set the upper and lower limits of the BGS density while monitoring the image. BGS changes image areas with densities below the lower limit to 0, and image areas with densities above the upper limit to 255.
Page 56: Step 3: Position Compensation
Section 2-4 Setting Inspection Conditions SHIFT+Right Keys: Increases the value in 10s. Left Key: Reduces the lowest digit by one. SHIFT+Left Keys: Decreases the value in 10s. Up and Down Keys: Switches between setting items. Use the same method to change the lower value. Select OK.
Page 57: Step 4: Measurement Region
Refer to page 33. 2-4-4-1 Selecting Region Numbers The F160 supports 32 measurement regions and 17 measurement methods. The measurement method can be set separately for each region. TwoCamera If two Cameras are used, there are 16 regions (0 to 15) for Measurement 0...
Page 58 Section 2-4 Setting Inspection Conditions Example: Using Two Measurement Regions Region 0 Drawn using Defect (Circum) to check for surface defects. Region 1 Drawn with Gray Search to check that the printed markings are correct and there are no missing parts. Select Measurement region.
Page 59 Measuring Binary Center of Gravity and Area Density images taken by the Camera are converted to binary images, made up of black and white pixels. The F160 performs measurements on the size (area) and position (center of gravity) of the area occupied by the white pixels.
Page 60 Lower [128] Reverse Auto ↑ ↓:Move ←→:Change Auto Reverse The F160 automatically Reverses dark and sets the binary level clear in the display Move the cursor to the upper limit and use the Left and Right Keys to change the value.
Page 61 Section 2-4 Setting Inspection Conditions CHECK Set the upper and lower limits to make the measurement object white. Make the measurement object white. Binary level Upper[255] Lower[128] Reverse Auto ↑ ↓:Move ←→:Change Select OK. The settings will be registered and the screen in (2.) will return. CHECK It is also possible to set the binary level so that measurement is performed only for an intermediate density range.
Page 62 Section 2-4 Setting Inspection Conditions Measuring Open-form Measurement Objects The measurement result changes depending on the orientation of the measurement object. Input image Fill profile: ON Select Measurement conditions. 0.Gravity and area Binary Measurement conditions Region Reference registration Judgement conditions Detailed conditions Coordinate mode The screen for setting the measurement conditions will be displayed.
Page 63 Section 2-4 Setting Inspection Conditions Select Region. 0.Gravity and area Binary Measurement conditions Region Reference registration Judgement conditions Detailed conditions Coordinate mode The Region Settings Screen will be displayed. Region EBox Ellipse N O T Circle Circumference Polygon Select New. Select the shape of the desired figure.
Page 64 Section 2-4 Setting Inspection Conditions If additional figures are to be drawn, select Add. Repeat steps 3 to 5 as necessary to create the desired shape. After drawing is completed, select End. The measurement region will be registered and the screen in (1.) will re- turn.
Page 65 Section 2-4 Setting Inspection Conditions Inspecting Positions from a Specified Point Once the reference values (area and center of gravity) have been obtained for the image currently displayed, the reference position is changed to an suitable point. Position inspection can be performed by calculating the difference between this reference position and the measurement position.
Page 66 Section 2-4 Setting Inspection Conditions STEP 5: Setting the Judgement Conditions Make settings for the area and center of gravity. Range for an OK judgement. Judgement conditions Area : 2035.000 Area range (0 to 9,999,999.999) 0.000 : 247808.000] Gravity X : 180.000 Range of movement of the measurement object 0.000 : 511.000] in the X direction (-9,999.999 to 9,999.999)
Page 67 Section 2-4 Setting Inspection Conditions Skipping X and Skipping Y Set how many pixels to skip in the measurement region during measurement. The default setting is 1, which means that all of the measurement region will be measured. Skipping X Pixel Skipping Y Select Detailed conditions.
Page 68: Step 5: Output Expressions
Section 2-4 Setting Inspection Conditions STEP 7: Setting the Coordinate Mode Select the type of coordinates. Before scroll: Output made using the coordinate values before position displacement compensation. Coordinate mode After scroll*: Output made using the coordinate values after position displacement compensation. Output coordinate: Refer to page 197 for position compensation.
Page 69: Step 6: Display
Section 2-4 Setting Inspection Conditions CHECK Select the destinations for data output under SYS/Output settings. Refer to page 286. 2-4-6 STEP 6: Display Figures, characters, data, and other information can be added to the screen display in Monitor and Run Modes. Up to 32 pieces of information can be added for each scene.
Page 70 The time taken for the measurement will be displayed. CHECK Compared to freeze displays, the measurement time for through displays will be up to 20 ms longer for frames and 10 ms longer for fields when F160-S1 Cameras are used. Overall Judgement The overall judgement will be NG if there is an NG in one or more measure- ment regions, position compensations, or output expressions.
Page 71 Section 2-4 Setting Inspection Conditions CHECK Press the SHIFT + Up/Down Keys to display the stored images in order. Refer to page 311. Camera 0 image Cam 0 Freeze Camera 1 image Cam 1 Freeze CHECK Measurement images can be stored. Up to 35 screens can be stored in mem- ory.
Page 72: Run Mode
Section 2-5 Run Mode Change the settings as required. Display settings None Display image Position compensation Display results All results of regions Compensated image All positions of regions Scene/mode Individual region Overall judgement All variables Processing tim Individual variable ↑ ↓ All data ↑...
Page 73 The time taken for the measurement will be displayed. CHECK Compared to freeze display, the measurement time for through display will be up to 20 ms longer for frames and 10 ms longer for fields when F160-S1 Cam- eras are used. Overall Judgement The overall judgement will be NG if there is an NG in one or more measure- ment regions, position compensations, or output expressions.
Page 74: Saving Settings And Exiting The F160
Data in memory will be de- stroyed, and the F160 may not operate correctly the next time it is started. Once the setting data has been saved, the screen in (1.) return.
Page 75 Section 2-6 Saving Settings and Exiting the F160 CHECK When Using the Scene Group Function The scene data set to Scene Group 0 and the system data will be saved to flash memory. The settings data for Scene Groups 1 to 31 will be overwritten...
Page 76: Selecting And Setting Measurement Methods
SECTION 3 Selecting and Setting Measurement Methods The Expert Menu provides 17 different measurement methods. The gravity and area measurement method was already used as an example in Setting Inspection Conditions, Step 4 Measurement Regions in Section 2 Basic Operations. This section explains the other 16 measurement methods. Area (Variable Box) .
Page 77 Surface Defects ..........3-6-1 STEP 1: Drawing the Measurement Region .
Page 78 3-12-2 STEP 2: Setting Search Regions ......3-12-3 STEP 3: Setting Judgement Conditions ..... . 3-12-4 STEP 4: Changing Detailed Conditions .
Page 79: Area (Variable Box)
3-1-1 STEP 1: Setting the Binary Level Set the level for converting 256-gradation images into binary images. The F160 performs measurement for the white pixels. Therefore, make the settings so that the measurement object is white. Select Measurement/<Region number>/Area (var.box).
Page 80: Step 2: Using The Fill Profile Function (Setting Judgement Conditions)
Lower [128] Reverse Auto ↑ ↓:Move ←→:Change Auto Reverse The F160 automatically Reverses black and sets the binary level white in the display Move the cursor to the upper limit and use the Left and Right Keys to change the value.
Page 81: Step 3: Drawing The Measurement Region
Section 3-1 Area (Variable Box) Select Measurement conditions. 0.Area(Var. box) Binary Measurement conoditions Left edge Upper edge Right edge Lower edge Reference registration Judgement conditions ↑ ↓ The screen for setting the measurement conditions will be displayed. Measurement conditions Fill profile : OFF Select either ON or OFF.
Page 82 Section 3-1 Area (Variable Box) Set the edge detection conditions. Set the direction for the edge search and the density changes. Measurement conditions Direction for edge detection: →, ←, ↑, ↓ → Direction : Color : Light→Dark Density change: Light→Dark, Dark→Light CHECK Combining Edge Detection Directions Set a combination of upper, lower, right, and left edge detection directions...
Page 83 Section 3-1 Area (Variable Box) The Measurement Conditions Settings Screen will be displayed. Measurement conditions Direction : → Color : Light→Dark Select the detection conditions for the left edge. Select End. The settings will be registered and the screen in (2.) will return. Drawing the Edge Detection Region Draw a region that includes the edge.
Page 84 Section 3-1 Area (Variable Box) CHECK Use the following procedure to fix the region. Measurement Objects with Variable Widths Only Draw the edge detection region so that the measurement region Y coordinates will remain the same for both the upper and lower edges. The upper and lower edges will always have these edge points.
Page 85 Section 3-1 Area (Variable Box) Changing Detailed Conditions as Required Change the detailed conditions when the measurement results are unsta- ble. Change and set the edge level, noise level, noise width, and offset width as required. (Normally, these four conditions can be left on the de- fault settings.) After changing the settings, perform an object measurement to check that measurement can still be performed correctly.
Page 86 F160 determines that there is no edge. Normally the default set- ting of 20 is sufficient. Adjust this to a higher value, however, if noise is causing false edges to be detected.
Page 87: Step 4: Registering Reference Values
Section 3-1 Area (Variable Box) Offset Width Set the adjustment width (in pixel units) for the detected edge position. Set a value between -511 and 511. The default setting is 0, which means measurement will start from position where the edge is detected. Offset width Edge detection point Left and right edges: Set the offset width on the X axis.
Page 88: Step 5: Setting Judgement Conditions
Section 3-1 Area (Variable Box) Select Reference registration. 0.Area(var. box) Binary Measurement conditions Left edge Upper edge Right edge Lower edge Reference registration Judgement conditions ↑ ↓ A cursor will appear at the position of the center of gravity. Measurement object Reference position Reference registration 251,184...
Page 89: Step 6: Setting Pixel Skipping
Section 3-1 Area (Variable Box) Select Judgement conditions. 0.Area(var. box) Binary Measurement conditions Left edge Upper edge Right edge Lower edge Reference registration Judgement conditions ↑ ↓ The Judgement Conditions Settings Screen will be displayed. Judgement conditions Area : 2035.000 2000.000 : 247808.000] Gravity X : 180.000...
Page 90: Step 7: Setting The Coordinate Mode
Section 3-1 Area (Variable Box) Select Detailed conditions. 0.Area(var. box) Measurement conditions Left edge Upper edge Right edge Lower edge Reference registration Judgement conditions Detailed conditions ↑ ↓ The Detailed Conditions Settings Screen will be displayed. Detailed conditions Skipping X : [ 1] Skipping Y : [ 1] Set the number of pixels to skip.
Page 91: Defect (Variable Box)
STEP 2 STEP 3 STEP 5 Register Change measurement measurement reference judgement detection coordinates conditions. region. values. conditions. conditions. mode. 3-2-1 STEP 1: Setting Measurement Conditions The F160 detects the defect position using density variations in the measure- ment region.
Page 92 Section 3-2 Defect (Variable Box) This section shows how to select the direction for calculating density changes in the measurement region. Measurement Application direction X and Y Measurement region directions Select to detect the defects for the whole measurement region. Calculates the variation in den- sity in the X-axis and Y-axis directions.
