Change the Chart Speed
Chart Speed controls how fast the sonar history moves down the view and how much detail is shown.
1. Side Imaging X-Press Menu: With a Side Imaging View displayed on-screen, press the MENU key once.
2. Select Chart Speed.
3. Press the RIGHT or LEFT Cursor keys to adjust the setting.
Change the View Colors
The Side Imaging X-Press Menu allows you to quickly change the display palette while you fish. See Customize the Side Imaging
View: Change the View Colors for more information.
1. Side Imaging X-Press Menu: With a Side Imaging View displayed on-screen, press the MENU key once.
2. Select SI Colors.
3. Select a palette.
Change the Imaging SwitchFire Mode
Imaging SwitchFire controls how the sonar returns are displayed in the Down Imaging and Side Imaging Views.
1. Main Menu: Press the MENU key twice. Select the Sonar tab.
2. Select Imaging SwitchFire.
3. Select Clear Mode or Max Mode.
Clear Mode: Clutter is filtered, and sonar returns are interpreted to provide more details on-screen about the objects within
the transducer beam(s).
Max Mode: The view shows the most sonar information available within the transducer beam(s).
101 Side Imaging Sonar
