Icom IC-F14 Service Manual Addendum page 51

SECTION 11. BC-160 (Optional)
[CHASSIS PARTS]
REF. ORDER
DESCRIPTION
NO. NO.
MP1 8010019750 2830 case
MP2 8110008220 2830 cover
MP3 8930039620 Leg cushion (A)
Screw PH BT M3 × 6 NI-ZU
MP4 8810008630
[MAIN UNIT]
REF. ORDER
DESCRIPTION
NO. NO.
J1 6510023070 Connector HEC2305-01-250
DS1 5040002740 LED RT3-03HRYG
MP1 8930064410 2830 TERMINAL
[ACCESSORIES]
REF ORDER
DESCRIPTION
NO. NO.
EP1 Charger BC-145E [EUR]
Optional product
Charger BC-145UK [UK]
Optional product
QTY.
1
1
2
1
QTY.
1
1
MP1 (M)
J1 (M)
3
QTY.
MAIN UNIT
1
1
MP4 (C)
11 - 1
DC
IN
J1
R39
MCR10-JPW
MP1 (C)
R40
MCR10-JPW
R6
Q3
22k
2SC4081
R43
DS1 (M) MCR10-JPW
R8
4.7k
MP2 (C)
MP3 (C)
L2
R51
CP6
0.47μ
MCR10-JPW
GND
RXD
TXD
RESET
VDD
VPP
CP7
Measurement condition
input DC.16V
rapid charging to BP-230
CP2 CP1
D2
1SS355
Q6
2SC4081
R2
5.00V
4.7k
10.05V
IC1
R60 NJM2801U1-0543-TE1
MCR10-JPW
1 5
VO VIN
2
GND
3 4
CD VOR
R13 C17 C18 R15
22k 0.1 0.01 56k
R14 R16
560k 560k
R11
IC2
22k
μPC494GS-A
1 16
R46 NO-INVIN NO-INVIN
2 15
MCR10-JPW
INVIN INVIN
3 14
FB REFOUT
Q4 4 13
DTC OC
2SC4081 5 12
CT VCC
6 11
RT C2
R52
7 10
MCR10-JPW GND E2
8 9
C1 E1
R44
MCR10-JPW
3.54V
R66
10k
IC3
μPD789112AMC-534-5A4-A
1 30
P23 RXD
2 29
P24 TXD
3 28
P25 P20
4 27
AVDD P11
5 26
ANI0 P10
6 25
ANI1 VDD
7 24
ANI2 VSS
8 23
ANI3 X1
R24
9 22
100 AVSS X2
10 21
IC0 IC0
11 20
P50 IC0
12 19
P51 RESET
13 18
R25
P52 P03
14 17
100
P53 P02
15 16
P00 P01
G
R
DS1
RT3-03HRYG
X1
CSTCR4M91G
4Vp-p
4.945MHz
Q2
RSQ035P03TR
L1
100μ
4 3
CHARGE
5 2
6 1
Q1
2SC4081
R4
10
VSENS to
battery
R58
9.6uS
MCR10-JPW
16.0V
D3
8.4V
SM240A-T
R5
0.12
GND
R20
33k
Q5
DTC144EU
R21
1k
CP8
R31
10k
CP3
R28
30k
CP4
8 7 6 5
IC4
NJM2904M
CP5
R27
2k
1 2 3 4
R47
R26
MCR10-JPW
10k
R32
R30
3.3k
100k
R67
R42 R48 R53 R61 R65
4.7
ERJ12-JPW ERJ12-JPW ERJ12-JPW MCR10-JPW MCR10-JPW
