shown on the screen:
oscillator 1 |waveform
wave squa|para 32|rang
After a short delay, the four names and values are shown again.
Press S1 again to bring the mixer page. L2 lights up in yellow, and the LCD display shows the
following parameters:
Mix 32|nois 0|sub
xmod off|amnt 31|fuzz
Press S1 again to get back to the oscillators page.
Using the encoder
When Ambika displays a parameters page, the rotary encoder can be used to scroll through the
parameters. The name of the active parameter is capitalized. For example, oscillator 1 range is here
the active parameter:
wave saw|para 0|Rang
wave squa|para 32|rang
Rotate the encoder clockwise to make tune the active parameter, rotate the encoder counter-
clockwise to make para the active parameter. If you continue rotating the encoder clockwise, the next
page will become active.
Once a parameter is selected (capitalized), click the encoder to edit it. The full name of the parameter
is displayed on the screen. The encoder can now be used to increment/decrement the parameter
value. Once the value has been set, click the encoder again.
Knob and encoder editing can be combined. Use a knob to rapidly adjust the value of a parameter,
and then, while the parameter name is still displayed on the screen, use the encoder to fine-tune the
value.
Shortcut. Hold the S8 switch while turning the encoder to increment/decrement values by 8 instead
http://mutable-instruments.net/ambika/manual
saw
-12|tune 12
0|wave squ1
0|crsh 0
0|tune 0
-12|tune 12
