Icom IC-F14 Service Manual Addendum page 17

Mar. 2009
[MAIN UNIT]
REF ORDER
NO. NO.
DS1 5040002670 S.LED CL-165HR/YG
MC1 7700002750 MIC EM9745P-38-G <HOR>
S1 2260001900 SWI SW-149 (SKHLLD)
S2 2260002800 S.SWI SW-167 (SKQTLAE010)
S3 2260002800 S.SWI SW-167 (SKQTLAE010)
S4 2250000490 ENC TP70TF5163-15.9F-2775
2250000490 ENC TP70TF5163-15.9F-2775
2250000490 ENC TP70TF5163-15.9F-2775
2250000490 ENC TP70TF5163-15.9F-2775
2250000490 ENC TP70TF5163-15.9F-2775
2250000490 ENC TP70TF5163-15.9F-2775
2250000490 ENC TP70TF5163-15.9F-2775
2250000490 ENC TP70TF5163-15.9F-2775
2250000490 ENC TP70TF5163-15.9F-2775
2250000490 ENC TP70TF5163-15.9F-2775
2250000490 ENC TP70TF5163-15.9F-2775
EP2 6910015600 S.BEA ACZ1005Y-241 (240)
EP3 6910015370 S.BEA ACZ1005Y-102-T
EP4 6910015370 S.BEA ACZ1005Y-102-T
EP6 6910015370 S.BEA ACZ1005Y-102-T
MP1 8410002531 S.HEA 2681 PA HEATSINK-1
MP3 8510016470 S.CAS 2775 VCO CASE
DESCRIPTION M.
LOCATION
T 102.8/12.4
B 99.4/44.2
B 60.9/44.2
[A]
[B]
[C]
[D]
[E]
[F]
[G]
[H]
[I]
[Q]
[R]
T 77.4/22.2
T
B 55.5/30.5
T 44.3/35.9
B
T 54.1/33.2
[CONNECT UNIT]
REF PARTS
H/V
NO. NO.
C501 4030017460 S.CER ECJ0EB1E102K
C502 4030016930 S.CER ECJ0EB1A104K
J501 6910016390 CON
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
34.7/32
79/28.2
5
DESCRIPTION M.
T
T
IMSA-9230B-1-02Z145-PT1
S.=Surface mount
H/V
LOCATION
8.3/5.3
9.3/5.3
