Introduction

DB3 is an all-in-one door lock and override module. This guide supports the installation of a DB3 in Remote
Start Ready (RSR) mode. This solution offers three (3) configuration options to control your system: 3x OEM Lock
Remote Start Activation, RF System or SmartStart (all sold separately).
Warning!
This module can only be flashed and configured using DirectLink at www.directechs.com or using the Directechs
Mobile application for smartphones. Refer to "Connecting the module" for more information.
This solution is compatible with the 2016 Volkswagen Golf (Smart Key) and offers the following features:
• AV-Parking Lights Control
• DL-Arm Factory Security
• DL-Disarm Factory Security
• DL-Door Lock Control
• DL-Door Unlock
• DL-Driver Priority Unlock
• DL-Trunk / Hatch Release
• FOB-Control of aftermarket alarm with OEM remote
• PK-Universal RF Bypass- Key Req'd
• RS-3x LOCK START (Start control using OEM Remote)
• RS-3x LOCK STOP (Stop control using OEM Remote)
• RS-RAP Shut Down (Retained ACC Power)
• RS-Remote Start Ready
• RS-SmartStart
• RS-Tach / RPM Output
• SS-Entry Monitoring ALL Door Pins
• SS-Entry Monitoring Hood Pin
• SS-Entry Monitoring Trunk/Hatch Pin
• SS-Factory Alarm Trigger Monitoring
• ST-Brake Status (foot brake)
• ST-Door Locks Status
• ST-E-Brake Status
• ST-Ignition Status
4
403.VW06 1.27 2016 Volkswagen Golf (Smart Key)
© 2017-02-08 Directed. All rights reserved.