Page 93: Step 2: Drawing The Measurement Region
Section 3-2 Defect (Variable Box) Select Measurement conditions. The Measurement Conditions Settings Screen will be displayed. Measurement conditions Measure direction : Box Select the measurement direction. Select End. The setting will be registered and the screen in (2.) will return. 3-2-2 STEP 2: Drawing the Measurement Region The measurement region is drawn by specifying the upper, lower, left, and...
Page 94 Section 3-2 Defect (Variable Box) The initial setting screen for the left edge will be displayed. Left edge Measurment conditions Region Detailed conditions Select Measurement conditions. The Measurement Conditions Settings Screen will be displayed. Measurement conditions Direction : → Color : Light→Dark Select the detection conditions for the left edge.
Page 95 Section 3-2 Defect (Variable Box) The Region Settings Screen will be displayed. Region 230,256 Draw a box-shaped region. CHECK The only figure that can be drawn is a box. Refer to page 28. CHECK Draw the region so that it includes the edge. Region Region The edge is not within the region.
Page 96 Section 3-2 Defect (Variable Box) Draw the edge detection region so that the measurement region X co- ordinates will remain the same for both the left and right edges. The left and right edges will always have these edge points. Note Specify Y line under Measurement conditions/measurement direc- tion.
Page 97: Step 3: Registering Reference Values
Section 3-2 Defect (Variable Box) Press the ESC Key to return to the initial screen for Defect (var. box). 3-2-3 STEP 3: Registering Reference Values The algorithms used to detect defects can be used for position detection. Reg- ister reference values when performing position detection. The X and Y coordi- nates of the position detected as a defect are registered for the reference values.
Page 98: Step 4: Setting Judgement Conditions
Section 3-2 Defect (Variable Box) A cursor will appear at the position of the defect. Measurement object Reference position Reference registration 251, 184 ENT:OK ↑ ↓←→:Move To change the position, use the Up/Down and Right/Left Keys to move the cursor. Press the ENT Key to confirm the setting.
Page 99: Step 5: Changing Detection Conditions
Section 3-2 Defect (Variable Box) The settings will be registered and the screen in (1.) will return. 3-2-5 STEP 5: Changing Detection Conditions To shorten measurement processing time, change the conditions for detecting defects. The greater the element size and comparing pitch, the shorter the processing time.
Page 100: Step 6: Setting The Coordinate Mode
Section 3-2 Defect (Variable Box) Example: Measurement Performed in X Direction Element Measurement region Element size (4 to 80). Default setting is 10. Compared Compared Density compared with surrounding elements. The greatest density difference for the surrounding elements with the greater density is the defect for that element.
Page 101: Gravity And Axis
STEP 1: Setting the Binary Level Set the level for converting 256-gradation images into binary images. The F160 performs measurement for the white areas. Therefore, make the settings so that the areas for the center of gravity or the axis angle are white.
Page 102 Lower [128] Reverse Auto ↑ ↓:Move ←→:Change Auto Reverse The F160 automatically Reverses dark and sets the binary level clear in the display Move the cursor to the upper limit and use the Left and Right Keys to change the value.
Page 103: Step 2: Drawing Measurement Regions
Section 3-3 Gravity and Axis CHECK Set the upper and lower limits to make the measurement object white. Binary level Upper [255] Lower [128] Reverse Auto ↑ ↓:Move ←→:Change Select OK. The settings will be registered and the screen in (2.) will return. CHECK It is also possible to set the binary level so that measurement is performed only for an intermediate density range.
Page 104 Section 3-3 Gravity and Axis An arrow cursor will appear. Up to three figures (0, 1, and 2) can be drawn. Region 375,341 Draw the region with the shape selected. The figure will be registered. Region Figure0 Once three figures have been drawn, Add will no longer be displayed.
Page 105: Step 3: Re-Registering Reference Values
Section 3-3 Gravity and Axis Correcting or Clearing Figures In the screen for step 6 above, select the figure to be changed or cleared using the Up and Down Keys and press the ENT Key. Figure 0 Figure 1 Region Figure0 Figure1 The figure for the figure number selected using the cursor will be displayed...
Page 106: Step 4: Setting Judgement Conditions
Section 3-3 Gravity and Axis Select Reference registration. 0.Gravity and axis Binary Region Reference registration Judgement conditions Detailed conditions Coordinate mode A cursor will appear at the position of the center of gravity. Reference position Measurement region Reference registration 251,184 ENT:OK ↑...
Page 107: Step 5: Setting Pixel Skipping
Section 3-3 Gravity and Axis Select Judgement conditions. 0.Gravity and axis Binary Region Reference registration Judgement conditions Detailed conditions Coordinate mode The Judgement Conditions Settings Screen will be displayed. Judgement conditinos Area 2035.000 2000.000 : 247808.000] Gravity X : 180.000 0.000 : 511.000] Gravity Y : 250.000...
Page 108: Step 6: Setting The Coordinate Mode
Section 3-3 Gravity and Axis Select Detailed conditions. 0.Gravity and axis Binary Region Reference registration Judgement conditions Detailed conditions Coordinate mode The Detailed Conditions Settings Screen will be displayed. Detailed conditions Skipping X : [ 1] Skipping Y : [ 1] Set the number of pixels to skip.
Page 109: Ocr For 1 Character
OCR for 1 Character The dictionary registered in the F160 is used to recognize alphanumeric char- acters and special symbols. The F160 can also evaluate whether or not the measurement area contains any detectable patterns (i.e., marks of any sort).
Page 110: Step 1: Setting Measurement Conditions
Section 3-4 OCR for 1 Character 3-4-1 STEP 1: Setting Measurement Conditions Set the conditions for recognizing characters. Color of recognised character Black*: The character color is darker than the background. Measurement conditions White: The character color is lighter than the background. Color Black Character printing type...
Page 111: Step 2: Drawing Measurement Regions
Section 3-4 OCR for 1 Character The Measurement Conditions Settings Screen will be displayed. Measurement conditions Color Black Object : Normal Alphabet : ON Number : ON Symbol : ON Unpattern : ON Make the settings for each item. Select End. The settings will be registered and the screen in (2.) will return.
Page 112: Step 3: Setting Judgement Conditions
Section 3-4 OCR for 1 Character Draw a box-shaped region. CHECK The only figure that can be drawn is a box. SeeAlso Refer to page 28 for information on how to draw regions. When the bottom right coordinates are specified, the region will be set, and the screen in (1.) will return.
Page 113: Classification
CHECK When multiple models are registered to the same index number, the F160 automatically creates auxiliary models between the models that are regis- tered. If the auxiliary models are added to the registered models when searches are performed, stable searches are possible even if there are varia- tions between the registered models.
Page 114 Section 3-5 Classification The initial screen for Classification is displayed. 0.Classification Model registration Search region Judgement conditions Detailed conditions Coordinate mode Select Model registration. The Model Registration Screen for index numbers 0 to 7 will be displayed. Use the SHIFT+Up/Down Keys to change the index number. Model registration Registration Delete...
Page 115 Section 3-5 Classification An arrow cursor will appear. Up to three figures (0, 1, and 2) can be drawn. Model registration 329,300 With the shape selected, draw the region to be registered as the model. The figure will be registered. Once three figures have been drawn, Add will no longer be displayed.
Page 116 Section 3-5 Classification 13. Press the TRIG Key to refresh the image. 14. Press the ESC Key. The screen in (12.) will return. 15. Repeat steps 3 to 11 to register further models. CHECK To add models to the same index number, use the Right Key to move the cursor.
Page 117: Step 2: Setting Search Regions
Section 3-5 Classification The selections Registration and Delete will be displayed. Registration Delete Select either Registration or Delete and press the ENT Key. If Registration is selected, the Model Registration Screen will be dis- played. Register the model. If Delete is selected, the selected model will be deleted. 3-5-2 STEP 2: Setting Search Regions Set the region to search for the model.
Page 118: Step 3: Setting Judgement Conditions
Section 3-5 Classification 3-5-3 STEP 3: Setting Judgement Conditions Set the judgement conditions for the correlation between the measurement object and the models and the position (X, Y) where the object was detected. Judgement conditions Range for an OK judgement. Correlation range (0 to 100) Correlation : 79 [ 60 : Position X :...
Page 119: Step 4: Changing Detailed Conditions
Section 3-5 Classification Make the settings. SeeAlso Refer to page 29 for details on inputting values. Select End. The settings will be registered and the screen in (1.) will return. 3-5-4 STEP 4: Changing Detailed Conditions Search-related settings can be changed under Detailed conditions. Change the detailed conditions when the measurement results are unstable and to increase processing speed.
Page 120 Section 3-5 Classification CHECK The F160 performs the following two-stage search internally. 2 Detailed Search 1 Rough Search Using a rough search model, the F160 The F160 uses a detailed search model and re-measures the images near the area that was searches for images with a correlation equal to or greater than the candidate level.
Page 121 Setting item Setting range Meaning Model skipping Automatic* The F160 automatically sets the most suitable skipping setting (X and Y) based on the model Detailed model size. The set values will be displayed for Model skipping skipping X/Y or Detailed model skipping X/Y.
Page 122: Step 5: Setting The Coordinate Mode
Section 3-5 Classification 3-5-5 STEP 5: Setting the Coordinate Mode Select the type of coordinates. Before scroll: Output made using the coordinate values before position displacement compensation. Coordinate mode After scroll*: Output made using the coordinate values after position displacement compensation. Output coordinate: Refer to page 197 for position compensation.
Page 123: Surface Defects
Section 3-6 Surface Defects Surface Defects Surface defects in the F160 measurement region are checked for through vari- ations in density. SeeAlso Refer to page 9. Operational Flow (If required) (If required) STEP 4 STEP 1 STEP 2 STEP 3...
Page 124 Section 3-6 Surface Defects Select Measurement/<Region number>/Defect. 0.Scn 0 =SET= Measurement Area(var. box) Defect(var. box) Gravity and area Gravity and axis OCR for 1 chara Classification Defect Density data The initial screen for Defect will be displayed. 0.Defect Region Reference registration Judgement conditions Detailed conditions Coordinate mode...
Page 125: Step 2: Re-Registering Reference Values
Section 3-6 Surface Defects 3-6-2 STEP 2: Re-registering Reference Values Position detection can also be performed using algorithms for detecting defects. When a measurement region is drawn, measurement is performed for the displayed image and the results are registered as the reference values (X and Y coordinates of the position where the defect was found).
Page 126: Step 3: Setting The Judgement Conditions
Section 3-6 Surface Defects A cursor will appear at the position of the defect. Measurement region Reference position Reference registration 251,184 To change the position, use the Up/Down and Right/Left Keys to move the cursor. Press the ENT Key to confirm the setting. The setting will be registered and the screen in (1.) will return.
Page 127: Step 4: Changing Detection Conditions
Section 3-6 Surface Defects 3-6-4 STEP 4: Changing Detection Conditions To shorten measurement processing time, change the conditions for detecting defects. The greater the element size and comparing pitch, the shorter the processing time. However, the accuracy of the measurement will decrease. Once the element size or comparing pitch setting has been changed, perform measurements to check that they can be performed correctly.
