ACCESSORIES

The following objects are present inside the box:

Control unit

Start guide and QR CODE

2 blocks for panel mounting

1 ENABLE contact terminal 2 poles pitch 5

Code: 2PL0363 - Screws tightening torque 0.5Nm

2 Supply and relay terminal 3 poles pitch 5

Code: 2PL0367 - Screws tightening torque 0.5Nm

1 PTC line connection terminal 3 poles

1 motor line terminal 4 poles pitch 5

Code: 2PL0369 - Screws tightening torque 0.5Nm

ATTENTION: always install the device using the terminals included in the pack. The use of terminals other

than those included with the control unit might cause malfunctions.

VRT200

1MN0030 REV. 2
