Summary of Contents for Ferax BJS-600
- Page 1 Instruktionsbok Manual Sticksåg Jig saw BJS - 600 Code no. 19694 - 0506...
-
Page 2: Table Of Contents
ENGLISH Applications The jigsaw can be used to cut workpieces of Original instructions various materials (wood, aluminium, plastic, metal etc.) precisely to size and in any desired CONTENTS shape. Introduction ..........41 Technical specification ......41 2. TECHNICAL SPECIFICATIONS Package contents ........41 Voltage ........ -
Page 3: Safetyinstructions
1. Speed control 2. Interlocking knob Wear ear and eye protection 3. Switch 4. Connection point vacuum cleaner 5. Allen key Hard materials such as steel, alumi- 6. Bottom plate nium, plastic. 7. Saw buckle 8. Pendulum Soft materials such as wood. 9. -
Page 4: Using The Appliance
5.2 Using the appliance 5.3 Electrical safety • Clamp the workpiece that you will be sawing Always check that the mains voltage in firmly into place. is the same as on the type plate of the • Remove any wood residue that is near or machine. stuck to the surface of the saw blade; do not use your hand for this. -
Page 5: Assembling Saw Blade
The jigsaw is suitable for all commercially blade can result in an unsatisfactory cut. available saw blades. • Push the guard down. 6.3 Adjusting the bottom plate Saw blade Type of workpiece (Fig. 3) Coarse Wood Medium Wood Fine Plastic, aluminium, steel Very fine Cutting curves (wood) 6.2 Assembling saw blade (Fig. -
Page 6: Operation
7. OPERATION The speed of the saw blade can be controlled with the rotary knob at the top of the jigsaw. 7.1 Operation The higher the position, the higher the speed. The highest position is 6. The ideal sawing speed will depend on the profile and the tooth of the saw blade and on the material you want to saw. -
Page 7: Dust-Collection
7.4 Dust-collection (Fig.7) 7.7 Parallel saw guide (Fig. 8) Fig. 7 Fig. 8 To keep the work surface clean, the jigsaw is If you want to make a saw cut that runs parallel equipped with a connection for dust extrac- to the edge of the plank, use the parallel saw tion. -
Page 8: Maintenance
• Put the jigsaw on the rounded front of the Maintain the jigsaw regularly to prevent unne- bottom plate . cessary problems. This will ensure that your • Switch on the appliance and slowly lower the appliance remains in optimum condition. jigsaw until it touches the workpiece. • Let the jigsaw cut into the workpiece gently • Keep the bottom plate clean so that no inac- without forcing it. -
Page 9: Cleaning
• The appliance runs noisily • The carbon brushes are worn. • Contact the service address on and/or very unevenly. the warranty card. • The saw buckle cannot be • The saw blade is stuck • Tap gently on the end of the pushed up to remove the saw saw blade with a hammer blade 8.2 Cleaning 8.4 Environment Regularly clean the machine housing with a... - Page 10 BJS - 600 DIAGRAM...
- Page 11 BJS - 600 PART LIST No. Description Specification No. Description Specification Plastic cover Switch Ø2 × 18 Actiyator Plastic shell Left housing SDS spring Convex pin Chuck Knob Ø3 × 12.5 Knob - spring Outer proof ring ball Ø4 Allocation-slide block 45 O ring Spring Back cover Steel spring...
- Page 12 Jig saw BJS - 600 ARETE SUPPLIES S.L. www.aretesupplies.com...
