TM-600 Mobile Radio Revision History Version Date Contents Revised 8130M60000000 January, 2007 Initial Release 8130M60000010 March, 2008 The following information is updated/added: 1. New frequency ranges (470-520MHz 350-400MHz 440-470MHz) are added. 2. Tuning Description, Parts List 1, Schematic Diagram and PCB View are updated.
Transmit only when people inside and outside the vehicle are at least the minimum distance away from a properly installed, externally mounted antenna. Mobile antenna substitution: Don’t substitute HYT supplied or approved antenna, or excessive radio frequency radiation will result. Please contact your dealer or the manufacturer for further instructions.
TM-600 Mobile Radio ▇ Operation Guidelines For vehicles equipped with electronic anti-skid braking systems, electronic ignition systems or electronic fuel injection systems, interferences may occur during radio transmission. If the foregoing electronic equipments are installed on your vehicle, please contact your dealer for further assistance to make sure that radio transmission will not interfere with these equipments.
TM-600 Mobile Radio Radio Overview Front Panel View 1) [Volume] Knob Rotate the knob clockwise to increase the volume, and rotate it counter-clockwise to decrease the volume. 2) Low Power Indicator This indicator glows when the radio is at low power.
Page 7
Note: Please refer to “Test Cable for Speaker Output” in “Tuning Description” for details. 3) Power Inlet Used to connect the HYT-authorized DC power cable for input of 13.6V DC power. 4) Antenna Connector Used to connect the external connector.
TM-600 Mobile Radio Software Specification Frame of Radio Modes Conventional Mode User Mode Tuning Mode Model Set Mode Wired Clone Mode Clone Mode Wireless Clone Mode PC Mode Keypad Entry for Mode Startup Mode Display Operation Remarks Channel No. The radio enters User Mode upon i.e.
Page 9
TM-600 Mobile Radio Key Assignment Your dealer may assign a function to the programmable key ([P1]/[P2], [▲]/[▼]). See the table below for more details. Note: "CH Number” in the table below indicates any value within 1~8. Key Assignment Function Setting...
Page 10
TM-600 Mobile Radio CH Up CH Number Channel up CH Down CH Number Channel down MONI A: Monitor MONI A CH Number Unmute-Momentary MONI B CH Number MONI B: Monitor Unmute-Toggle MONI C: Carrier MONI C CH Number Squelch-Momentary MONI D...
Page 11
TM-600 Mobile Radio Scan ● Scan Temporarily add/delete a nuisance ● Add/Delete channel. Reverse CH Number Reverse frequency Talk Around CH Number Talk around SEL SQL SQL Number (0.-9.) Select squelch level. Home Channel HomeCH Number (1-8) Home channel [▲]...
Page 12
TM-600 Mobile Radio HDC Encode Call List Number HDC call Lone Worker L. or L Lone worker [▼] Whisper R. or R Whisper AUX A None AUX A AUX B None AUX B Transparent Enable/disable Transparent Transmission Mode CH Number Transmission Mode.
Page 13
TM-600 Mobile Radio Clone Mode Data can be transferred from one radio to another through Wired Clone Mode or Wireless Clone Mode. Wired Clone Mode 1) Power on the source radio while holding down [P1]+[P2]. Then “C” is displayed on the 8-segment numeric LED.
TM-600 Mobile Radio Tuning Mode 1. For Tuning Mode, operate as follows: 1) Power on the radio while holding down [P1]. The LED flashes red twice, and then the radio enters Tuning Mode. 2) Use [▲]/[▼] to select a tuning item among 0-9, A-F, with “0.-9.”, “A.-F.” displayed respectively.
Page 15
TM-600 Mobile Radio Center 3. CTCSS: 67.0Hz Center 4. CTCSS: 67.0Hz Center 0. CTCSS: 151.4Hz 1. CTCSS: 151.4Hz High 2. CTCSS: 151.4Hz Center 3. CTCSS: 151.4Hz Center 4. CTCSS: 151.4Hz Center 0. CTCSS: 254.1Hz 1. CTCSS: 254.1Hz 2. High CTCSS: 254.1Hz Center 3....
