*actual product may vary from photos
Advertisement
Table of Contents
Related Manuals for StarTech.com S3520BU33ER
Summary of Contents for StarTech.com S3520BU33ER
- Page 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 09/16/2013...
- Page 2 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby...
-
Page 3: Table Of Contents
Table of Contents Introduction ....................1 Packaging Contents ..........................1 System Requirements ..........................1 Product Diagram ..................2 Front View ..............................2 Rear View ..............................2 Hardware Installation ................3 Configure RAID ..................6 RAID Modes ..............................6 Set RAID ................................ 6 How to Use ....................7 Connecting the Hard Drive ........................ -
Page 4: Introduction
Introduction Packaging Contents • 1 x USB 3.0/eSATA HDD RAID Enclosure • 1 x USB 3.0 Cable • 1 x eSATA Cable • 1 x Universal Power Adapter and Clips (NA/UK/EU) • 1 x Rubber foot set • 1 x Instruction Manual System Requirements •... -
Page 5: Product Diagram
Product Diagram Front View 1. Front Panel 2. Drive Activity LEDs 3. Power Button Rear View 1. eSATA Port 2. RAID Switch 3. Set RAID Button 4. USB 3.0 Port 5. Power Jack 6. Drive Fan Instruction Manual... -
Page 6: Hardware Installation
Hardware Installation WARNING! Hard drives and storage enclosures require careful handling, especially when being transported. If you are not careful with your hard disk, lost data may result. Always handle your hard drive and storage device with caution. Be sure that you are properly grounded by wearing an anti-static strap when handling computer components or discharge yourself of any static electricity build-up by touching a large grounded metal surface (such as the computer case) for several seconds. - Page 7 3. Lift the panel off to reveal the drive bays. 4. Slide each of your hard drives into the bay Instruction Manual...
- Page 8 5. Place the front panel back on by placing it over the drive bay, and sliding it into place. 6. Replace the screw using the Phillips head screw driver. 7. (optional) If using eSATA, connect the the included eSATA cable from an available eSATA port on your computer system to the eSATA port on the enclosure.
-
Page 9: Configure Raid
Configure RAID RAID Modes JBOD JBOD COMBINE Span (Big) MIRRORING RAID1 STRIPING RAID0 Set RAID 1. Turn off the unit, by Pushing the Power button on the front panel. 2. Set the RAID switch to the RAID mode of your choice. 3. -
Page 10: How To Use
How to Use Connecting the Hard Drive Once the enclosure has been attached to a computer, and your RAID configuration has been set the drivers will install automatically, and the inserted drives will be accessible as though they were installed within the system. Prior to using the drive array, it will need to be formatted according to your operating system requirements. -
Page 11: Initializing The Hard Drive
Initializing the Hard Drive 1. If the drive array is new it may need to be initialized and formatted before use. From the main Windows desktop, right-click on “My Computer” (“Computer” in Vista/ 7 / 8), then select Manage. In the new Computer Management window, select Disk Management from the left window panel. -
Page 12: Specifications
