Lobby Camera Phone DR-2AG/RF1
• Thank you for purchasing COMMAX products.
• Thank you for purchasing COMMAX products.
• Please carefully read this User's Guide (in particular, precautions for safety) before using a product and follow
• Please carefully read this User's Guide (in particular, precautions for safety) before using a product and follow
instructions to use a product exactly.
instructions to use a product exactly.
• The company is not responsible for any safety accidents caused by abnormal operation of the product.
• The company is not responsible for any safety accidents caused by abnormal operation of the product.
www.safemag.ru
54
www.safemag.ru

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DR-2AG/RF1 and is the answer not in the manual?

Questions and answers

Related Manuals for Commax DR-2AG/RF1

Summary of Contents for Commax DR-2AG/RF1

  • Page 1: User Manual

    User Manual Lobby Camera Phone DR-2AG/RF1 • Thank you for purchasing COMMAX products. • Thank you for purchasing COMMAX products. • Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow • Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow instructions to use a product exactly.

  • Page 2: Table Of Contents

    33. Part list ...........................52 34. Specifications and Features ....................52 35. RF-ID Model (Optional) ......................53 1. Greeting * Thank you for purchasing a COMMAX product * This product is a high tech Main Entrance interphone that supports electronic Please read this manual carefully. www.safemag.ru...

  • Page 3: Safety Warning & Caution

    www.safemag.ru 2. Safety Warning & Caution Please follow the things described below in order to prevent any danger or property damage. Warning Prohibition. It may cause a serious damage or No disassembly injury if violated. No touch Must follow strictly. Caution Shows plugging out the power cord It may cause a minor damage or...
  • Page 4 www.safemag.ru Warning Please don’ t disassemble, If an abnormal sound, burning Please don’t insert any Please use only the designated smell or smoke is coming out repair or rebuild this product metallic or burnable materials batteries for the products of arbitrarily (please contact the of the product, please plug out into the ventilation hole.

  • Page 5: Parts

    www.safemag.ru 3. Parts 3-1. The name of parts Function Function Speaker C-MIC OLED Display Electric Key Button RFID card receiver Line connecting button Name Searching button / Reset Button Menu Page Button Circuit Connect Switch Up & Down scroll button/ Program Button Call Button Number button...
  • Page 6 www.safemag.ru 3-2. Important function ✽ Starting OLED display (Power ON OLED display) ✽ RF/ID Receiver ③(Optional) When open door by wireless card key, please tag it to this points.(See bellow photo). "Open door" message and Icon will be displayed in OLED. ✽...
  • Page 7 www.safemag.ru ✽ Name searching button ⑥(S : Search) Tenants name searching button. ✽ Electric key button ⑫(K : Key) Open door by Password Number. (Deactivate Password LOCK function only.) ✽ Cancel button ⑩(X : Cancel) When user wants to cancel function, press it. ✽...
  • Page 8 www.safemag.ru ✽ Call security 1. Press, name search button and call security which is top of the name list. 2. Press "9999" and press call button. ✽ Must know before use. 1) If you hear "beep beep beep..."during any program modes, please restart from the beginning.

  • Page 9: Password Type

    www.safemag.ru 4. Password type 4-1. Password for the Management Office ("Management Password") A password for the Manager Factory default for the Manager Password is 4321. 4-2. Password for any buildings ("Building Password") A common password for a corresponding building. Factory default for the Building Password is 1234. 4-3.

  • Page 10: How To Input Password

    www.safemag.ru 5. How to input Password 5-1. Press management Password • P - old Password - E - New Password - E • Password must be 4 digits. • "0000", "1234", "4321" can't be used as Password ① Press program button (P). ②...
  • Page 11 www.safemag.ru 5-2. Press building Password • P - old Password - E - 1 - E - New Password - E • Password must be 4 digits. • "0000°", "1234", "4321" can't be used as Password ① Press program button (P). ②...
  • Page 12 www.safemag.ru 5-3. Press house (Unit) Password • K - 20 - E- house Number - E- old Password - E - New Password - E • Password must be 4 digits. • "0000", "1234", "4321" can't be used as Password •...