Page 16
TM-600 Mobile Radio Center 4. No signal SQL 9 5. No signal High 6. No signal Center 0. No signal SQL 9 1. No signal High 2. No signal SQL 9 Center 3. No signal Center 4. No signal SQL 9 5....
Page 17
TM-600 Mobile Radio Note: L: lowest frequency; H: highest frequency; C: center frequency Frequency RX/TX 1 ( C ) 2 ( L ) 3 ( H ) range RX(MHz) 155.15 136.15 173.85 145.55 164.55 155.00 155.20 155.40 0(V) TX(MHz) 155.00 136.00...
TM-600 Mobile Radio Circuit Description Frequency Configuration The receiver utilizes double conversion superheterodyne. The first IF is 49.95MHz and the second IF is 450KHz. The first local oscillator signal is supplied by the PLL circuit, while the second local oscillator signal (50.4MHz) is generated from the frequency tripling of TCXO (16.8MHz).
TM-600 Mobile Radio 3. IF Amplifier The first IF signal is amplified by Q113 and then enters IC102 (TA31136FN), where the signal is mixed with the second local oscillator signal (50.4MHz) to generate the second IF signal (450KHz). The second IF signal then feeds through a ceramic filter (N: CF202;...
TM-600 Mobile Radio 2. RF Driver and Final-stage Power Amplifier Circuit The TX-RF signal from Q703 in the VCO circuit is amplified by Q101, Q110 and Q109, and goes to the final-stage amplifier (IC101) for further amplification. Then the amplified signal enters LPF and is transmitted from the antenna.
Page 21
TM-600 Mobile Radio Control Circuit The control circuit is composed of CPU, reset IC and power supply control circuit. 1. CPU IC502 (CPU) operates at 9.8304MHz. CPU controls data transmission between E2PROM (IC501), RX circuit, TX circuit, control circuit, display circuit and peripheral circuit.
TM-600 Mobile Radio Vout provides power supply for IC601, IC602 and IC803, which produces 8V, 5V, 3.3V voltage to the circuit. 3. Reset Circuit The reset circuit (also called “Watchdog”) includes a reset IC (CN813LESA) and a peripheral circuit. When a breakdown occurs due to change in external voltage, the CPU would reboot your radio through reset IC automatically.
TM-600 Mobile Radio Semiconductor Data Positive voltage regulator: TA7805F (Power Unit IC602), TA7808S (Power Unit IC601) EEPROM: CAT24C256WI 256K CATALYST (CPU Unit IC501) Pin Function Pin No. Name Function 1~3 A0~A2 Address input Ground Serial data input/output Serial clock input...
Page 24
TM-600 Mobile Radio Audio Power Amplifier: TDA7297D(AFPwr Unit IC511) Pin Function Pin No. Name Function PW GND Power ground 1 OUT1+ Output 1+ OUT1- Output 1- Supply voltage Input 1 Operating Switch STAND-BY Operating Switch PW GND Power ground 2...
Page 25
TM-600 Mobile Radio RESET RESET Reset XOUT XOUT Clock output Ground Clock input P85/NMI P84/INT2 AFRDF MSK RX detect for baseband chip P83/INT1 DTMFSTD Not used P82/INT0 AUX1 AUX 1 P81/TA4in [Power] switch control H: Off L: On P80/TA4out CTC_OUT...
Page 26
H: mute /IGN Ignition sensor input H: Off L: On [Power] switch input L: On TYPE TM-600/TM-610 selection input H: TM-600 L: TM-610 Not used Not used [P1] input L: On (external resistor pulled up) [P2] input L: On (external resistor pulled up) [▼] input...
