3
Installation
3.1
Installing the Module into the Terminal Cover
3.2
DeviceNet
Terminal
Description
1
V-
2
CAN_L
3
Shield
4
CAN_H
5
V+
Notes:
• For DeviceNet
TM
power supply and network cabling details, refer to the DeviceNet
• All terminals have basic isolation (single insulating distance).
• Protection against contact can only be ensured with additional measures (i.e. double insulation).
Figure 1: Installing the DeviceNet Communciations Module
Terminal Block
TM
Recommended
Important
Wire Color
Black
If controller is located at either end of the network, a terminating resistor (120 ohm,
Blue
metal film, 1/4 Watt) should be connected across CAN_L and CAN_H.
Bare
Terminal 3 is not connected to Earth ground.
If controller is located at either end of the network, a terminating resistor (120 ohm,
White
metal film, 1/4 Watt) should be connected across CAN_L and CAN_H.
Red
11 - 25 VDC power supply; current consumption (100mA @ 11VDC max)
1 2 3 4 5
TM
specification.
5
0.5 Nm/ 4.5 lb-in
< _ 2.8 mm²
(12-22 AWG)
7mm
CMVDVN01A
