Humminbird HELIX 5 G2 SERIES Operation Manual page 73

On
Off
Switch Frequencies
If the transducer includes more than one downbeam frequency, use the CHECK/INFO key to quickly change the frequency used in
the Circular Flasher View. For more information see Set up Sonar.
1. Press the CHECK/INFO key.
Turn on Jigging Mode if you've selected Medium or Medium/High Frequency in the 2D CHIRP
Display Frequency menu (with 2D CHIRP Mode turned on), or if you've selected 83 kHz or 83/200
kHz in the 2D Display Frequency menu (with 2D CHIRP Mode turned off). When Jigging Mode is
turned on, the sonar returns are refined on the view, and the chart speed slows down to show
more detail.
Turn off Jigging Mode if you've selected Low Frequency in the 2D CHIRP Display Frequency
menu (with 2D CHIRP Mode turned on), or if you've selected 200 kHz in the 2D Display
Frequency menu (with 2D CHIRP Mode turned off). Turn off Jigging Mode to display the sonar
history at the selected chart speed and see coarser returns on the display.
Using the CHECK key to Switch Frequencies
Switch Frequencies
73
frequency
label
Circular Flasher
