ZyXEL Communications Prestige 660H Series Manual

ZyXEL Communications Prestige 660H Series Manual

Adsl 2/2+ gateway
Hide thumbs Also See for Prestige 660H Series:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
Prestige 660H Series
ADSL 2/2+ Gateway
Compact Guide
Version 3.40 (QT)
April 2004

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Prestige 660H Series and is the answer not in the manual?

Questions and answers

Related Manuals for ZyXEL Communications Prestige 660H Series

Summary of Contents for ZyXEL Communications Prestige 660H Series

  • Page 1 Prestige 660H Series ADSL 2/2+ Gateway Compact Guide Version 3.40 (QT) April 2004...

  • Page 2: Table Of Contents

    Prestige 660H Series Compact Guide 1 Introducing the Prestige...3 2 Hardware ...4 2.1 Rear Panel Connections...4 2.2 The Front Panel LEDs ...5 3 Setting Up Your Computer’s IP Address ...6 3.1 Windows 95/98/Me...6 3.2 Windows 2000/NT/XP ...9 3.3 Checking/Updating Your Computer’s IP Address...10 3.4 Testing the Connection to the Prestige...10...

  • Page 3: Introducing The Prestige

    Prestige 660H Series Compact Guide 1 Introducing the Prestige The Prestige 660H ADSL 2/2+ Gateway is the ideal all-in-one device for small networks connecting to the Internet via ADSL. Key features of the Prestige include NAT, content filter and firewall. See your User’s Guide for more details on all Prestige features.

  • Page 4: Hardware

    Prestige 660H Series Compact Guide 2 Hardware 2.1 Rear Panel Connections Figure 1 Prestige Rear Panel Connections Table 1 Prestige Rear Panel Description LABEL Connect to a telephone jack using the included phone wire. Connect to a computer/external hub using an Ethernet cable.

  • Page 5: The Front Panel Leds

    Prestige 660H Series Compact Guide Table 1 Prestige Rear Panel Description LABEL RESET You only need to use this button if you’ve forgotten the Prestige’s password. It returns the Prestige to the factory defaults (password is 1234, LAN IP address 192.168.1.1 etc.; see your User’s Guide for details).

  • Page 6: Setting Up Your Computer's Ip Address

    Prestige 660H Series Compact Guide Table 2 Front Panel LED Description COLOR DSL/ACT Green Amber 3 Setting Up Your Computer’s IP Address Skip this section if your computer is already set up to accept a dynamic IP address. This is the default for most new computers.
  • Page 7 Prestige 660H Series Compact Guide The Network window Configuration tab displays a list of installed components. You need a network adapter, the TCP/IP protocol and Client for Microsoft Networks. In the Network window Configuration tab, select your network adapter's TCP/IP entry and click Properties.

  • Page 8: Verifying Your Computer's Ip Address

    Prestige 660H Series Compact Guide Click the DNS Configuration tab. -If you do not know your DNS information, select Disable DNS. -If you know your DNS information, select Enable DNS and type the information in the fields below (you may not need to fill them all in).

  • Page 9: Windows 2000/Nt/Xp

    Prestige 660H Series Compact Guide In the Run window, type "winipcfg" and then click OK to open the IP Configuration window. Select your network adapter. You should see your computer's IP address, subnet mask and default gateway. 3.2 Windows 2000/NT/XP In Windows XP, click start, Control Panel.

  • Page 10: Checking/Updating Your Computer's Ip Address

    Prestige 660H Series Compact Guide Click Advanced. Remove any previously installed gateways in the IP Settings tab and click OK to go back to the Internet Protocol TCP/IP Properties screen. Click OK to close the Internet Protocol (TCP/IP) Properties window.

  • Page 11: Configuring Your Prestige

    Prestige 660H Series Compact Guide C:\>ping 192.168.1.1 Pinging 192.168.1.1 with 32 bytes of data: Reply from 192.168.1.1: bytes=32 time=10ms TTL=254 Reply from 192.168.1.1: bytes=32 time<10ms TTL=254 Reply from 192.168.1.1: bytes=32 time<10ms TTL=254 Reply from 192.168.1.1: bytes=32 time<10ms TTL=254 Ping statistics for 192.168.1.1:...
  • Page 12 Prestige 660H Series Compact Guide Default user name. Figure 4 Web Configurator: Password Screen Step 3. You should now see the web configurator Site Map screen. Click Wizard Setup to begin a series of screens to configure your Prestige for the first time.