Page 128: Density Data
Section 3-7 Density Data 3-6-5 STEP 5: Setting the Coordinate Mode Select the type of coordinates. Before scroll: Output made using the coordinate values before position displacement compensation. Coordinate mode After scroll*: Output made using the coordinate values after position displacement compensation. Output coordinate: Refer to page 197 for position compensation.
Page 129: Step 1: Drawing Measurement Regions
Section 3-7 Density Data Operational Flow STEP 1 STEP 2 Draw the Set the measurement judgement region. conditions. 3-7-1 STEP 1: Drawing Measurement Regions CHECK Regions can be created by combining up to 3 different figures. Regions with difficult shapes can be drawn and sections not to be measured can be left out of the region by combining different figures.
Page 130 Section 3-7 Density Data An arrow cursor will appear. Up to three figures (0, 1, and 2) can be drawn. Region 262,231 Draw the figure in the region to be used as the measurement region. The figure will be registered. Once three figures have been drawn, Add will no longer be displayed.
Page 131: Step 2: Setting Judgement Conditions
Section 3-7 Density Data Correcting or Clearing Figures In the screen for step 7 above, select the figure to be changed or cleared using the Up and Down Keys and press the ENT Key. Figure 0 Figure 1 Region Figure0 Figure1 The figure for the figure number selected using the cursor will be displayed with solid lines.
Page 132: Edge Pitch
Section 3-8 Edge Pitch The Judgement Conditions Settings Screen will be displayed. Judgement coordinate Density average : 39.945 [ 0.000 : 255.000] Density deviation : 31.376. [ 0.000 : 255.000] : Make the settings for each item. SeeAlso Refer to page 29 for details on inputting values. Select End.
Page 133: Step 2: Drawing Measurement Regions
Section 3-8 Edge Pitch Select Measurement region/<Region number>/Edge pitch. 0.Scn 0 =SET= Measurement Defect(var. box) Gravity and area Gravity and axis OCR for 1 chara Classification Defect Density data Edge pitch ↑ ↓ ↑ ↓ S+ESC:Edit The initial screen for Edge Pitch will be displayed. 0.Edge pitch Measurement conditions Region...
Page 134 Section 3-8 Edge Pitch CHECK Edges are detected in the direction of the long side of the measurement region. Incorrect Correct Measurement region Measurement Detection region direction 5 edges 0 edges Detection direction Select Region. 0.Edge pitch Measurement conditions Region Judgement conditions Detailed conditions Coordinate mode...
Page 135: Step 3: Setting Judgement Conditions
Section 3-8 Edge Pitch 3-8-3 STEP 3: Setting Judgement Conditions Set the ranges for an OK judgement. Ranges for an OK judgement Judgement conditions Number of edges : 5 [ 0 : 255] Range for number of edges (0 to 255) Average pitch : 9.322 0.000 : 9999.999 ]...
Page 136: Step 4: Changing Detailed Conditions
Section 3-8 Edge Pitch 3-8-4 STEP 4: Changing Detailed Conditions Change the detailed conditions when the measurement results are unstable. Normally, these conditions can be left on the default settings. Detailed conditions Edge level : [ 10 ]% To prevent incorrect detection due to noise (0 to 255). Min.
Page 137: Edge Position
Section 3-9 Edge Position 3-8-5 STEP 5: Setting the Coordinate Mode Select the type of coordinates. Coordinate mode Output made using coordinate values Calibration : OFF set using calibration. OFF*: Output made using Camera coordinate values. Refer to p. 185 for information on calibration. The default setting is marked with an asterisk.* CHECK If the coordinate mode is changed after the judgement conditions have been...
Page 138: Step 1: Setting Edge Detection Conditions
Section 3-9 Edge Position Operational Flow (If required) (If required) STEP 3 STEP 5 STEP 1 STEP 2 STEP 4 STEP 6 Draw the Re-register Change Set edge measurement reference judgement detailed coordinate detection region. value. conditions. conditions. mode. conditions. 3-9-1 STEP 1: Setting Edge Detection Conditions Set the direction for edge detection and the density changes.
Page 139: Step 2: Drawing Measurement Regions
Section 3-9 Edge Position Select Measurement conditions. The Measurement Conditions Settings Screen will be displayed. Measurement conditions → Direction Color : Light→Dark Select the edge detection conditions. Select End. The settings will be registered and the screen in (2.) will return. 3-9-2 STEP 2: Drawing Measurement Regions Draw a measurement region to include all the edges for detection.
Page 140: Step 3: Re-Registering Reference Values
Section 3-9 Edge Position The Region Settings Screen will be displayed. Region 270,230 Draw a box-shaped region. CHECK The only figure that can be drawn is a box. SeeAlso Refer to page 28 for information on how to draw regions. The region will be set and the screen in (1.) will return.
Page 141: Step 4: Setting Judgement Conditions
Section 3-9 Edge Position Select Reference registration. 0.Edge position Measurement conditions Region Regerence registration Judgement conditions Detailed conditions Coordinate mode A cursor will appear at the edge position. Reference registration 95,211 ENT:OK ↑ ↓←→:Move Measurement region Reference position To change the position, use the Up/Down and Right/Left Keys to move the cursor.
Page 142: Step 5: Changing Detailed Conditions
Section 3-9 Edge Position CHECK Position X and Position Y will change depending on the settings under Mea- surement/Direction. The Y coordinates are set when ↑ and ↓ are selected. The X coordinates are set when ← and → are selected. Note: The origin and coordinate system change depending on the calibration settings.
Page 143 Section 3-9 Edge Position Select Detailed conditions. 0.Edge position Measurement conditions Region Reference registration Judgement conditions Detailed conditions Coordinate mode Left edge Measurement conditions Region Detailed conditions The Detailed Conditions Settings Screen will be displayed. Detailed conditions Edge level : [ 50]% Noise level : [ 20] Noise width : [ 0]pix Change the settings.
Page 144: Edge Width
Section 3-10 Edge Width 3-9-6 STEP 6: Setting the Coordinate Mode Select the type of coordinates. Before scroll: Output made using the coordinate values before position displacement compensation. Coordinate mode After scroll*: Output made using the coordinate values after position displacement compensation. Output coordinate: Refer to page 197 for position compensation.
Page 145: Step 1: Setting Edge Detection Conditions
Section 3-10 Edge Width Operational Flow (If required) (If required) STEP 3 STEP 5 STEP 1 STEP 2 STEP 4 STEP 6 Set edge Draw the Change Re-register judgement detection measurement detailed reference coordinate conditions. conditions. region. conditions. value. mode. 3-10-1 STEP 1: Setting Edge Detection Conditions Set the direction for the edge search and density deviation range.
Page 146: Step 2: Drawing Measurement Regions
Section 3-10 Edge Width Select Measurement/<Region number>/Edge width. 0.Scn 0 =SET= Measurement Garvity and axis OCR for 1 chara Classification Defect Density data Edge pitch Edge position Edge width ↑ ↓ ↑ ↓ S+ESC:Edit The initial screen for Edge width will be displayed. 0.Edge width Measurement conditions Region...
Page 147: Step 3: Re-Registering Reference Value
Section 3-10 Edge Width range of the measurement object. Correct Incorrect Correct Width Width Width Measurement Measurement Measurement region region region Select Region. 0.Edge width Measurement conditions Region Reference registration Judgement conditions Detailed conditions Coordinate mode The Region Settings Screen will be displayed. Region 283,351 Draw a box-shaped region.
Page 148 Section 3-10 Edge Width Inspecting Positions from a Specified Point Once the reference value (edge position) has been obtained for the image cur- rently displayed, the reference position is changed to an suitable point. Posi- tion inspection can be performed by calculating the difference between this reference position and the measurement position.
Page 149: Step 4: Setting Judgement Conditions
Section 3-10 Edge Width 3-10-4 STEP 4: Setting Judgement Conditions Set the width range for an OK judgement. Judgement conditions Range for an OK judgement Width 25.000 0.000 : 511.000 Width range (0 to 9,999.999) Measurement result for displayed image Select Judgement conditions.
Page 150: Step 6: Setting The Coordinate Mode
Section 3-10 Edge Width Select Detailed conditions. 0.Edge width Measurement conditions Region Reference registration Judgement conditions Detailed conditions Coordinate mode The Detailed Conditions Settings Screen will be displayed. For edge 1 Detailed conditions Edge level 1 : [ 50]% Noise level 1 : [ 20] Noise width 1 : [ 0]pix Edge level 2 : [ 50]% Noise level 2 : [ 20]...
Page 151 Section 3-10 Edge Width Select Coordinate mode. 0.Edge width Measurement conditions Region Reference registration Judgement conditions Detailed conditions Coordinate mode The Coordinate Mode Settings Screen will be displayed. Coordinate mode Calibration : OFF Make the settings for each item. Select End. The settings will be registered and the screen in (1.) will return.
Page 152: Gray Search And Precise Search
Section 3-11 Gray Search and Precise Search 3-11 Gray Search and Precise Search Register an image pattern (called a model) in advance. The part of an input image that is most similar to the model is found, the position is calculated in pixel units, and the degree of similarity is expressed with a correlation value.
Page 153 Section 3-11 Gray Search and Precise Search The initial screen for Gray Search will be displayed. 0.Gray search Model registration Search coordinate Search region Judgement conditions Detailed conditions Coordinate mode Select Model registration. The Model Registration Screen will be displayed. Model registration EBox Ellipse...
Page 154: Step 2: Changing The Search Coordinates
Section 3-11 Gray Search and Precise Search CHECK Figures drawn using OR mode are displayed with solid lines and figures drawn using NOT mode are displayed with dotted lines. Figure 1 (drawn using OR) Figure 2 (drawn using NOT) Figure 3 (drawn using OR) Correcting or Clearing Figures In the screen for step 7 above, select the figure to be changed or cleared using the Up and Down Keys and press the ENT Key.
Page 155: Step 3: Setting The Search Region
Section 3-11 Gray Search and Precise Search CHECK If the model is re-registered, the search coordinates are changed to the center position of the new model. Select Search coordinates. 0.Gray search Model registration Search coordinate Search region Judgement conditions Detailed conditions Coordinate mode A cursor will appear in the center position.
Page 156: Step 4: Setting Judgement Conditions
Section 3-11 Gray Search and Precise Search The model will be displayed in solid lines. Model Search region 500,356 Draw a box-shaped search region. CHECK The only figure that can be drawn is a box. SeeAlso Refer to page 28 for methods for drawing regions. The search region will be set and the screen in (1.) will return.
Page 157: Step 5: Changing Detailed Conditions
Section 3-11 Gray Search and Precise Search Select Judgement conditions. 0.Gray search Model registration Search coordinate Search region Judgement conditions Detaild conditions Coordinate mode The Judgement Conditions Settings Screen will be displayed. Judgement conditions Correlation : 79 [ 60 : Position X : 180.000 0.000 : 511.000]...
Page 158: Step 6: Setting The Coordinate Mode
Section 3-11 Gray Search and Precise Search Use the Down Key to scroll through the setting items. Detailed conditions Candidate level : [ 60] Model skipping : Auto Model skipping X : [ 4] Model skipping Y : [ 4] Search skipping : Auto Search skipping X...
Page 159: Flexible Search
Section 3-12 Flexible Search The Coordinate Mode Settings Screen will be displayed. Coordinate mode Output coordinate : After scroll Calibration : OFF Make the settings for each item. Select End. The settings will be registered and the screen in (1.) will return. 3-12 Flexible Search Use flexible search to identify the shapes of inconsistent measurement...
