CHAPTER 3: HEADERS & JUMPERS SETUP
3.1
H
OW T O
The illustration shows how to set up jumpers. When the jumper cap is
placed on pins, the jumper is "close", if not, that means the jumper is
"open".
Pin opened
3.2
D
S
ET AIL
JPANEL1: Front Panel Heade r
This 16-pin connector includes Power-on, Reset, HDD LED, Power LED, Sleep
button and speaker connection. It allows user to connect the PC case's f ront
panel switch functions.
Pin
Assignment
1
+5V
2
N/A
3
N/A
4
Speaker
5
HDD LED (+)
6
HDD LED (-)
7
Ground
8
Reset control
S
J
ET UP
UMPERS
Pin closed
ETT INGS
Functio n
Speaker
Connector
Hard drive
LED
Reset button
Pin1-2 closed
P WR_LE D
S LP
On/Off
-
+ +
9
16
1
8
-
+
S PK
RS T
HLED
Pin
Assignment
9
Sleep control
10
Ground
11
N/A
12
Power LED (+)
13
Power LED (+)
14
Power LED (-)
15
Power button
16
Ground
P35D2-A 7
Functio n
Sleep button
N/A
Power LED
Power-on button
13
