FCC Statement and Copyright
This equipment has been tested and found to comply with the limits of a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. There is no guarantee that interference will not occur in a
particular installation.
The vendor makes no representations or warranties with respect to the
contents here of and specially disclaims any implied warranties of
merchantability or fitness for any purpose. Further the vendor reserves the
right to revise this publication and to make changes to the contents here of
without obligation to notify any party beforehand.
Duplication of this publication, in part or in whole is not allowed without
first obtaining the vendor's approval in writing.
The content of this user's is subject to be changed without notice and we
will not be responsible for any mistakes found in this user's manual. All the
brand and product names are trademarks of their respective companies.
i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P4TDQ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Biostar P4TDQ

  • Page 1 FCC Statement and Copyright This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 2: Table Of Contents

    ENGLISH... 1 P4TDQ Features ...1 Package contents...1 Layout of P4TDQ ...2 CPU Installation...3 DDR DIMM Modules: DDR1-2...4 Jumpers, Headers, Connectors & Slots...5 ESPAÑOL... 9 Características del P4TDQ...9 Contenido del Paquete ...9 Disposición del P4TDQ ...10 Instalación de la CPU...11 Módulos DDR DIMM: DDR1-2 ...12 Conectores, Cabezales, Puentes y Ranuras ...13...
  • Page 3: English

    English P4TDQ Features Use Intel 82845GL/ 82801DB Chipset, ITE IT8712F, LAN Chip (optional). Contains on board I/O facilities, which include one serial port, a parallel port, a PS/2 mouse port, a PS/2 keyboard port, audio ports, USB ports, a LAN port (optional), a game port, and a monitor port.
  • Page 4: Layout Of P4Tdq

    Layout of P4TDQ JKBMS1 & Mouse JUSBV1 USB & LAN JRJ45USB1 JCOM1 JPRNT1 JVGA1 JUSBV2 JGAME_USB1 JAUDIO1 JTAD1 Codec JCDIN1 CHIP CNR1 JCFAN1 JATXPWR2 JATXPWR1 INTEL 845GL IDE2 JDIMMVOLT PCI1 JUSBV3 INTEL 82801DB PCI2 (ICH4) JUSB1 PCI3 JCMOS1 WOL1 JUSB2...
  • Page 5: Cpu Installation

    CPU Installation Pull the lever sideways away from the socket then raise the lever up to 90-degree angle. Locate Pin A in the socket and lock for the white dot or cut edge in the CPU. Match Pin A with the white dot/cut edge then insert the CPU.
  • Page 6: Ddr Dimm Modules: Ddr1-2

    DDR DIMM Modules: DDR1-2 DRAM Access Time: 2.5V Unbuffered DDR 200/266 MHz Type required. DRAM Type: 64MB/ 128MB/ 256MB/ 512MB/ 1GB DIMM Module (184 pin) DIMM Socket DDR Module Location DDR 1 64MB/128MB/256MB/512MB/1GB DDR 2 64MB/128MB/256MB/512MB/1GB * The list shown above for DRAM configuration is only for reference. How to install a DIMM Module 1.
  • Page 7: Jumpers, Headers, Connectors & Slots

    Peripheral Component Interconnect Slots: PCI1-3 This motherboard is equipped with 3 standard PCI slots. PCI stands for Peripheral Component Interconnect, and it is a bus standard for expansion cards, which has, supplanted the older ISA bus standard in most ports.
  • Page 8 DIMM Power Selection Connector: JDIMMVOLT Pin 1-2 on ==> 2.6V Pin 3-4 on ==> 2.7V JDIMMVOLT Pin 5-6 on ==> 2.8V Pin 7-8 on ==> 2.9V (Default ==> 2.5V) It strongly recommended to set DDR DIMM voltage in default setting 2.5V, and it for over voltage function.
  • Page 9 Front Panel Connector: JPANEL1 PWR_LED HLED ==> Speaker Conn. HLED ==> Hard Driver LED ==> Reset Button ==> Infrared Conn. ==> Sleep Button PWR_LED ==> Power LED ON/ OFF ==> Power-on Button Audio Subsystem: JAUDIO1/ JTAD1(Optional)/JCDIN1 JTAD1(Optional) (Telephony Audio Header) JAUDIO1 (Front Audio Header) ON/OFF...
  • Page 10: Back Panel Connectors

    Clear CMOS Jumper: JCMOS1 Pin 1-2 on ==> Normal Operation Pin 2-3 on ==> Clear CMOS Data JCMOS1 Back Panel Connectors RJ45USB1 JKBMS1 JPRNT1 LAN(Optional) PS/2 Mouse Parallel PS/2 COM1 COM1 Keyboard JCOM1 (default) JGAME1_USB1 Game Port/ USB Ports (optional) Speaker Line In Mic VGA1...
  • Page 11: Español

