Federal regulations require ceiling fans

with light kits manufactured or imported

after January 1, 2009, to limit total

wattage consumed by the light kit to

190W.

Therefore, this fan is equipped

with a wattage limiting device.

Installation Guide

For Models:

E-WOD52ABZ5C

E-WOD52CS5C

LISTED

For

Wet Location

E192641

net weight of fan: 18.08 lb. (8.2 kg)

READ THESE INSTRUCTIONS AND

SAVE THEM FOR FUTURE USE

Need help?

Do you have a question about the E-WOD52ABZ5C and is the answer not in the manual?

Questions and answers

Summary of Contents for Ellington E-WOD52ABZ5C

Page 1: Table Of Contents
190W. Therefore, this fan is equipped with a wattage limiting device. Installation Guide For Models: E-WOD52ABZ5C E-WOD52CS5C Table of Contents: Safety Tips. pg. 1 Unpacking Your Fan. pg. 2 Parts Inventory. pg. 2 Installation Preparation.
Page 2: Safety Tips
SAFETY TIPS. WARNING: To reduce the risk of electrical shock, turn off the electricity to the fan at the main fuse box or circuit panel before you begin the fan installation or before servicing the fan or installing accessories. READ ALL INSTRUCTIONS AND SAFETY INFORMATION CAREFULLY BEFORE INSTALLING YOUR FAN AND SAVE THESE INSTRUCTIONS.
Page 3: Unpacking Your Fan
1. Unpacking Your Fan. Carefully open the packaging. Remove items from Styrofoam inserts. Remove motor housing and place on carpet or Styrofoam to avoid damage to finish. Do not discard fan carton or Styrofoam inserts should this fan need to be returned for repairs.
Page 4: Installation Preparation
3. Installation Preparation. blade edge To prevent personal injury and damage, ensure that the hanging location allows the blades a inches clearance of 7ft. (2.13m) from the floor and 30in. 7 feet (76cm) (76cm) from any wall or obstruction. (2.13m) This fan is suitable for room sizes up to 400 square feet (37.2 square meters).
Page 5 5. Fan Assembly (with downrod). If you wish to extend the hanging length of set screw hole your fan, you must remove the hanging ball set screw from the 4in. downrod provided to use with an stop pin extended downrod (sold separately). [If you wish to use the 4in.
Page 6: Fan Assembly. Pgs
5. Fan Assembly (with downrod). (cont.) With the hanging bracket secured to the outlet box and able to support the fan, you are now ready to hang your fan. Grab the fan firmly with two hands. Slide downrod through opening in hanging hanging bracket tab bracket and let hanging ball rest on the hanging hanging ball slot...
Page 7: Wiring
7. Wiring. CAUTION: Be sure outlet box is properly grounded and that a ground wire (GREEN or Bare) is present. white supply wire ground Make sure all electrical connections comply with (green or bare) Local Codes or Ordinances and the National black supply wire Electrical Code.
Page 8: Blade Assembly
9. Blade Assembly. Time Saver: Washers for blade screws can be set on each blade screw prior to installing blades. motor housing Locate 15 blade attachment screws and washers in one of the hardware packs. Hold blade arm up to blade and align holes. (Be sure to install blades with ridged-side facing up and flat side facing the floor).
Page 10: Testing Your Fan
10. Light Kit Assembly (Optional). (cont.) Place lock washer and hex nut on threaded rod. Tighten hex hex nut nut over lock washer so that the light kit fitter fits securely on molex connections lock washer the switch housing cap. Make wire connections as described below.
Page 11: Troubleshooting
Troubleshooting. Warranty. ELLINGTON LIMITED LIFETIME WARRANTY: ELLINGTON/LITEX INDUSTRIES, LTD. warrants this fan to the original household purchaser for indoor and outdoor use under the following provisions: 1-YEAR WARRANTY: ELLINGTON/LITEX INDUSTRIES, LTD. Problem: Fan fails to operate. will replace or repair any fan which has faulty performance Solutions: due to a defect in material or workmanship.