Page 160 CHECK When multiple models are registered to the same index number, the F160 automatically creates auxiliary models between the models that are regis- tered. If the auxiliary models are added to the registered models when searches are performed, stable searches are possible even if there are varia- tions between the registered models.
Page 161 Section 3-12 Flexible Search The selection items will be displayed. Model registration EBox Ellipse Circle Circumference Polygon Select New. Select the shape of the desired figure. Select the desired drawing mode (OR/NOT). SeeAlso Refer to page 28 for methods for drawing regions. The arrow cursor will be displayed.
Page 162 Section 3-12 Flexible Search The registered model is displayed as a thumbnail. Registered model Model registration ENT:Select SFT+ESC:Input image 12. Repeat steps 3 to 11 to register further models. CHECK To refresh the display image, press the SHIFT + ESC Keys at the Model Registration Screen.
Page 163: Step 2: Setting Search Regions
Section 3-12 Flexible Search Clearing or Overwriting Registered Models Select the model to be cleared or overwritten from the thumbnails and press the ENT Key. C u r s o r Model registration The selections Registration and Delete will be displayed. Registration Delete Select either Registration or Delete and press the ENT Key.
Page 164: Step 3: Setting Judgement Conditions
Section 3-12 Flexible Search CHECK The only figure that can be drawn is a box. SeeAlso Refer to page 28 for methods for drawing regions. The search region will be set and the screen in (1.) will return 3-12-3 STEP 3: Setting Judgement Conditions Set the judgement conditions for the correlation between the measurement image and the models and the position (X, Y) where the object was detected.
Page 165: Step 4: Changing Detailed Conditions
Section 3-12 Flexible Search The Judgement Conditions Settings Screen will be displayed. Judgement conditions Correlation : 79 [ 60 : Position X : 180.000 [ 0.000 : 511.000] Position Y : 250.000 0.000 : 483.000] Make the settings. SeeAlso Refer to page 29 for details on inputting values. Select End.
Page 166: Labeling
Section 3-13 Labeling 3-12-5 STEP 5: Setting the Coordinate Mode Select the type of coordinates. Before scroll: Output made using the coordinate values before position displacement compensation. Coordinate mode After scroll*: Output made using the coordinate values after position displacement compensation. Output coordinate: Refer to page 197 for position compensation.
Page 167: Step 1: Setting The Binary Level
STEP 1: Setting the Binary Level Set the level for converting 256-gradation images into binary images. The F160 performs measurement for the white pixels. Therefore, make the set- tings so that the label measurement areas are white. In this explanation, 3 circles on a measurement object will be used as an example.
Page 168: Step 2: Setting Measurement Conditions
Lower [128] Reverse Auto ↑ ↓:Move ←→:Change Auto Reverse The F160 automatically Reverses dark and sets the binary level white in the display Move the cursor to the upper limit and use the Left and Right Keys to change the value.
Page 169 Section 3-13 Labeling Change the other settings as well when necessary. Default settings are indicated with an asterisk. Area range for labels (0 to 9,999,999.999 (0*)) Measurement conditions Output conditions for measurement value: Area OFF*: Measures the binary image 0.000 : 247808.000 ] Measures all pixels outside the Outside trimming :...
Page 170: Step 3: Drawing Measurement Regions
Section 3-13 Labeling The Measurement Conditions Settings Screen will be displayed. Measurement conditions Area 0.000 : 247808.000 Outside trimming : Filling up holes Sort Area descending order Label No. : [ 0] Change the settings. SeeAlso Refer to page 29 for details on inputting values. The settings will be registered and the screen in (1.) will return.
Page 171 Section 3-13 Labeling CHECK Regions can be created by combining up to 3 different figures. Regions with difficult shapes can be drawn and sections not to be measured can be left out of the region by combining different figures. Select Region. 0.Labeling Binary Measurement conditions...
Page 172 Section 3-13 Labeling The figure will be registered. Region Figure0 Once three figures have been drawn, Add will no longer be displayed. If additional figures are to be drawn, select Add. Repeat steps 3 to 5 as necessary to create the desired shape. After drawing is completed, select End.
Page 173: Step 4: Re-Registering Reference Values
Section 3-13 Labeling If Correct is selected, the cursor will be displayed. Correct the size and po- sition of the figure as desired. If Clear is selected, the selected figure will be cleared. 3-13-4 STEP 4: Re-registering Reference Values This operation is performed when only the reference values are to be re-regis- tered.
Page 174: Step 5: Setting Judgement Conditions
Section 3-13 Labeling Sort conditions: X center of gravity, ascending Label number: 0 Reference position Measurement region Reference registration 251,184 ENT:OK ↑ ↓←→:Move To change the position, use the Up/Down and Right/Left Keys to move the cursor. Press the ENT Key to confirm the setting. The setting will be registered and the screen in (1.) will return.
Page 175: Step 6: Setting The Coordinate Mode
Section 3-13 Labeling The Judgement Conditions Settings Screen will be displayed. Judgement conditions Number of labels : 8 [ 0: 2500] Judge area : 2035.000 2000.000 : 2300.000 Gravity X : 26.000 0.000 : 511.000] Gravity Y :157.000 0.000 : 483.000] Make the settings for each item.
Page 176: Relative Search
Section 3-14 Relative Search The Coordinate Mode Settings Screen will be displayed. Coordinate mode Output coordinate : After scroll Calibration : OFF Make the settings for each item. Select End. The settings will be registered and the screen in (1.) will return. 3-14 Relative Search Use this method to obtain the positions of markings, holes, and other features,...
Page 177 Section 3-14 Relative Search CHECK It does not matter whether the reference position or measurement position is registered as Model 1 or Model 2. Decide which is registered as which model, based on whether the width is to be output as a positive or negative value.
Page 178 Section 3-14 Relative Search The Model Registration Screen will be displayed. Model registration Ellipse Circle Circumference Polygon Select New. Select the shape of the desired figure. Select the desired drawing mode (OR/NOT). SeeAlso Refer to page 28 for methods for drawing regions. An arrow cursor will appear.
Page 179 Section 3-14 Relative Search The search coordinates (display cursor) and the model region will be displayed. Figure 1 (drawn using OR) Figure 2 (drawn using NOT) Figure 3 (drawn using OR) CHECK Figures drawn using OR mode are displayed with solid lines and fig- ures drawn using NOT mode are displayed with dotted lines.
Page 180 Section 3-14 Relative Search CHECK If the model is re-registered, the search coordinates are changed to the center position of the new model. Select Search coordinates. Model 0 setting Model registration Search coordinate Seach region A display cursor will appear in the center position. Search coordinate 385,346 Search coordinate...
Page 181: Step 2: Setting Judgement Conditions
Section 3-14 Relative Search The model will be displayed with solid lines. Search region 472,444 Model Draw a box-shaped search region. CHECK The only figure that can be drawn is a box. SeeAlso Refer to page 28 for methods for drawing regions. The search region will be set and the screen for step a) will return.
Page 182: Step 3: Changing Detailed Conditions
Section 3-14 Relative Search Select Judgement conditions. 0.Relative search Model 0 setting Model 1 setting Judgement conditions Detailed conditions Coordinate mode The Judgement Conditions Settings Screen will be displayed. Judgement conditions Correlation 0 : 79 [ 60 : 100 ] Correlation 1 : 82 [ 60 : 100 ] Width X(1-0) : 85..737...
Page 183: Step 4: Setting The Coordinate Mode
Section 3-14 Relative Search Use the Down Key to scroll through the setting items. Detailed conditions Candidate 0 level : [ 60] Model 0 skipping : Auto Model 0 skipping X : [ 4] Model 0 skipping Y : [ 4] Search 0 skipping : Auto Search 0 skipping X...
Page 184: Rotation Search
3-15-1 STEP 1: Setting Measurement Conditions Set the conditions for searches. The F160 rotates the image by the skipping angle (See note 1.) within the rotation range (See note 2.) to search. Measurement conditions Note 1 Skipping angle...
Page 185 Coordinates and Rotation Angle Direction Depending on whether a right-handed or left-handed coordinate system has been set for the F160, the rotation angle direction changes. Check the rotation angle direction before making rotation search settings. • When Coordinate mode/Calibration is set to OFF, the coordinate system becomes a left-handed system.
Page 186: Step 2: Registering A Model
Section 3-15 Rotation Search Select Measurement/<Region number>/Rotation search. 0.Scn 0 =SET= Measurement Edge position Edge width Gray search Precise search Flexible search Labeling Relative search Rotation search ↑ ↓ ↑ ↓ S+ESC:Edit The initial screen for Rotation search will be displayed. 0.Rotation search Measurement conditions Model registration...
Page 187 Section 3-15 Rotation Search CHECK Models can be created by combining up to 3 different figures. Regions with dif- ficult shapes can be drawn and sections not to be measured can be left out of the region by combining different figures. Select Model registration.
Page 188 Section 3-15 Rotation Search The figure will be registered. Once three figures have been drawn, Add will no longer be displayed. Model registration Figure0 If additional figures are to be drawn, select Add. Repeat steps 3 to 5 as necessary to create the desired shape. After drawing is completed, select End.
Page 189: Step 3: Changing The Search Coordinates
Section 3-15 Rotation Search CHECK To re-register models, repeat from step 1 under Step 2: Registering Mod- els. 3-15-3 STEP 3: Changing the Search Coordinates Use this function to change the search coordinates only. When a model is registered, the center position of the model is registered as the search coordinates.
Page 190: Step 4: Setting Search Regions
Section 3-15 Rotation Search 3-15-4 STEP 4: Setting Search Regions Set the region to search for the model. The whole region of the input image can be searched, however processing time can be reduced and accuracy improved by limiting the search region. Select Search region.
Page 191: Step 6: Changing Detailed Conditions
Section 3-15 Rotation Search CHECK Correlation When OK condition for correlation is set between 60 and 100: Image 3 Image 0 Image 1 Image 2 Correlation: Judgement: CHECK Position X and Position Y Movement range in X direction Movement range OK NG Select Judgement conditions.
Page 192: Step 7: Setting The Coordinate Mode
Section 3-15 Rotation Search Select Detailed conditions. 0.Rotation search Measurement conditions Model registration Search coordinate Search region Judgement conditions Detailed conditions Coordinate mode The Detailed Conditions Settings Screen will be displayed. Detailed conditions Candidate level : [ 60] Model skipping : Auto Model skipping X : [ 4]...
Page 193 Section 3-15 Rotation Search Select Coordinate mode. 0.Rotation search Measurement conditions Model registration Search coordinate Search region Judgement conditions Detailed conditions Coordinate mode The Coordinate Mode Settings Screen will be displayed. Coordinate mode Output coordinate : After scroll Calibration : OFF Make the settings for each item.
Page 194: Detailed Setting Operations
SECTION 4 Detailed Setting Operations This section explains in more detail the basic setting operations for the Expert Menus that were explained in Section 2 Basic Operations: Setting Inspection Conditions. Calibration ........... . 4-1-1 Sampling .
