modif. 1|in1 lfo1|in2
The upper part of this page allows the routing of up to 14 modulation sources to synthesis
parameters. The first knob is used to select one of the 14 virtual "modulation patchcords", while the
other knobs on the first row are respectively used to edit its source (*srce*), destination (*dest*), and
the attenuation amount (*amnt*).
For example, this line:
Modul. 4|srce env3|dest
Indicates that the third envelope is routed to the VCA gain.
The modulation sources are the following:
1. env1, env2, env3: ADSR envelopes.
2. lfo1, lfo2, lfo3: Part LFOs (bipolar).
3. lfo4: Voice LFO.
4. mod1, mod2, mod3, mod4: Modifiers (see next section).
5. seq1, seq2: Step sequences 1 & 2.
6. arp: Arpeggiator gate pattern.
7. velo: Note velocity.
8. aftr: Note aftertouch.
9. bend: Pitch-pend wheel (bipolar).
10. mwhl: Modulation wheel.
11. whl2: Modulation wheel 2, Joystick negative Y axis or Breath controller.
12. pdal: Expression pedal.
13. note: MIDI note number (bipolar).
14. gate: Keyboard gate (null when the key is released).
15. nois: White noise sampled at 1kHz.
16. random: Random value, updated every time a note is retriggered.
17. 256 to 4: Boring constant values.
http://mutable-instruments.net/ambika/manual
lfo2|oper off
vca|amnt 63
