Understand The Circular Flasher View - Humminbird HELIX 5 G2 SERIES Operation Manual

U
NDERSTAND THE
You can use the Circular Flasher View with Ice Fishing Mode turned on or off. When Ice Fishing Mode is turned on, the view is
maximized with information you need for ice fishing, including the depth, connected battery power percentage, and related menu
settings.
Like a traditional sonar view, the Circular Flasher View displays the sonar return intensity with different colors.
Strong returns often result from rocky or hard bottoms (compacted sediment, rocks, fallen trees), while weaker returns often result
from soft bottoms (sand, mud), vegetation, and small fish.
The colors used to represent high, medium, to low intensity returns are determined by the palette you choose (see Adjust Settings
While you Fish: Change the Sonar Colors Palette).
percentage
of power for
connected
battery
sensitivity
NOTE: To change the beam frequency or adjust the noise filter, see Set up Sonar.
C F
IRCULAR LASHER
Circular Flasher View with Ice Fishing Mode Turned On
V
IEW
69
zoom level
depth
Circular Flasher
