Icom IC-F14 Service Manual Addendum page 2

Apr. 2012 Apr. 2012
5-2 RECEIVE ADJUSTMENT
1) Select an adjustment item using cursor or [↑] / [↓] keys of the PC's keyboard.
2) Set or modify the adjustment value as specifi ed using [←] / [→] keys of the PC's keyboard, then push the [ENTER] key.
ADJUSTMENT ADJUSTMENT CONDITION
RECEIVE 1 <For IC-F14S/F15S/F16S only>
SENSITIVITY
Clone the "ADJ CH RX.icf" into the transceiver.
-Preparation-
• C o n n e c t a n S S G t o t h e
antenna connector.
-Adjustment- 2 • CH. (16CH/2CH) : CH.11/CH.1
• Receiving
CONVINIENT: [BPF (T1)] and [BPF (T2)] can be adjusted at same time as below.
2 • CH. (16CH/2CH) : CH.11/CH.1
• Receiving
SQUELCH 1 <For IC-F14S/F15S/F16S only>
-Preparation-
Clone the "ADJ CH RX.icf" into the transceiver.
• C o n n e c t a n S S G t o t h e
antenna connector.
-Adjustment- 2 • CH. (16CH/2CH) : CH.12/CH.2
• Receiving
(Replacement page)
OPERATION
• Set the SSG as;
Frequency : 136.0000 MHz
Level : +20 dBμ
Modulation : 1 kHz
Deviation : 3.5 kHz
1) Select the item [BPF (T1)], then
push the [ENTER] key.
2) Select the item [BPF (T2)], then
push the [ENTER] key.
• Select the item [BPF ALL], then
push the [ENTER] key.
• Set the SSG as;
Frequency : 136.0000 MHz
Level : –14 dBμ
Modulation : 1 kHz
Deviation : 3.5 kHz
1) Decrease the adjustment value
[SQL] to close the squelch once,
then increase the value to open the
squelch.
2) Select the item [SQL], then push
the [ENTER] key to store the adjust
value.
5 - 7
ADJUSTMENT
VALUE
ITEM
– –
[BPF (T1)] (Automatic
[BPF (T2)] adjustment)
(Automatic
[BPF ALL]
adjustment)
– –
(Automatic
[SQL]
adjustment)
