Mutable Instruments ambika User Manual page 20

Ambika – User manual | Mutable Instruments
20 of 44
off Mixing: Oscillators 1 and 2 are mixed together
sync Mixing and sync: Oscillators 1 and 2 are mixed
together, with oscillator 2's waveform phase-synced
to oscillator 1's
ring Ring modulation: Oscillators 1 and 2 are mixed
together, and simultaneously sent to a ring-modulator
xor Xor modulation: Oscillators 1 and 2 are mixed
together, and simultaneously sent to a digital XOR
cross-modulator
fold Foldback distortion: Oscillators 1 and 2 are mixed
together, and sent to a foldback distortion
bits Bit reduction: Oscillators 1 and 2 are mixed together,
and sent to a bit depth reducer
Filter (S2)
Freq 96|reso 0
env2 24|lfo2 0
freq (frequency): Filter cutoff frequency.
reso (resonance): Filter resonance.
mode (mode): Filter mode (low-pass / band-pass / high-pass). Note that this setting takes effect only
if the SVF filter board is installed. With the standard SMR-4 filter board, the filter is always a low-pass
no matter the position of this setting!
env2 (env2->vcf): Modulation amount from envelope 2 to VCF. If you want to set a negative
modulation amount, you can patch env2 to the VCF in the modulations section and ignore this
parameter.
lfo2 (lfo2->vcf): Modulation amount from LFO 2 to VCF. Again, if you want to set a negative
modulation amount, you can patch the LFO 2 to the VCF in the modulations section and ignore this
parameter.
Envelopes and LFOs (S3)
Ambika has three ADSR envelopes, three part LFOs and one voice LFO.
A part LFO is shared among all voices assigned to a part and is used for creating global sweeps,
http://mutable-instruments.net/ambika/manual
nothing
nothing
balance between the original mixed
signal and the ring-modulated signal
balance between the original mixed
signal and the XOR signal
Amount of foldback distortion
Amount of quantization noise
mode lp