  • Page 13: Common Screen Command Buttons

    Prestige 660H Series Compact Guide Navigation panel LOGOUT Figure 5 Web Configurator: Site Map Screen The Prestige automatically times out after five minutes of inactivity. Simply log back into the Prestige if this happens to 4.2 Common Screen Command Buttons The following table shows common command buttons found on many web configurator screens.
  • Page 14 Prestige 660H Series Compact Guide Figure 6 Wizard Screen 1 Step 2. The second wizard screen varies depending on what mode and encapsulation type you use. All screens shown are with routing mode. Configure the fields and click Next to continue.
  • Page 15 Prestige 660H Series Compact Guide Figure 7 Internet Connection with PPPoE Select Nailed-Up Connection when you want your connection up all the time. The Prestige will try to bring up the connection automatically if it is disconnected From the Network Address Translation drop-down list box, select SUA Only, Full Feature or None.
  • Page 16 Prestige 660H Series Compact Guide Figure 9 Internet Connection with ENET ENCAP Figure 10 Internet Connection with PPPoA In the ENET ENCAP Gateway field, enter the gateway IP address given by your ISP. Refer to Figure 7 for other field...
  • Page 17 Prestige 660H Series Compact Guide Step 3. Verify the settings in the screen shown next. To change the LAN information on the Prestige, click Change LAN Configurations. Otherwise click Save Settings to save the configuration and skip to step 5.
  • Page 18 Prestige 660H Series Compact Guide Figure 12 Wizard: LAN Configuration From the DHCP Server drop-down list box, select ON to allow your Prestige to assign IP addresses, an IP default gateway and DNS servers to computer systems that support the DHCP client.

  • Page 19: Test Your Internet Connection

    Prestige 660H Series Compact Guide Figure 13 Wizard Screen 4 4.4 Test Your Internet Connection Launch your web browser and navigate to www.zyxel.com. Internet access is just the beginning. Refer to the User’s Guide for more detailed information on the complete range of Prestige features.

  • Page 20: Configuring Sua Server

    Prestige 660H Series Compact Guide One-to-One: One-to-one mode maps one local IP address to one global IP address. Note that port numbers do not change for One-to-one NAT mapping type. Many-to-One: Many-to-One mode maps multiple local IP addresses to one global IP address.
  • Page 21 Prestige 660H Series Compact Guide The following table describes the labels in this screen. LABEL Start Port Type a port number in this field. To forward only one port, type the port number again in the End Port field. To forward a series of ports, type the start port number here and the end port number in the End Port field.

  • Page 22: Firewall Overview

    Prestige 660H Series Compact Guide 5.3 Firewall Overview The Prestige firewall is a stateful inspection firewall and is designed to protect against Denial of Service attacks when activated. The Prestige’s purpose is to allow a private Local Area Network (LAN) to be securely connected to the Internet. The Prestige can be used to prevent theft, destruction and modification of data, as well as log events, which may be important to the security of your network.

  • Page 23: Enabling The Firewall

    Prestige 660H Series Compact Guide 5.4 Enabling the Firewall From the main screen, click Advanced Setup, Firewall and then Config to open the screen as shown. Enable (or activate) the firewall by selecting the Enable Firewall check box as seen in the following screen.
  • Page 24 Prestige 660H Series Compact Guide The following table describes the labels in this screen. LABEL The default Should packets that do not match the following rules be blocked or action for forwarded? Make your choice from the drop down list box. Note that packets not “block”...
  • Page 25 Prestige 660H Series Compact Guide LABEL The following read-only fields summarize the rules you have created that apply to traffic traveling in the selected packet direction. The firewall rules that you configure (summarized below) take priority over the general firewall action settings above.
  • Page 26 Prestige 660H Series Compact Guide Available Service buttons. For a comprehensive list of port numbers and services, visit the IANA (Internet Assigned Number Authority) web site. Step 3. Configure the Source Address and Destination Address for the rule. Figure 19 Creating/Editing A Firewall Rule...

  • Page 27: Configuring Source And Destination Addresses

    Prestige 660H Series Compact Guide Table 5 Creating/Editing A Firewall Rule LABEL Source Address Click SrcAdd to add a new address, SrcEdit to edit an existing one or SrcDelete to delete one. Please see the next section for more information on adding and editing source addresses.
  • Page 28 Prestige 660H Series Compact Guide Figure 20 Adding/Editing Source and Destination Addresses The following table describes the labels in this screen. Table 6 Adding/Editing Source and Destination Addresses LABEL Address Type Do you want your rule to apply to packets with a particular (single) IP address, a range of IP addresses (e.g., 192.168.1.10 to...

  • Page 29: Troubleshooting

    Prestige 660H Series Compact Guide 6 Troubleshooting PROBLEM None of the Make sure that you have the correct power adaptor connected to LEDs turn on the Prestige and plugged in to an appropriate power source. Check when you turn all cable connections.
