Introduction：
SW-3023 is a USB 3.0 to dual-SATA hard drive enclosure. It supports simultaneous access of two 2.5" or
3.5" SATA hard disk for both data read and data write. It is also backward compatible with USB 2.0 and USB
1.1. The maximum transfer speed of USB 3.0 can reach 5Gbps. The actual transfer speed of SW-3023 is
depends on HDD/SSD.
SW-3023 supports
Flash Copy, Offline Clone, Online Clone, Security
and system files from Source HDD to Target HDD
high storage capacity, high data transfer rate, and best data protection.
Function Chart：
8
1、Power indicator.
2、Bay '1' HDD read/write access indicator.
3、Bay '2' HDD read/write access indicator.
4、Clone processing 25%, 50%, 75%, 100% indicator.
5、Clone button.
6、Bay '1
7、Bay '2'
8、USB3.0 input
9、Power switch (ON/OFF)
10、DC input
Function：
• Complies with Gen2i/Gen2m of Serial ATA II Electrical Specification 2.6
• Supports SATA II Asynchronous Signal Recovery (Hot Plug) feature
• Complies with USB 3.0 Specification, USB Mass Storage Class, Bulk-Only Transport Specification
• Supports USB Super-Speed/High-Speed/Full-Speed Operation
• Supports USB2.0/USB3.0 power saving mode
• Support auto-spin down after idle for 5 mins
• Supports Dual LUN for USB2.0/USB3.0
• One Touch clone function.
SW-3023 Manual
10
9
Erase, which is able to copy data
twice faster than other similar
3
1
7
6
4
5
2
1
product. SW-3023 provides
Advertisement
Related Manuals for StarTech.com SW-3023
Summary of Contents for StarTech.com SW-3023
- Page 1 Introduction： SW-3023 is a USB 3.0 to dual-SATA hard drive enclosure. It supports simultaneous access of two 2.5” or 3.5” SATA hard disk for both data read and data write. It is also backward compatible with USB 2.0 and USB 1.1.
- Page 2 • Easy to Install and Set-up • Design for Win2000, WinXP, WinVista, Win7, Win8, MAC 9.2 or later version.
- Page 3 HDD to Bay ‘1’; target HDD to Bay ‘2’, and then turn on the power b、Once the Bays indicators are on, that means SW-3023 is ready for clone. c、 Press and hold the clone button for 3 seconds until the indicator light is blinking, press the button once more...
- Page 4 d、Clone progress indicator flashes and shows the progress (25%, 50%, 75%, 100%). e、Once clone is finished, all progress indicators will light up. f、Turn off power and take out the HDD carefully g、Please note that after the clone operation, if the target and the source HDD is connected to PC at the same time, only one HDD will be placed online.
- Page 5 S/N # accordingly (you can find the S/N# on the license sticker) f、Please insert Source HDD and Target HDD well to the docking, connect SW-3023 to PC via USB cable. Turn on the power,...
- Page 6 g、The “CloneDrive” will show the HDD info of each bay. h、User can choose to “clone the external Disk”, which means the HDD in bay 1 will be the source HDD, and HDD in bay2 are the target HDD.
- Page 7 i、User can choose to “Clone system disk to external disk”, which means the system disk inside the PC would be the source HDD, and all the HDD in bay 1, 2 will be the target HDD. Warning: all the data in the TARGET HDD will be erased after the CloneDrive clone operation. Please make sure the data in TARGET HDD is backuped.
- Page 8 Source HDD and Target HDD well to the docking, connect SW-3023 to PC via USB cable. Turn on the power. You can find the FlashCopy icon on your desktop. Then double click the FlashCopy Icon to...
- Page 9 start the program. e、For the first time install, you will need to fill in the S/N # accordingly (you can find the S/N# on the license sticker) f、After the program start, user can see content in bay1 and bay2 HDD, select the folder to be copied and draw the folder from the source HDD to the destination HDD.
- Page 10 g、After finishing the file selection, press the start button to activate the FlashCopy function. h、The process window pop up and detail copy information is showed on the window.. i、After the FlashCopy finish operation the report windows shows above.
- Page 11 Please insert the HDD to be erased to the docking, connect SW-3023 to PC via USB cable. Turn on the power. You can find the DiskErase icon on your desktop. Double click the DiskErase Icon to start the program.
- Page 12 e. Choose the HDD on docking to be erased. f. Choose the algorithm to be used for data wipe out.
- Page 13 g. Click the “Start” icon to start the data wipe out operation. h. Please enter the verification code to be sure you want to start the data erase. Warning: Once the data is erased, there is no way to bring it back!!!!!!! i.
