User Manual
Door station unit DR-2L
• Thank you for purchasing COMMAX products.
• Please carefully read this User's Guide (in particular, precautions for safety) before using a product and follow
instructions to use a product exactly.
• The company is not responsible for any safety accidents caused by abnormal operation of the product.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DR-2L and is the answer not in the manual?

Questions and answers

Related Manuals for Commax DR-2L

Summary of Contents for Commax DR-2L

  • Page 1: User Manual

    User Manual Door station unit DR-2L • Thank you for purchasing COMMAX products. • Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow instructions to use a product exactly. • The company is not responsible for any safety accidents caused by abnormal operation of the product.

  • Page 2: Table Of Contents

    Contents 1. Introduction ........... 2 2. Important Safeguards ........3 3. Overview ............4 4. Wiring and Installation ........5 5. Specifications..........6...

  • Page 3: Introduction

    The model number is located on the bottom and record the serial number in the space provided below(available). Refer to these numbers whenever you call upon your COMMAX dealer regarding this product. Model No.

  • Page 4: Important Safeguards

    2. Important Safeguards ▲ Damage Requiring Service : This equipment from the power source and source and refer servicing to qualified service per- sonnel under the following conditions ⓐ when the power is damaged. ⓑ if liquid has been spoiled or objects have hallen into the unit ⓒ...

  • Page 5: Overview

    3. Overview BACK SIDE-1 FRONT SIDE BACK SIDE-2 C-MIC: transmits visitor’s voice(outdoor → indoor) Call button: Needed to make a call to household (Operation status LED) Speaker: transmits householder’s voice(indoor → outdoor)

  • Page 6: Wiring And Installation

    4.Wiring and Installation 1. Mount bracket on the wall with screws(T4 x 18). 2. Connect the Room station cables to the door station cables. 3. Place door station on the bracket and fix it with provided screws. (M4 x 10) SCREW T4X18(2EA) SCREW M4X10(1EA)

  • Page 7: Specifications

    5. Specifications MODEL DR-2L Wiring System (household) DOOR PHONE 2-wire system(nonpolar) Communication method Full Duplex Rated voltage (supplied from the DOOR PHONE) (MAX 0.3W) Operating Temperature -10°C ~ +40°C Dimensions (mm) 186(W)×126(H)×23(D)mm Weight(g) 280g...
  • Page 8 513-11, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, Korea Int’l Business Dept. : Tel.; +82-31-7393-540~550 Fax.; +82-31-745-2133 Web site : www.commax.com Printed In Korea / 2013.06.105...