  • Page 13: Check House Password

    www.safemag.ru 6. Check house Password 6-1. Check house Password • P - management Password - E - 16 - E - Household Unit Number E ① Press program button (P). ② Press management Password. ③ Press call button (E). ④ Press "16" (Set ID Number function key) ⑤...

  • Page 14: Set Building Number And Id To Lobby Panel

    www.safemag.ru 7. Set building Number and ID to Lobby panel • This setting is mandatory because building Number and ID automatically are set up when lobby panel call house and security guard. • Max. 99 lobby panel can be installed for one building. 7-1.
  • Page 15 www.safemag.ru 7-2. Set ID no. in Lobby Panel • P - Management Password - E - 3 - E - ID - E ① Press program button (P). ② Press management Password. ③ Press call button (E). ④ Press "3" (Set ID Number function key) ⑤...

  • Page 16: Rf Card Key Appliances

    www.safemag.ru 8. RF card key appliances 8-1 RF card key test way • P- Management Password - E - 9 - E - Card Test - X(Cancel) • This function is only for the test of wireless card key ① Press down the (P) button ②...
  • Page 17 www.safemag.ru 8-2. RF card key input way • P- Management Password - E- 10 - E - Place card close to the RF/ID receiver - X(cancel) <References> Up to 2048 cards can be registered(if not to connect with SecuMAX) www.safemag.ru...
  • Page 18 www.safemag.ru 8-3. RF card key separate deletion way • P - Management Password - E - 12 - E - Delete cards - X(Cancel) ① Press Program Button "P" ② Press Management Password ③ Press Call Button "E" ④ Press number "12"(separate delete number) ⑤...
  • Page 19 www.safemag.ru 8-4. RF card key registration check way • P- Management password - E - 13 - E - Check the cards - X(Cancel) ① Press Program Button "P" ② Press Management Password ③ Press Call Button "E" ④ Press number "13"(registration check) ⑤...
  • Page 20 www.safemag.ru 8-5. RF card key all delete way • P - Management password - E - 11 - E - E • All deletion way is only useful when initially set up, unless all registered cards are to be deleted. ①...
  • Page 21 www.safemag.ru 8-6. RF card key capacity change way • P- Management password - E - 19 - E - 0 - E : Up to 2048 RF Cards can be registered • P- Management password - E - 19 - E - 1 - E : Unlimited RF Cards can be registered ①...
  • Page 22 www.safemag.ru 8-7. RF card key data transmission • P - Management Passwords - E - 32 - E - Press destination lobby phone number - E ① Press Program Button "P" ② Press Management password ③ Press Call Button "E" ④...
  • Page 23 www.safemag.ru 8-8. RF card key data reception • P- Management Passwords - E - 33 - E - Press source lobby phone number - E ① Press Program Button "P" ② Press Management password ③ Press Call Button "E" ④ Press number "33" for data reception ⑤...

  • Page 24: Set To Be Forced Opening The Main Entrance Door By Secumax

    www.safemag.ru 9. Set to be forced opening the Main Entrance door by SecuMAX • P - Management password - E - 22 - E - 0 - E : Forwarding to SecuMAX disabled • P - Management password - E - 22 - E - 1 - E : Forwarding to SecuMAX enabled •...

  • Page 25: Door Opening Hours Setting

    www.safemag.ru 10. Door opening hours setting • P - Management Passwords - E - 5 - E - Opening hours - E • This function is to control the common entrance door opening hours ① Press Program Button "P" ② Press Management Passwords ③...

  • Page 26: Line-By-Line Call Function Setting

    www.safemag.ru 11. Line-by-line call function Setting • P - Management password - E - 21 - E - 0 - E: available for entire house call • P - Management password - E - 21 - E - Line number - E : call only specified line ex) In case 1 line ~ 2 line, input "0102"...