Page 195 4-10-1 STEP 1: Setting Display Conditions ......4-10-2 STEP 2: Drawing Figures ....... . . 4-11 Displaying Results (Lines, Boxes, Circles, and Cursors) .
Page 196: Calibration
• When the magnifications in the X and Y directions are different, perform sampling measurement in 3 places. CHECK The point measured by the F160 becomes the specified point for calibration, giving a higher degree of accuracy than the when using Point specification.
Page 197 Section 4-1 Calibration Select Adjust/Calibration. 0.Scn 0 =SET= Adjust Shutter Speed Light control Filtering order(Position) Filtering(Position) BGS levels(Position) Filtering order(Measurement) Filtering(Measurement) BGS levels(Measurement) Calibration The initial screen for Calibration will be displayed. Calibration Sampling Model registration Spcifying Sampling Specifying coordinate axis Parameter input Reference parameter Select Sampling.
Page 198 Upper limit Binary level Upper [255] Lower [128] Reverse Auto ↑ ↓:Move ←→:Change Auto Reverse The F160 automatically Reverses black and sets the binary level white in the display SeeAlso Refer to page 48 for information on setting binary levels.
Page 199 Section 4-1 Calibration The model will be registered and the screen in (3.) will return. Calibration Sampling Model registration Specifying Sampling Specifying coordinate axis Parameter input Reference parameter Select Sampling. The first Sampling Screen will be displayed. Sampling region Reference position 1time(s) Sampling Decide whether or not to change the sampling region.
Page 200 Section 4-1 Calibration CHECK Draw the region so that there will not be 2 or more similar figures within the sampling region. Incorrect Correct Sampling region Sampling region The region will be set and the Sampling Screen will return. Sampling region 1time(s) Sampling 10.
Page 201: Specifying Points
Section 4-1 Calibration 2time(s) Sampling 12. Repeat steps 8 to 11 and perform sampling for at least two locations. Once sampling has been completed, a confirmation message will be dis- played. Registering calibration Parameters. Execute Cancel 13. Select Execute. The settings will be registered and the screen in (2.) will return. 4-1-2 Specifying Points This function is used to specify and set any point in pixel units.
Page 202 Section 4-1 Calibration Select Adjust/Calibration. 0.Scn 0 =SET= Adjust Shutter Speed Light control Filtering order(Position) Filtering(Position) BGS levels(Position) Filtering order(Measurement) Filtering(Measurement) BGS levels(Measurement) Calibration The initial screen for Calibration will be displayed. Calibration Sampling input Specifying point Specifying coordinate axis Parameter input Reference parameter Select Specifying point.
Page 203: Specifying Coordinate Axis
Section 4-1 Calibration The coordinates for the 1st point will be set and the Specifying Point Screen for the 2nd point will be displayed. Repeat steps 3 and 4 and specify 2 or more points. Once point specification has been completed, a confirmation message will be displayed.
Page 204 Section 4-1 Calibration The screen for specifying the origin will be displayed. Origin Coordinate axis X= 255 X= 242 100.0 -100.0 100.0 -100.0 Use the Up/Down and Right/Left Keys to move the cursor to the position to be specified and press the ENT Key. Up/Down and Right/Left Keys: Moves the position one pixel at a time.
Page 205: Parameter Input
Section 4-1 Calibration Use the following procedure to specify the actual dimensions that corre- spond to one pixel. Right and Down Keys: Enlarges the image 10 gradations at a time. SHIFT+Right and Down Keys: Enlarges the image 100 gradations at a time.
Page 206 Magnification and Units Set the physical unit that will correspond to one pixel. Set a value in the range 0.010 to 9.999 for the magnification. F160 screen 200 pixels The magnification is 20(mm) / 200(pixels) = 0.1(mm/pix). In other words, 1 pixel in camera coordinates will correspond to 0.1 mm in physical units.
Page 207: Reference Parameters
Section 4-1 Calibration The initial screen for Calibration will be displayed. Calibration Sampling input Specifying point Specifying coordinate axis Parameter input Reference parameter Select Parameter input. The Parameter Input Screen will be displayed. Parameter input Origin Upper left Coordinate Lefthand Magnification [1.000] Make the settings for each item.
Page 208: Position Displacement Compensation
Section 4-2 Position Displacement Compensation Select Adjust/Calibration. 0.Scn 0 =SET= Adjust Shutter Speed Light control Filtering order(Position) Filtering(Position) BGS levels(Position) Filtering order(Measurement) Filtering(Measurement) BGS levels(Measurement) Calibration The initial settings screen for Calibration will be displayed. Calibration Sampling input Specifying point Specifying coordinate axis Parameter input Reference parameter...
Page 209: Setting Position Displacement Compensation Regions And Directions
4-2-1 Setting Position Displacement Compensation Regions and Directions The F160 has two position compensation regions. Normally, only one position compensation is required. To ensure accurate position compensation or to reduce processing time, perform two-stage compensation. Processing Order for Position Compensation...
Page 210 Section 4-2 Position Displacement Compensation Gray search, page 141 Edge position, page 126 Rotation search, page 173 When the settings have been completed for the measurement conditions, the screen in (3.) will return. 0.Scn 0 =SET= Position P0. Gravity and area Press the ESC Key.
Page 211 Section 4-2 Position Displacement Compensation Two regions each can be set for 1st region and 2nd region. The number of regions to be set depends on the position compensation settings. Refer to the following examples when making the settings. Gravity and area Example Can be converted to binary image (No background noise)
Page 212 Section 4-2 Position Displacement Compensation Edge position Example Changes in density Refer to page 204 Measurement object not at an angle Gray search Example Measurement object with characteritic feature Refer to page 205 Gravity and angle Example Converted to binary image (Axis angle can be found) Refer to page 206 Rotation search...
Page 213 Setting the Binary Level Set the level for converting 256-gradation images into binary images. The F160 performs measurement for the white pixels. Therefore, make the set- tings so that the areas for which the measurement is desired are white. Measurement object Make the measurement object white.
Page 214 Setting the Binary Level Set the level for converting 256-gradation images into binary images. The F160 performs measurement for the white pixels. Therefore, make the set- tings so that the areas to be counted as labels are white. Measurement object Sort: Area,descending order Label No.: 0...
Page 215 Section 4-2 Position Displacement Compensation Set the conditions for judging labels. Set the range for an OK judgement. Example: NG judgement Measurement region The area of the specified label within the measurement region is too small. Once steps 1 to 4 have been completed, the measurement conditions have been set.
Page 216 Section 4-2 Position Displacement Compensation measurement object in the correct position. Reference position for region 0 Reference position for region 1 Edge of measurement object CHECK Scroll the edge position of the measurement object to this reference posi- tion. Setting the Judgement Conditions for Region 0 It is necessary to set judgement conditions for position displacement com- pensation in order to evaluate whether the measurement object is con- tained within the field of view at the time of measurement.
Page 217 Section 4-2 Position Displacement Compensation object in the correct position. Model Search coordinate CHECK Scroll the search coordinates for the measurement object to this position. Setting the Search Region Set the region for which the model is to be searched. It is possible to per- form a search for the entire input image but processing time can be re- duced and accuracy can be increased by setting limits on the search range.
Page 218 Section 4-2 Position Displacement Compensation Set the level for converting 256-gradation images into binary images. The F160 performs measurement for the white pixels. Therefore, make the set- tings so that the areas to be measured are white. Measurement object Make the measurement object white.
Page 219 Section 4-2 Position Displacement Compensation 4-2-1-6 Objects at an Angle with Characteristic Features Measurement method: Rotation search. Refer to page 173. Position displacement compensation region: 1st region (Region 0) Compensation direction: 1st direction. Setting the Measurement Conditions Set the conditions for the search. Registering the Model A characteristic part of the measurement image, is registered as a model.
Page 220 Section 4-2 Position Displacement Compensation Setting Compensation Direction The X and Y coordinates measured for region 0 are used, so specify Re- gion 0 for X, Y, and θ. Region 0 Region 0 θ Region 0 4-2-1-7 Precise Position Compensation of Measurement Objects at an Angle Measurement method: Rotation search.
Page 221 Section 4-2 Position Displacement Compensation 4-2-1-8 Accurate Position Compensation Measurement method: Edge position. Refer to page 126. Region and direction used: 1st region (Region 0), 1st direction 2nd region (Region 3), 2nd direction The displacement for the 1st region is scrolled and then the displacement for the 2nd region is scrolled, so accurate position compensation can be ensured.
Page 222: Details On Expressions
Section 4-3 Details on Expressions Set the edge position conditions for the X direction. Setting 2nd Direction The displacement in the X direction will be compensated, so make the set- tings shown in the following diagram Region 3 None θ None Details on Expressions Expressions are used to set the data to be output to external devices or Mem-...
Page 223: Setting Expressions
Section 4-3 Details on Expressions Data The measurement result for each region can be output. Calculated values can be output. Output number 32 expressions can be set in data 0 to 31. Data0. R0.X-R1.X Expression Measurement result for displayed image Measurement : : 578908.965 ENT:Change Judgements...
Page 224 Section 4-3 Details on Expressions A list of the expression numbers will be displayed. Variable ↑ ↓ S+ESC:Edit Select the number of the expression to be set. The screen for making expression settings will be displayed. Variable0 Measurement : 0.000] Upper 0.000] Lower...
Page 225 Section 4-3 Details on Expressions Select the region number to be set. A submenu will be displayed. The displayed submenu will depend on the measurement conditions set for the region. SeeAlso Refer to page 217 for a list of submenus. Select the setting item from the submenu.
Page 226 Section 4-3 Details on Expressions The settings will be registered. Variable R0.X-R1.X ↑ ↓ S+ESC:Edit CHECK Press the SHIFT + ESC Keys at this screen to copy or clear the expres- sion. The correlation information will be copied for expressions with corre- lation information.
Page 227 Section 4-3 Details on Expressions SeeAlso Refer to page 223. Type of Expression No. expression Measurement Judgement result Variable VR.0 to VR.31 VJ.0 to VJ.31 Data RS.0 to RS.31 Judge PR.0 to PR.31 PJ.0 to PJ.31 Arithmetic Operators Operators Meaning Addition Subtraction Multiplication...
Page 228 Section 4-3 Details on Expressions Function Meaning ANGL Calculates the angle between a straight line joining two points, such as the center of gravity or the center of a model, and a hori- zontal line. The result will be in the range -180 to 180 ° . ANGL(Y component, X component) Example: Set the following to calculate the angle between the straight line joining the center of gravity for region 0 and the cen-...
Page 229 Section 4-3 Details on Expressions Measurement item Meaning Measurement Y2 Y coordinate for lower-right corner of measurement region Gravity X X coordinate for center of gravity of measurement result Gravity Y Y coordinate for center of gravity of measurement result Area AR Area of measurement result Reversed area RA...
Page 230 Section 4-3 Details on Expressions Measurement item Meaning Displacement DY Difference between measurement and reference Y coordi- nate Axis displacement DT Difference between measurement and reference axis (See note.) angle. Diff. area DA Difference between area of measurement and area of ref- erence value Note TH, ST, and DT appear only when the region for gravity and axis is selected.
Page 231 Section 4-3 Details on Expressions Density Average Measurement item Meaning Judge JG Judgement result Dens average AV Density average for measurement result Dens deviation DV Density deviation for measurement region Ref. average SA Density average when measurement region drawn Ref. deviation SD Density deviation when measurement region drawn Diff.
