4) SPECIFICATION

Maximum hole cutting capacity in .2/.3C steel = 75mm dia. x 75mm deep
Arbor bore = MT3.
Motor Unit
Voltages
Normal full load
Electro Magnet
Size
Holding Force at 20°C with 25mm minimum plate thickness
The use on any material less than 25mm thick will progressively
reduce the magnetic performance. If possible, substitute
material should be positioned under the magnet and work
piece to equate to a suitable material thickness. If this is not
possible, an alternative secure method of restraining the
machine must be used.
Total Load (magnet + motor)
Overall Dimensions
Height - maximum extended
Height - minimum
Width (including capstan fitting)
Length Overall (including guard)
Nett Weight
Vibration total values (triax vector sum) in accordance with
EN61029-1:
Level of sound pressure in accordance with EN61029-1:
Ear and eye defenders must be worn when operating this machine. Wear gloves to protect hands when operating the
machine.
These tools are UK designed and manufactured with globally sourced components and conform with the requirements
of EEC Document HD.400.1 and BS.2769/84
Suitable only for a single phase 50-60Hz A.C. power supply
Do not use your magnetic drill on the same structure when arc welding is in progress.
D.C. current will earth back through the magnet and cause irreparable damage.
WARNING: THIS APPLIANCE MUST BE EARTHED!
NB: ANY MODIFICATIONS TO THIS MACHINE WILL INVALIDATE THE GUARANTEE
Original Instructions
DO NOT USE ON D.C. SUPPLY
6
Aug 2016
110V 50-60Hz 230V 50-60Hz
18.0 A 1800 W 8.6 A
0.97 A 102W 0.52 A
220mm long
114mm wide
18500N
1902W
713mm
528mm
214mm
375mm
23.1kgs
Element 75/1T Element 75/3T
Vibration emission value Vibration emission value
2
(a ):3.762m/s (a
h
Uncertainty(K):1.5m/s² Uncertainty(K):1.5m/s²
Sound pressure(LpA):
Sound pressure(LpA):
88.0 dB(A)
Acoustic power(LwA):
Acoustic power(LwA):
101.0 dB(A)
Uncertainty(K)：3dB(A)
Uncertainty(K)：3dB(A)
1800 W
111W
1911W
22.8kgs
):3.737 m/s²
h
87.0 dB(A)
100.0 dB(A)
