Date Format
US Standard (mm/dd/yy) or European
Standard (dd/mm/yy). Default: U.S. Standard
Custom Main Display
Display:
• Res Vol or Continuous Rate
• Power Source Always or Low 9 volt battery only
Default: Res Vol and Low 9V
Auto Review*
Select the automatic program review feature
during the pump's power‑up sequence.
Default: On
• Dose Counters (0 to 999 Given and/or
Attempted). Default: On
• Given. Default: On
• Doses Hour By Hour (up to 48 hours in
increments of 1 hour). Default: Off
• Patient Review. Default: Off
• Pain Scale (subjective pain scale rating of
0 to 10 in increments of 1). Default: On
• Pain Scale Log (0 to 500 entries). Default: On
• Delivery Log (0 to 500 events). Default: Off
• Event Log (0 to 500 events). Default: Off
• New Patient Marker. Default: On
New Patient Marker*
Reports/No Clear, Power‑up/No Clear,
Reports/Clear, Power‑up/Clear
Default: Reports/No Clear
Air Detector Required
Required or Not Required.
Default: Not Required
Note The CADD‑Sentry Medication Software programming mode must be used to change a customized code back to the standard lock level
®
code with CADD‑Prizm PCS II pumps with software revision E or higher.
®
* If programmed to be part of pump programming screens in Biomed Toolbox.
6
Default:ing the Lock Level Code &
Clinician Bolus Code
The standard Lock Level Code (061) can be
changed to a customized code using the
Biomed Toolbox Custom Lock Code feature.
See the Operator's Manual supplied with the
pump for instructions on customizing the Lock
Level Code. If it becomes necessary to change
a customized code back to the standard Lock
Level Code, do the following:
1. Press the OPTIONS key until the Lock Level
screen appears
2. Press the ENTER key twice
3. Scroll to 911
4. Press the OPTIONS key
Compatible Reservoirs and
Administration Sets
• 50‑ml or 100‑ml CADD
cassette reservoir, used with the CADD
extension set with anti‑siphon valve.
• CADD administration set with integral
®
anti‑siphon valve, with or without bag spike
(allows use of flexible plastic bag or sterile
vial with injector)
• CADD
administration set with add on
®
anti‑siphon valve and bag spike (allows for
gravity priming before attaching the add on
anti‑siphon valve)
Remote Dose Cord
Smiths Medical provides a Remote Dose Cord
for the PCA delivery mode. The push button
switch is a Single Pole Double Throw (SPDT).
When the Remote Dose Cord is attached to the
pump, the patient may press the Remote Dose
button to receive a Demand Dose. The clinician
may use the Remote Dose button to deliver a
clinician bolus. For easy access, the Remote
Dose cord may be fastened to the patient's
clothing or bedsheet with the attached clip.
NOTE
To detach the Remote Dose cord from the
pump, grasp the Remote Dose cord connector
and pull back using a straight, steady motion.
Do not twist or turn the connector, or use
any instrument to remove it. For additional
specifications refer to the Operator's Manual
provided with the product.