Page 232 Section 4-3 Details on Expressions Measurement item Meaning Reference SY Y coordinate when measurement region drawn Displacement DX Difference between measurement and reference X coordi- nate Displacement DY Difference between measurement and reference Y coordi- nate Labeling Measurement item Meaning Judge JG Judgement result No.
Page 233 Section 4-3 Details on Expressions Measurement item Meaning Reference SX Difference in X coordinates of positions where models reg- istered (model 1 - model 0) Reference SY Difference in Y coordinates of positions where models reg- istered (model 1 - model 0) Ref.
Page 234 Section 4-3 Details on Expressions When Judge JG Is Set for Expression/Data Only the first judgement step outlined above will be preformed. The following results will be output to an external device: For an OK judgment: 0.000 For an NG judgement: -1.000 When not measured: -2.000 Calculating Using Other Expression Values When Variable, Data, or Judge are selected from the list of setting items, cal-...
Page 235 Section 4-3 Details on Expressions Make the settings for Variable 0, Variable 1, and Judge 1. Variable0 DIST(R0.SX,R0.SY,R1.SX,R1.SY) Measurement : 158.121 Set the expression for calculating Upper 180.000] the distance between the two points Lower 130.000] of the reference position. ENT:Change Variable1 DIST(R0.X,R0.Y,R1.X,R1.Y)
Page 236: Display Details
Section 4-4 Display Details numbers are used for VR.@, RS.@, and PR.@, the previous calculation result will be inserted. When the distance between the two points in the measurement region Order for Calculation in example 1 is calculated and 120.25 added to that value. Variable0 Variable 0 ↓...
Page 237 Section 4-4 Display Details added for each scene. This section gives information on the settings possible under Display in Set Mode. CHECK The data set here will be displayed when None or All positions of regions are selected under System/Conditions/Display settings/Display results. Only fixed figures are always displayed, even if other items are selected.
Page 238: Display Strings
Section 4-5 Display Strings CHECK The following customize functions are supported in addition to Display. Unnecessary information can be Messages can be changed to omitted from the display. words normally used. (This setting is applied to all scenes.) Change scene name to detection target Omit this section from display.
Page 239: Step 1: Setting Display Characters
Section 4-5 Display Strings Operational Flow STEP 1 STEP 3 STEP 2 Set display Set display Set display position. conditions. characters. 4-5-1 STEP 1: Setting Display Characters Up to 29 standard size alphanumeric characters can be set. The characters can be selected from the list of characters on the displayed software key- board.
Page 240: Step 2: Setting Display Conditions
Section 4-5 Display Strings Once all characters have been selected, select END. The settings will be registered and the screen in (2.) will return. 4-5-2 STEP 2: Setting Display Conditions Set the conditions for display. The font cannot be specified. The display font will be the same as the menu font.
Page 241: Displaying Measurements
Section 4-6 Displaying Measurements Select Position. 0.Display string String Conditions Position The cursor for setting position and the display region will be displayed. Position 13,8 Display region TwoCamera Press the SHIFT+ENT Keys to switch between Camera 0 and Camera 1 images.
Page 242 Section 4-6 Displaying Measurements Select Display/<Region number>/Display measure. 0.Scn 0 =SET= Display Display string Display measure Display judge Display item Display time Display figure Display line Display box ↑ ↓ ↑ ↓ S+ESC:Edit The setting selections will be displayed. 0.Display measure Measurement Conditions Position...
Page 243: Step 2: Setting Display Conditions
Section 4-6 Displaying Measurements The expression will be set and the screen in (3.) will return. Measurement R0.X-R1.X Measurement : ENT:Change Press the ESC Key. The settings will be registered and the screen in (2.) will return. 4-6-2 STEP 2: Setting Display Conditions Set the conditions for display.
Page 244: Displaying Judgements
Section 4-7 Displaying Judgements Make the settings for each item. Select End. The settings will be registered and the screen in (1.) will return. 4-6-3 STEP 3: Setting Display Position Set the position for character display. The size of the display region shown on the screen is the same as the actual size when displayed.
Page 245 Section 4-7 Displaying Judgements The setting selections will be displayed. 0.Display judge Judge conditions OK string NG string Conditions Position Select Judge conditions. The Judge Conditions Settings Screen will be displayed. Judge conditions Measurement : 0.000 0.000] Upper 0.000] Lower ENT:Change Move the cursor to the square brackets [ ] for the expression and press the ENT Key.
Page 246: Step 2: Setting Display Characters For Ok And Ng Judgements
Section 4-7 Displaying Judgements Press the ESC Key. The settings will be registered and the screen in (2.) will return. 4-7-2 STEP 2: Setting Display Characters for OK and NG Judgements When the judgement result for the expression set in STEP 1: Setting Judge- ment Criteria is OK, set the characters to be displayed for a NG judgement.
Page 247: Step 3: Setting Display Conditions
Section 4-7 Displaying Judgements 4-7-3 STEP 3: Setting Display Conditions Set the conditions for display. The font cannot be specified. The display font will be the same as the menu font. Font size Conditions Twice the height/width of menu font Large: Same size as the menu font Normal:*...
Page 248: Displaying Measurement Region Names
Section 4-8 Displaying Measurement Region Names Displaying Measurement Region Names Use this function to display in Run and Monitor Modes one measurement region name set to the scene. SeeAlso Refer to page 248 for information on inputting comments. CHECK The data set here will be enabled when None or All positions of regions is selected under System/Conditions/Display settings/Display results.
Page 249: Displaying Measurement Time
Refer to page 229. Displaying Measurement Time This function displays the date and time of the measurement on the screens in Run and Monitor Modes. The calendar in the F160 must be adjusted and set beforehand. SeeAlso Refer to page 317.
Page 250: Step 1: Selecting The Display Data
Section 4-9 Displaying Measurement Time 4-9-1 STEP 1: Selecting the Display Data Select the format for the date and time display. Format Display MMDD HHMMSS* 10/01 01:23:45 MMDDHHMM 10/01 01:23 HHMMSS 01:23:45 HHMM 01:23 Note *The default setting is marked with an asterisk. Select Display/Display time.
Page 251: Displaying Fixed Figures
Section 4-10 Displaying Fixed Figures 4-10 Displaying Fixed Figures Use this function to display lines, boxes, circles, and arcs at a fixed position on screens in Run and Monitor Modes. CHECK If the image is reduced, the figure will also be reduced. CHECK Select Display results to display figures using measurement results.
Page 252: Step 2: Drawing Figures
Section 4-10 Displaying Fixed Figures The setting selections will be displayed. 0.Display figure Conditions Draw Select Conditions. The Conditions Settings Screen will be displayed. Conditions Color Figure0 Camera : Camera0 Make the settings for each item. Select End. The settings will be registered and the screen in (1.) will return. 4-10-2 STEP 2: Drawing Figures Select a line, box, circle, circumference, or arc.
Page 253: Displaying Results (Lines, Boxes, Circles, And Cursors)
Section 4-11 Displaying Results (Lines, Boxes, Circles, and Cursors) The Draw Screen will be displayed. Draw 225,221 When Line has been selected, line options of Solid line and Dash line will be displayed. Choose one of these options. Draw the figure in the desired position. SeeAlso Refer to page 28 for methods for drawing regions.
Page 254: Step 1: Setting Display Conditions
Section 4-11 Displaying Results (Lines, Boxes, Circles, and Cursors) 4-11-1 STEP 1: Setting Display Conditions Set the conditions for display. Color Conditions : Green : Red Color OK color Solid line* Property : Solid line Dash line Camera : Camera0 Fill profile Only displayed when two Cameras are used.
Page 255: Step 2: Drawing Figures
Section 4-11 Displaying Results (Lines, Boxes, Circles, and Cursors) 4-11-2 STEP 2: Drawing Figures The coordinates for the figure are set using expressions. SeeAlso Refer to page 211 for methods for setting expressions. Display Coordinate specification method Box result Upper left coordinate (1st point X, 1st point Y) Lower right coordinate (2nd point X, 2nd point Y) Circle result Center coordinate (Center X, Center Y)
Page 256: Editing Measurement Regions And Position Compensation Regions
Section 4-12 Editing Measurement Regions and Position Compensation Regions Place the cursor in the square brackets [ ] for 1st point X and press the ENT Key. The setting items will be displayed. 1st point X Position Measurement Variable ANGL Data ATAN Judge...
Page 257 Section 4-12 Editing Measurement Regions and Position Compensation Regions • Labeling • Gray search • Edge position • Rotation search CHECK The copy function can be executed only within the same scene. When span- ning scenes, copy the whole scene group. SeeAlso Refer to page 254.
Page 258: Clearing Regions
Section 4-12 Editing Measurement Regions and Position Compensation Regions If there is a comment entered for a region, that comment will also be dis- played. Position compensation regions Gravity and area Gray search Gravity and area Gravity and axis Gray search Defect ↑...
Page 259: Changing Region Names (Inputting Comments)
Section 4-12 Editing Measurement Regions and Position Compensation Regions A confirmation message will be displayed. This region will be cleard. Execute Cancel Select Execute. The measurement data for the selected region number will be cleared and the screen in (2.) will return. 4-12-3 Changing Region Names (Inputting Comments) Any comment can be added to any region.
Page 260 Section 4-12 Editing Measurement Regions and Position Compensation Regions The software keyboard will be displayed. Measurement item comment Gravity and area SPC DEL BS INS ← → ENT:Select Ins. Set up to 16 standard characters. SeeAlso Refer to page 31 for details on inputting characters. Once all characters have been set, select END.
Page 262: Other Functions
SECTION 5 Other Functions This section describes additional functions such as changing the measurement setup or backing up data. Changing Scenes and Scene Groups ....... . 5-1-1 Setting Measurement Conditions for Different Models: Changing Scenes253 5-1-2...
Page 263: Changing Scenes And Scene Groups
If a Memory Card is not used, only Scene group 0 can be used. Scene group 0 Scene 0 Scene 1 Scene 30 F160 Scene 31 Scene groups 1 to 31 can be used if a Memory Card is mounted. Scene group 0 Scene 0...
Page 264 Use the scene changing function to switch between different measurement conditions for different measurement setups or measurement objects. Scene 0 will be displayed by default when the power is turned ON, however, the F160 also accommodates scenes 1 to 31. If a Memory Card is inserted and the scene group function used, up to 1,024 scenes can be set.
Page 265: Copying Scene Data
Section 5-1 Changing Scenes and Scene Groups Using Scene Group Function Insert a Memory Card. ---- ---ms 0.Scn 0 Freeze Display the Basic Screen for Monitor Mode or Run Mode. Move the cursor to Scn and press the ENT Key. The Scn 0 to Scn 7 options will be displayed.
Page 266: Initializing Measurement Conditions: Clearing Scenes
Section 5-1 Changing Scenes and Scene Groups CHECK Scene data can be copied only within the same scene group. To copy data between scene groups, copy the whole scene group. Refer to page 257. Move the cursor to Scn and press the ENT Key. ---- ---ms 0.Scn 0 0.Scn 0...
