9U Wall-Mount Rack Enclosure
RK920WALM
FR: Guide de l'utilisateur - fr.startech.com
DE: Bedienungsanleitung - de.startech.com
ES: Guía del usuario - es.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
IT: Guida per l'uso - it.startech.com
For the latest information, technical specifications, and support for
this product, please visit www.StarTech.com/RK920WALM.
Manual Revision: 12/22/2022
*actual product may vary from photos
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for StarTech.com STCRK920WALM
Summary of Contents for StarTech.com STCRK920WALM
- Page 1 9U Wall-Mount Rack Enclosure RK920WALM *actual product may vary from photos FR: Guide de l’utilisateur - fr.startech.com DE: Bedienungsanleitung - de.startech.com ES: Guía del usuario - es.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com IT: Guida per l’uso - it.startech.com For the latest information, technical specifications, and support for this product, please visit www.StarTech.com/RK920WALM.
- Page 2 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby...
- Page 3 注意 Warning statements 必ず取扱説明書に従って本製品の組み立てを行って下さい。 Make sure that you assemble this product according to the instructions. Read the entire manual and make sure that you understand the instructions before you start to assemble 最初に取扱説明書を最後まで読み、 本製品の組み立て方をすべて理解してから組み立て作業を and use this product. 始めて下さい。 Wall structures vary, and it is important to make sure that the type of wall structure and mounting 壁面の構造は建物によって異なります。...
- Page 4 Mensagens de aviso Certifique-se de que monta este produto de acordo com as instruções. Leia todo o manual e certifique-se de que entende as instruções antes de começar a montar e a utilizar este produto. As estruturas de parede variam e é importante certificar-se de que o tipo de estrutura de parede e hardware de montagem que está...
-
Page 5: Table Of Contents
Table of Contents Warnings ..............................i Introduction ....................1 Product diagram ............................1 Product dimensions ..........................2 Package contents ............................2 Requirements ............................. 2 Ground the enclosure ................3 Lock or unlock the front door ..............4 Remove the side panels ................4 Access your cables .................6 Reverse the front door ................7 Adjust the depth of the mounting rails ..........9 Use the mounting rail tapped holes ...........10... -
Page 6: Introduction
Introduction Product diagram Front door Side panel Vents Cable access cover Cable access opening Mounting plate Top panel Bottom panel Instruction manual... -
Page 7: Product Dimensions
• 3 x Pre-installed M4x8 mm screws • 1 x instruction manual Requirements • Phillips™ type screwdriver • Appropriate tools and mounting hardware for the type of wall you’re using Requirements are subject to change. For the latest requirements, please visit www.StarTech.com/RK920WALM. Instruction manual... -
Page 8: Ground The Enclosure
Ground the enclosure Warning! This product must be grounded. Do not use this product without an earth ground connection. 1. Use an M6 screw to attach a grounding wire to the front or rear grounding point on the enclosure. 2. Route the wire under the frame of the enclosure and connect the wire to your facility’s earth ground connection. -
Page 9: Lock Or Unlock The Front Door
Lock or unlock the front door • To lock or unlock the front door of the enclosure, insert one of the provided door keys in the lock on the door and turn the key clockwise or counterclockwise. Remove the side panels 1. - Page 10 3. Lift the side panel free from the enclosure. (figure 3) 4. Repeat steps 1 to 3 to remove the other side panel. figure 3 To put the side panels back on the enclosure, place one of the side panels in the groove at the bottom of the enclosure.
-
Page 11: Access Your Cables
Access your cables Both the top and bottom panels of the enclosure have cable access covers that you can remove to access and manage your cables. 1. To take off a cable access cover, use a Phillips type screwdriver to remove the two screws on both ends of the cable access cover. -
Page 12: Reverse The Front Door
Reverse the front door To accommodate different rack configurations, you can reverse the front door of the enclosure so that it opens to the left or right of the enclosure. The front door of the enclosure is attached to the enclosure with levers that are located at the top and bottom of the front door. - Page 13 3. Flip the front door so that the levers are located on the opposite side. 4. Position the front door so that the top and bottom levers are aligned with the washers located in the hinge area of the enclosure. 5.
-
Page 14: Adjust The Depth Of The Mounting Rails
Adjust the depth of the mounting rails The mounting rails come preinstalled in the enclosure. Both the front and back sets of mounting rails can be adjusted independently in 3/4 inch (20 mm) increments to accommodate different sizes of equipment. Warning! Do not attempt to adjust the mounting rails when equipment is installed in the enclosure. -
Page 15: Use The Mounting Rail Tapped Holes
Use the mounting rail tapped holes The mounting rails come preinstalled in the enclosure but you can adjust the mounting rails so that you can use the tapped holes to install your equipment. Warning! Do not attempt to adjust the mounting rails when equipment is installed in the enclosure. -
Page 16: Mount The Enclosure To The Wall
Mount the enclosure to the wall Warning! Remove all equipment from the enclosure before you attempt to mount the enclosure to the wall. Warning! Wall structures vary and it is important to make sure that the type of wall structure and mounting hardware that you are using will properly support the mounted equipment. - Page 17 2. Fasten the mounting plate to the wall using the appropriate hardware and the four mounting holes 3. Attach the enclosure to the mounting plate by hanging the enclosure onto the three mounting plate hooks. Fasten the enclosure using the three screws from Step Instruction Manual...
-
Page 18: Install Equipment
Install equipment Warning! Do not add equipment to the enclosure until the enclosure is securely attached to the wall. Warning! When you load equipment into this product, load the heaviest equipment in the bottom rails first. Continue loading equipment in a descending order of weight, so that the lighter equipment is installed in the upper sections of this enclosure and the heavier items are on the bottom. -
Page 19: Technical Support
Limitation of liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 20 Hard-to-find made easy. At StarTech.com, that isn’t a slogan. It’s a promise. StarTech.com is your one-stop source for every connectivity part you need. From the latest technology to legacy products — and all the parts that bridge the old and new — we can help you find the parts that connect your solutions.
