OPERATOR MANUAL
IMPORTANT INFORMATION, KEEP FOR OPERATOR
This manual provides information for:
MODEL HY-6CAV
HYPLUS™
ATMOSPHERIC
STEAMER CAVITIES
· For Models: HY-6SM, HY-6SG, HY 6SE
· Capacity: 6 Steamer Pans (12" x 20" x 2-1/2")
THIS MANUAL MUST BE RETAINED FOR FUTURE REFERENCE.
READ, UNDERSTAND AND FOLLOW THE INSTRUCTIONS AND
WARNINGS CONTAINED IN THIS MANUAL.
WARNING / FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
WARNING
Improper installation, adjustment, alteration, service
or maintenance can cause property damage, injury or
death. Read the installation, operating and maintenance
instructions thoroughly before installing or servicing this
equipment.
It is the responsibility of the consignee to inspect the container upon receipt of
same and to determine the possibility of any damage, including concealed dam-
age. Unified Brands suggests that if you are suspicious of damage to make a
notation on the delivery receipt. It will be the responsibility of the consignee to file
a claim with the carrier. We recommend that you do so at once.
Manufacture Service/Questions 888-994-7636.
Information contained in this document is known to be current and accurate at the time
of printing/creation. Unified Brands recommends referencing our product line websites,
unifiedbrands.net, for the most updated product information and specifications.
PART NUMBER 121001 REV D (10/10)
DOMESTIC
READY
ON
WATER FILL
LOW WATER
HIGH PRESSURE
1055 Mendell Davis Drive
Jackson, MS 39272
888-994-7636, fax 888-864-7636
unifiedbrands.net
Advertisement
Table of Contents
Related Manuals for Groen HY-6CAV
Summary of Contents for Groen HY-6CAV
- Page 1 OPERATOR MANUAL IMPORTANT INFORMATION, KEEP FOR OPERATOR This manual provides information for: MODEL HY-6CAV DOMESTIC HYPLUS™ ATMOSPHERIC STEAMER CAVITIES · For Models: HY-6SM, HY-6SG, HY 6SE · Capacity: 6 Steamer Pans (12” x 20” x 2-1/2”) READY WATER FILL LOW WATER HIGH PRESSURE THIS MANUAL MUST BE RETAINED FOR FUTURE REFERENCE.
-
Page 2: Important Operator Warnings
DO NOT USE CLEANING OR DE-LIMING AGENTS THAT CONTAIN SULFAMIC ACID OR ANY CHLORIDE, INCLUDING HYDROCHLORIC ACID. IF THE CHLORIDE CONTENT OF ANY PRODUCT IS UNCLEAR, CONSULT THE MANUFACTURER. DO NOT USE CLEANING OR DE-LIMING AGENTS THAT CONTAIN MORE THAN 30% PHOSPHORIC ACID. OM-HY-6CAV... - Page 3 USE NO DE-GREASER THAT CONTAINS POTASSIUM HYDROXIDE OR SODIUM HYDROXIDE OR IS ALKALINE. WARNING: USE OF ANY REPLACEMENT PARTS OTHER THAN THOSE SUPPLIED BY GROEN OR THEIR AUTHORIZED SERvICE AGENTS vOIDS ALL WARRANTIES AND CAN CAUSE BODILY INJURY TO THE OPERATOR AND DAMAGE THE EQUIPMENT. SERvICE PERFORMED BY OTHER THAN FACTORY- AUTHORIZED PERSONNEL WILL vOID ALL WARRANTIES.
-
Page 4: Table Of Contents
370 Wabasha St. Paul, Minnesota 55102 800 328-3663 or 612 293-2233 NATIONAL FIRE PROTECTION ASSOCIATION 60 Battery March Park Quincy, Massachusetts 02269 NFPA/70 The National Electrical Code NSF INTERNATIONAL 789 North Dixboro Road P.O. Box 130140 Ann Arbor, Michigan 48113-0140 OM-HY-6CAV... -
Page 5: Equipment Description
Equipment Description THIS OPERATOR MANUAL APPLIES The Groen HY-6 HyPlus Steamer is designed to bring you years of service. It has ONLY TO THE CAVITIES (COOKING two stainless steel cavities (cooking chambers) and a control compartment, which CHAMBERS) OF YOUR HY-6S SERIES houses the electrical components and steam valves. -
Page 6: Installation
MAKING ELECTRICAL OR MECHANICAL CHANGES TO THE UNIT WITHOUT APPROVAL Electrical Supply Connection FROM THE GROEN FOOD SERVICE On models HY-6SG and HY6-SE, power is supplied to cavity controls ENGINEERING DEPARTMENT MAY VOID and blower from the boiler base, and no other electrical connections are WARRANTIES. - Page 7 Leave an air gap between the hose and the building drain, and don’t allow water traps in the line. OM-HY-6CAV 7...