Page 267: Adding Comments To Scenes
Section 5-1 Changing Scenes and Scene Groups The Copy/Clear/Comment Menu will be displayed. Copy Clear Comment Select Clear. A confirmation message will be displayed. This scene data will be cleared Execute Cancel Select Execute. The scene will be cleared. 5-1-4 Adding Comments to Scenes Any comment can be added to each scene.
Page 268: Using Scene Group Function
Section 5-1 Changing Scenes and Scene Groups The scene name will be changed. ---- ---ms 0.LABEL 5-1-5 Using Scene Group Function Use the scene group function to copy and clear whole scene groups and change the scene group name to any 11 standard characters. Insert a Memory Card.
Page 269: Backing Up Data
Memory Card. The same data can also be loaded from a com- puter to the F160. Saving and loading data enables using the same data on other F160 Controllers. It is recommended that data is backed up in case data is lost or the F160 mal- functions. Data...
Page 270 Use the protocol that matches the computer settings. Start the Hyper Terminal program on the computer and make the following communications settings. The same communications settings must be used on both the F160 and the modem on the computer. Item Setting...
Page 271 Section 5-2 Backing Up Data The mode selections will be displayed. ---- ---ms 0.Scn 0 TOOL SAVE Select TOOL. The data selections will be displayed. TOOL System data Scn Group data Scene data System+Scn Group data Image data Memory card Clear image Line brightness I/O monitor...
Page 272 When the transfer has been completed, the screen in (8.) will return. Loading Data from the Computer Data F160 Personal computer Follow steps 1 to 3 in the above procedure to connect the F160 and the computer. SeeAlso Refer to page 258. Select Transfer/Send File from the Hyper Terminal menu.
Page 273 Section 5-2 Backing Up Data Once the preparations have been completed on the computer, display the Basic Screen for Monitor Mode or Run Mode. ---- ---ms 0.Scn 0 Freeze Move the cursor to MON (or RUN) and press the ENT Key. The mode selections will be displayed.
Page 274: Backing Up To Memory Cards
System data Execute Cancel 12. Select Execute. The data will be transferred from the computer to the F160. When loading has been completed, the screen in (1.) will return. 5-2-2 Backing Up to Memory Cards This section describes inserting a Memory Card and backing up settings data to the Memory Card.
Page 275 Section 5-2 Backing Up Data Saving from the F160 to the Memory Card Insert the Memory Card. ---- ---ms 0.Scn 0 Freeze Display the Basic Screen for Monitor Mode or Run Mode. Move the cursor to MON (or RUN) and press the ENT Key.
Page 276 Section 5-2 Backing Up Data Select the desired number for scene group, scene, or image data. Scene group Scene No. Image data Scn Group 0 Scn 0 Memory 0 Scn Group 1 Scn 1 Memory 1 Scn Group 2 Scn 2 Memory 2 Scn Group 3 Scn 3...
Page 277 When saving has been completed, the screen in (6.) will return. Loading from the Memory Card to the F160 Follow steps 1 to 5 for Saving from the F160 to the Memory Card and move to the screen for selecting load destinations.
Page 278: Backing Up To Flash Memory
Card. Precaution Flash memory and Memory Card data is loaded each time the F160 is started up. Therefore, when settings have been changed, be sure to save to flash memory before turning the power OFF. If the power is turned OFF without sav- ing, all of the setting changes will be lost.
Page 279: Checking Image Density Distribution: Line Brightness
Data in memory will be de- stroyed, and the F160 may not operate correctly the next time it is started. When saving has been completed, the screen for step 1 will return.
Page 280 Section 5-3 Checking Image Density Distribution: Line Brightness • Use to check if the light distribution is uneven. If a homogeneous color is being displayed but the graph has an incline, it indicates that the lighting is uneven. • Use to find how great the density difference is between the location to be measured and the background.
Page 281: Checking I/O Status With External Devices
Section 5-4 Checking I/O Status with External Devices The tool selections will be displayed. TOOL System data Scn Group data Scn data System+Scn Group data Image data Memory card Clear image Line brightness I/O monitor Select Line brightness. The Line Brightness screen will be displayed. Line brightness Density range X: 36 - 200...
Page 282 Output to external device. Press the TRIG Key once to send a test character string “TEST STRING” from the F160 to the external device. The contents of the test character string can be changed. Refer to page 272. Input from external device. If more than 26 characters are received, only the first 26 characters will be displayed.
Page 283: Parallel Interface
Section 5-4 Checking I/O Status with External Devices Changing Test Character String and Echo Back Display the Serial I/O Monitor Screen and press the SHIFT+ENT Keys. The screen for making detailed settings will be displayed. Echo back : ON Test string : [TEST STRING] Select ON or OFF for Echo back.
Page 284: Memory Card Operations
The screen in (5.) will return. Memory Card Operations Data settings and measurement images can be saved from the F160 to a Memory Card. The files on the Memory Card can be copied and the file names changed. This section explains these operations for Memory Cards.
Page 285: Creating Directories
Turn OFF the power supply to the Memory Card before removing the Memory Card. If the power is not turned OFF before the Memory Card is removed, the Memory Card and the F160 may be damaged. Refer to page 280. 5-5-1...
Page 286 Section 5-5 Memory Card Operations A list of files in the Memory Card root directory will be displayed. File operation 00/11/01 SYSDAT1 SYD 00/11/01 SYSDAT2 SYD 00/11/01 SYSDAT3 SYD 00/11/01 BOTTLE 00/11/02 SEAL 00/11/02 ENT:Select S+ESC:Edit Press the SHIFT+ESC Keys. The edit menu will be displayed.
Page 287: Copying Files
Section 5-5 Memory Card Operations CHECK The directory is displayed in the list of files, encased in square brackets [ ]. Move the cursor to the directory and press the ENT Key to display a list of files in that directory. Example When directory [DIC_1] is selected.
Page 288: Checking File Properties
Section 5-5 Memory Card Operations The edit menu will be displayed. Property Make directory New file Change name Delete Select New file. CHECK If Make directory is selected, the screen for creating new directories will be displayed. Files can be saved in the newly created directory. The software keyboard will be displayed.
Page 289: Changing File Names
Section 5-5 Memory Card Operations Move the cursor to the file for which the information is to be checked and press the SHIFT + ENT Keys. File operation 00/11/01 SYSDAT1 SYD 00/11/01 SYSDAT2 SYD 00/11/01 SYSDAT3 SYD 00/11/01 BOTTLE 00/11/02 SEAL 00/11/02 ENT:Select S+ESC:Edit...
Page 290: Deleting Files And Directories
Section 5-5 Memory Card Operations The edit menu will be displayed. Property Make directory Change name Delete Select Change name. A software keyboard will be displayed. Change name(System data) [SYSDA ].SYD A B C D E F G H I J K L M N O P Q R S T U V W X Y Z a b c d e f g h i j k l m n o p q r s t u v w x y z...
Page 291: Turning Off The Power Supply To The Memory Card
Turn OFF the power supply to the Memory Card before removing the Memory Card. If the power is not turned OFF before the Memory Card is removed, the Memory Card and the F160 may be damaged. CHECK The total space and free space on the Memory Card will be displayed on this screen.
Page 292 Section 5-5 Memory Card Operations The Drive Status Screen will be displayed. Drive status Drive C0 : Inserted Inserted Free space B/62436KB Stop If a Memory Card is inserted, “Inserted” will be highlighted. Change the display to Stop. CHECK If a Memory Card is not inserted, the display will be “Not inserted.” Select End.
Page 294: System Settings
SECTION 6 System Settings This section describes how to set conditions related to the system environment. Refer to the Communications Reference Manual for information on communications specifications. Entering System Mode ......... . Camera Settings .
Page 295: Entering System Mode
The model is written on each Unit. Menu item Models Details Camera F150-S1A Select the model of the connected Camera. F160-S1* Other Intelligent Lighting 0 Out of use* If a Camera with Intelligent Lighting is con- nected, select the model of the Intelligent Intelligent Lighting 1 LTC20 Lighting.
Page 296 External Strobe disable, start Strobe disable, end Clamp pulse timing [ 80]CLK [ 25]CLK Clamp pulse width ↑ ↓ Precaution When changing the Camera model, save settings data in flash memory. Set the measurement conditions after starting the F160 again.
Page 297: Measurement Result Output Destinations
Section 6-3 Measurement Result Output Destinations Measurement Result Output Destinations The F150 can output judgements and data for measured objects to an exter- nal device. Use the following procedure to make destination settings for judg- ment output and data output. Output item Output destination Data...
Page 298: Selecting Serial Interface As The Output Destination
Section 6-3 Measurement Result Output Destinations 6-3-1 Selecting Serial Interface as the Output Destination Select the format for the outputting data via the serial interface. ASCII Format The following items can be set. Item Details Output form Select ASCII*. Digits of integer Set the number of digits for integer output.
Page 299: Selecting The Memory Card As The Output Destination
Section 6-3 Measurement Result Output Destinations Select Serial. The Output (Serial) Settings Screen will be displayed. Output(Serial) Output form ASCII DIgits of integer Digits of decimal Minus Field separator Comma Record separator Delimiter 0 Suppress SeeAlso Refer to page 29 for details on inputting values. Change the settings for each item.
Page 300 Section 6-3 Measurement Result Output Destinations Binary Format The measurement result multiplied by 1,000 is output as 4 consecutive digits. Item Details Output form Select Binary. Digits of integer These settings are only for ASCII format. No settings are required for binary format.
Page 301: Screen Display And Monitor
Section 6-4 Screen Display and Monitor CHECK The output file will be saved in the OUTFILE directory in the root directory. The screen in (3.) will return. Select End. The settings will be saved and the screen in (2.) will return. Screen Display and Monitor 6-4-1 Measurement Screen Settings...
Page 302 Section 6-4 Screen Display and Monitor The Display Settings Screen will be displayed. Display settings Display image Freeze Display results None Compensated image Scene/mode menu Overall judgement Processing time ↑ ↓ Change the settings for each item. Select End. The settings will be registered and the screen in (2.) will return. Image after Position Compensation Select the image display after measurement if position displacement compen- sation has been specified.
Page 303 Section 6-4 Screen Display and Monitor Selection Details Last NG The image of the latest image to receive an overall judgement of NG is displayed. The latest measurement results are always displayed for overall judgement and measurement time. Be careful, because the display image and the overall judgement will not match when this image type is selected if the latest mea- surement gave an OK judgement.
Page 304 Section 6-4 Screen Display and Monitor CHECK The description given here is based on default key allocations. Be careful if the key allocations have been changed. None (default) Only the overall judgement will be displayed. 0.Scn 0 OK 67ms Freeze Position The position displacement compensation result will be displayed.
Page 305 Section 6-4 Screen Display and Monitor TwoCamera Use the Up/Down Keys to switch Cameras. This operation is disabled for reduction displays. All Positions of The set measurement regions and position displacement compensation Regions regions are displayed in solid lines. OK 67ms 0.Scn 0 All positions of regions Freeze...
Page 306 Section 6-4 Screen Display and Monitor CHECK The variable names and judgement conditions can be adjusted. Press the SHIFT + ENT Keys in the variable screen shown above and the screen for selecting variables will be displayed. Move the cursor to the variable to be adjusted and press the ENT Key.
