- Page 1 (Webpage Setting) Operation anual Digital P System PS -5240 RQ...
-
Page 2: Table Of Contents
DIGITAL PA SYSTEM Contents Contents Webpage Setting ..........................1 Ⅰ. Initial Web network setup......................1 Ⅱ. 1 Common Screen........................4 Ⅱ. 2 Audio Setup ........................5 Ⅱ. 3 Network Setup........................6 Ⅱ. 4 Time Setup ..........................7 Ⅱ. 5 View Log..........................8 Ⅱ. 6 System Management ......................9 Ⅱ. -
Page 3: Webpage Setting
※ If the computer’s wireless network is turned on, turn it off and proceed. c. Unicate with the device and to each other. ※ Please download the latest version of the manual as manual may change depending on the firmware version. (www.inter-m.com) PSI-5240IRQ... - Page 4 Problems connecting? ① Make sure the cable is in good working order. ② Make sure that you are able to “ping” the PSI-5240IRQ from the network device. (If there is no response, rework the network configuration) ③ Make sure equipment is turned on.
- Page 5 DIGITAL PA SYSTEM USER ID : admin USER ID : user f. Click the Network Settings menu in the left navigation pane to configure the network setting of the PSI-5240IRQ. PSI-5240IRQ...
-
Page 6: Ⅱ. 1 Common Screen
① Name of the device connected to the web is displayed. ② Set the language of the web page. ③ Displays the information of web connected device. (Device Name/Device IP/Web Version) ④ Menu available from the web page. ⑤ Corresponding screen is displayed when menu is selected. PSI-5240IRQ... -
Page 7: Ⅱ. 2 Audio Setup
② Press [Reset] button to reset server IP address of audio, server port and name of host. ③ Operation information of audio client is displayed on the screen. ④ Currently connected server information of audio stream is displayed. ⑤ Name of host and real-time audio is displayed, and volume control is available. PSI-5240IRQ... -
Page 8: Ⅱ. 3 Network Setup
⑤ Click [Apply] button to apply the modified information from steps ② and ③ and ④. ⑥ Click [Initialize] button to reset the modified information from steps ② and ③ and ④. ⑦ [Network Setup] Help & Tips are displayed. PSI-5240IRQ... -
Page 9: Ⅱ. 4 Time Setup
Periodic time to synchronize the clock. (ex: If set for 15:00 hour, at every 3:00 pm, synchronization sets the time on the device.) ④ Click [Apply] button to apply the set time. ⑤ [Time Setup] Help & Tips are displayed. PSI-5240IRQ... -
Page 10: Ⅱ. 5 View Log
② Click [Download the log] button to save log information as a file. ③ Click [Refresh] button to reload the log. ④ Click [Clear Log] button to clear the log information. ⑤ [View Log] Help & Tips are displayed. PSI-5240IRQ... -
Page 11: Ⅱ. 6 System Management
※ S/W Upgrade extensions: .tar.gz ② Click [Apply] button to upgrade the selected file to the device. ③ Click [Initialize] button to reset the file selected in step ①. ④ [System Upgrade] Help & Tips are displayed. PSI-5240IRQ... -
Page 12: Ⅱ. 6. 2 Password Change
② Enter the current password. ③ Enter new password. ④ Enter new password once more. ⑤ Click [Apply]button to change to new password. ⑥ Click [Initialize] button to reset the newly entered password. ⑦ [Password Change] Help & Tips are displayed. PSI-5240IRQ... -
Page 13: Ⅱ. 6. 3 System Check Setup
③ Click [Apply] button to apply the modified information from steps ① and ②. ④ Click [Initialize] button to reset the modified information from steps ① and ②. (Default value: 12 Hour 00 Minute, Inactive) ⑤ [System Check Setup] Help & Tips are displayed. PSI-5240IRQ... -
Page 14: Ⅱ. 6. 4 Restart System
DIGITAL PA SYSTEM Ⅱ. 6. 4 Restart System ① ② ① Click [Apply] button to restart the system. ② [Restart System] Help & Tips are displayed. PSI-5240IRQ... -
Page 15: Ⅱ. 6. 5 Factory Set System
DIGITAL PA SYSTEM Ⅱ. 6. 5 Factory Set System ① ② ① Click [Apply] button to set back to factory default settings. ② [Factory Set System] Help & Tips are displayed. PSI-5240IRQ... - Page 16 Inter-M, Ltd. (Korea) began operations in 1983. Since then, Inter-M has grown to become one of the largest manufacturers of professional audio and commercial sound electronics equipment in the world. Inter-M has gained worldwide recognition for its own branded products, as well as private label manufacturing of electronics sold under other names (OEM).
