Overview

The CS2MX is a high performance metal detector operating on the 'MOTION'
principle. This means that the search-head must be kept moving at a steady sweep
speed to achieve optimum performance.
There is a pin-point function which switches off the motion effect so that the
search-head can be brought to rest over the target signal.
The discrimination system is capable of eliminating signals from a variety of metals
which are likely to be valueless.
The CS2MX is designed to offer high performance whilst being easy to operate.
We wish you good hunting!

Rapid start

Follow these simple steps to start using the CS2MX within minutes:
1. Insert the lower stem into the upper stem (first press in the spring clip).
2. Twist the locking device so that the stem is locked at the required length.
3. Coil the search-head lead around the stem.
4. Remove the battery compartment cover by loosening the four retaining screws.
5. Fit 8 x AA batteries to the battery holder being careful to observe polarity
and good contact.
6. Rotate the discrimination control to the '3' on the DISC dial.
7. Switch on and rotate the sensitivity control to '8' on the SENS dial.
8. START DETECTING. Metal targets give a sharp audio signal from the loudspeaker.
Signals from small pieces of iron rubbish are ignored. Pressing the pin-point button
means you can stop swinging the search-head from side to side and identify the exact
position of the target.