-
Page 8: Installation
3. Cold water (for faucet on 36” or wider units with kettles. 4. Cold water (for condenser spray). 5. Not used. 6. Drain (for steamers and condenser spray). Also for kettle condensate and sink where used. 7. Electrical (conduit through underside, terminals at the right on the inside). OM-HY-6CAV... -
Page 9: Initial Start-Up
Turn off power to the gas or electric pressure boiler. Refer to the steam boiler operator manual, if necessary. If the unit functions as described above, it is ready for use. If it does not, contact your Groen Authorized Service Agent. OM-HY-6CAV 9... -
Page 10: Operation
Steam will be delivered to the cavity until the timer is returned to OFF. Open the door. Using a pad or oven mitt to protect your hands, remove the pans from the steamer. 10. To shut down the unit, turn the Timer to the OFF position. OM-HY-6CAV... -
Page 11: Cleaning
NEVER HOSE OR STEAM CLEAN ANY PART OF Mild detergent THE UNIT. Stainless steel exterior cleaner such as Groen Spray Degreaser (Part No. 114801), Zepper® DON’T MIX DE-LIMING AGENTS (ACID) WITH DE- De-greaser, such as EncompasS®, Malone 34®, Puritan Puribrute®, or GREASERS (ALKALI ) ANYWHERE IN THE UNIT. -
Page 12: Maintenance
Certain parts may need replacement after BEFORE REPLACING ANY PART TURN OFF prolonged use. If there is a need for service, only Groen personnel or Authorized Groen THE ELECTRICAL POWER TO THE UNIT. Service Representatives should do the work. -
Page 13: Troubleshooting
Troubleshooting Groen Steamers are designed to operate smoothly and efficiently when properly maintained. However, the following is a list of things to check if there is a problem. Wiring diagrams are furnished inside the service panel. SYMPTOMS WHAT TO CHECK Timer control will not operate a. -
Page 14: Parts List
HY-6SG, HY-6SE, and HY-6SM Parts List Steamer Cavity Only OM-HY-6CAV... - Page 15 Connector 054493 Cable Clamp 087958 Tube, Upper 100551 Nut, 10-32 071256 Elbow 042364 Nut, 8-32 002632 100553 Transformer, 75VA 480V - SE - 480V 121717 Tube, Supply 100552 Transformer, 75VA 208/240V - SE 121716 Lower Cavity Drain Hose 088848 OM-HY-6CAV 15...
- Page 16 Motor/Fan Parts List Assembly DESCRIPTION PART NO. Motor 096739 Slinger Washer 096831 Motor Mounting Plate 094134 Shaft Seal 096868 Plate Seal Holder 096752 OM-HY-6CAV...
- Page 17 Retainer, Top 123156 Cover, Right Side HY-6SG 143778 Screw, 8-32 x 3/8 slotted hex head 004173 Cover, Left Side 123184 Door Handle 129723 Cover Assembly, Top 123182 Door Hinge 094143 Screw, 10-32 x 3/8 Truss Head 004173 Outer Door 094140 OM-HY-6CAV 17...
- Page 18 069762 Door Screws 05764 U-Channel Assy. (Incl. Door Spring 078911) 094144 Door Hinge 094143 Latch Spring 078911 Outer Door 094140 Latch Pin 078914 Insulate Board (not shown) 094142 Left Pan Rack 094148 Blower Cover/Right Pan Rack 096788 X-Not Shown OM-HY-6CAV...
- Page 19 Spray Condenser Description Part No. Description Part No. Solenoid Valve (Spray Condenser) 099221 Spacer 099212 Hose d “ ID x 8” Long 099282b Hose, Outlet 1 “ID x 3” Long 099280b Rubber Flap 099213 Anchor Coupling, d” NPT N89267 OM-HY-6CAV 19...
-
Page 20: Parts List
Hole Plug, 7/8” Dia. 137553 Bushing, Strain Relief 121742 Harness, Power Cord, HY-6SM 137842 Screw, Hex Slot Washer HD Cap, 8-32 x 074242 Nut, Hex Keps, #8-32 069784 1/4” Long Screw Round HD, 8-32 x 1 1/4” Long 005056 OM-HY-6CAV... -
Page 21: Electrical Schematics
HY-6SM HyPlus Electrical Schematic Steamer Cavities OM-HY-6CAV 21... - Page 22 HY-6SE HyPlus Electrical Schematic Steamer Cavities OM-HY-6CAV...
-
Page 23: Electrical Schematics
HY-6SG HyPlus Electrical Schematic Steamer Cavities OM-HY-6CAV 23... -
Page 24: Service Log
Service Log Model No: Purchased From: Serial No: Location: Date Purchased: Date Installed: Purchase Order No: For Service Call: Date Maintenance Performed Performed By OM-HY-6CAV... - Page 25 OM-HY-6CAV 25...
- Page 26 OM-HY-6CAV...
- Page 27 OM-HY-6CAV 27...
- Page 28 1055 Mendell Davis Drive • Jackson MS 39272 888-994-7636 • 601-372-3903 • Fax 888-864-7636 unifiedbrands.net PART NUMBER 121001 REV D (10/10) © 2010 Unified Brands. All Rights Reserved. Unified Brands is a wholly-owned subsidiary of Dover Corporation.