  • Page 27: Automatic Calling Function Of Guard Station Configuration

    www.safemag.ru 12. Automatic calling function of guard station configuration • P - Management password - E - 27 - E - 0 - E : Automatic call mode • P - Management password - E - 27 - E - 1 - E : Emergency call mode •...

  • Page 28: Call Tones Selection

    www.safemag.ru 13. Call Tones selection • P - Management password - E - 7 - E - 0 - E : Melody sound • P - Management password - E - 7 - E - 1 - E : Bell(Ringer sound) •...

  • Page 29: Setting The Number Of Call Ring Repetitions

    www.safemag.ru 14. Setting the Number of Call Ring Repetitions • P - Management Password - E - 25 - E - 0 - E : Continuous call ring enabled. • P - Management Password - E - 25 - E - 1 - E : 1 time Call ring enabled. •...

  • Page 30: Door Release By External Information Forwarding To Secumax Way

    www.safemag.ru 15. Door release by external information forwarding to SecuMAX way • P - Management password - E - 18 - E - 0 - E : Forwarding to SecuMAX disabled • P - Management password - E - 18 - E - 1 - E : Forwarding to SecuMAX enabled •...

  • Page 31: Set To Be Forced Opening The Main Entrance Door By Secumax

    www.safemag.ru 16. Set to be forced opening the Main Entrance door by SecuMAX • P - Management password - E - 29 - E - 0 - E : Forced opening by SecuMAX disabled • P - Management password - E - 29 - E - 1 - E : Forced opening by SecuMAX disabled •...

  • Page 32: Setting The Time To Trigger The Notice To Be Forced Door Forwarding To Secumax

    www.safemag.ru 17. Setting the time to trigger the notice to be forced door forwarding to SecuMAX • P - Management password - E - 24 - E - 0 - E : This function is disabled • P - Management password - E - 29 - E - 1 - E : Set the time(second) •...

  • Page 33: Selecting The Wiring Method

    www.safemag.ru 18. Selecting the Wiring Method • P - Management Password - E -6 - E - 4 - E : common 4 wire method • P - Management Password - E - 6 - E - 6 - E : common 6 wire method •...

  • Page 34: Registration Of Household Unit Number

    www.safemag.ru 19. Registration of Household Unit Number • P - Management Password - E - 15 - E - Call Security from the monitor.- number of household - E - serial number - E • This method applies to the case that there is no security station installed. Calling security from the monitor will direct the call to the lobby phone.
  • Page 35 www.safemag.ru ① Press Program Button "P". ② Press Management password. ③ Press Call Button "E". ④ Press "15" (number fifteen). ⑤ Press Call Button "E". ⑥ From a household unit, call security. The factory default household unit number appears on the OLED display of the lobby phone. Please Press the actual unit number. ⑦...

  • Page 36: Checking Status Of Household Units

    www.safemag.ru 20. Checking Status of Household Units • P - Management password - E - 14 - Unit Number - E - serial number - E • This function is to check the status of installed in each household unit. www.safemag.ru...
  • Page 37 www.safemag.ru ① Press Program Button "P". ② Press Management Password. ③ Press Call Button "E". ④ Press "14" (number fourteen). ⑤ Press Call Button "E". ⑥ Press the Unit Number and press Call Button "E". ⑦ Press "0" (number zero as Master lobby phone or Press a corresponding lobby phone number) and press Call Button "E".

  • Page 38: Setting The Keypad Led Option

    www.safemag.ru 21. Setting the Keypad LED Option • P – Management Password – E – 20 – 0 – E : Keypad LED OFF • P – Management Password – E – 20 – 1 – E : Keypad LED ON •...

  • Page 39: Activation Of Electronic Key (Password) Function

    www.safemag.ru 22. Activation of Electronic Key (Password) Function • P - Management Password - E - 31 - 1 - E : Electronic Key (Password) enabled. • P - Management Password - E - 31 - 0 - E : Electronic Key (Password) disabled. •...