Page 27
TM-600 Mobile Radio AVCC AVCC P97/Sin4 AUX3 AUX 3 P96/Sout4 AUX6 AUX 6 P95/Clk4 APCO Audio PA control...
TM-600 Mobile Radio Component Description TX-RX Unit Ref. No. Part Name Type Description IC101 Power module Power module IC501 AT2408N12.5S EROM IC401 AK2346 Audio processor IC404 TA75W558FU Dual operational amplifier IC403 TC75W51FU Dual operational amplifier IC803 XC62FP3302P Positive voltage regulator...
Page 58
TM-600 Mobile Radio Material No. Description Qty.Ref. No.Print No Remarks 395 3101051030020 C163 Chip capacitor GRM155R71E103KA01D 0.01UF K 25V 396 3101051030020 C239 Chip capacitor GRM155R71E103KA01D 0.01UF K 25V 397 3101051030020 C240 Chip capacitor GRM155R71E103KA01D 0.01UF K 25V 398 3101051030020 C243 Chip capacitor GRM155R71E103KA01D 0.01UF K 25V...
Page 59
TM-600 Mobile Radio Material No. Description Qty.Ref. No.Print No. Remarks 439 3101051040010 Chip capacitor GRM36Y5V104Z25PT 0.1UF Z 25V C911 440 3101051050000 C438 Chip capacitor GRM155R60J105K6.3PT 1UF K 6.3V 441 3101051050000 C444 Chip capacitor GRM155R60J105K6.3PT 1UF K 6.3V 442 3101051050000 Chip capacitor GRM155R60J105K6.3PT 1UF K 6.3V...
Page 60
TM-600 Mobile Radio Material No. Description Qty.Ref. No. P rint No Remarks 483 3101054710010 C211 Chip capacitor GRM155R71H471KA01D 470PF K 50V 484 3101054710010 C214 Chip capacitor GRM155R71H471KA01D 470PF K 50V 485 3101054710010 C248 Chip capacitor GRM155R71H471KA01D 470PF K 50V 486 3101054710010...
Page 61
TM-600 Mobile Radio Material No. Description Qty.Ref. No.Print No. Remarks C119 U4:350-400MHz 528 3101060300010 Chip capacitor GRM1885C1H3R0BZ01D 3PF B 50V C813 529 3101060390000 C109 Chip capacitor GRM1885C1HR30BZ01D 0.3PF B 50V 530 3101060390000 Chip capacitor GRM1885C1HR30BZ01D 0.3PF B 50V C110 531 3101060400010 Chip capacitor GRM1885C1H4R0BZ01D 4PF B 50V...
Page 62
TM-600 Mobile Radio Material No. Description Qty.Ref. No. P rint No. Remarks 571 3101061040010 Chip capacitor 0603 0.1UF K 16V C135 572 3101061040010 Chip capacitor 0603 0.1UF K 16V C145 573 3101061040010 Chip capacitor 0603 0.1UF K 16V C222 574 3101061040010 Chip capacitor 0603 0.1UF K 16V C235 575 3101061040010 Chip capacitor 0603 0.1UF K 16V...
Page 63
TM-600 Mobile Radio Material No. Description Qty. Ref. No.Print No. Remarks 615 3101064710000 C144 Chip capacitor GRM188R71H471KA01D 470PF K 50V 616 3101064710000 C147 Chip capacitor GRM188R71H471KA01D 470PF K 50V 617 3101064710000 C192 Chip capacitor GRM188R71H471KA01D 470PF K 50V 618 3101064710000...
Page 64
TM-600 Mobile Radio Material No. Description Qty. Ref. No. Print No. Remarks 659 3104074750070 C904 U4:350-400MHz Tantalum capacitor TEESVP1A475M8R 4.7UF M 10V 660 3104081040020 C221 Tantalum capacitor TEESVA1V104M8R 0.1UF M 35V 661 3104081040020 C816 Tantalum capacitor TEESVA1V104M8R 0.1UF M 35V...
