11.2.1 Add/Edit Port Forwarding

Click Add New Rule in the Port Forwarding screen or click the Edit icon next to an existing rule to open
the following screen.
Figure 78 Port Forwarding: Add/Edit
The following table describes the labels in this screen.
Table 56 Port Forwarding: Add/Edit
LABEL
Active
Service Name
WAN Interface
Start Port
Chapter 11 Network Address Translation (NAT)
DESCRIPTION
Select to enable or disable the rule.
Enter a name to identify this rule using keyboard characters (A-Z, a-z, 1-2 and so on).
Select the WAN interface through which the service is forwarded.
You must have already configured a WAN connection with NAT enabled.
Enter the original destination port for the packets.
To forward only one port, enter the port number again in the End Port field.
To forward a series of ports, enter the start port number here and the end port number in the End
Port field.