    Español Características del P4TDQ Usa Chipset Intel 82845GL/ 82801DB, ITE IT8712F, LAN Chip (opcional). Contiene facilidades I/O integrados en la placa madre en el que incluye un puerto en serie paralelo, un puerto paralelo, un puerto para el ratón PS/2, un puerto para teclado PS/2, puertos de audio, puertos USB, puerto LAN (opcional), un puerto para juegos y un puerto para el monitor.
  • Page 12: Disposición Del P4Tdq

    Disposición del P4TDQ JKBMS1 Teclado & Raton JUSBV1 USB & LAN JRJ45USB1 JCOM1 JPRNT1 JVGA1 JUSBV2 JGAME_USB1 JAUDIO1 JTAD1 Codec JCDIN1 CHIP CNR1 JCFAN1 JATXPWR2 JATXPWR1 INTEL 845GL IDE2 JDIMMVOLT PCI1 JUSBV3 INTEL 82801DB PCI2 (ICH4) JUSB1 PCI3 JCMOS1 WOL1...
  • Page 13: Instalación De La Cpu

    Instalación de la CPU Tire de la palanca del lado del zócalo, luego levante la palanca hasta un ángulo de 90 grados. Sitúe el contacto A del zócalo y busque el punto blanco o corte el borde en la CPU. Empareje el contacto A con el punto blanco/ corte del borde, luego inserte la CPU.
  • Page 14: Módulos Ddr Dimm: Ddr1-2

    Módulos DDR DIMM: DDR1-2 DRAM Tiempo de Acceso: 2.5V Unbuffered DDR 200/266MHz Tipo requerido. DRAM Tipo: 64MB/ 128MB/ 256MB/ 512MB/ 1GB Módulo DIMM (184 Contactos) Localización del Zócalo Módulo DDR DIMM DDR 1 64MB/128MB/256MB/512MB/1GB DDR 2 64MB/128MB/256MB/512MB/1GB * La lista de arriba para la configuarción DRAM es solamente para referencia.
  • Page 15: Conectores, Cabezales, Puentes Y Ranuras

    Conectores, Cabezales, Puentes y Ranuras Conectores del Disco Duro: IDE1/ IDE2 La placa madre tiene un controlador de 32-bit PCI IDE que proporciona Modo PIO 0~4, Bus Master, y funcionalida Ultra DMA / 33/ 66/ 100. Tiene dos conectores HDD IDE1 (primario) y IDE2 (secundario). El conector IDE puede conectar a un master y un drive esclavo, así...
  • Page 16 Conector de la Corriente de Selección DIMM: JDIMMVOLT Contacto 1-2 encendido ==> 2.6V Contacto 3-4 encendido ==> 2.7V JDIMMVOLT Contacto 5-6 encendido ==> 2.8V Contacto 7-8 encendido ==> 2.9V (Predeterminado ==> 2.5V) Es fuertemente recomendado que fije el voltaje del DDR DIMM predeterminado en 2.5V, y sobre el sobre voltaje de función.
  • Page 17 Conector del Panel Frontal: JPANEL1 PWR_LED HLED ==> Conector de Altavoz HLED ==> LED del Disco Duro ==> Boton de Reinicio ==> Conector Infrarojo ==> Boton de Suspension PWR_LED ==> Corriente LED ON/ OFF ==> Boton de Encendido Subsistema de Audio: JAUDIO1/ JTAD1(Opcional)/JCDIN1 JTAD1(Opcional) (Cabezal de Audio Telefonico)
  • Page 18 Puente de Borrar CMOS: JCMOS1 Contacto 1-2 encendido ==> Operacion Normal (default) Contacto 2-3 encendido ==> Borrar Datos CMOS JCMOS1 Conectores del Panel Trasero RJ45USB1 JKBMS1 JPRNT1 LAN(Opcional) Raton PS/2 Paralelo Teclado COM1 COM1 PS/2 JCOM1 JGAME1_USB1 Puerto de Juego/ Puertos USB (opcional) Salida del Entrada...
  • Page 19: Trouble Shooting

    Trouble Shooting PROBABLE No power to the system at all Power light don’t illuminate, fan inside power supply does not turn on. Indicator light on keyboard does not turn on PROBABLE System inoperative. Keyboard lights are on, power indicator lights are lit, hard drive is spinning.
  • Page 20: Solución De Problemas

    Solución de Problemas CAUSA PROBABLE No hay corriente en el sistema. La luz de corriente no ilumina, ventilador dentro de la fuente de alimentación apagada. Indicador de luz del teclado apagado. CAUSA PROBABLE Sistema inoperativo. Luz del teclado encendido, luz de indicador de corriente iluminado, disco rígido está...
  • Page 21 04/24/2002...