TM-600 Mobile Radio Tuning Description Key Functions 1. Front Panel [Volume] Knob ① Low Power Indicator ② Scan Indicator ③ ④ 8-segment Numeric LED [▲] Key ⑤ [▼] Key ⑥ TX/RX Indicator ⑦ [Power] Switch ⑧ ⑨ [P2] Key [P1] Key ⑩...
Page 94
TM-600 Mobile Radio Panel Tuning Mode Function Increase the tuning value. [▲] Decrease the tuning value. [▼] Exit from the sub-item. [P1] If a tuning item is displayed, the radio will enter its sub-item; if a [P2] sub-item is displayed, the radio will save the value and enter another sub-item.
Page 96
TM-600 Mobile Radio [P2] Rx Sensitivity(Low) Sensitivity [P2] Rx Sensitivity(CL) [P2] Rx Sensitivity(Center) [P2] Rx Sensitivity(HC) [P2] Rx Sensitivity(High) [P2] [▲] / [▼] KEY [P2] Squelch On (Center) Squelch On (9/3) [P2] Squelch On (Low) [P2] Squelch On (High) [P2]...
Page 97
TM-600 Mobile Radio Required Test Equipment Test Equipment Method Specifications Standard Signal Frequency Range VHF: 136-174MHz;UHF: 400-470MHz 450-500MHz Generator (SSG) 470-520MHz 350-400MHz 440-470MHz Modulation Frequency modulation and external modulation Output Power 0.1uV~1mV Power Meter Input Impedance 50Ω Frequency Range VHF: 136-174MHz;UHF: 400-470MHz 450-500MHz...
Page 98
TM-600 Mobile Radio Test Cable for Speaker Output DUMMY To Audio VIVM Distortion Meter Test Cable for Microphone Input The following test cable is recommended. HOOK Audio MICG VTVM 8 PIN 1:CM 5:PTT/TXD 2:HOOK/RXD 6:GND 3.MIC 7:PSB 4:ME 8:MBL Cautions When Removing or Attaching the Shield Cover 1.
Page 99
TM-600 Mobile Radio Tuning Description and Specification This mobile radio can be tuned manually or via the programming software only. Manual tuning is described below. (Refer to “Tuning Mode” in “Software Specification”.) Instrument: Radio Communication Test Set 1 set Spectrum Analyzer...
Page 100
TM-600 Mobile Radio TM-600 VHF: 136-174MHz; TM-600 U1: 400-470MHz; TM-600 U2: 450-500MHz; TM-600 U3: 470-520MHz; TM-600 U4: 350-400MHz; TM-600 U5: 440-470MHz; Measurement Tuning Item Condition Specification/Remarks Test Instrument Terminal Part Method 1. Power 13.6V DC Supply Note: 1. This radio may be installed in negative ground electrical system only. Reverse polarity will cause the cable fuse to blow.
Page 101
TM-600 Mobile Radio Transmitter Measurement Tuning Specification Item Condition /Remarks Test Instrument Terminal Part Method Switch to CH4 Radio 4. TX Error<50Hz (Do not enter any Communication Adjust VR801. Adjust channel frequency. Frequency tuning item). Test Set High power: PO=23~25WW I≤8.0A...
Page 102
TM-600 Mobile Radio Each channel corresponds to a Radio specific TX Adjust deviation to: Communication [▲]/[▼] 10. CTCSS 0.75KHz±0.15KHz(W) frequency; enter Test Set to set Deviation 0.60KHz±0.15KHz(M) items “4”, “5” and CTCSS. Filter: 0.37KHz±0.15KHz(N “6” to adjust LPF: 300Hz 67Hz/151.4Hz/254.1...
Page 103
TM-600 Mobile Radio Receiver Measurement Tuning Specification/ Item Condition Test Remarks Terminal Part Method Instrument UHF: Use [▲]/[▼] key Adjust the gain to adjust to the maximum software setting; value; the center Each channel then press [P2] frequency 15. RF corresponds to a ANT .
