Ellington E-VER54ABZ5LKRW Installation Manual

Ellington E-VER54ABZ5LKRW Installation Manual

Elevating style

Advertisement

Federal regulations require ceiling fans
with light kits manufactured or imported
after January 1, 2009, to limit total
wattage consumed by the light kit to
190W.
Therefore, this fan is equipped
with a wattage limiting device.
Installation Guide
For Models:
E-VER54ABZ5LKRW
E-VER54BNK5LKRW
E206035
net weight of fan: 20.28 lb. (9.2 kg)
READ THESE INSTRUCTIONS
AND SAVE THEM FOR FUTURE USE

Table of Contents:

Warranty. pg. 9
PRINTED IN CHINA

Advertisement

Table of Contents
loading

Summary of Contents for Ellington E-VER54ABZ5LKRW

  • Page 1: Table Of Contents

    Therefore, this fan is equipped with a wattage limiting device. Installation Guide Table of Contents: For Models: Safety Tips. pg. 1 E-VER54ABZ5LKRW Unpacking Your Fan. pg. 2 E-VER54BNK5LKRW Parts Inventory. pg. 2 Installation Preparation. pg. 3 Hanging Bracket Installation. pg. 3 Fan Assembly.
  • Page 2: Safety Tips

    SAFETY TIPS. WARNING: To reduce the risk of electrical shock, turn off the electricity to the fan at the main fuse box or circuit panel before you begin the fan installation or before servicing the fan or installing accessories. READ ALL INSTRUCTIONS AND SAFETY INFORMATION CAREFULLY BEFORE INSTALLING YOUR FAN AND SAVE THESE INSTRUCTIONS.
  • Page 3: Unpacking Your Fan

    1. Unpacking Your Fan. Carefully open the packaging. Remove items from Styrofoam inserts. Remove motor housing and place on carpet or Styrofoam to avoid damage to finish. Do not discard fan carton or Styrofoam inserts should this fan need to be returned for repairs.
  • Page 4: Installation Preparation

    3. Installation Preparation. blade edge To prevent personal injury and damage, ensure inches that the hanging location allows the blades a 7 feet (76cm) (2.13m) clearance of 7ft. (2.13m) from the floor and 30in. (76cm) from any wall or obstruction. 12ft.
  • Page 5: Fan Assembly. Pgs

    5. Fan Assembly. set screw hole set screw stop pin If you wish to extend the hanging length of your fan, you must remove the hanging ball from the 8in. downrod provided to use with an extended hanging ball downrod (sold separately). [If you wish to use the 8in.
  • Page 6: Wiring. Pgs

    5. Fan Assembly. (cont.) safety cable loop wood With the hanging bracket secured to the outlet box ceiling and able to support the fan, you are now ready to joist hang your fan. Grab the fan firmly with two hands. wood screw Slide downrod through opening in hanging bracket and washer...
  • Page 7: Canopy Assembly

    white supply wire 6. Wiring. (cont.) black supply wire CAUTION: Be sure outlet box is properly grounded and ground (green that a ground wire (GREEN or Bare) is present. or bare) blue Make sure all electrical connections comply with Local Codes or Ordinances and the National Electrical Code.
  • Page 8: Blade Assembly

    8. Blade Assembly. blade attachment screws Locate 15 blade attachment screws in one of the hardware packs. Hold blade plate up to blade blade arm and align holes, as shown, and lower blade arm blade over blade holes. Insert 3 blade attachment screws with fingers first and then tighten screws securely with a Phillips screwdriver.
  • Page 9: Wall Control Operation

    10. Wall Control Operation. ON/OFF slider switch - turns wall control ON or OFF HI button - turns fan to HIGH speed MED button - turns fan to MEDIUM speed LOW button - turns fan to LOW speed FAN OFF button - turns fan OFF REV button - used to REVERSE blade direction (fan must be set on low before reversing blade direction)
  • Page 10: Troubleshooting

    Troubleshooting. Warranty. ELLINGTON LIFETIME LIMITED WARRANTY: WARNING: Failure to disconnect power supply ELLINGTON/LITEX INDUSTRIES, LTD. warrants this fan to the prior to troubleshooting any wiring issues may original household purchaser for indoor use under the result in serious injury. following provisions: Problem: Fan fails to operate.