  • Page 40: Setting The Volume Of Voice And Beep Sound

    www.safemag.ru 23. Setting the Volume of Voice and Beep Sound • P - Management Password - E - 30 - E - Beep Volume (1~2) - Voice Volume (1~7) - E • This function enables the adjustment of Beep & Voice volume. ①...

  • Page 41: Method Of Name Data Sending

    www.safemag.ru 24. Method of name data sending • P - Management Password - E - 34 - E - Press destination lobby phone number - E ① Press Program Button "P". ② Press Management Password. ③ Press Call Button "E". ④...

  • Page 42: How To Receive The Name Of The Data

    www.safemag.ru 25. How to receive the name of the data • P - Management Password - E - 35 - E - Press source lobby phone number - E ① Press Program Button "P". ② Press Management Password. ③ Press Call Button "E". ④...

  • Page 43: Setting The Door Release By Building Password

    www.safemag.ru 26. Setting the door release by building password 26-1. Setting the Door Release by Building Password • P – Management Password – E – 28 – 1 – E : Door release by Building Password enabled. • P – Management Password – E – 28 – 0 – E : Door release by Building Password disabled.
  • Page 44 www.safemag.ru 26-2. Using a door release by Building Password function. www.safemag.ru...

  • Page 45: When You Want To Call A Household

    www.safemag.ru 27. When you want to call a household 1) called to a household 1) called to a household www.safemag.ru...

  • Page 46: When You Want To Call A Guard Station

    www.safemag.ru 28. When you want to call a Guard Station 29. Door Release by Unit Password www.safemag.ru...

  • Page 47: Supplement (Summary Of Various Programs)

    www.safemag.ru 30. Supplement (summary of various programs) Setting Passwords 1. P–Previous Management Password–E–0–E– New Management Password–E : Management Password Registration. 2. P-Previous Building Password-E-1-E-New Building Password-E : Building Password Registration 3. K-20-E-Household Unit Number-E-Previous Unit Password-E-New Unit Password-E : Unit Password Registration 4.
  • Page 48 www.safemag.ru SecuMAX Management 1. P-Management Password-E-18-E : Set to Door release by external information forwarding to SecuMAX. 2. P-Management Password-E-22-E : Set to Door release by internal information forwarding to SecuMAX. 3. P-Management Password-E-29-E : Set to be forced opening the Main Entrance door by SecuMAX.

  • Page 49: Wiring Information

    www.safemag.ru 31. Wiring Information 1) Guard interphone GateView GuardStation 481 GuardStation www.safemag.ru...
  • Page 50 www.safemag.ru 2) Sensor connection method www.safemag.ru...
  • Page 51 www.safemag.ru 3) entrance interphone (DR-2AG) <Caution> • If installed outdoor, it requires extra molding for water-proof and rainshield. www.safemag.ru...
  • Page 52 www.safemag.ru 4) System schematic www.safemag.ru...

  • Page 53: Miscellaneous

    Bracket + Flush Mount Bracket SCREW. FHM 4X40 SUS NI 34. Specifications and Features Installation Flush Mount Type installation Model DR-2AG/RF1 UTP Cable(ø 0.5) Floor Distributor(common 6 wires), Wiring Security station phone(common 4 wires) Power Source , 1A Power Consumption...

  • Page 54: Rf-Id Model (Optional)

    35. RF-ID Model (Optional) Communication Device Certification(RF Option) Model Name DR-2AG/RF1 Frequency 13.56MHz Antenna power range Under 47.5mV/m within 10 meter radius Power Emission Type Number of Channel 1 Channel Modulation method Communication method Simplex Operation Method Temperature -10°C(tested up to -40°C) ~ +50°C, 95%...
  • Page 55 513-11, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, Korea Int’l Business Dept. Tel. : +82-31-7393-540~550 Fax. : +82-31-745-2133 Web site : www.commax.com PM132AGRF110 Printed In Korea / 2013.12.104 www.safemag.ru...