Page 104
TM-600 Mobile Radio CH: RX HI, ±1.5KHz(N) manually switch Filter: to CH3 (H). 0.3-3.0KHz Radio Press [P2] key Communicat twice for CPU need ion Test Set to read and Enter items “C” adjust software SSG Output: write SQL level. and “D”; switch...
Serial data input TXD2 Serial data output Audio output after tuned by K301 TYPE Model select (H:TM-600; L: TM-610) SW position signal output 4 SW position signal output 3 SW position signal output 2 SW position signal output 1 SLED...
Page 106
Serial data input TXD2 Serial data output Audio input after tuned by K301 TYPE Model select (H:TM-600; L: TM-610) SW position signal output 4 SW position signal output 3 SW position signal output 2 SW position signal output 1 SLED...
Page 107
TM-600 Mobile Radio AF-OUT Filtered audio output Filtered CTCSS/CDCSS output MIC signal output MIC signal output Ground Ignition sense input Power input from [Power] switch (13.6V+15%) AUX1 Programmable auxiliary port AUX2 Programmable auxiliary port AUX4 Programmable auxiliary port AUX5 Programmable auxiliary port...
Page 109
TM-600 Mobile Radio Check Normal Power-on Check the RF circuit can’t alert tone? control circuit be driven Speaker works Replace the well? speaker Read available Check read 9.8304MHz works or not? circuit normally? Reset Replace Q117 works Q117 normally? Pin10 is of...
Page 111
TM-600 Mobile Radio Transmitter No output Power supply Check power works normally? supply circuit Current is Check Q603 & Control voltage is normal? Q604 normal? High Check transistor Bias voltage and low pass network Check driver stage. Repair Driver stage is...
TM-600 Mobile Radio Disassembly and Reassembly for Repair Disassembly 1. Power off the radio; then remove the power cable and screw out the antenna connector. 2. Remove the upper cover. 3. Loosen the eight locking screws; then remove the shield cover, and disconnect FFC and speaker connection cable which bind the control board PCB and the main board PCB.
Page 113
TM-600 Mobile Radio 5. Pull out the [Volume] Knob, and screw out the copper nut from the potentiometer. Then loosen the four screws locking the front case, and take out the control board PCB. Use an electric iron and a screwdriver to disassemble the antenna connector, power cable, external board and water-proof ring on this board.
Page 114
TM-600 Mobile Radio Reassembly For the reassembly of the transceiver, please refer to “Disassembly”. Other procedures are as follows: 1. Fix the bracket (for main unit) by using four self-tapping screws. 2. Screw on four adjustment screws (each with a shrapnel and a shim).
TM-600 Mobile Radio TM-600 Parts List 2 Material No. Material Name Qty. 3608002002090 Power management IC 6201190000010 Shield cover of PA module RF PA module 7600028000000 Conductive fabric for shield cover of PA module 5205000000280 Speaker jack 6100144000000 Waterproof ring for external board...
TM-600 Mobile Radio Specifications General VHF: 136-174MHz UHF: 400-470MHz 450-500MHz 470-520MHz Frequency Range 350-400MHz 440-470MHz Channel Capacity Channel Spacing 25KHz/20KHz/12.5KHz Operating Voltage 13.6V±15% Standby ≤0.5A Current Receive ≤2A Drain Transmit ≤8A(25W) ≤5A(5W) Operating Temperature -30 ~+60 ℃ ℃ Dimensions (L×W×D) 125×152×43mm...
Page 143
TM-600 Mobile Radio HYT endeavors to achieve the accuracy and completeness of this manual, but no warranty of accuracy or reliability is given. All the specifications and designs are subject to change without notice due to continuous technology development. Changes which may occur after publication are highlighted by Revision History contained in Service Manual.