Page 307 Section 6-4 Screen Display and Monitor Individual Variable, Individual Data, and Individual Judgements The measurement values for an expression are displayed. Use the Up/Down Keys to switch between expressions. OK 67ms 0.Scn 0 Individual judge Judge0 Judge :OK Expressions : P0.X 100 Measurement : 124567.000 Freeze...
Page 308: Selecting Color Or Monochrome Monitors
Section 6-4 Screen Display and Monitor displays in order. Data Judge Variables All Judge All Data All Variables Individual Judge Individual Data Individual Variable Region Position Compensation Position Compensation All Result of Regions All Result of Regions All Positions of Regions All Positions of Regions Individual Region Individual Region...
Page 309: Changing Character Or Figure Colors
Section 6-4 Screen Display and Monitor The Monitor Settings Screen will be displayed. Monitor Monitor Color Color Monochrome Select the monitor type. Select End. The settings will be registered and the screen in (2.) will return. 6-4-3 Changing Character or Figure Colors The color for characters or added figures can be set.
Page 310: Creating Original Colors
Section 6-4 Screen Display and Monitor OK and NG Colors The judgement display, all measurement values, and the measurement region will be displayed in the color set under OK color or NG color, depending on the measurement result. OK color NG color (square color) OK 67ms 0.Scn 0...
Page 311 Section 6-4 Screen Display and Monitor SeeAlso Refer to page 298 for information on how to display the original color. The default settings are shown below. Display item R (red) G (green) B (blue) Original 0 Original 1 Original 2 Original 3 Original 4 Original 5...
Page 312: Customizing Operations
(See note 1.) Previous scene group Note 1 Function keys are suppported only for Next scene group F160-KP. Clear image If the F150-KP is being used, input will not be possible using these keys, even if Erase characters key allocations are made.
Page 313 Section 6-5 Customizing Operations Function of Allocated Functions Item Function None Nothing allocated. Display settings Displays the SYS/Conditions/Display settings screen. Previous image Displays the previous memory image. (See note 1.) Next image (See Displays the next memory image. note 1.) Change back- Changes the brightness of the background (dark e clear) for ground...
Page 314 Section 6-5 Customizing Operations Thumbnail Display Stored images are displayed 4 at a time, making it faster to find a particular measurement image. Last (Mem 0) Last 1 (Mem 1) Last 2 (Mem 2) Last 3 (Mem 3) SHIFT+Up/Down Keys: Switches to the last four or next four images. Up/Down and Left/Right Keys: Moves the thick frame for selecting images.
Page 315: Capturing And Saving Images
Turn ON the display capture function to capture the image displayed on the monitor screen and save it to the Memory Card. Stored images can be pasted to documents on a personal computer or loaded to the F160 and re-measured. The default setting is OFF. CHECK •...
Page 316 LIVE .BMP Density images with 256 graduations will be saved in bitmap format. These images can be loaded to the F160 and re- measured. (Binary images will also be Captured display saved in bitmap format OK 67ms 0.Scn 0...
Page 317: Masking Display Of Setting Items
Section 6-5 Customizing Operations 6-5-3 Masking Display of Setting Items The following menu selections are displayed when you enter Set Mode. Menu items that will not be used can be set to not be displayed. Example: Default Set mode menu Position and Display set to not appear.
Page 318: Masking Display Of Processing Items
Section 6-5 Customizing Operations 6-5-4 Masking Display of Processing Items The F160 has multiple processing items and these are displayed when mea- surement regions are being set. Each item can be set to be displayed or not displayed. Example: The default display items set under Area (var.
Page 319: Setting Passwords
Section 6-5 Customizing Operations Precaution If this function is set to OFF and settings data changed, always save the data before changing scene groups. When scene groups are changed, data from the flash memory or the Memory Card is loaded. So if the changed settings data is not saved, the data will be replaced by the loaded data.
Page 320 Section 6-5 Customizing Operations The Password Settings Screen will be displayed. Password Mode switch : Unnecessary Scene switch : Unnecessary Set Necessary or Unnecessary. Select End. If Necessary has been selected, the Input Password Settings Screen will be displayed. Input Password A B C D E F G H I J K L M N O P Q R S T U V W X Y Z a b c d e f g h i j k l m n...
Page 321: Setting Conditions For Saving Measurement Images
Manual. Setting Conditions for Saving Measurement Images The F160 can save up to 35 measured images. These 35 images are shared by 32 scenes. The condition for saving the images can be selected from sav- ing only when the measurement result is NG or saving all images regardless of the measurement result.
Page 322: Displaying Stored Images
Section 6-6 Setting Conditions for Saving Measurement Images The Measurement Control Settings Screen will be displayed. Measurement control Image storage None STEP in measure None BUSY range Only NG Reflect position Reflect region Reflect variable Reflect judge Change the conditions under Image storage. Select End.
Page 323 Section 6-6 Setting Conditions for Saving Measurement Images Details Display Freeze The image that has just been measured is displayed. The type of image displayed depends on the settings in SYS/Display. Through Last NG Note 1 Refer to page 290. Reduction freeze The Camera number is added to the front of the display if there Reduction through...
Page 324: Clearing All Stored Images
Section 6-6 Setting Conditions for Saving Measurement Images CHECK When Display is set to Last NG or Reduction last NG, the display cannot be switched to stored images. Change the display to Freeze or another display mode and then use the SHIFT+Up/Down Keys to switch between images. 6-6-2 Clearing All Stored Images All images are automatically cleared when the power is turned OFF, but the...
Page 325: Using Busy Signals
Using BUSY Signals Using BUSY Signals The BUSY signal is a control signal used to show that the F160 is busy pro- cessing. The ON/OFF timing of this BUSY signal is monitored at the external device to time communications. The handling of the BUSY signal can be changed to create a smoother system.
Page 326: Selecting Items To Be Shown In Overall Judgements
Section 6-8 Selecting Items to be Shown in Overall Judgements The Measurement Control Settings Screen will be displayed. Measurement control Image storage None STEP in measure ERR ON BUSY range Measurement Reflect position Reflect region Reflect variable Reflect judge Change the STEP in measure and BUSY range settings. Select End.
Page 327: Setting Startup Conditions
Use the following procedure to set the status when the power is turned ON. If the F160 is set to start in Run Mode for the scene where the desired measure- ment conditions are registered, measurement of objects can be started by simply turning the power ON.
Page 328: Setting The Calendar Date And Time (Date/Time)
Section 6-10 Setting the Calendar Date and Time (Date/Time) The Startup Mode Settings Screen will be displayed. Startup mode Startup Scn Group : Scn Group 0 Startup scene Scn 0 Startup mode Language : English Menu selection Camera settings Change the settings. Select End.
Page 329: Checking The Software Version
Section 6-11 Checking System Information The Memory capacity/Version Menu will be displayed. Memory capacity Version Select Memory capacity. The memory capacity will be displayed. Free space Total space Memory capacity Work memory(Main) 11992/16384 KB Work memory(Model) 7168/ 7168 KB Flash memory(Program) 768/ 2048 KB Flash memory(Data) 2048/ 2048 KB...
Page 330: Changing To Conversational Menus
Select OK to exit this screen. The screen in (2.) will return. 6-12 Changing to Conversational Menus The F160 has Conversational Menus and Expert Menus. The data items that are held when switching from the Expert Menus to the Conversational Menus are given below. Data...
Page 331 Conversational Menus. Cancel Select OK. CHECK If scene group 0 is displayed, the data will be saved to the F160 internal flash memory. If scene groups 1 to 31 are displayed, the data will be saved (overwritten) to the Memory Card.
Page 332: Appendix
SECTION 7 Appendix Terminology........... Character Codes.
Page 333: Terminology
Upper and lower threshold values (binary levels) are set and the parts of the density image that fall within that gradatiion range are converted to white pixels and the rest are converted to black pixels. The F160 uses the white pixels to measure the object.
Page 334: Character Codes
Section 7-2 Character Codes Term Explanation Auxiliary model Auxiliary models are models created between the registered models. Auxiliary models are automatically created by the F160 when multiple models have been registered to the same index number. Registered models Auxiliary Auxiliary Auxiliary...
Page 335: Troubleshooting
→ ← ↑ ↓ Troubleshooting This section lists the errors that may occur during F160 operation, along with their probable causes and remedies. The letters used in the reference page column represent the following refer- ence materials: Setup: Setup Manual Expert: Expert Menu Operation Manual (this manual) Comm.: Communications Reference Manual...
Page 336 Camera is not connected prop- Check the following: Setup erly.* - Are the Camera Cables connected to the F160? Expert: page 284 - Is the Camera Cable disconnected from the Camera? - Check the settings under SYS/Camera settings then cycle the power.
Page 337 Background must not be same Change one of the colors. color as Normal Communications error (Data trans- Turn OFF the power to the F160, and check for the following Comm., fer) (See note.)* items before restarting the F150. Setup - The cable is connected properly.
Page 338 Troubleshooting Error message Causes and remedies Refer- ences Timeout error. (Data transmis- Turn OFF the power to the F160, and check for the following Comm., sion)(See note.)* items before restarting the F150. Setup - The cable is connected properly. Timeout error (Normal) - The communications specifications for the external device and Timeout error.
Page 339: Faq
Section 7-4 Error message Causes and remedies Refer- ences Memory card is not inserted (See Insert the recommended Memory Card. Setup note.)* Insufficient free space of memory - Delete unnecessary files to create free space. Expert: card (See note.)* page 279 - Replace the Memory Card with a bigger capacity card.
Page 340 Index conditions See inspection conditions area (variable box) See judgement conditions See also measurement methods Console, 24 procedure, 68 Console keys auxiliary models customizing, 301 classification, 109 conversational menus, 319 compatibility, 14 coordinate mode area (variable box), 79 background suppression. See BGS, 41 classification, 111 backing up data, 258 defect, 117...
Page 341 Index Detailed Conditions Settings Screen edge width classification, 108 See also measurement methods edge pitch, 125 procedure, 133 edge position, 132 erosion, 42 edge width, 139 errors, 324 flexible search, 154 examples, 33 gray/precision search, 146 expert menus relative search, 171 See also menus rotation search, 181 starting, 22...
Page 342 39 displaying stored images, 311 line brightness, 268 input commands, 62 input devices, 24 inputting manuals characters, 31 F160 manuals, xi numeric values, 29 measured images inspection conditions conditions for saving, 310 setting, 35 measurement conditions installation, 22...
Page 343 Index measurement regions, 46 area (variable box), 70 OCR for 1 character defect, 112 See also measurement methods defect (variable box), 82 character codes, 323 density data, 118 procedure, 98 displaying, 294 offset width drawing, 51 area (variable box), 76 edge pitch, 122 operating modes, 26 edge position, 128...
Page 344 Index reference values serial interface, 62 area (variable box), 76 checking I/O status, 270 defect (variable box), 86 outputting results, 287 edge position, 129 shutter speed, 37 edge width, 136 smoothing, 42 gravity and area, 53 software system version, 318 gravity and axis, 94 starting, 22 labeling, 162...
Page 346: Revision History
Revision History A manual revision code appears as a suffix to the catalog number on the front cover of the manual. Cat. No. Z147-E1-02 Revision code The following table outlines the changes made to the manual during each revision. Page numbers refer to the previous version.
